JumpSport ALLEYOOP ProFlex-II Basketball Set User Manual page 4

Assembly and Installation Instructions
Tools
Installation of the ProFlex Basketball Set requires a 13mm hex wrench, a 14mm hex wrench, a 17mm hex wrench, and a
Phillips screwdriver. Two double-sided hex wrenches are included in Box #2 (see Reference #2 and #3 in the list below).
An 8 foot A-Frame ladder will be useful for some Steps (use care and follow procedures for use). Safety glasses and
gloves are also recommended for safety.
Parts List
Your ProFlex Basketball Set is shipped with the parts shown below. The backboard ships in one box, and all the other
parts and hardware are shipped in a second box. If any parts are missing, immediately call JumpSport Customer Service
at 888-567-5867.
Note: M10 bolts (and related hardware) are bigger in diameter than M8 bolts (and related hardware). The two
wrenches are the only parts not shown on the following page.
Reference # Part #
1 BAC-P-10372-01 AlleyOOP Backboard V2
2 TOO-P-10343-01 Combo wrench with notch on handle (fits 14mm & 17mm hex heads)
3 TOO-P-10344-01 Combo wrench (fits 13mm & 17mm hex heads)
4 PLA-P-10967-01 Back plate V2
5 PLA-P-10376-01 Long bracket V2
6 PLA-P-10337-01 Front plate V2
7 HOO-P-10338-01 Hoop Assembly V2
8 NET-P-10339-01 Net V2
9 BAL-P-10340-01 Ball
10 CAP-P-10341A
11 CLA-P-10342-01 Pole clamp V2
12 BOL-P-10349A
13 WAS-P-10346A
14 NUT-P-10374A
15 NUT-P-10352A
16 SPR-P-10355A
17 WAS-P-10351A
18 SCR-P-22125-00 M8 screw, button head, 3/4in
19 SCR-P-10347-01 M8 screw, tapered head, 1in
20 WAS-P-10357A
21 NUT-P-10348A
22 NUT-P-10358A
Ball cap with notch
M10 bolt, 5-1/2in
M10 washer (fits M10 bolts + 2 spare)
M10 standard nut (fits M10 bolts +2 spare)
M10 Nylock nut (fits M10 bolts)
Hoop spring
Spring cap
M8 washer (fits M8 screw)
M8 standard nut (fits M8 screw)
M8 Nylock nut (fits M8 srew)
Description
4
Quantity Box #
1 1
1 2
1 2
1 2
2 2
1 2
1 2
1 2
1 2
1 2
2 2
4 2
2 2
2 2
4 2
4 2
4 2
2 2
2 2
2 2
2 2
2 2
