OPERATION MANUAL
MODEL:
* Write down the model name.
(Refer to the rating label.)
* Bitte schreiben Sie den Modellnamen auf.
(Siehe Typenschild)
* Veuillez écrire le nom du modèle.
(Consultez l'étiquette des spécifi cations.)
* Anote el nombre de modelo.
(Consulte la etiqueta de califi cación).
* Annotare il nome del modello.
(Fare riferimento all'etichetta delle specifi che).
* Καταγράψτε το όνομα μοντέλου.
(Ανατρέξτε στην ετικέτα τεχνικών στοιχείων.)
* Registe o nome de modelo.
(Consulte a etiqueta de classifi cação.)
* Запишите название модели.
(См. на паспортной табличке.)
* Lütfen model adını not ed n z.
(Derece et ket ne bakınız.)
PART No. 9387858150-02
AIR CONDITIONER (Wall-mounted type)
Before using this product, read these instructions thoroughly
and keep this manual for future reference.
BEDIENUNGSANLEITUNG
KLIMAANLAGE (Wandmontierter Typ)
Bevor Sie dieses Produkt verwenden, lesen Sie diese
Anweisungen sorgfältig durch und bewahren Sie diese
Anleitung für späteres Nachschlagen auf.
CLIMATISEUR (Type à montage mural)
Avant d'utiliser ce produit, veuillez lire attentivement ces
instructions. Conservez ce manuel pour référence future.
MANUAL DE FUNCIONAMIENTO
ACONDICIONADOR DE AIRE (Tipo montado en pared)
Antes de utilizar el producto, lea estas instrucciones detenida-
mente y conserve este manual para consultarlo en el futuro.
CONDIZIONATORE D'ARIA (Tipo montato a parete)
Prima di utilizzare l'apparecchio, leggere attentamente
le presenti istruzioni e conservare il manuale per poterlo
ΚΛΙΜΑΤΙΣΤΙΚΟ (Επιτοίχιος τύπος)
Προτού χρησιμοποιήσετε το προϊόν, διαβάστε προσεκτικά τις
παρούσες οδηγίες και φυλάξτε το παρόν εγχειρίδιο, ώστε να
μπορείτε να ανατρέχετε σε αυτό στο μέλλον.
MANUAL DE FUNCIONAMENTO
AR CONDICIONADO (Tipo mural)
Antes de utilizar este produto, leia atentamente estas instruções
e guarde este manual para referência futura.
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
КОНДИЦИОНЕР ВОЗДУХА (Настенного типа)
Перед эксплуатацией устройства внимательно
ознакомьтесь с данным руководством и сохраняйте его для
Bu ürünü kullanmadan önce ver len tal matları d kkatl ce okuyun
ve daha sonra tekrar faydalanmak üzere saklayın.
OPERATION MANUAL
MODE D'EMPLOI
MANUALE DI ISTRUZIONI
consultare il futuro.
ΕΓΧΕΙΡΙΔΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
использования в будущем.
KULLANIM KILAVUZU
KLİMA (Duvara Monte t p)

Advertisement

loading
Need help?

Need help?

Do you have a question about the ASG09-KMCF and is the answer not in the manual?

Questions and answers

Summary of Contents for General ASG09-KMCF

  • Page 1 OPERATION MANUAL OPERATION MANUAL AIR CONDITIONER (Wall-mounted type) Before using this product, read these instructions thoroughly and keep this manual for future reference. BEDIENUNGSANLEITUNG KLIMAANLAGE (Wandmontierter Typ) Bevor Sie dieses Produkt verwenden, lesen Sie diese Anweisungen sorgfältig durch und bewahren Sie diese Anleitung für späteres Nachschlagen auf.
  • Page 2 11. CLEANING AND CARE ........... 11 • Do not start or stop the operation of this product by 12. GENERAL INFORMATION ........12 inserting or pulling out the power plug, or by turning on or off the circuit breaker.
  • Page 3 Explanation of symbols displayed on the indoor unit or outdoor unit. CAUTION WARNING • Do not place any other electrical products or This symbol shows that this product uses a household belongings under this product. Dripping fl ammable refrigerant. If the refrigerant is leaked and condensation from this product might get them wet exposed to an external ignition source, there is a risk and may cause damage or malfunction of your...
  • Page 4 3.2. Remote controller 3. NAME OF PARTS When you use the optional remote controller, the appearance CAUTION and the operation procedure may diff er. For details, refer to the operation manual of each remote For appropriate signal transmission between the remote controller.
  • Page 5 CAUTION • To prevent malfunction or damage of the remote controller: - Place remote controller at where will not be exposed to direct sunlight or excessive heat. - Remove batteries if the product is not going to be used for an extended period. •...
  • Page 6 NOTES: 3.3. Inserting batteries • In the Cooling or Dry mode, set the temperature lower than the current room temperature. Battery type: R03/LR03/AAA x 2 • In the Cooling mode, the indoor unit fan may stop from time to time to perform Fan control for energy saving that enables power-saving operation by stopping the rotation of the indoor unit fan when the outdoor unit is stopped.
  • Page 7 ■ Airfl ow direction range 6.3. Sleep timer Up/down airfl ow direction The Sleep timer supports your comfortable sleep by moderating the air Change by conditioner operation gradually. Cooling, Dry 1 ⇄ 2 ⇄ 3 ( ⇄ 4 ⇄ 5 ⇄ 6) 1.
  • Page 8 8. OTHER OPERATIONS 9. WLAN control This operation manual describes only the setting procedure of the 8.1. Powerful operation remote controller. For how to operate the mobile app, refer to the operation manual of the mobile app. In the Powerful operation, the air conditioner will operate at maximum power and strong airfl...
  • Page 9 • If you know that there are people in the vicinity of the air “AIRSTAGE Mobile” is a trademark of FUJITSU GENERAL LIMITED. conditioner, inform them in advance that you will operate it Android and Google Play are registered trademarks of Google LLC.
  • Page 10 NOTES: 9.2. Setting to use WLAN control • This device complies with Part 15 of FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: Step 1. Mobile app installation (1) this device may not cause interference, and 1.
  • Page 11 1. Be sure to turn air conditioner off and disconnect all the Initialization (reset) power supplies. Initialize (reset) the WLAN adapter in the following situations: 2. Open the intake grille. • Changing the access point • Disposing of this product •...
  • Page 12 2. Remove the air fi lters. 11. CLEANING AND CARE Lift up the air fi lters' handle, disconnect the two lower tabs, and pull out. CAUTION Air Filter handle • Before cleaning this product, be sure to turn it off and disconnect all the power supply.
  • Page 13 2. Remove the Ion deodorization fi lter from the air cleaning unit for 2 seconds or less. fi lter holder. 3. Install the new Ion deodorization fi lter. 12. GENERAL INFORMATION Removing and installing intake grille ■ Heating performance This air conditioner operates on the heat-pump principle, absorbing heat ■...
  • Page 14 ■ Malfunctions caused by other electrical 13.2. Multi-split type air conditioner devices Use of other electrical appliances, such as an electric shaver or nearby This indoor unit can be connected to a multi-split type outdoor use of a wireless radio transmitter, may cause the malfunction of the air unit.
  • Page 15 14. TROUBLESHOOTING Airfl ow is weak or stops. □ Is the fan speed set to Quiet? ⇒ To change the fan speed, refer to page 5. WARNING □ Has the Fan Control for Energy Saving set? In this case, the indoor unit fan may stop temporarily while the Cooling operation. In the following events, immediately stop the ⇒ To cancel the Fan control for energy saving, refer to page 6.
  • Page 16 I have not received the e-mail when registering my account. State Causes and solutions page □ Set the domain permissions so that it is not rejected as spam. Timer setting error because of Auto restart The method of registering additional air conditioners is unclear. ⇒...
