Sealey LEDWC01 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
1. SAFETY
1.1. GENERAL SAFETY
Ensure the lamp is fully charged before initial use.
9
DO NOT turn the lamp on when it is being charged.
8
DO NOT shine directly into your, another person's or an animal's eyes.
8
DO NOT allow children to use the lamp.
8
DO NOT handle or move the lamp whilst it is being charged.
8
DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8
DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
8
recharge the battery at least once every six months of non-use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire:
‰
DO NOT attempt to open, disassemble, modify or service the battery pack.
8
DO NOT crush, puncture, short external contacts or dispose of in fire or water.
8
DO NOT expose to temperatures above 60°C (140°F).
8
Recycle or dispose of used battery as stipulated by local regulation.
9
2. INTRODUCTION
i
Heavy-duty inspection lamp with dimming function. Supplied with one strong magnet on the base and two on the back. Lumen output on side lamp
30-300lm with dimming function and 100lm on top light. Operating time 2-10hr on side lamp and 5.5hr on the top light. Charging time is 2.5hr.
Includes LED indicator for level of charge on the front of the torch. Charger not included, compatible with Model No's WCB1 and WCB2 Wireless
Charging Bases.
3. SPECIFICATION
i
Model No: ............................................................................................. LEDWC01
Battery ............................................................................................ 3.7v 1200mAh
Charging Time ............................................................................................... 2.5hr
IP Rating .........................................................................................................IP68
LED Qty ............................................................................................................. 12
Lumen Output: .................................................... Side; 30-300lm, Top light; 100lm
Operating Time: ..................................................... 2-10hr/5.5hr - 30-300lm/100lm
IMPORTANT WARRANTY INFORMATION
The battery fitted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time.
We will provide warranty against mechanical and electrical defect for a period of one year - this DOES NOT cover fair wear and tear.
If the battery is not properly charged before first use, or regularly conditioned, its capacity will diminish. Under these circumstances
we will not replace the battery regardless of whether it is less than one year old.
4. OPERATION
4.1. CHARGING THE LAMP (fig.1)
4.1.1. Rest the lamp on the charging platform such that the charging pad on the torch lies directly above the charge pad on the platform.
4.1.2. The left hand RED LED on the torch will illuminate and the GREEN LEDS to its right will light or flash depending on the state of the
battery. A solid green LED indicates that the torch is charged to that level, a flashing green LED indicates that the torch is charging.
When fully charged all three green LEDs will be lit.
4.2. OPERATING THE LAMP (fig.2)
4.2.1. The lamp ON/OFF/FADE button is located on the side of the lamp (fig.2). The operation sequence is: one press for top LED, second
press turns front lamp on and top lamp off. A third press that is held on causes front lamp output to decrease. Press and hold once
more and the lamp output will increase. To turn the unit off one further press of the switch is required.
4.2.2. The battery state LEDs turn off approximately 1 minute after turning the lamp on. When the charge is 25% the red LED will light.
4.2.3. The lamp may be suspended by the hook on rear of lamp or attached to any ferrous surface by using the magnets on the back of the
torch or the magnet in the base.
© Jack Sealey Limited
3W + 1W COB LED INSPECTION LAMP -
WIRELESS RECHARGEABLE
LEDWC01
MODEL NO:
Original Language Version LEDWC01 Issue 1 22/07/19
