- Page 1 EN User Manual | Hob HGB75420YM aeg.com\register...
- Page 2 Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................11 5. DAILY USE....................11 6.
- Page 3 • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. • If the appliance has a child safety device, it should be activated.
- Page 4 • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. • If the supply cord is damaged, it must be replaced by the manufacturer, an authorized Service or similarly qualified persons in order to avoid a hazard.
- Page 5 under the appliance to prevent access to fuses removed from the holder), earth the bottom. leakage trips and contactors. • The electrical installation must have an 2.2 Electrical Connection isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact WARNING! opening width of minimum 3 mm.
- Page 6 CAUTION! WARNING! The use of a gas cooking appliance Risk of damage to the appliance. results in the production of heat, moisture • Do not keep hot cookware on the control and products of combustion in the room panel. in which it is installed. Ensure that the •...
- Page 7 use abrasive products, abrasive cleaning • Contact your municipal authority for pads, solvents or metal objects. information on how to dispose of the • Do not clean the burners in the appliance. dishwasher. • Disconnect the appliance from the mains supply.
- Page 8 3.4 Adjustment of minimum level Liquid gas Use the rubber pipe holder for liquid gas. To adjust the minimum level of the burners: Always engage the gasket. Then continue with the gas connection. 1. Light the burner. 2. Turn the knob on the minimum position. The flexible pipe is prepared for apply when: 3.
- Page 9 3.7 Assembly • Do not let the power cable to heat up to a temperature higher than 90° C. 3.6 Connection cable To replace the connection cable use only the special cable or its equivalent. The cable type is: H03V2V2-F T90. Make sure that the cable section is applicable to the voltage and the working temperature.
- Page 10 CAUTION! Install the appliance only on a worktop with flat surface. 3.8 Possibilities for insertion The panel installed below the hob must be easy to remove and let an easy access in case a technical assistance intervention is necessary. Kitchen unit with door min 6 mm min 30 mm min 5 mm...
- Page 11 4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Control knobs 4.2 Control knob Symbol Description no gas supply / off position ignition position / maximum gas supply Semi-rapid burner minimum gas supply Multi Crown burner 1 - 9 power levels Rapid burner Auxiliary burner 5.
- Page 12 5.2 Ignition of the burner CAUTION! In the absence of electricity you can ignite the burner without electrical device; Always light the burner before you put on in this case approach the burner with a the cookware. flame, turn the control knob counter- clockwise to maximum gas supply WARNING! position and push it down.
- Page 13 6.2 Diameters of cookware CAUTION! Make sure that the bottoms of pots do CAUTION! not stand too close to the control knob, Use cookware with diameters applicable otherwise the flame heats the control to the size of burners. knob up. Burner Diameter of CAUTION!
- Page 14 Food categories Recipes Burner type Power level French fries Multi Crown Fried dishes Donuts Multi Crown Roasting nuts Semi-rapid Snacks cooked with pan Croutons of bread Multi Crown Pancakes Semi-rapid Caramel Auxiliary Desserts Custard Auxiliary Panna cotta Auxiliary All recipes for approximately 4 portions. For an optimal delicate cooking use the auxiliary burner.
- Page 15 7.3 Cleaning the hob 2. The enamel coating occasionally can have rough edges, so be careful when • Remove immediately: melted plastic, you wash the pan supports by hand and plastic foil, sugar and food with sugar, dry them. If necessary, remove stubborn otherwise, the dirt can cause damage to stains with a paste cleaner.
- Page 16 Problem Possible cause Remedy The fuse is blown. Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician. Burner cap and crown are placed in‐ Place the burner cap and crown cor‐ correctly.
- Page 17 9. TECHNICAL DATA 9.1 Hob dimensions Width 744 mm Depth 510 mm 9.2 Bypass diameters BURNER Ø BYPASS 1/100 mm Multi Crown Rapid Semi-rapid Auxiliary 9.3 Other technical data Gas original: G30/G31 (3B/P) 30/30 mbar 825 g/h TOTAL POWER: Gas replacement: G20 (2H) 20 mbar 11,65 kW Electric supply:...
- Page 18 MINIMUM POWER kW INJECTOR MARK Semi-rapid 1,85 Auxiliary 0,33 10. ENERGY EFFICIENCY 10.1 Product Information according to EU Ecodesign regulation Model identification HGB75420YM Type of hob Built-in hob Number of gas burners Left rear - Semi-rapid 60.5% Centre Rear - Multi Crown 57.1%...
