Nemalux LS Series Manual

Nemalux
I N D U S T R I A L
TEMPORARY LIGHTING STRING

APPLICATION

Intended for temporary lighting requirements in industrial, marine and hazardous locations, the LS
light stringer is rated for indoor and outdoor use. With a protection level of IP66 / NEMA4X the
versatile LS o ers a lightweight solution for surface and hook mount applications during construc-
tion, operation and maintenance.
Conforms to:
Hazardous Location Certi cation:
Housing:
Rated Voltage:
Rated Power:
Connections:
Temperature Range:
Ingress Protection:
MADE IN CANADA
TM
Installation
UL 844, UL 1088, CAN/ULC-S1088, UL 1598, UL 1598A:
CSA 22.2 No. 137
Class I, Division 2, Groups ABCD, T5;
Class II, Division 1, Groups EFG, T5;
Class III;
Class I, Zone 2, Groups IIC;
Class I, Zone 20, Groups IIIC
Copper-free Case Aluminum & Borosilicate Glass
120 VAC , 50/60 Hz
19.5W per module
Standard: Black: Line | White: Neutral | Green: Ground
-50° C to +70° C
IP66/67 | Suitable for Wet Locations. Marine Outside type (Salt water).
www.nemalux.com | sales@nemalux.com | Tel 403•242•7475 | Fax 403•243•6190
Spec Sheet Webpage
LS Series
rev. A-20
1-6
