Sealey LED3605G Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
Ensure the lamp is fully charged before initial use.
9
DO NOT turn the lamp on when it is being charged.
8
DO NOT shine directly into your, another person's or an animal's eyes.
8
DO NOT allow children to use the lamp.
8
DO NOT handle or move the lamp whilst it is being charged.
8
DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8
DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
8
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire:
‰
DO NOT attempt to open, disassemble, modify or service the battery pack.
8
DO NOT crush, puncture, short external contacts or dispose of in fire or water.
8
DO NOT expose to temperatures above 60°C (140°F).
8
Recycle or dispose of used battery as stipulated by local regulation.
9
If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
9
water and seek immediate medical attention.
2. INTRODUCTION
Unique and innovative 360° swivel and tilt function enables the light source to be positioned in any direction. Super bright 10W SMD
LED light produces 1000 lumens and a smaller 4W SMD LED which produces 400 lumens. Includes an additional high power 4W LED
directional torch. Features a swivel hook and rubber covered magnet which allow hands-free operation. Rechargeable high quality 3.7V
2600mAh Lithium-ion battery. LED charge indicator - flash green for charging and continuous green for fully charged. Inspection arm can
be folded 270º. High-impact IK07 Rated. Charges via a USB Type-C cable (Supplied).
3. SPECIFICATION
MODEL NO:
Battery:
Charging Time:
IP Rating:
LED Type:
Length:
Lumen Output:
Operating Time:
4. OPERATION
4.1. CHARGING THE LAMP
4.1.1. Connect the USB cable to the USB INPUT on the side of the lamp.
4.1.2. Plug the USB cable into supply and turn on.
4.2. OPERATING THE LAMP
WARNING! Direct the lens away from your eyes before switching on the lamp.
‰
4.2.1. Toggle the lamp between the main light, small light and OFF using the ON/OFF switch.
4.2.2. Hold the ON/OFF switch to adjust brightness.
4.2.3. The lamp may be attached to any magnetic surface by using the magnet on the base.
5. MAINTENANCE
Keep the torch clean by wiping with a damp cloth.
9
Store torch in a dry childproof area.
9
5.1. IMPORTANT WARRANTY INFORMATION
The battery fitted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time.
We will provide warranty against mechanical and electrical defect for a period of one year - this DOES NOT cover fair wear and tear.
If the battery is not properly charged before first use, or regularly conditioned, its capacity will diminish.
Under these circumstances we will not replace the battery regardless of whether it is less than one year old.
© Jack Sealey Limited
360° RECHARGEABLE INSPECTION LIGHT, 10W
& 2 X 4W SMD LED
MODEL NO:
LED3605G / LED3605R / LED3605GR
3.7V 2.6Ah Li-ion
2.5hr
IP54
10W + 2 x 4W SMD
205mm
Top Spotlight; 300lm, Front Light; 1000lm, Rear Light; 400lm
Top Spotlight; 3.5hr, Front Light; 2.5hr, Rear Light; 3hr
Original Language Version
LED3605G, LED3605R, LED3605GR
LED3605G LED3605R LED3605GR
SWIVEL
USB INPUT
FIG.1
SWIVEL
Issue 1
ON/OFF
19/02/24
