Dishwasher

User manual

DW50DG4**F**/DW50DG4**B**

DW0010_IB_DW4000RM_English.indd 1

2024-06-17

4:39:59

Need help?

Do you have a question about the DW50DG430B00EU and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung DW50DG430B00EU

Page 1 Dishwasher User manual DW50DG4**F**/DW50DG4**B** DW0010_IB_DW4000RM_English.indd 1 2024-06-17 4:39:59...
Page 2 Contents Safety information What you need to know about safety instructions Important safety symbols Instructions about the WEEE Important safety precautions Instructions when using your dishwasher Instructions for protecting your children Instructions for installing your dishwasher Installation What’s included Installation requirements Step-by-step installation (Built-in models) Skirting board (Not applicable for free standing model) Before you start...
Page 3 Troubleshooting Checkpoints Information codes Cycle chart Appendix Transportation/relocation Protection against frost Disposing the dishwasher and helping the environment Specifications For standard test Contact information QUESTIONS OR COMMENTS? English DW0010_IB_DW4000RM_English.indd 3 2024-06-17 4:39:59...
Page 4 If you have any questions or concerns, contact your nearest service center or find help and information online at www.samsung.com. Important safety symbols...
Page 5 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, visit our sustainability page available via www.samsung.com English DW0010_IB_DW4000RM_English.indd 5 2024-06-17...
Page 6 Safety information Important safety precautions To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a...
Page 7 6. For appliances with ventilation openings in the base, a carpet must not obstruct the openings. 7. Children of less than 3 years should be kept away unless continuously supervised. 8. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a...
Page 8 Safety information Instructions when using your dishwasher This dishwasher is not designed for commercial use. It is intended for use in domestic households and in similar working and residential environments such as: • Shops • Offices and showrooms and by residents in establishments such as: •...
Page 9 Instructions for protecting your children This appliance is not a toy! To avoid the risk of injury, keep children well away and do not allow them to play in or around the dishwasher or to use the controls. They will not understand the potential dangers posed by it.
Page 10 Safety information Instructions for installing your dishwasher Before setting up the appliance, check it for any externally visible damage. Under no circumstances should you use a damaged appliance. A damaged appliance could be dangerous. The dishwasher must only be plugged into the electricity supply via a suitable switched socket.
Page 11 The plastic housing of the water connection contains an electrical component. The housing must not be submerged in water. There are electrical wires in the hose of Aqua-Stop. Never cut the water inlet hose, even if it is too long. Installation, maintenance and repairs may only be carried out by a suitably qualified and competent person in strict accordance with current national and local safety regulations.
Page 12 Safety information In the event of a fault or for cleaning purposes, the appliance is only completely isolated from the electiricity supply when: • it is switched off at the wall socket and the plug is withdrawn, or • it is switched off at the mains, or •...
Page 13 Make sure all the parts are included in the product package. If you have a question about the dishwasher or the parts, contact a local Samsung customer centre or your retailer. The actual appearance of the dishwasher may differ, depending on your model and country.
Page 14 Installation Installation kit (not provided) Hose clamp Tools required (not provided) Safety glasses Gloves Flashlight Wrench (22 mm) for the front foot Torx T15 Pliers Nipper Tape measure Pencil Phillips screwdriver Flat head Cutting knife screwdriver Level Hole saw (80-100 mm) English DW0010_IB_DW4000RM_English.indd 14 2024-06-17...
Page 15 • Do not modify the power plug of the Then, contact a local Samsung customer dishwasher. If the power plug does centre or a qualified technician. not fit the outlet, have a proper outlet installed by a qualified electrician.
Page 16 Installation Drain Ambient temperature If you are using a drain system dedicated Do not install the dishwasher in an area to the dishwasher, connect the drain hose exposed to freezing temperatures. The to a drain system that is between 30 cm dishwasher always retains some water in and 70 cm off the ground.
Page 17 Step-by-step installation (Built-in models) The installation procedure may differ depending on the model. STEP 1 Select a location Select a location that meets the following conditions. • The location must have a solid floor that can support the weight of the dishwasher.
Page 18 Installation Cabinet dimensions NOTE Check if the distance between the floor and the bottom of the worktop is more than 850 mm. If so, insert the sub foot included in the installation kit. For details, see the next section. If the distance is less than 850 mm, skip to STEP 3. English DW0010_IB_DW4000RM_English.indd 18 2024-06-17...
Page 19 STEP 2 To insert the sub foot If the distance between the floor and the bottom of the worktop is more than 850 mm, insert the sub foot into the hole on the bottom of the dishwasher before you start the installation.
Page 20 Installation STEP 4 Arrange the hoses 1. Clean the bottom of the countertop. 2. Attach the protective sticker as shown. 3. Pull the power plug, the water hose, and the drain hose through the sink hole. CAUTION • Use caution not to kink or step on the power plug or the hoses.
Page 21 STEP 5 Install the custom panel 1. Put the installation template on the back of the custom panel and fix it Ø2 temporarily using transparent tape. Note that the rear of the custom panel will be attached to the dishwasher door. CAUTION •...
Page 22 Installation 5. Insert the door brackets (C) on the custom panel to the holes (E) on the the dishwasher door to fix the custom panel. 6. While holding the custom panel, attach it to the door and insert the custom 30 mm panel fixers (A) into the holes (F) as shown in the figure.
Page 23 9. Open the dishwasher door and remove the 4 screws. CAUTION Use caution when opening the door. The door might open or close unexpectedly if the spring level is not adjusted appropriately, resulting in physical injury. 10. Secure the custom panel to the door by fastening the 4 screws (3.5 X 45).
Page 24 Installation STEP 6 Level the dishwasher For Built-In models You can adjust the height of the dishwasher to level it. Note that in these steps, the dishwasher is currently inserted halfway. 1. Use the level to check if the dishwasher is level.
Page 25 (For free standing models) 1. Use a level to check whether the dishwasher is level. 2. Turn the levelling feet under the four bottom corners to adjust the height. - You can adjust the height up to 20 mm. 3. When levelling is complete, check if the door opens and closes properly.
Page 26 Installation STEP 7 Secure the dishwasher You can use the brackets to secure the dishwasher to the countertop. Alternatively, you can drill the side holes to secure the dishwasher to the cabinet sides. To the countertop using the brackets 1. Insert the provided brackets into the top front holes of the dishwasher as shown.
Page 27 To the sides CAUTION If the plastic caps are not assembled, water may leak and cause a fire or electric shock. 1. Remove the plastic caps. 2. Tighten the 2 screws (Ø3.5 X 16) to the 2 places (marked on the illustration). 3.
Page 28 Installation STEP 8 Connect the drain hose 1. Connect the drain hose to the drain outlet. CAUTION • Install the drain system properly so that the drain hose does not come out of the drain outlet in the draining process. •...
Page 29 Skirting board (Not applicable for free standing model) 1. Put the skirting board on the bottom of the dishwasher. 2. Open the door of the dishwasher, and draw a baseline on the skirting board where it interferes with the door. 3.
Page 30 Before you start Follow these instructions carefully to ensure proper installation of the dishwasher and to prevent accidents when washing dishes. Dishwasher at a glance DW50DG43*B0 NOTE: “ * ” Asterisk(s) means variant model and can be varied (0-9) or (A-Z). 01 Upper rack 02 Lower rack 03 Salt storage...
Page 31 DW50DG45*B0 NOTE: “ * ” Asterisk(s) means variant model and can be varied (0-9) or (A-Z). 01 Cutlery rack 02 Upper rack 03 Salt storage 04 Lower rack 05 Dispenser 06 Door 07 Base 08 Inlet hose 09 Drain hose English DW0010_IB_DW4000RM_English.indd 31 2024-06-17...
Page 32 Before you start DW50DG45*FS 01 Cutlery rack 02 Upper rack 03 Salt storage 04 Lower rack 05 Dispenser 06 Door 07 Base 08 Inlet hose 09 Drain hose English DW0010_IB_DW4000RM_English.indd 32 2024-06-17 4:40:03...
Page 33 CAUTION • Do not wash items that are covered with ash, sand, wax, lubricating grease, or paint. These materials will damage the dishwasher. Ash does not dissolve and will spread inside the dishwasher. • Remove food remains such as bones, fruit seeds, etc. and waste such as toothpicks, paper napkins, etc.
Page 34 Before you start Basic use of racks Height adjustment You can adjust the height of the upper rack so that the lower rack can accommodate larger sized dishes. Depending on the height of the upper rack, the lower rack can accommodate plates up to 29 cm in diameter, and the upper rack can accommodate plates up to 18 cm.
Page 35 Upper rack removal CAUTION • Do not operate the dishwasher without the upper rack. Otherwise, noises occur and the dishwasher does not operate properly. • Because the upper rack is removable, insert the upper rack properly to ensure the dishwasher operates normally. Pull the upper rack to the front until it is fully extended, and then lift it slightly to remove.
Page 36 Before you start Loading dishes Lower rack We recommend that you place large items, that are difficult to clean (such as pots, pans, lids, serving dishes and bowls), in to the lower rack. It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking the rotation of the upper nozzle.
Page 37 Using the folding tines For better stacking of pots and pans, the tines can be folded down as show in the figure. Upper rack The upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty).
Page 38 Before you start Cutlery rack (DW50DG45* model only) The cutlery rack is best for flatware and cooking or serving utensils. Use the cutlery rack to organize flatware or utensils. NOTE The cutlery rack can be removed if you need more space on the upper rack to clean larger items.
Page 39 Filling the detergent 1. Open the detergent dispenser cap by pushing the detergent dispenser catch to the right. NOTE The cap remains open at the end of a cycle. 2. Add the recommended amount of detergent to the main wash detergent compartment.
Page 40 Before you start 4. If the items are heavily soiled, pour a small amount of detergent onto the door for better cleaning results. (For amount of detergent, refer to the “Recommended amount of detergent” section.) NOTE The additional detergent will activate during the pre-wash process.
Page 41 Rinse aid reservoir Rinse aid improves the drying performance of the dishwasher. When the Rinse Refill indicator lights up on the control panel, refill with rinse aid. Only use liquid rinse aid. Powdered rinse aid will clog the reservoir opening and cause the dishwasher to malfunction.
Page 42 Before you start Salt storage CAUTION • Use dishwasher-specific salt only. Do not use any other type of salt or solvent. This may damage the salt storage and the water softening system. • To prevent corrosion due to an excessive amount of salt or salty water, always fill the salt storage immediately before a washing cycle gets started.
Page 43 Salt indicator The indicator ( ) turns on if there is not enough salt for the next several cycles. Touchpad responsiveness To prevent the touch-enabled controls from losing responsiveness, follow these instructions. • Touch the centre of each button with one finger.
Page 44 Before you start Setting mode (For fully built in model : DW50DG45*B00/ DW50DG43*B00) You can change the sound, auto door open function, rinse aid level, and water hardness settings to your preference. Entering the Setting mode 1. Turn the dishwasher on. 2.
Page 45 Rinse aid level setting You can change the amount of rinse aid applied during a cycle. 1. Press the Sanitize button to select the rinse aid level setting menu. - The display shows the current setting. (Default setting: “d4”) 2. Press the AUTO cycle button to change the setting. - You can select from d1 - d5 (minimum –...
Page 46 Before you start Setting mode (For free standing model : DW50DG45*FSR) You can change the sound, auto door open function, rinse aid level, and water hardness settings to your preference. Entering the Setting mode 1. Turn the dishwasher on. 2. Press and hold the Program button for five seconds within 60 seconds from turning on the dishwasher.
Page 47 Rinse aid level setting You can change the amount of rinse aid applied during a cycle. 1. Press the Rinse Add button to select the rinse aid level setting menu. - The display shows the current setting. (Default setting: “d4”) 2.
Page 48 Operations Control panel DW50DG4**B0 01 POWER Press to turn the dishwasher on or off. Press to select a desired wash cycle. For more information, see 02 Cycle the “Cycle overview” section on page 52. 03 Upper rack only Press to wash items using only the upper rack to save energy. 04 Lower rack only Press to wash items using only the lower rack to save energy.
Page 49 Indicators No Salt indicator Lights up when the salt storage runs out of salt. Rinse Refill indicator Lights up if the dishwasher runs out of rinse aid. Lights up if Control Lock is activated, and blinks if any Control Lock indicator button except for the POWER button is pressed.
Page 50 Operations DW50DG45*FS 01 POWER Press to turn the dishwasher on or off. Press to select a desired wash cycle. For more information, see 02 Program the “Cycle overview” section on page 52. Press to wash small number of items to save energy. •...
Page 51 Indicators No Salt indicator Lights up when the salt storage runs out of salt. Rinse Refill indicator Lights up if the dishwasher runs out of rinse aid. Lights up if Control Lock is activated, and blinks if any Control Lock indicator button except for the POWER button is pressed.
Page 52 Operations Cycle overview This cycle detects the level of soil and automatically initiates 01 AUTO the optimal cycle, which is appropriate for all levels of soiled items. This cycle reduces power and water consumption, which is 02 ECO appropriate for normally soiled items. 03 Intensive Select this cycle for heavily soiled items.
Page 53 Simple steps to start 1. Open the door, and then load the dishwasher. Make sure to remove food remains and waste on the dishes. 2. Apply detergent to the detergent dispenser. For better results, add rinse aids. 3. Press POWER, and then select a cycle with necessary options (Upper rack only, Lower rack only, Half load, Rinse Add, Sanitize, Multi tab, and Delay Start).
Page 54 Operations Salt storage (For fully built in model : DW50DG45*B00/ DW50DG43*B00) The water softener is designed to remove minerals and salts from the water, which would have a detrimental or adverse effect on the operation of the appliance. The higher the content of these minerals and salts, the harder your water is.
Page 55 Salt storage (For free standing model : DW50DG45*FSR) The water softener is designed to remove minerals and salts from the water, which would have a detrimental or adverse effect on the operation of the appliance. The higher the content of these minerals and salts, the harder your water is. The softener should be adjusted according to the hardness of the water in your area.
Page 56 Operations Water Salt Water hardness Autonomy hardness consumption (cycles/1 kgs) °dH °fH °Clark mmol/l setting (gram/cycle) 0-0.94 6-11 10-20 7-14 1.0-2.0 12-17 21-30 15-21 2.1-3.0 18-22 31-40 22-28 3.1-4.0 23-34 41-60 29-42 4.1-6.0 35-55 61-98 43-69 6.1-9.8 NOTE • 1 dH (German degree) = 0.178 mmol/l •...
Page 57 Delay Start You can delay the cycle starting time up to 24 hours in 1-hour increments. To increase the delay time, press Delay Start. The hour displayed indicates the time at which the cycle will start. 1. Open the door, and then load the dishwasher. 2.
Page 58 Maintenance Cleaning Keep the dishwasher clean to improve performance, reduce unnecessary repairs, and lengthen the lifecycle. Exterior Clean spills on the surface of the dishwasher immediately. Use a soft, damp cloth on the control panel to gently wipe away spills and dust. CAUTION •...
Page 59 Nozzles To prevent the nozzles from being clogged or if the nozzles are clogged, remove and clean each nozzle. Use caution when removing the nozzles as they may break. Upper nozzle 1. Open the door, and then pull out the upper rack to reveal the upper nozzle.
Page 60 Maintenance Filter We recommend cleaning the filter every month. 1. Open the door, and then remove the lower rack first. 2. Turn the filter handle counterclockwise to unlock the Coarse filter. 3. Remove the Coarse filter, and then the cylindrical micro filter underneath. English DW0010_IB_DW4000RM_English.indd 60 2024-06-17...
Page 61 4. Remove any dirt and impurities from the micro filter and the Coarse filter. 5. Rinse them with running water, and then dry well. 6. Reinsert the filter, and then the Coarse filter. 7. Turn the filter handle clockwise to lock. CAUTION Make sure the Coarse filter is closed properly.
Page 62 Troubleshooting Checkpoints If you encounter an issue with the dishwasher, first check the table below and try the suggestions. Symptom Possible cause Action • Make sure the door is latched and completely closed. The door is not completely • Make sure the upper rack closed.
Page 63 Symptom Possible cause Action • Select a cycle according to An incorrect cycle was the soil level of the dishes selected. as instructed in this manual. • Clean the filters. The filters are clogged or not • Make sure the filters are correctly fastened.
Page 64 Troubleshooting Symptom Possible cause Action The dishwasher makes a sound when the dispenser cover is • This is normal. open and the drain pump is operating. The dishwasher is • Make sure the dishwasher too noisy. The dishwasher is not level. is level.
Page 65 Distribution motor check • Abnormal working with distribution motor assembly, or main PCB. If the issue continues, contact a local Samsung service center. If any information code keeps appearing on the screen, contact a local Samsung service centre. English DW0010_IB_DW4000RM_English.indd 65...
Page 66 Cycle chart DW50DG45*FSR / DW50DG45*B00 / DW50DG43*B00 Cycle AUTO Intensive Amount of food Very light to heavy Normal Heavy remains Pre wash (45 °C)  Pre wash (50 °C)  Main wash (48 °C) Main wash (45 °C- Main wash (60 °C) ...
Page 67 Appendix Transportation/relocation Make sure the dishwasher is empty with no loose parts. First, drain the dishwasher as follows. 1. Open the door, and then turn the dishwasher on. 2. Select and run the ECO cycle. 3. Press START, and then close the door. 4.
Page 68 Appendix Specifications FS(Free Standing) FBI (Fully Built In) MODEL DW50DG45*FSR DW50DG45*B00 DW50DG43*B00 Power 220-240 V~, 50 Hz Water pressure 0.04-1.0 MPa Wash capacity 10 place setting 10 place setting 9 place setting Rated power 1760-2100 W Dimension 448 x 600 x 845 mm 448 x 550 x 815 mm (Width x Depth x Height) Weight (Unpacked)
Page 69 For standard test NOTE The information for comparability test as follows. DW50DG45*FSR/DW50DG45*B00 • Washing capacity: 10 place settings • Test standard: EN 60436 • Position of upper rack: lower position • Wash cycle: ECO • Additional options: None • Rinse aid level setting: d5 •...
Page 70 For standard test DW50DG43*B00 • Washing capacity: 9 place settings • Test standard: EN 60436 • Position of upper rack: lower position • Wash cycle: ECO • Additional options: None • Rinse aid level setting: d5 • Water hardness level setting: H3 •...
Page 71 21 62 90 99 www.samsung.com/no/support DENMARK 70 70 19 70 www.samsung.com/dk/support FINLAND 030-622 75 15 www.samsung.com/fi/support SWEDEN 0771-400 300 www.samsung.com/se/support AUSTRIA 0800 72 67 864 (0800-SAMSUNG) www.samsung.com/at/support www.samsung.com/ch/support (German) SWITZERLAND 0800 726 786 www.samsung.com/ch_fr/support (French) HUNGARY 0680SAMSUNG (0680-726-7864) www.samsung.com/hu/support CZECH 800 - SAMSUNG (800-726786) www.samsung.com/cz/support...
Page 72 Luni - Vineri: 9 AM - 6 PM ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support 8009 4000 CYPRUS only from landline, toll free 80111-SAMSUNG (80111 726 7864) www.samsung.com/gr/support from mobile and land line GREECE (+30) 210 6897691 from mobile and land line 801-172-678* POLAND http://www.samsung.com/pl/support/...
Page 73 Memo DW0010_IB_DW4000RM_English.indd 73 2024-06-17 4:40:08...
Page 74 Memo DW0010_IB_DW4000RM_English.indd 74 2024-06-17 4:40:08...
