7.3 Glossary
a-release – see Shunt trip device;
Activating magnet – see Cl osing drive;
Anti-pumping device – see SU control PCB. Prevents reclosing
after a close-open operation, as long as the device initiating
closing is maintained in the position for closing
Arc runners – (also: arc probes; arc horns). Provide safe arc
leading into the arc chute. There are two arc runners mounted
in Gerapid breaker, front and back.
Arcing contact – – (also: pre-contact; arcing pre-contact). An
arcing contact on which the arc is intended to be established, to
avoid wearing and burning of the main contacts. It is mounted
at the top of fl exibl e band. It is easy to replace. Spring loaded to
maintain proper contact force.
Auxiliary contact – (also: make/break contact; a-/b-contact,
changeover contact, convertibl e contact). A contact included in
an auxiliary circuit and mechanically operated by the breaker.
Auxiliary switch – (also: auxil iary switch; make/break contact; a-
/b-contact). A switch block containing up to 10 auxiliary con-
tacts,. Mechanically operated by the mechanism of the breaker
during switching operations. Auxiliary switch block is mounted
in lower compartment of the control box. Every contact can be
either NO or NC, configured by appropriate wiring.
Closing drive – (al so: activating magnet; closing sol enoid; sol e-
noid drive). High power, black solenoid coil, mounted at the front
of the breaker, below the control box. Use for electric and re-
mote closing of the main contacts. Power consumption is up to
2.6kW. Closing time is ~150ms.
Closing operation – (also: switching ON; CLOSE operation). It is
operation, by which the breaker is brought from the OPEN posi-
tion to the CLOSED position.
Closing solenoid - see Cl osing drive;
Control circuit terminals – (also: control sockets/pl ugs). Fully in-
sulated sockets at the front cover of control box. Intended for
external connection to the auxiliary and control circuits.
ED coil – (also: el ectro-dynamic coil ). An impulse coil release. Ac-
tuating element of ED impulse release, mounted on the base,
under the mechanism.
Electro-Dynamic impulse release – (also: ED tripping; impul se
rel ease). Release device, consist of actuator (ED coil) and control
circuit (NEKO PCB with C-bank). This is an auxiliary release, acti-
vated by high-energy impulse of current. The impulse is shaped
by internal (NEKO) or external C-bank. Opening time is less 3ms.
Time to charge capacitors is ~15sec.
Forced tripping release – (also: FTU; forced tripping device/unit).
Fully insulated, direct, mechanical tripping pin, mounted thru
the bottom of the breaker. The breaker will be tripped open, by
pushing of this pin upward,
Lever for manual operating – (also: hand l ever). Hand lever can
be used for both, closing and opening manual operation. It is in-
tend for use only during maintenance.
M ain circuit – (also: mains; primary circuit; current path). All the
conductive parts of the breaker included in the circuit, which is
intend to close or open. It consists of: main terminal s (upper and
l ower), fixed contact, fl exibl e band and lower bus bar.
M ain terminals – (also: main connections). Two conductive bars
provided for electrical connection to external main circuit. Dif-
ferent configurations are avaiable.
NEKO control PCB – (also: ED coil control unit; internal C-bank
control ). Control circuit PCB to supervise the operation of the ED
coil. It consists of control circuit and bank of capacitors. Re-
quired to energize the ED impulse coil.
