Pittway NOTIFIER AFM-16AT Installation Manual

The annunciator fixed module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A
NNUNCIATOR
Installation Manual for the
AFM-16AT and AFM-32A
Annunciator Modules
www.PDF-Zoo.com
THE
F
IXED
M
ODULE
firealarmresources.com
12 Clintonville Road
Northford, CT 06472
203-484-7161 FAX: 203-484-7118
Document 15048
07/16/97 Revision:
ECN 97-294
D1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOTIFIER AFM-16AT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pittway NOTIFIER AFM-16AT

Summary of Contents for Pittway NOTIFIER AFM-16AT

  • Page 1 12 Clintonville Road Northford, CT 06472 203-484-7161 FAX: 203-484-7118 NNUNCIATOR IXED ODULE Installation Manual for the AFM-16AT and AFM-32A Annunciator Modules Document 15048 07/16/97 Revision: ECN 97-294 www.PDF-Zoo.com firealarmresources.com...
  • Page 2 www.PDF-Zoo.com firealarmresources.com...

  • Page 3: Table Of Contents

    Table of Contents Section One: The AFM Section Two: Inventory Section Three: Installation Mounting the Backbox Terminating the Shield Inserting Display Labels Annunciator Jumper Options Mounting the Dress Plate Applying the Annunciator Label Installing AFM Options AFM Field Connections Installation Requirements Main Power Supply Connections Operation Section Four:...

  • Page 4: Section One

    Section One: The AFM Annunciator Fixed Modules provide the control panel with discrete display and control points. These annunciators turn their LEDs ON and OFF as commanded by the system's CPU. In addition, they report selected switch activations to the CPU for action. Limits The AFM-16AT is intended for use in systems that require 16 annunciation points or less.
  • Page 5 Wiring Communication between the control panel and the AFM is accomplished over a two-wire power-limited EIA-485 serial interface (formerly referred to as RS-485). This communica- tion, to include the wiring, is supervised by the control panel's CPU. Loss of communication results in "System Trouble"...

  • Page 6: Inventory

    Section Two: Inventory AFM-16AT (H = 8-3/8" W = 4-3/8" D = 1-3/8") The Annunciator Fixed Module-16AT con- tains 16 red alarm and 16 yellow trouble LEDs, 16 momentary touch-pad switches, a system trouble LED, an ON LINE/POWER LED, and a local piezo sounder with a silence/acknowledge switch for audible in- dication of alarm and trouble conditions.
  • Page 7 ABF-1 (H = 9-15/16" W = 4-5/8" D = 2-1/2") The Annunciator Flush Box-1 provides for the remote mounting of the AFM annunciator in a flush-mount enclosure . The ABF-1 includes a trim plate (height=11" width=6-1/4"), mounting hardware, and an adhesive-backed annuncia- tor label.

  • Page 8: Installation

    Section Three: Installation AFM Installation Summary Run the EIA-485 and power circuits out to the location of the annunciator. Select an appropriate knockout on the backbox and mount the backbox. Connect the backbox to a solid ground, such as a properly grounded metallic cold water pipe.

  • Page 9: Mounting The Backbox

    Figure 3-1: Mounting the Backbox Select a knockout on the backbox. Mount the backbox and draw all annunciator, power, and telephone wiring (if employing an APJ-1) into the enclosure. Connect the backbox to a solid ground such as a metallic cold water pipe. Figure 3-2: Terminating the Shield The EIA-485 circuit should be wired using a twisted-pair cable having a Characteristic Impedance of approximately 120 ohms.
  • Page 10 AFM-16AT Slide-In Labels Slide-in labels for the AFM-16AT Annunciator are contained on the following pages. Two labels are required for the AFM– 16AT - one for the left-hand side and one for the right-hand side of the faceplate. Each label has a distinctive format. Three types of labels are offered: Set A: Factory-printed zone labels: These provide labels for alarm zones 1 through 16.
  • Page 11 AFM-32A Slide-In Labels Slide-in labels for the AFM-32A Annunciator are contained on the following pages. Two labels are required for the AFM– 32A - one for the left-hand side and one for the right-hand side of the faceplate. Each label has a distinctive format. Three types of labels are offered: Set D: Factory-printed zone labels: These provide labels for alarm zones 1 through 32.

  • Page 12: Inserting Display Labels

    Figure 3-3: Inserting Display Labels Remove the center pages of this manual. If using the custom user display labels, type the appropriate information on the labels. Carefully cut out the labels and insert them into the AFM by slipping them into the label slots on the back side of the annunciator face plate.

  • Page 13: Mounting The Dress Plate

    Figure 3-5: Mounting the Dress Plate Position the annunciator over the screw studs on the dress plate and secure with two nuts and lock washers provided. ABF-1 Dress Plate Figure 3-6: Applying the Annunciator Label Remove backing from adhesive-backed Annunciator Label and affix the label to the bottom of the ABF-1 Dress Plate as illustrated.

  • Page 14: Installing Afm Options

    Figure 3-7: Installing AFM Options If employing an Annunciator Key Switch (AKS-1), mount the switch to the ABF-1 Dress Plate. Plug the switch leads from the AKS-1 into Connector J4 on the annunciator. If employing an Annunciator Phone Jack (APJ-1), mount the jack to the ABF-1 Dress Plate.

  • Page 15: Afm Field Connections

    Figure 3-8: AFM Field Connections Connect the annunciator and power wiring to the terminal blocks on the back of the AFM as illustrated below. EIA-485 and power must be power-limited EIA-485 ( - ) EIA-485 (+) 24 VDC ( - ) 24 VDC (+) Caution! Failure to observe proper polarity on these connections may...

  • Page 16: Installation Requirements

    Installation Requirements The EIA-485 circuit that drives the AFM must be connected to the CPU as illustrated below. Connect the EIA-485 (+) and (-) lines to the CPU terminals. On a System 5000, ensure that the CPU U4 ROM software is Part Number 73085 or greater. Supervised and Power-limited EIA-485 (-) (+) EIA-485...

  • Page 17: Main Power Supply Connections

    Figure 3-10: Main Power Supply Connections The AFM annunciator can be powered by an MPS-24A or an MPS-24B. This power run to the annunciator need not contain a Power Supervision Relay since loss of power is inherently supervised through communication loss. MPS-24A Main Power Supply : Connect the power run for the AFM to MPS-24A TB3 Terminals 1 (+) and 2 (-) (1 amp max) or Terminals 3 (+) and 4 (-) (3 amps max).

  • Page 18: Section Four

    Section Four: Operation Figure 4-1: AFM-16AT Operation Acknowledge This switch serves two purposes: Switch 1) When pressed, it lights all the LEDs on the AFM (except the On Line LED) and sounds the piezo for as long as the switch is held down. 2) It acknowledges all status changes for the AFM.

  • Page 19: Afm-32A Operation

    Figure 4-2: AFM-32A Operation Local Silence/Acknowledge This switch serves two purposes: Switch 1) When pressed, it lights all the LEDs on the AFM (except the On Line LED) and sounds the piezo for as long as the switch is held down. 2) It acknowledges all status changes for the AFM.

  • Page 20: Annunciator Point Functions

    Annunciator Operation Annunciator points "track" or follow those control panel points they are programmed to annunciate; they do not latch. The table below outlines the annunciation of various circuits and functions. Note: Control Switches marked "not used" will still function as local LAMP TEST or local ACKNOWLEDGE switches for their respective points.
  • Page 21 NOTES www.PDF-Zoo.com Document 15048 Rev. D1 07/16/97 P/N 15048:D1 firealarmresources.com...
  • Page 22 NOTES www.PDF-Zoo.com Document 15048 Rev. D1 07/16/97 P/N 15048:D1 firealarmresources.com...
  • Page 23 www.PDF-Zoo.com Document 15048 Rev. D1 07/16/97 P/N 15048:D1 firealarmresources.com...
  • Page 24 Limited Warranty ® NOTIFIER warrants its products to be free from defects in materials and workmanship for eighteen (18) months from the date of manufacture, under normal use and service. Products are date stamped at time of manufacture. The sole and ®...
  • Page 25 Set A Set A Set B Set B Zone Label #1 Zone Label #2 System/Zone System/Zone Label #1 Label #2 OCAL ILENCE AND OCAL ILENCE AND CKNOWLEDGE CKNOWLEDGE YSTEM ROUBLE YSTEM ROUBLE Cut out along dotted line Cut out along dotted line Cut out along dotted line Cut out along dotted line and insert into the left-...
  • Page 26 Set E Set D Set D Custom User Label #1 Zone Label #1 Zone Label #2 OCAL ILENCE AND OCAL ILENCE AND CKNOWLEDGE CKNOWLEDGE YSTEM ROUBLE YSTEM ROUBLE Cut out along dotted line Cut out along dotted line Cut out along dotted line and insert into the left- and insert into the right- and insert into the left-...
  • Page 27 Set C Set C Set C Set C Custom User Custom User Custom User Custom User Label #1 Label #2 Label #1 Label #2 OCAL ILENCE AND OCAL ILENCE AND CKNOWLEDGE CKNOWLEDGE YSTEM ROUBLE YSTEM ROUBLE Cut out along dotted line Cut out along dotted line Cut out along dotted line Cut out along dotted line...
  • Page 28 Set F Set E Set E Custom User Label #2 System/Zone Label #2 System/Zone Label #1 OCAL ILENCE AND CKNOWLEDGE YSTEM ROUBLE Cut out along dotted line Cut out along dotted line Cut out along dotted line and insert into the left- and insert into the right- and insert into the right- hand side of AFM-32A...
