HGB64200SM
USER
MANUAL
EN
User Manual
Hob

Advertisement

Table of Contents
loading

Related Manuals for AEG HGB64200SM

Summary of Contents for AEG HGB64200SM

  • Page 1 HGB64200SM User Manual USER MANUAL...

  • Page 2: Table Of Contents

    10. ENERGY EFFICIENCY..................... 18 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3 ENGLISH usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 • years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a...
  • Page 4 CAUTION: The appliance must not be supplied • through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility. CAUTION: The cooking process has to be supervised.

  • Page 5: Safety Instructions

    ENGLISH 2. SAFETY INSTRUCTIONS 2.2 Electrical Connection This appliance is suitable for the following markets: GB IE WARNING! Risk of fire and electric 2.1 Installation shock. WARNING! • All electrical connections should be Only a qualified person must made by a qualified electrician. install this appliance.
  • Page 6 • Do not pull the mains cable to • Do not operate the appliance with disconnect the appliance. Always pull wet hands or when it has contact with the mains plug. water. • Use only correct isolation devices: line •...

  • Page 7: Installation

    ENGLISH • The use of a gas cooking appliance • Deactivate the appliance and let it results in the production of heat and cool down before you clean it. moisture. Provide good ventilation in • Disconnect the appliance from the the room where the appliance is electrical supply before maintenance.
  • Page 8 B.S. 5440, Par. 2 and B.S. 6891 Current The manufacturer will not accept liability, Editions. should the above instructions or any of the other safety instructions incorporated The hob should not be installed in a bed in this instruction booklet be ignored.
  • Page 9 ENGLISH CAUTION! Make sure that the gas supply pressure of the appliance obeys the recommended values. Rigid connection: Carry out connection by using metal rigid pipes (copper with mechanical end). 3.4 Injectors replacement 1. Remove the pan supports. 2. Remove the caps and crowns of the burner.
  • Page 10 National Inspection Council for Electrical Installation Contracting [NICEIC]). The manufacturer refuses to be held responsible, if these safety measures are not abided by. Supply connections This hob has to be connected to 220-240 V (~ 50-60 Hz ) electricity supply.
  • Page 11 ENGLISH The wires in the cord are coloured as symbol , or coloured green and follows: yellow. 2. Connect the blue (neutral) wire to the Green and yellow - Earth terminal which is marked with the letter 'N' or coloured blue. Blue - Neutral 3.
  • Page 12 400 mm 50 mm A. Supplied seal If a furniture unit is B. Supplied bracket installed at a distance of 400 mm above the hob, there must be a minimum safety distance of 50 mm to the left or right from the edge of the hob.

  • Page 13: Product Description

    ENGLISH 4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Semi-rapid burner Rapid burner Auxiliary burner Control knobs 4.2 Control knob Symbol Description Symbol Description ignition position / maxi- mum gas supply no gas supply / off posi- tion minimum gas supply 5.

  • Page 14: Hints And Tips

    If after some tries the burner If the burner accidentally does not light, check if the goes out, turn the control crown and its cap are in knob to the off position and correct positions. try to light the burner again after minimum 1 minute.

  • Page 15: Care And Cleaning

    ENGLISH 6.2 Diameters of cookware Burner Diameter of Use cookware with cookware (mm) diameters applicable to the size of burners. Semi-rapid 120 - 240 Auxiliary 80 - 220 Burner Diameter of cookware (mm) Rapid 180 - 260 7. CARE AND CLEANING Be very careful when you WARNING! replace the pan supports...

  • Page 16: Troubleshooting

    7.3 Cleaning the hob 7.4 Cleaning the spark plug • Remove immediately: melted plastic, This feature is obtained through a plastic foil, sugar and food with sugar, ceramic ignition candle with a metal otherwise, the dirt can cause damage electrode.

  • Page 17: Technical Data

    ENGLISH conditions of guarantee are in the guarantee booklet. 8.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A.

  • Page 18: Energy Efficiency

    NOMINAL GAS FLOW g/h POWER kW POWER kW MARK G30 28-30 G31 37 mbar mbar Rapid 0,95 Semi-rapid Auxiliary 0,33 10. ENERGY EFFICIENCY 10.1 Product information according to EU 66/2014 Model identification HGB64200SM Type of hob Built-in hob Number of gas burners...
  • Page 19 ENGLISH Left rear - Semi-rapid 62.8% Right rear - Semi-rapid 60.8% Energy efficiency per gas burner (EE gas burner) Left front - Rapid 58.6% Right front - Auxiliary not applicable Energy efficiency for the gas hob 60.7% (EE gas hob) EN 30-2-1: Domestic cooking appliances burning gas - Part 2-1 : Rational use of energy - General 10.2 Energy saving...
  • Page 20 www.aeg.com/shop...
