- Page 1 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions UNI 360D SKU: SW10115 EAN: 4260754980775...
- Page 2 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions Table of Contents 1. Packaging content warning/accessories 2. Installing D5 and DDC pump 3. Configuration with 2 radiators 4. Flow Diagram 5. Installing the Distrobution Plate 6. Installing the Distrobution Plate with supplied mounts 7.
- Page 3 Stealkey Customs cooling products. Do not disas- semble the water block. Doing so will void the warranty. Turn o昀昀 your system and discharge your body's static charge before proceeding with the installation.
- Page 4 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions Installing D5 and DDC pump Step 1: Remove the 4 x M4 x 20 mm screws (3mm hexagon socket). Set the screws aside as they will be needed to secure the pump.
- Page 5 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions Step 3: Installing the D5 pump. Place the D5 ring over the pump and place it on the adapter. Tighten the screws with 2.5 Nm. Handle with care when tightening; acrylic can crack.
- Page 6 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions PLANNING THE WATER CIRCUIT FOR 2 RADIATORS A configuration with 2 radiators is shown here. Close any unused ports with the provided plugs. UNI 360D RADIATOR TOP INLET PLUG FILL Port (SET BLIND)
- Page 7 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions Flow Diagram (Back View)
- Page 8 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions INSTALLING THE DISTRIBUTION PLATE With the included M3 screws, you can mount the distro plate directly to any standard 360 mm fan bracket. M3x 6 mm Screw Fan Bracket...
- Page 9 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions INSTALLING THE DISTRIBUTION PLATE WITH SUPPLIED MOUNTS An installation example with the SK-UNI Mounting Bracket 28 mm. Not included in the scope of delivery. SK-UNI mounting bracket 28mm (120mm fan) 120mm Fan...
- Page 10 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions Dimensions in millimeter (mm)
- Page 11 SK-UNI 360D Distroplate - Acryl Black Assembly Instructions CONNECTING THE D-RGB CABLE Connect the D-RGB cable to a compatible motherboard (3-Pin ARGB Connector). INSTALLING THE CONNECTIONS Mount the connections with G1/4 thread and close the remaining connections with sea- ling plugs. Always perform a leak test before applying power to the system components (max.
