Nemalux LS Series Installation Manual

LS Series Installation Manual
TEMPORARY STRINGER LIGHT
APPLICATION
The LS is rated for indoor and outdoor use, addressing temporary lighting needs in industrial, marine,
and hazardous locations. With an IP66/67 protection level, the versatile LS o ers a lightweight solution
during construction, operation, and maintenance.
Conforms to:
Hazardous Location
Certi cation:
Housing:
Rated Voltage:
Rated Power:
Connections:
Temperature Range:
Ingress Protection:
MADE IN CANADA
Installation
UL 844, UL 1088, CAN/ULC-S1088, UL 1598, UL 1598A:
CSA 22.2 No.137
Class I, Division 2, Groups ABCD, T5;
Class II, Division 1, Groups EFG, T5;
Class III;
Class I, Zone 2, Groups IIC;
Class I, Zone 20, Groups IIIC
Copper-free high pressure die-cast aluminum body & borosilicate glass lens.
120 VAC , 50/60 Hz
19.5W per module
Standard: Black: Line | White: Neutral | Green: Ground
-50° C to +70° C
IP66/67 | Suitable for wet locations. Marine outside type (salt water).
www.nemalux.com | sales@nemalux.com | Tel 403•242•7475 | Fax 403•243•6190
Spec Sheet Webpage
LS
rev. C-01
1-6
