parts List
ITEM QTY REFERENCE
Required Circuit Components
1 13 C1, C25, C26, C29, C31,
C32, C33, C34, C35, C36,
C37, C71, C72
2 4 C2, C3, C8, C19
3 9 C4, C6, C9, C11, C14,
C18, C67, C68, C69
4 5 C5, C7, C10, C12, C15
5 4 C13, C16, C27, C28
6 2 C17, C40
7 1 C20
8 2 C21, C24
9 1 C22
10 2 C23, C70
11 1 C30
12 2 C38, C39
13 2 C41, C42
14 1 C43
15 1 C44
16 9 C45, C48, C49, C53, C54,
C58, C61, C62, C64
17 10 C46, C50, C51, C52, C55,
C56, C57, C59, C60, C63
18 1 C47
19 0 C65
20 1 C66
21 2 C73, C74
22 1 C75
23 2 C76, C77
24 1 D1
25 1 D2
26 1 D3
27 10 E1, E2, E3, E5–E11
28 2 E4, E12
29 2 JP1, JP2
30 1 J1
31 3 J2, J3, J8
32 1 J4
33 2 J5, J6
34 1 J7
35 1 J9
36 2 J10, J11
PART DESCRIPTION
CAP., X7R, 0.1µF, 16V 10% 0402
CAP., NPO, 0.01µF, 25V 5% 0603
CAP., X7R, 1µF, 16V 10% 0603
CAP., TANT., 47µF, 16V 10% 7343
CAP., X5R, 4.7µF, 16V 20% 1206
CAP., X5R, 10µF, 10V 20% 0603
CAP., C0G, 4.7pF, 50V ± 0.25pF 0603
CAP., X7R, 0.1µF, 16V 10% 0603
CAP., X7R, 1µF, 25V 10% 0603
CAP., X7R, 47µF, 10V 10% 1210
CAP., X5R, 3.3µF, 16V 10% 0603
CAP., COG, 27pF, 50V 5% 0402
CAP., COG, 100pF, 25V 5% 0201
CAP., X5R, 0.01µF, 16V 10% 0402
CAP., X7R, 47nF, 25V 10% 0402
CAP., X5R, 100µF, 6.3V 20% 1206
CAP., X7S, 2.2µF, 4V 20% 0306
CAP., COG, 10pF, 25V 5% 0201
CAP., OPT, 0402
CAP., NP0, 1pF, 25V ±.25pF 0402
CAP., X7R, 4.7µF, 50V 10% 1206
CAP., X7R, 10µF, 50V 10% 1210
CAP., X5R, 1µF, 50V 10% 0603
DIODE, TVS, 70V,SMA
DIODE, TVS, 24V,SMA
LED, RED, WATERCLEAR, 0805
TEST POINT, TURRET, .061, PBF
TEST POINT, TURRET, .094, PBF
HEADER, 3 PIN, .079
HEADER, 2×7 DUAL ROW
CON., SMA JACK, STRAIGHT, THRU-HOLE
CON., SMA PCB TOP MOUNT
CON., SMA 50Ω EDGE-LAUNCH
CONNECTOR, USB TYPE B, RIGHT ANGLE PCB
MOUNT
HEADER, 2X5, 0.100
CONNECTOR, HSMC
DEMO MANUAL DC2085
MANUFACTURER/PART NUMBER
AVX, 0402YC104KAT2A
TDK, C1608C0G1H103J
AVX, 0603YC105KAT2A
AVX, TAJD476K016RNJ
TDK, C3216X5R1C475M
AVX, 0603ZD106MA2T
AVX, 06035A4R7CAT2A
TDK, C1608X7R1C104K
TDK, C1608X7R1E105K
MURATA, GRM32ER71A476KE15L
TDK, C1608X5R1C335K
TDK, C1005C0G1H270J
TDK, C0603C0G1E101J
MURATA, GRM155R61C103KA01D
MURATA, GRM155R71E473KA88D
TDK, C3216X5R0J107M
MURATA, LLL185C70G225ME01L
MURATA, GRM0335C1E100JA01D
OPTION
AVX, 04023A1R0CAT2A
MURATA, GRM31CR71H475KA12L
MURATA, GRM32ER71H106KA12L
MURATA, GRM188R61H105KAALD
DIODES INC./ ZETEX, SMAT70A-13-F
DIODES INC./ ZETEX, SMAJ24A-13-F
WÜRTH, 150080RS75000
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS, NRPN031PAEN-RC
MOLEX 87831-1420
AMPHENOL CONNEX, 132134
AEP, 9650-1113-005
EMERSON, 142-0701-851
FCI, 61729-0010BLF
SAMTEC, TSW-105-07-L-D
SAMTEC, ASP-122952-01
