Kohler INNATE K-8340X-2EXWT-0 Installation Manual page 4

Overall Sketch
Finished wall
305/400
SPECIFICATIONS
Flush volume
Water efficiency grade*
Rated voltage
Rated power*
* The description of water efficiency label marked on intelligent toilet: water efficiency label represents a compliance mark of the water efficiency grade etc. performance of intelligent toilet.
* Power value testing condition: dynamic pressure 0.2MPa, inlet water temp 15°C.
1382001-T01-D
720
626
Kohler reserves the right to change ma rked dimensions without prior notice.
5.5L
Level III
305mm/400mm
min inlet water pressure 0.07MPa (dynamic)
max inlet water pressure 0.74MPa
220V~, 50Hz
1100W
About 720mm x 432mm x 550mm
About 51kg
1-35
1-40
Receptacle
390
300
150
Finished floor
Angle valve installation
position G1/2 threads
Fig 1
4
432
400
300
321
Unit: mm
550
Kohler Co.
