- Page 1 9,67$3366HULHV 9,67$36HULHV 3URJUDPPLQJ*XLGH...
- Page 2 TO ENTER PROGRAMMING MODE: Local programming requires the use of an alpha keypad connected to the keypad terminals on the control. A. POWER UP, then depress [ ✱ ] and [#] both at once, within 50 seconds of powering up (if ✱ 98 was used to exit program mode, this method must be used to reenter program mode).
- Page 3 352*5$00,1*)250 Programmable values apply to all controls, except field *189, which applies to the VISTA-20PS only. Entry of a number other than one specified will give unpredictable results. Values shown in brackets are factory defaults. Entries shown in dashed boxes indicate partition entries for VISTA-20P only (not applicable for VISTA-15P). Field Function Data Entries...
- Page 4 NOTE: Entry of a number other than one specified will give unpredictable results. For fields *43- *46: Enter 0–9; #+11 for B; #+12 for C; #+13 for D; #+14 for E; #+15 for F. Enter [ ✱ ] as the fourth digit if a 3-digit account number (for 3+1 dialer reporting format) is used.
- Page 5 ✱ 65 OPEN REPORT CODE [0,0,0] See box above. Part. 1 Part. 2 Common ✱ 66 ARM AWAY/STAY RPT CODE [0,0,0,0,0,0] See box above. Away Stay Away Stay Away Stay Part. 1 Part. 2 Common ✱ 67 RF XMTR LOW BAT REPORT CODE [00] See box on previous page.
- Page 6 ✱ 92 PHONE LINE MONITOR ENABLE [0,0] UL: see Inst. Instructions for requirements NOTE: Output Device must either be programmed to be STOPPED in field ✱80 or STOPPED by Code + # + 8 + – 6 –...
- Page 7 MISCELLANEOUS SYSTEM FIELDS (*174-*181) ✱ 174 CLEAN ME REPORTING OPTIONS 0 = disable; 1 = Clean Me signal reports; Note: If Clean Me is enabled, you must enter “3” in (for ESL smoke detectors) field ✱56 programming for zone 1 response time. ✱...
- Page 8 Configurable Zone Types Worksheets Configurable zone types 90 and 91 can be programmed via downloader software or from a keypad using data fields*182-*185. Configurable zone types 92 and 93 (VISTA-20P only) can only be programmed using the downloader software. Programming Configurable Zone Type options involves making 10 entries in data field *182 for zone type 90 and field *184 for zone type 91, where each entry represents the sum of the values of the various options shown in the tables below.
- Page 9 *56 ZONE PROGRAMMING WORKSHEET (VISTA-15P supports up to 32 zones: 1-6, 9-34) [default shown in brackets] Zone Zn Type Part. Report Hardwire Rsp. Time Location Type [09] [EOL] [01] [EOL] [03] [EOL] [03] [EOL] [03] [EOL] [03] [EOL] [03] [EOL] [03] [EOL] Zone...
- Page 10 *57 FUNCTION KEY PROGRAMMING Option Function Comments Paging Time Display Arm AWAY Arm STAY Arm NIGHT-STAY Step Arming Device Activation Device: Comm. Test Macro Key 1 Macro Key 2 Macro Key 3 Macro Key 4 Emergency Keys: zone 95 zone 99 zone 96 paging Personal Emergency...
- Page 11 ✱ 80 OUTPUT DEFINITIONS Fill in the required data on the worksheet below and follow the programming procedure in the installation manual as you enter the data during the displays and prompts that appear in sequence. Notes: 1. For Relays, 4229 and 4204 devices are programmed in *79, *80, and *81 modes. ✱...
- Page 12 Zone Type Definitions Use this zone type if the zone is not used. Type 00 Zone Not Used • Assign to zones that are used for primary entry and exit. Type 01 • Provides entry delay if the control is armed in the Away or Stay modes. Entry/Exit Burglary #1 •...
- Page 13 • Arms the system in Away mode when the zone is activated. Type 21 • Pushbutton units send the user number to the central station when arming or disarming. Arm-Away • User code for button must be assigned. • Disarms the system when the zone is activated. Type 22 •...
- Page 14 ALPHA VOCABULARY LIST (For Entering Zone Descriptors) • 057 DOOR ∗ (Word Space) – L – – R – – V – • 106 LAUNDRY ∗ RADIO VALVE • 059 DOWN – A – VAULT • 107 LEFT • 156 REAR •...
- Page 15 5800 Series Transmitter Input Loop Identification All of the transmitters illustrated below have one or more unique factory assigned input (loop) ID codes. Each of the inputs requires its own programming zone (e.g., a 5804's four inputs require four programming zones). WIRELESS INPUT TYPES LOOP 3 "RF"...
- Page 16 A DIVISION OF PITTWAY CORPORATION 165 Eileen Way, Syosset, NY 11791 Copyright © 2001 Pittway Corporation ¬.359 l K5305-1PRV1 4/02...
