Prestige 653HWI Series

ADSL Security Gateway with IEEE802.11g and ISDN Backup

User's Guide

Version 3.40

October 2003

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the PRESTIGE 653HX and is the answer not in the manual?

Questions and answers

Summary of Contents for ZyXEL Communications PRESTIGE 653HX

Page 1 Prestige 653HWI Series ADSL Security Gateway with IEEE802.11g and ISDN Backup User's Guide Version 3.40 October 2003...
Page 2: Copyright
Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patent rights of others.
Page 3 4. Consult the dealer or an experienced radio/TV technician for help. Notice 1 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Certifications Refer to the product page at www.zyxel.com. FCC Statement...
Page 4: Zyxel Limited Warranty
ZyXEL shall in no event be held liable for indirect or consequential damages of any kind of character to the purchaser.
Page 5: Customer Support
Brief description of the problem and the steps you took to solve it. METHOD E-MAIL TELEPHONE/FAX WEB SITE/ FTP SITE REGULAR MAIL SUPPORT/SALES LOCATION WORLDWIDE support@zyxel.com.tw +886-3-578-3942 www.zyxel.com ZyXEL Communications Corp., 6 Innovation Road II, Science- www.europe.zyxel.com Based Industrial Park, Hsinchu 300, Taiwan. sales@zyxel.com.tw +886-3-578-2439 ftp.europe.zyxel.com NORTH support@zyxel.com +1-800-255-4101 www.us.zyxel.com AMERICA sales@zyxel.com...
Page 7: Table Of Contents
Prestige 653HWI Series User’s Guide Table of Contents Copyright................................. ii Federal Communications Commission (FCC) Interference Statement.............iii ZyXEL Limited Warranty ..........................iv Customer Support............................v List of Figures .............................. xiv List of Tables .............................. xxiv List of Charts .............................. xxx Preface ............................... xxxii What is DSL? ............................
Page 8 Prestige 653HWI Series User’s Guide Chapter 5 LAN Setup ..........................5-1 LAN Overview...........................5-1 DNS Server Address ........................5-1 DNS Server Address Assignment ....................5-2 LAN TCP/IP ..........................5-2 Configuring LAN ........................5-4 Chapter 6 Wireless LAN Setup ........................6-1 Wireless LAN Overview......................6-1 Levels of Security ........................6-3 Data Encryption with WEP ......................6-4 Configuring MAC Filter......................6-6 Network Authentication ......................6-8...
Page 9 Firewall and Content Filters ........................IV Chapter 11 Firewalls..........................11-1 11.1 Firewall Overview ........................11-1 11.2 Types of Firewalls........................11-1 11.3 Introduction to ZyXEL’s Firewall ...................11-2 11.4 Denial of Service ........................11-3 11.5 Stateful Inspection ........................11-7 11.6 Guidelines For Enhancing Security With Your Firewall ............11-11 11.7 Packet Filtering Vs Firewall ....................11-12...
Page 10 18.5 Configuring Remote Management ...................18-3 Chapter 19 Universal Plug-and-Play (UPnP) ..................19-1 19.1 Introducing Universal Plug and Play..................19-1 19.2 UPnP and ZyXEL ........................19-2 19.3 Installing UPnP in Windows Example ..................19-3 19.4 Using UPnP in Windows XP Example ..................19-5 Chapter 20 Logs Screens ...........................20-1 20.1 Logs Overview .........................20-1...
Page 11 Prestige 653HWI Series User’s Guide 21.5 Scheduler ..........................21-4 21.6 Maximize Bandwidth Usage....................21-4 21.7 Bandwidth Borrowing......................21-7 21.8 Configuring Summary ......................21-9 21.9 Configuring Class Setup ......................21-11 21.10 Configuring Monitor......................21-18 Maintenance ...............................VIII Chapter 22 Maintenance ...........................22-1 22.1 Maintenance Overview ......................22-1 22.2 System Status Screen .......................22-1 22.3 DHCP Table Screen.........................22-6 22.4 Wireless Screens ........................22-7 22.5 Diagnostic Screens........................22-9...
Page 12 Prestige 653HWI Series User’s Guide Chapter 28 Internet Access ........................28-1 28.1 Internet Access Overview ......................28-1 28.2 IP Policies ..........................28-1 28.3 IP Alias.............................28-1 28.4 IP Alias Setup...........................28-2 28.5 Route IP Setup..........................28-4 28.6 Internet Access Configuration....................28-5 Chapter 29 Remote Node Configuration....................29-1 29.1 Remote Node Setup Overview ....................29-1 29.2 Remote Node Setup........................29-1 29.3 Remote Node Network Layer Options ..................29-5 29.4 Remote Node Filter ........................29-8...
Page 13 Prestige 653HWI Series User’s Guide 35.2 Supported MIBs ........................35-2 35.3 SNMP Configuration .......................35-2 35.4 SNMP Traps ..........................35-4 Chapter 36 System Security........................36-1 36.1 System Security ........................36-1 36.2 Creating User Accounts on the Prestige...................36-5 Chapter 37 System Information and Diagnosis..................37-1 37.1 System Status...........................37-1 37.2 System Information........................37-3 37.3 Log and Trace ..........................37-5 37.4 Diagnostic ..........................37-8...
Page 14 Prestige 653HWI Series User’s Guide Chapter 44 SA Monitor ..........................44-1 44.1 SA Monitor Overview......................44-1 44.2 Using SA Monitor ........................44-1 Chapter 45 Internal SPTGEN........................45-1 45.1 Internal SPTGEN Overview.....................45-1 45.2 The Configuration Text File Format ..................45-1 45.3 Internal SPTGEN FTP Download Example................45-3 45.4 Internal SPTGEN FTP Upload Example..................45-4 Appendices and Index..........................XII Appendix A Troubleshooting........................A-1...
Page 15: List Of Figures
Prestige 653HWI Series User’s Guide List of Figures Figure 1-1 Prestige Internet Access Application.....................1-8 Figure 1-2 Firewall Application........................1-9 Figure 1-3 VPN Application .........................1-10 Figure 1-4 Prestige LAN-to-LAN Application .....................1-11 Figure 2-1 Password Screen ...........................2-2 Figure 2-2 Web Configurator SITE MAP Screen ...................2-3 Figure 2-3 Example Xmodem Upload......................2-4 Figure 3-1 Wizard Screen 1 ..........................3-3 Figure 3-2 Internet Connection with PPPoE....................3-6...
Page 16 Prestige 653HWI Series User’s Guide Figure 6-8 RADIUS ............................. 6-14 Figure 7-1 Example of Traffic Shaping......................7-4 Figure 7-2 WAN Functions ..........................7-4 ..........................7-1 Figure 7-3 WAN DSL Setup Figure 7-4 ISDN Connection Setup ....................... 7-5 ......................... 7-8 Figure 7-5 ISDN Dial In Setup ........................
Page 17 Prestige 653HWI Series User’s Guide Figure 12-2 Attack Alert ..........................12-4 Figure 13-1 LAN to WAN Traffic.........................13-4 Figure 13-2 WAN to LAN Traffic.........................13-5 Figure 13-3 Firewall Rules Summary: First Screen..................13-6 Figure 13-4 Creating/Editing A Firewall Rule....................13-11 Figure 13-5 Adding/Editing Source and Destination Addresses..............13-13 Figure 13-6 Timeout ...........................13-14 Figure 14-1 Customized Services .........................14-1 Figure 14-2 Creating/Editing A Customized Service..................14-2...
Page 18 Prestige 653HWI Series User’s Guide Figure 17-8 Global Setting......................... 17-24 Figure 17-9 Telecommuters Sharing One VPN Rule Example ..............17-26 Figure 17-10 Telecommuters Using Unique VPN Rules Example ............17-27 Figure 18-1 Telnet Configuration on a TCP/IP Network ................18-2 Figure 18-2 Remote Management........................
Page 19 Prestige 653HWI Series User’s Guide Figure 22-8 Diagnostic ISDN Line......................22-13 Figure 22-9 Firmware Upgrade ........................22-15 Figure 22-10 Network Temporarily Disconnected..................22-16 Figure 22-11 Error Message ........................22-16 Figure 23-1 Login Screen ..........................23-2 Figure 23-2 Prestige 653 SMT Menu Overview...................23-3 Figure 23-3 SMT Main Menu........................23-5 Figure 23-4 Menu 23 System Password .......................23-6 Figure 24-1 Menu 1 General Setup.......................24-2 Figure 24-2 Menu 1.1 Configure Dynamic DNS..................24-3...
Page 20 Prestige 653HWI Series User’s Guide Figure 27-2 Menu 3.5.1 WLAN MAC Address Filtering ................27-3 Figure 28-1 Physical Network ........................28-2 Figure 28-2 Partitioned Logical Networks....................28-2 Figure 28-3 Menu 3.2 TCP/IP and DHCP Setup..................28-3 Figure 28-4 Menu 3.2.1 IP Alias Setup ......................28-3 Figure 28-5 Menu 1 General Setup ......................
Page 21 Prestige 653HWI Series User’s Guide Figure 32-4 Menu 15.1 Address Mapping Sets.....................32-4 Figure 32-5 Menu 15.1.255 SUA Address Mapping Rules ................32-5 Figure 32-6 Menu 15.1.1 First Set ........................32-6 Figure 32-7 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set..........32-8 Figure 32-8 Menu 15.2 NAT Server Setup ....................32-9 Figure 32-9 Menu 15.2.1 NAT Server Setup ....................32-10 Figure 32-10 Multiple Servers Behind NAT Example................32-11 Figure 32-11 NAT Example 1 ........................32-12...
Page 22 Prestige 653HWI Series User’s Guide Figure 34-9 TEL_FTP_WEB_SNM Filter Rules Summary ................ 34-7 Figure 34-10 Menu 21.1.x.1 TCP/IP Filter Rule..................34-9 Figure 34-11 Executing an IP Filter ......................34-12 Figure 34-12 Menu 21.1.5.1 Generic Filter Rule ..................34-13 Figure 34-13 Protocol and Device Filter Sets .................... 34-15 Figure 34-14 Sample Telnet Filter......................
Page 23 Prestige 653HWI Series User’s Guide Figure 37-9 Menu 24.4 System Maintenance : Diagnostic................37-9 Figure 38-1 Telnet in Menu 24.5 ........................38-3 Figure 38-2 FTP Session Example........................38-4 Figure 38-3 Menu 24.5 System Maintenance : Backup Configuration............38-6 Figure 38-4 Menu 24.5 System Maintenance : Starting Xmodem Download Screen ........38-6 Figure 38-5 Backup Configuration Example ....................38-7 Figure 38-6 Successful Backup Confirmation Screen ..................38-7 Figure 38-7 Telnet into Menu 24.6 .......................38-8...
Page 24 Prestige 653HWI Series User’s Guide Figure 41-1 Menu 25 IP Routing Policy Setup .................... 41-2 Figure 41-2 Menu 25.1 IP Routing Policy Setup ..................41-3 Figure 41-3 Menu 25.1.1 IP Routing Policy ....................41-4 Figure 41-4 Menu 3.2 TCP/IP and DHCP Ethernet Setup ................41-6 Figure 41-5 Menu 11.3 Remote Node Network Layer Options ..............
Page 25 Prestige 653HWI Series User’s Guide List of Tables Table 3-1 Wizard Screen 1..........................3-3 Table 3-2 Internet Connection with PPPoE ....................3-7 Table 3-3 Internet Connection with RFC 1483 ....................3-8 Table 3-4 Internet Connection with ENET ENCAP ..................3-9 Table 3-5 Internet Connection with PPPoA....................3-11 Table 3-6 Wizard: LAN Configuration ......................3-13 Table 4-1 Password............................4-1 Table 5-1 LAN..............................5-4...
Page 26 Prestige 653HWI Series User’s Guide Table 8-7 Address Mapping Rule Edit ......................8-13 Table 9-1 DDNS............................. 9-2 Table 10-1 Time/Date........................... 10-2 Table 11-1 Common IP Ports ........................11-4 Table 11-2 ICMP Commands That Trigger Alerts..................11-6 Table 11-3 Legal NetBIOS Commands......................11-7 Table 11-4 Legal SMTP Commands ......................11-7 Table 12-1 Attack Alert ..........................
Page 27 Prestige 653HWI Series User’s Guide Table 17-9 VPN Manual Setup ........................17-20 Table 17-10 SA Monitor ..........................17-23 Table 17-11 Global Setting .........................17-24 Table 17-12 Telecommuter and Headquarters Configuration Example ............17-25 Table 18-1 Remote Management ........................18-3 Table 19-1 Configuring UPnP ........................19-2 Table 20-1 Log Settings..........................20-3 Table 20-2 View Logs...........................20-4 Table 20-3 SMTP Error Messages ........................20-5 Table 21-1 Application and Subnet-based Bandwidth Management Example ..........21-3...
Page 28 Prestige 653HWI Series User’s Guide Table 24-1 Menu 1 General Setup........................ 24-2 Table 24-2 Menu 1.1 Configure Dynamic DNS................... 24-3 Table 25-1 Menu 2 WAN Backup Setup ...................... 25-2 Table 25-2 Menu 2.1Traffic Redirect Setup....................25-4 Table 25-3 Menu 2 ISDN Dial Backup Setup....................25-5 Table 25-4 Menu 2.2.2 NetCAPI Setup .......................
Page 29 Prestige 653HWI Series User’s Guide Table 34-3 Menu 21.1.x.1 TCP/IP Filter Rule ....................34-10 Table 34-4 Menu 21.1.5.1 Generic Filter Rule ...................34-14 Table 34-5 Filter Sets Table ........................34-19 Table 35-1 Menu 22 SNMP Configuration ....................35-3 Table 35-2 SNMP Traps..........................35-4 Table 35-3 Ports and Permanent Virtual Circuits..................35-4 Table 36-1 Menu 23.2 System Security : RADIUS Server................36-2 Table 36-2 Menu 23.4 System Security : IEEE802.1x .................36-4 Table 36-3 Menu 14.1 Edit Dial-in User.......................36-6...
Page 30 Prestige 653HWI Series User’s Guide Table 44-1 Menu 27.2 SA Monitor ......................44-2 List of Tables xxix...
Page 31: List Of Charts
Prestige 653HWI Series User’s Guide List of Charts Chart A-1 Troubleshooting the Start-Up of Your Prestige ................A-1 Chart A-2 Troubleshooting the LAN LED.....................A-1 Chart A-3 Troubleshooting the DSL LED .....................A-2 Chart A-4 Troubleshooting the LAN Interface ....................A-2 Chart A-5 Troubleshooting the WAN Interface .....................A-3 Chart A-6 Troubleshooting Internet Access ....................A-3 Chart A-7 Troubleshooting the Password ......................A-4 Chart A-8 Troubleshooting the Web Configurator..................A-4...
Page 32 Prestige 653HWI Series User’s Guide Chart K-4 Attack Logs ...........................K-3 Chart K-5 Access Logs ..........................K-4 Chart K-6 TCP Reset Logs..........................K-5 Chart K-7 ICMP Notes...........................K-5 Chart K-8 Sample IKE Key Exchange Logs....................K-8 Chart K-9 Sample IPSec Logs During Packet Transmission ...............K-10 Chart K-10 RFC-2408 ISAKMP Payload Types..................K-11 List of Charts xxxi...
Page 33: Preface
Web Configurator Online Help Embedded web help for descriptions of individual screens and supplementary information. ZyXEL Glossary and Web Site Please refer to www.zyxel.com for an online glossary of networking terms and additional support documentation. xxxii Preface...
Page 34: Syntax Conventions
Help us help you! E-mail all User Guide-related comments, questions or suggestions for improvement to techwriters@zyxel.com.tw or send regular mail to The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 300, Taiwan. Thank you! Syntax Conventions •...
Page 35: What Is Dsl
Prestige 653HWI Series User’s Guide What is DSL? DSL (Digital Subscriber Line) technology enhances the data capacity of the existing twisted-pair wire that runs between the local telephone company switching offices and most homes and offices. While the wire itself can handle higher frequencies, the telephone switching equipment is designed to cut off signals above 4,000 Hz to filter noise off the voice line, but now everybody is searching for ways to get more bandwidth to improve access to the Web - hence DSL technologies.
Page 36: Getting Started
Getting Started Part I: Getting Started This part is structured as a step-by-step guide to help you access your Prestige. It covers key features and applications, accessing the web configurator and configuring the wizard screens for initial setup.
Page 37: Chapter 1 Getting To Know Your Prestige
Prestige 653HWI Series User’s Guide Chapter 1 Getting To Know Your Prestige This chapter describes the key features and applications of your Prestige Introducing the Prestige 653HWI Your Prestige integrates high-speed 10/100Mbps auto-negotiating LAN interface(s), a high-speed ADSL port and an ISDN Interface into a single package. The Prestige is ideal for high-speed Internet browsing and making LAN-to-LAN connections to remote networks.
Page 38: Traffic Redirect
Prestige 653HWI Series User’s Guide Firewall The Prestige is a stateful inspection firewall with DoS (Denial of Service) protection. By default, when the firewall is activated, all incoming traffic from the WAN to the LAN is blocked unless it is initiated from the LAN.
Page 39: Isdn Interface
Prestige 653HWI Series User’s Guide ISDN Interface ♦ Call scheduling The Prestige can manage a remote node and dictate when a remote node should be called and for how long. ♦ Budget Control Budget management allows you to set a limit on the total outgoing call time of the Prestige within certain times.
Page 40 Prestige 653HWI Series User’s Guide Incoming Call Support In addition to making outgoing calls, you can configure the router to act as a remote access server for telecommuting employees. Outgoing Data Call Bumping Support Call bumping is a feature that allows the router to manage an MP (Multilink Protocol) bundle dynamically, dropping or reconnecting a channel in a bundle when necessary.
Page 41: Dynamic Dns Support
Prestige 653HWI Series User’s Guide Auto-crossover 10/100 Mbps Ethernet Interface(s) These interfaces automatically adjust to either a crossover or straight-through Ethernet cable. LAN/DMZ Interface The Prestige provides a LAN port that can function as a virtual DeMilitarized Zone (DMZ) port. Public servers (Web, FTP, etc.) attached to the DMZ port are visible to the outside world (while still being protected from DoS (Denial of Service) attacks such as SYN flooding and Ping of Death) and can also be accessed from the secure LAN.
Page 42: Protocol Support
Prestige 653HWI Series User’s Guide • Protocol Support ♦ DHCP Support DHCP (Dynamic Host Configuration Protocol) allows the individual clients (computers) to obtain the TCP/IP configuration at start-up from a centralized DHCP server. The Prestige has built-in DHCP server capability enabled by default. It can assign IP addresses, an IP default gateway and DNS servers to DHCP clients.
Page 43: Network Management
Prestige 653HWI Series User’s Guide Network Management ♦ Menu driven SMT (System Management Terminal) management ♦ Embedded web configurator ♦ CLI (Command Line Interpreter) ♦ Remote Management via Telnet or Web. ♦ SNMP manageable ♦ DHCP Server/Client/Relay ♦ Built-in Diagnostic Tools ♦...
Page 44: Applications For The Prestige
Prestige 653HWI Series User’s Guide Housing Your Prestige's compact and ventilated housing minimizes space requirements making it easy to position anywhere in your busy office. Applications for the Prestige Here are some example uses for which the Prestige is well suited. 1.3.1 Internet Access The Prestige is the ideal high-speed Internet access solution.
Page 45: Figure 1-2 Firewall Application
Prestige 653HWI Series User’s Guide 1.3.2 Firewall for Secure Broadband Internet Access The Prestige provides protection from attacks by Internet hackers. By default, the firewall blocks all incoming traffic from the WAN. The firewall supports TCP/UDP inspection and DoS (Denial of Services) detection and prevention, as well as real time alerts, reports and logs.
Page 46: Figure 1-3 Vpn Application
Prestige 653HWI Series User’s Guide Figure 1-3 VPN Application 1.3.4 LAN to LAN Application You can use the Prestige to connect two geogr ly dispersed networks over the ADSL line. A typical aphical LAN-to-LAN application for your Prestige is shown as follows. 1-10 Getting To Know Your Prestige...
Page 47: Figure 1-4 Prestige Lan-To-Lan Application
Prestige 653HWI Series User’s Guide Figure 1-4 Prestige LAN-to-LAN Application Getting To Know Your Prestige 1-11...
Page 49: Chapter 2 Introducing The Web Configurator
Prestige 653HWI Series User’s Guide Chapter 2 Introducing the Web Configurator This chapter describes how to access and navigate the web configurator. Web Configurator Overview The embedded web configurator allows you to manage the Prestige from anywhere through a browser such as Microsoft Internet Explorer or Netscape Navigator.
Page 50: Navigating The Prestige Web Configurator
Prestige 653HWI Series User’s Guide Figure 2-1 Password Screen Step 6. You should now see the SITE MAP screen. The Prestige automatically times out after five minutes of inactivity. Simply log back into the Prestige if this happens to you. Navigating the Prestige Web Configurator The following summarizes how to navigate the web configurator from the SITE MAP screen.
Page 51: Resetting The Prestige
Prestige 653HWI Series User’s Guide Wizard Setup Navigation panel Logout Figure 2-2 Web Configurator SITE MAP Screen Click the icon (located in the top right corner of most screens) to view embedded help. Resetting the Prestige If you forget your password or cannot access the SMT menu, you will need to reload the factory-default configuration file or use the RESET button the back of the Prestige.
Page 52: Figure 2-3 Example Xmodem Upload
Prestige 653HWI Series User’s Guide 2.4.2 Uploading a Configuration File Via Console Port Download the default configuration file from the ZyXEL FTP site, unzip it and save it in a folder. Step 1. Turn off the Prestige, begin a terminal emulation software session and turn on the Prestige again.
Page 53: Chapter 3 Wizard Setup
Prestige 653HWI Series User’s Guide Chapter 3 Wizard Setup This chapter provides information on the Wizard Setup screens in the web configurator. Wizard Setup Introduction Use the Wizard Setup screens to configure your system for Internet access settings and fill in the fields with the information in the Internet Account Information table of the Compact Guide or Read Me First.
Page 54: Multiplexing
Prestige 653HWI Series User’s Guide 3.2.4 RFC 1483 RFC 1483 describes two methods for Multiprotocol Encapsulation over ATM Adaptation Layer 5 (AAL5). The first method allows multiplexing of multiple protocols over a single ATM virtual circuit (LLC-based multiplexing) and the second method assumes that each protocol is carried over a separate ATM virtual circuit (VC-based multiplexing).
Page 55: Figure 3-1 Wizard Screen 1
Prestige 653HWI Series User’s Guide Figure 3-1 Wizard Screen 1 The following table describes the fields in this screen. Table 3-1 Wizard Screen 1 LABEL DESCRIPTION Mode From the Mode drop-down list box, select Routing (default) if your ISP allows multiple computers to share an Internet account.
Page 56: Ip Address And Subnet Mask
Prestige 653HWI Series User’s Guide Table 3-1 Wizard Screen 1 LABEL DESCRIPTION Next Click this button to go to the next wizard screen. The next wizard screen you see depends on what protocol you chose above. Click on the protocol link to see the next wizard screen for that protocol.
Page 57: Ip Assignment With Pppoa Or Pppoe Encapsulation
Prestige 653HWI Series User’s Guide 3.7.1 IP Assignment with PPPoA or PPPoE Encapsulation If you have a dynamic IP, then the IP Address and ENET ENCAP Gateway fields are not applicable (N/A). If you have a static IP, then you only need to fill in the IP Address field and not the ENET ENCAP Gateway field.
Page 58: Nailed-Up Connection (Ppp)
Prestige 653HWI Series User’s Guide Nailed-Up Connection (PPP) A nailed-up connection is a dial-up line where the connection is always up regardless of traffic demand. The Prestige does two things when you specify a nailed-up connection. The first is that idle timeout is disabled. The second is that the Prestige will try to bring up the connection when turned on and whenever the connection is down.
Page 59: Table 3-2 Internet Connection With Pppoe
Prestige 653HWI Series User’s Guide The following table describes the fields in this screen. Table 3-2 Internet Connection with PPPoE LABEL DESCRIPTION Service Name Type the name of your PPPoE service here. User Name Enter the user name exactly as your ISP assigned. If assigned a name in the form user@domain where domain identifies a service name, then enter both components exactly as given.
Page 60: Figure 3-3 Internet Connection With Rfc 1483
Prestige 653HWI Series User’s Guide Figure 3-3 Internet Connection with RFC 1483 The following table describes the fields in this screen. Table 3-3 Internet Connection with RFC 1483 LABEL DESCRIPTION IP Address This field is available if you select Routing in the Mode field. Type your ISP assigned IP address in this field.
Page 61: Figure 3-4 Internet Connection With Enet Encap
Prestige 653HWI Series User’s Guide Figure 3-4 Internet Connection with ENET ENCAP The following table describes the fields in this screen. Table 3-4 Internet Connection with ENET ENCAP LABEL DESCRIPTION IP Address A static IP address is a fixed IP that your ISP gives you. A dynamic IP address is not fixed;...
Page 62: Figure 3-5 Internet Connection With Pppoa
Prestige 653HWI Series User’s Guide Table 3-4 Internet Connection with ENET ENCAP LABEL DESCRIPTION Network Address Select None, SUA Only or Full Feature from the drop-sown list box. Refer to the NAT Translation chapter for more details. Back Click Back to go back to the first wizard screen. Next Click Next to continue to the next wizard screen.
Page 63: Dhcp Setup
Prestige 653HWI Series User’s Guide Table 3-5 Internet Connection with PPPoA LABEL DESCRIPTION User Name Enter the login name that your ISP gives you. Password Enter the password associated with the user name above. This option is available if you select Routing in the Mode field. IP Address A static IP address is a fixed IP that your ISP gives you.
Page 64: Wizard Setup Configuration: Third Screen
Prestige 653HWI Series User’s Guide 3.11.1 IP Pool Setup The Prestige is pre-configured with a pool of 32 IP addresses starting from 192.168.1.33 to 192.168.1.64 for the client machines. This leaves 31 IP addresses, 192.168.1.2 to 192.168.1.32 (excluding the Prestige itself which has a default IP of 192.168.1.1) for other server machines, for example, server for mail, FTP, telnet, web, etc., that you may have.
Page 65: Figure 3-7 Wizard: Lan Configuration
Prestige 653HWI Series User’s Guide Figure 3-7 Wizard: LAN Configuration The following table describes the fields in this screen. Table 3-6 Wizard: LAN Configuration LABEL DESCRIPTION LAN IP Address Enter the IP address of your Prestige in dotted decimal notation, for example, 192.168.1.1 (factory default).
Page 66: Wizard Setup Configuration: Connection Tests
Prestige 653HWI Series User’s Guide Table 3-6 Wizard: LAN Configuration LABEL DESCRIPTION Client IP Pool Starting This field specifies the first of the contiguous addresses in the IP address pool. Address Size of Client IP Pool This field specifies the size or count of the IP address pool. Primary DNS Server Enter the IP addresses of the DNS servers.
Page 67: Test Your Internet Connection
3.14 Test Your Internet Connection Launch your web browser and navigate to www.zyxel.com. Internet access is just the beginning. Refer to the rest of this User’s Guide for more detailed information on the complete range of Prestige features. If you cannot access the Internet, open the web configurator again to confirm that the Internet settings you configured in the Wizard Setup are correct.
Page 68: Password, Lan, Wireless Lan And Wan
Password, LAN, Wireless LAN and WAN Part II: Password, LAN, Wireless LAN and WAN This part covers the password, LAN (Local Area Network), wireless LAN and WAN setup.
Page 69: Chapter 4 Password Setup
Prestige 653HWI Series User’s Guide Chapter 4 Password Setup This chapter provides information on the Password screen. Password Overview It is highly recommended that you change the password for accessing the Prestige. Configuring Password To change your Prestige’s password (recommended), click Password. The screen appears as shown. Figure 4-1 Password The following table describes the fields in this screen.
Page 70 Prestige 653HWI Series User’s Guide Table 4-1 Password LABEL DESCRIPTION Retype to Confirm Type the new password again in this field. Click Apply to save your changes back to the Prestige. Apply Cancel Click Cancel to begin configuring this screen afresh. Password Setup...
Page 71: Chapter 5 Lan Setup
DNS (Domain Name System) is for mapping a domain name to its corresponding IP address and vice versa, for example, the IP address of www.zyxel.com is 204.217.0.2. The DNS server is extremely important because without it, you must know the IP address of a machine before you can access it. The DNS server...
Page 72: Dns Server Address Assignment
Prestige 653HWI Series User’s Guide addresses that you enter in the DHCP setup are passed to the client machines along with the assigned IP address and subnet mask. There are two ways that an ISP disseminates the DNS server addresses. The first is for an ISP to tell a customer the DNS server addresses, usually in the form of an information sheet, when s/he signs up.
Page 73: Rip Setup
Prestige 653HWI Series User’s Guide DHCP server enabled with 32 client IP addresses starting from 192.168.1.33. These parameters should work for the majority of installations. If your ISP gives you explicit DNS server address(es), read the embedded web configurator help regarding what fields need to be configured. 5.4.2 IP Address and Subnet Mask Refer to the IP Address and Subnet Mask section in the Wizard Setup chapter for this information.
Page 74: Configuring Lan
Prestige 653HWI Series User’s Guide WAN interfaces in the web configurator (LAN; WAN). Select None to disable IP multicasting on these interfaces. Configuring LAN Click LAN to open the following screen. Figure 5-2 LAN The following table describes the fields in this screen. LAN Setup...
Page 75: Table 5-1 Lan
Prestige 653HWI Series User’s Guide Table 5-1 LAN LABEL DESCRIPTION DHCP If set to Server, your Prestige can assign IP addresses, an IP default gateway and DNS servers to Windows 95, Windows NT and other systems that support the DHCP client.
Page 76 Prestige 653HWI Series User’s Guide Table 5-1 LAN LABEL DESCRIPTION Apply Click this button to save these settings back to the Prestige. Cancel Click this button to reset the fields in this screen. LAN Setup...
Page 77: Chapter 6 Wireless Lan Setup
Prestige 653HWI Series User’s Guide Chapter 6 Wireless LAN Setup This chapter discusses how to configure Wireless LAN on the Prestige. Wireless LAN Overview This section introduces the wireless LAN and some basic configurations. Wireless LANs can be as simple as two computers with wireless LAN cards communicating in a peer-to-peer network or as complex as a number of computers with wireless LAN cards communicating through access points which bridge network traffic to the wired LAN.
Page 78: Figure 6-1 Rts Threshold
Prestige 653HWI Series User’s Guide 6.1.4 RTS/CTS A hidden node occurs when two stations are within range of the same access point, but are not within range of each other. The following figure illustrates a hidden node. Both stations (STA) are within range of the access point (AP) or wireless gateway, but out-of-range of each other, so they cannot “hear”...
Page 79: Levels Of Security
Prestige 653HWI Series User’s Guide Enabling the RTS Threshold causes redundant network overhead that could negatively affect the throughput performance instead of providing a remedy. 6.1.5 Fragmentation Threshold A Fragmentation Threshold is the maximum data fragment size (between 256 and 2432 bytes) that can be sent in the wireless network before the Prestige will fragment the packet into smaller data frames.
Page 80: Data Encryption With Wep
Prestige 653HWI Series User’s Guide Data Encryption with WEP WEP encryption scrambles the data transmitted between the wireless stations and the access points to keep network communications private. It encrypts unicast and multicast communications in a network. Both the wireless stations and the access points must use the same WEP key for data encryption and decryption. Your Prestige allows you to configure up to four 64-bit or 128-bit WEP keys but only one key can be enabled at any one time.
Page 81: Table 6-1 Wireless
Prestige 653HWI Series User’s Guide Table 6-1 Wireless LABEL DESCRIPTION The ESSID (Extended Service Set Identification) is a unique name to identify the Prestige in the wireless LAN. Wireless stations associating to the Prestige must have the same ESSID. ESSID Enter a descriptive name (up to 32 characters).
Page 82: Configuring Mac Filter
Prestige 653HWI Series User’s Guide Table 6-1 Wireless LABEL DESCRIPTION Apply Click Apply to save your changes back to the Prestige. Cancel Click Cancel to begin configuring this screen afresh. Configuring MAC Filter The MAC filter screen allows you to configure the Prestige to give exclusive access to up to 32 devices (Allow Association) or exclude up to 32 devices from accessing the Prestige (Deny Association).
Page 83: Figure 6-4 Mac Address Filter
Prestige 653HWI Series User’s Guide Figure 6-4 MAC Address Filter The following table describes the fields in this menu. Wireless LAN Setup...
Page 84: Network Authentication
Prestige 653HWI Series User’s Guide Table 6-2 MAC Address Filter LABEL DESCRIPTION Active Select Yes from the drop down list box to enable MAC address filtering Action Define the filter action for the list of MAC addresses in the MAC address filter table. Select Deny Association to block access to the router, MAC addresses not listed will be allowed to access the router.
Page 85: Types Of Radius Messages
Prestige 653HWI Series User’s Guide • Accounting Keeps track of the client’s network activity. RADIUS is a simple package exchange in which your Prestige acts as a message relay between the wireless station and the network RADIUS server. Types of RADIUS Messages The following types of RADIUS messages are exchanged between the access point and the RADIUS server for user authentication: •...
Page 86: Configuring 802.1X
Prestige 653HWI Series User’s Guide an EAP-compatible RADIUS server, the access point helps a wireless station and a RADIUS server perform authentication. Figure 6-5 EAP Authentication The details below provide a general description of how IEEE 802.1x EAP authentication works. For an example list of EAP-MD5 authentication steps, see the IEEE 802.1x appendix.
Page 87: Table 6-3 802.1X
Prestige 653HWI Series User’s Guide Table 6-3 802.1x LABEL DESCRIPTION To control wireless stations access to the wired network, select a control method from the drop-down list box. Choose from No Authentication Required, Authentication Required and No Access Allowed. No Authentication Required allows all wireless stations access to the wired network Wireless Port without entering user names and passwords.
Page 88: Configuring Local User Authentication
Prestige 653HWI Series User’s Guide Table 6-3 802.1x LABEL DESCRIPTION This field is activated only when you select Authentication Required in the Wireless Port Control field. The authentication database contains wireless station login information. The local user database is the built-in database on the Prestige. The RADIUS is an external server. Use this drop-down list box to select which database the Prestige should use (first) to authenticate a wireless station.
Page 89: Figure 6-7 Local User Database
Prestige 653HWI Series User’s Guide Figure 6-7 Local User Database The following table describes the fields in this screen. Wireless LAN Setup 6-13...
Page 90: Configuring Radius
Prestige 653HWI Series User’s Guide Table 6-4 Local User Database LABEL DESCRIPTION This is the index number of a local user account. Active Select this check box to enable the user profile. User Name Enter the user name of the user profile. Password Enter a password up to 31 characters long for this user profile.
Page 91: Table 6-5 Radius
Prestige 653HWI Series User’s Guide The following table describes the fields in this screen. Table 6-5 RADIUS LABEL DESCRIPTION Authentication Server Active Select Yes from the drop-down list box to enable user authentication through an external authentication server. Server IP Address Enter the IP address of the external authentication server in dotted decimal notation.
Page 93: Chapter 7 Wan Setup
Use the ISDN interface for dial-in remote management access or a dial backup connection. NetCAPI Your ZyXEL router can take full advantage of popular European ISDN services. NetCAPI is ZyXEL's implementation of CAPI (Common ISDN Application Program Interface) capabilities over a network. It runs over DCP (Device Control Protocol) developed by RVS-COM.
Page 94: Metric
Prestige 653HWI Series User’s Guide Using ISDN-DCP, the Prestige acts as a DCP server. By default, the Prestige listens for DCP messages on TCP port number 2578 (the Internet-assigned number for RVS-COM DCP). When the Prestige receives a DCP message from a DCP client i.e., a workstation, the Prestige processes the message and acts on it. Your Prestige supports all the DCP messages specified in the ISDN-DCP specification.
Page 95: Traffic Shaping
Prestige 653HWI Series User’s Guide Operationally, PPPoE saves significant effort for both you and the ISP or carrier, as it requires no specific configuration of the broadband modem at the customer site. By implementing PPPoE directly on the Prestige (rather than individual computers), the computers on the LAN do not need PPPoE software installed, since the Prestige does that part of the task.
Page 96: Configuring Wan Functions
Prestige 653HWI Series User’s Guide Figure 7-1 Example of Traffic Shaping Configuring WAN Functions To change your Prestige’s WAN remote node settings, click WAN to access the WAN Functions screen. Figure 7-2 WAN Functions The following table describes the fields in this screen. WAN Setup...
Page 97: Table 7-1 Wan Functions
Prestige 653HWI Series User’s Guide Table 7-1 WAN Functions LABEL DESCRIPTION DSL setup The screen differs by the To edit your DSL settings, click WAN DSL Setup. encapsulation. ISDN Connection Setup You can use the ISDN interface as a backup in the event that the regular WAN connection is dropped.
Page 98: Configuring Wan Dsl Setup
Prestige 653HWI Series User’s Guide Configuring WAN DSL Setup To edit your DSL settings, click WAN DSL Setup. The screen differs by the encapsulation. Figure 7-3 WAN DSL Setup WAN Setup...
Page 99: Table 7-2 Wan Dsl Setup
Prestige 653HWI Series User’s Guide The following table describes the fields in this screen. Table 7-2 WAN DSL Setup LABEL DESCRIPTION Name Enter the name of your Internet Service Provider, e.g., MyISP. This information is for identification purposes only. Mode Select Routing (default) from the drop-down list box if your ISP allows multiple computers to share an Internet account.
Page 100 Prestige 653HWI Series User’s Guide Table 7-2 WAN DSL Setup LABEL DESCRIPTION Sustain Cell Rate The Sustain Cell Rate (SCR) sets the average cell rate (long-term) that can be transmitted. Type the SCR, which must be less than the PCR. Note that system default is 0 cells/sec.
Page 101 Prestige 653HWI Series User’s Guide Table 7-2 WAN DSL Setup LABEL DESCRIPTION Subnet Mask Enter a subnet mask in dotted decimal notation. (ENET ENCAP Refer to the Subnetting appendix in the to calculate a subnet mask If you are encapsulation only) implementing subnetting.
Page 102: Isdn Connection Setup
Prestige 653HWI Series User’s Guide ISDN Connection Setup To edit your Prestige’s advanced WAN backup settings, click WAN, ISDN Connection Setup. The screen appears as shown. Figure 7-4 ISDN Connection Setup 7-10 WAN Setup...
Page 103: Table 7-3 Isdn Connection Setup
Prestige 653HWI Series User’s Guide The following table describes the fields in this screen. ISDN Connection Setup Table 7-3 LABEL DESCRIPTION Basic ISDN Phone Number The number of your ISDN line. Outside Line Prefix A PABX (Private Automatic Branch eXchange) generally requires you to dial a number (a single digit in most cases) when you need an outside line.
Page 104 Prestige 653HWI Series User’s Guide ISDN Connection Setup Table 7-3 LABEL DESCRIPTION Nailed-Up Select Nailed-Up Connection when you want your connection up all the time. The Connection Prestige will try to bring up the connection automatically if it is disconnected. Connect on Demand Select Connect on Demand when you don't want the connection up all the time and specify an idle time-out in the Max Idle Timeout field.
Page 105: Isdn Dial In Setup
Prestige 653HWI Series User’s Guide 7.10 ISDN Dial In Setup To edit your Prestige’s Dial In Setup, click WAN ISDN Dial In Setup. The screen appears as shown. Figure 7-5 ISDN Dial In Setup The following table describes the fields in this screen. WAN Setup 7-13...
Page 106 Prestige 653HWI Series User’s Guide Table 7-4 ISDN Dial In Setup LABEL DESCRIPTION Incoming Rem Login Name Type the remote node login name that the remote node must use to access the Prestige. Rem Password Type the remote node password corresponding to the remote node login name. IP Address Rem IP Address Type the IP address of the remote node in dotted decimal notation.
Page 107: Configuring Netcapi
Prestige 653HWI Series User’s Guide 7.11 Configuring NetCAPI To edit your Prestige’s NetCAPI settings, click WAN, NetCAPI Setup. The screen appears as shown. Figure 7-6 Configuring NetCAPI The following table describes the fields in this screen. WAN Setup 7-15...
Page 108: Table 7-5 Configuring Netcapi
Prestige 653HWI Series User’s Guide Table 7-5 Configuring NetCAPI LABEL DESCRIPTION Active Select this check box to enable NetCAPI. When you want to use NetCAPI to place outgoing calls or to listen to incoming calls, Max Number of you must start RVSCOM on your computer, and RVSCOM registers itself to the Registered Prestige.
Page 109: Figure 7-7 Configuration Example
Prestige 653HWI Series User’s Guide Figure 7-7 Configuration Example Before entering any configurations, you must install the CAPI driver (RVS-CE) and communication program such as RVS-COM Lite on your computer. 7.11.2 RVS-COM RVS-COM includes an ISDN CAPI driver with its communication program. RVS-CE (Core Engine) is an ISDN-CAPI 2.0 driver for Windows 95/98/NT that can be used by different ISDN communication programs (such as AVM Fritz or RVS-COM) to access the ISDN on the Prestige.
Page 110: Wan Backup
Prestige 653HWI Series User’s Guide 7.12 WAN Backup Should the DSL connection fail, traffic redirect can transfer data to a backup gateway. You can also use the ISDN port for a dial-up connection should the DSL connection fail. To set up the ISDN port for backup usage, first make sure you have set up the port connection (see the Compact Guide).
Page 111: Figure 7-9 Traffic Redirect Wan Setup
Prestige 653HWI Series User’s Guide Figure 7-9 Traffic Redirect WAN Setup The following network topology allows you to avoid triangle route security issues when the backup gateway is connected to the LAN or DMZ. Use IP alias to configure the LAN into two or three logical networks with the Prestige itself as the gateway for each LAN network.
Page 112: Figure 7-10 Traffic Redirect Lan Setup
Prestige 653HWI Series User’s Guide Figure 7-10 Traffic Redirect LAN Setup 7-20 WAN Setup...
Page 113: Configuring Wan Backup
Prestige 653HWI Series User’s Guide 7.15 Configuring WAN Backup To change your Prestige’s WAN backup settings, click WAN, then WAN Backup. The screen appears as shown. Figure 7-11 WAN Backup Setup The following table describes the fields in this screen. WAN Setup 7-21...
Page 114: Metric
Prestige 653HWI Series User’s Guide Table 7-6 WAN Backup Setup LABEL DESCRIPTION Backup Type Select the method that the Prestige uses to check the DSL connection. Select DSL Link to have the Prestige check the DSL connection’s physical layer. Select ICMP to have the Prestige periodically ping the IP addresses configured in the Check WAN IP Address fields.
Page 115 Prestige 653HWI Series User’s Guide Table 7-6 WAN Backup Setup LABEL DESCRIPTION Backup Gateway Type the IP address of your backup gateway in dotted decimal notation. The Prestige automatically forwards traffic to this IP address if the Prestige's Internet connection terminates. ISDN Dial Backup Active Select this check box to turn on dial backup.
Page 116: Nat, Dynamic Dns And Time Zone
NAT, Dynamic DNS and Time Zone Part III: NAT, Dynamic DNS and Time Zone This part covers NAT (Network Address Translation), dynamic DNS (Domain Name Sever) and Time Zone setup.
Page 117: Nat Overview
Prestige 653HWI Series User’s Guide Chapter 8 Network Address Translation (NAT) Screens This chapter discusses how to configure NAT on the Prestige. NAT Overview NAT (Network Address Translation - NAT, RFC 1631) is the translation of the IP address of a host in a packet, for example, the source address of an outgoing packet, used within one network to a different IP address known within another network.
Page 118: What Nat Does
Prestige 653HWI Series User’s Guide NAT never changes the IP address (either local or global) of an outside host. 8.1.2 What NAT Does In the simplest form, NAT changes the source IP address in a packet received from a subscriber (the inside local address) to another (the inside global address) before forwarding the packet to the WAN side.
Page 119: Figure 8-1 How Nat Works
Prestige 653HWI Series User’s Guide Figure 8-1 How NAT Works 8.1.4 NAT Application The following figure illustrates a possible NAT application, where three inside LANs (logical LANs using IP Alias) behind the Prestige can communicate with three distinct WAN networks. More examples follow at the end of this chapter.
Page 120: Figure 8-2 Nat Application With Ip Alias
2. Many to One: In Many-to-One mode, the Prestige maps multiple local IP addresses to one global IP address. This is equivalent to SUA (for instance, PAT, port address translation), ZyXEL’s Single User Account feature that previous ZyXEL routers supported (the SUA Only option in today’s routers).
Page 121: Sua (Single User Account) Versus Nat
Prestige 653HWI Series User’s Guide 5. Server: This type allows you to specify inside servers of different services behind the NAT to be accessible to the outside world although, it is highly recommended that you use the DMZ port for these servers instead.
Page 122: Sua Server
Prestige 653HWI Series User’s Guide 1. Choose SUA Only if you have just one public WAN IP address for your Prestige. 2. Choose Full Feature if you have multiple public WAN IP addresses for your Prestige. SUA Server A SUA server set is a list of inside (behind NAT on the LAN) servers, for example, web or FTP, that you can make visible to the outside world even though SUA makes your whole inside network appear as a single computer to the outside world.
Page 123: Table 8-3 Services And Port Numbers
Prestige 653HWI Series User’s Guide Many residential broadband ISP accounts do not allow you to run any server processes (such as a Web or FTP server) from your location. Your ISP may periodically check for servers and may suspend your account if it discovers any active services at your location.
Page 124: Selecting The Nat Mode
Prestige 653HWI Series User’s Guide IP address assigned by ISP. Figure 8-3 Multiple Servers Behind NAT Example Selecting the NAT Mode You must create a firewall rule in addition to setting up SUA/NAT, to allow traffic from the WAN to be forwarded through the Prestige. Click NAT to open the following screen.
Page 125: Configuring Sua Server
Prestige 653HWI Series User’s Guide Table 8-4 NAT Mode LABEL DESCRIPTION None Select this radio button to disable NAT. Select this radio button if you have just one public WAN IP address for your Prestige. The SUA Only Prestige uses Address Mapping Set 1 in the NAT - Edit SUA NAT Server Set screen. Edit Details Click this link to go to the NAT - Edit SUA NAT Server Set screen.
Page 126: Figure 8-5 Edit Sua/Nat Server Set
Prestige 653HWI Series User’s Guide Figure 8-5 Edit SUA/NAT Server Set The following table describes the fields in this screen. Table 8-5 Edit SUA/NAT Server Set LABEL DESCRIPTION Start Port No. Enter a port number in this field. To forward only one port, enter the port number again in the End Port No. field. To forward a series of ports, enter the start port number here and the end port number in the End Port No.
Page 127: Configuring Address Mapping
Prestige 653HWI Series User’s Guide Table 8-5 Edit SUA/NAT Server Set LABEL DESCRIPTION Server IP Enter your server IP address in this field. Address Save Click Save to save your changes back to the Prestige. Cancel Click Cancel to return to the previous configuration. Configuring Address Mapping Ordering your rules is important because the Prestige applies the rules in the order that you specify.
Page 128: Editing An Address Mapping Rule
One-to-one NAT mapping type. M-1: Many-to-One mode maps multiple local IP addresses to one global IP address. This is equivalent to SUA (i.e., PAT, port address translation), ZyXEL's Single User Account feature that previous ZyXEL routers supported only.
Page 129: Figure 8-7 Address Mapping Rule Edit
Note that port numbers do not change for One-to-one NAT mapping type. 2. Many-to-One: Many-to-One mode maps multiple local IP addresses to one global IP address. This is equivalent to SUA (i.e., PAT, port address translation), ZyXEL's Single User Account feature that previous ZyXEL routers supported only.
Page 130 Prestige 653HWI Series User’s Guide Global Start IP This is the starting global IP address (IGA). Enter 0.0.0.0 here if you have a dynamic IP address from your ISP. Global End IP This is the ending global IP address (IGA). This field is N/A for One-to-One, Many- to-One and Server mapping types.
Page 131: Chapter 9 Dynamic Dns Setup
Prestige 653HWI Series User’s Guide Chapter 9 Dynamic DNS Setup This chapter discusses how to configure your Prestige to use Dynamic DNS. Dynamic DNS Dynamic DNS allows you to update your current dynamic IP address with one or many dynamic DNS services so that anyone can contact you (in NetMeeting, CU-SeeMe, etc.).
Page 132: Figure 9-1 Ddns
Prestige 653HWI Series User’s Guide Figure 9-1 DDNS The following table describes the fields in this screen. Table 9-1 DDNS LABEL DESCRIPTION Active Select this check box to use dynamic DNS. Service Provider Select the name of your Dynamic DNS service provider. Host Names Type the domain name assigned to your Prestige by your Dynamic DNS provider.
Page 133: Chapter 10 Time Zone
Prestige 653HWI Series User’s Guide Chapter 10 Time Zone Use this screen to configure the Prestige’s time and date settings. 10.1 Configuring Time Zone To change your Prestige’s time and date, click Time Zone. The screen appears as shown. Use this screen to configure the Prestige’s time based on your local time zone.
Page 134: Table 10-1 Time/Date
Prestige 653HWI Series User’s Guide The following table describes the fields in this screen. Table 10-1 Time/Date LABEL DESCRIPTION Time Server Use Time Server Select the time service protocol that your time server sends when you turn on the when Bootup Prestige.
Page 135 Prestige 653HWI Series User’s Guide Table 10-1 Time/Date LABEL DESCRIPTION Current Time This field displays the time of your Prestige. Each time you reload this page, the Prestige synchronizes the time with the time server. New Time This field displays the last updated time from the time server. When you select None in the Use Time Server when Bootup field, enter the new time in this field and then click Apply.
Page 136: Firewall And Content Filters
Firewall and Content Filters Part IV: Firewall and Content Filters This part introduces firewalls in general and the Prestige firewall. It also explains customized services and logs and gives example firewall rules and an overview of content filtering.
Page 137: Chapter 11 Firewalls
Prestige 653HWI Series User’s Guide Chapter 11 Firewalls This chapter gives some background information on firewalls and introduces the Prestige firewall. 11.1 Firewall Overview Originally, the term firewall referred to a construction technique designed to prevent the spread of fire from one room to another.
Page 138: Introduction To Zyxel's Firewall
See section 11.5 for more information on Stateful Inspection. Firewalls, of one type or another, have become an integral part of standard security solutions for enterprises. 11.3 Introduction to ZyXEL’s Firewall The Prestige firewall is a stateful inspection firewall and is designed to protect against Denial of Service attacks when activated (in SMT menu 21.2 or in the web configurator).
Page 139: Denial Of Service
Prestige 653HWI Series User’s Guide Figure 11-1 Prestige Firewall Application 11.4 Denial of Service Denials of Service (DoS) attacks are aimed at devices and networks with a connection to the Internet. Their goal is not to steal information, but to disable a device or network so users no longer have access to network resources.
Page 140: Table 11-1 Common Ip Ports
Prestige 653HWI Series User’s Guide Table 11-1 Common IP Ports Telnet HTTP SMTP POP3 11.4.2 Types of DoS Attacks There are four types of DoS attacks: 1. Those that exploit bugs in a TCP/IP implementation. 2. Those that exploit weaknesses in the TCP/IP specification. 3.
Page 141: Figure 11-2 Three-Way Handshake
Prestige 653HWI Series User’s Guide Figure 11-2 Three-Way Handshake Under normal circumstances, the application that initiates a session sends a SYN (synchronize) packet to the receiving server. The receiver sends back an ACK (acknowledgment) packet and its own SYN, and then the initiator responds with an ACK (acknowledgment).
Page 142: Figure 11-4 Smurf Attack
Prestige 653HWI Series User’s Guide 2-b In a LAND Attack, hackers flood SYN packets into the network with a spoofed source IP address of the targeted system. This makes it appear as if the host computer sent the packets to itself, making the system unavailable while the target system tries to respond to itself.
Page 143: Stateful Inspection
Prestige 653HWI Series User’s Guide Table 11-3 Legal NetBIOS Commands MESSAGE: REQUEST: POSITIVE: NEGATIVE: RETARGET: KEEPALIVE: All SMTP commands are illegal except for those displayed in the following tables. Table 11-4 Legal SMTP Commands AUTH DATA EHLO ETRN EXPN HELO HELP MAIL NOOP...
Page 144: Figure 11-5 Stateful Inspection
Prestige 653HWI Series User’s Guide Denies all sessions originating from the WAN to the LAN. User A initiates a telnet session. Return traffic for User A’s telnet session is permitted. Other Telnet traffic is blocked. Figure 11-5 Stateful Inspection The previous figure shows the Prestige’s default firewall rules in action as well as demonstrates how stateful inspection works.
Page 145: Stateful Inspection And The Prestige
Prestige 653HWI Series User’s Guide 4. Based on the obtained state information, a firewall rule creates a temporary access list entry that is inserted at the beginning of the WAN interface's inbound extended access list. This temporary access list entry is designed to permit inbound packets of the same connection as the outbound packet just inspected.
Page 146: Tcp Security
Prestige 653HWI Series User’s Guide Below is a brief technical description of how these connections are tracked. Connections may either be defined by the upper protocols (for instance, TCP), or by the Prestige itself (as with the "virtual connections" created for UDP and ICMP). 11.5.3 TCP Security The Prestige uses state information embedded in TCP packets.
Page 147: Guidelines For Enhancing Security With Your Firewall
Prestige 653HWI Series User’s Guide 11.5.5 Upper Layer Protocols Some higher layer protocols (such as FTP and RealAudio) utilize multiple network connections simultaneously. In general terms, they usually have a "control connection" which is used for sending commands between endpoints, and then "data connections" which are used for transmitting bulk information. Consider the FTP protocol.
Page 148: Packet Filtering Vs Firewall
Prestige 653HWI Series User’s Guide 1. Encourage your company or organization to develop a comprehensive security plan. Good network administration takes into account what hackers can do and prepares against attacks. The best defense against hackers is information. Educate all employees about the importance of security and how to minimize risk.
Page 149: When To Use Filtering
Prestige 653HWI Series User’s Guide Packet filtering only checks the header portion of an IP packet. When To Use Filtering 1. To block/allow LAN packets by their MAC addresses. 2. To block/allow special IP packets which are neither TCP nor UDP, nor ICMP packets. 3.
Page 150 Prestige 653HWI Series User’s Guide 6. The firewall can block specific URL traffic that might occur in the future. The URL can be saved in an Access Control List (ACL) database. 11-14 Firewalls...
Page 151: Chapter 12 Firewall Configuration
Prestige 653HWI Series User’s Guide Chapter 12 Firewall Configuration This chapter shows you how to enable and configure the Prestige firewall. 12.1 Remote Management and the Firewall When remote management is configured to allow management (see the Remote Management chapter) and the firewall is enabled: •...
Page 152: Attack Alert
Prestige 653HWI Series User’s Guide 12.3 Attack Alert Attack alerts are real-time reports of DoS attacks. In the Attack Alert screen, shown later, you may choose to generate an alert whenever an attack is detected. For DoS attacks, the Prestige uses thresholds to determine when to drop sessions that do not become fully established.
Page 153: Tcp Maximum Incomplete And Blocking Time
Prestige 653HWI Series User’s Guide The Prestige measures both the total number of existing half-open sessions and the rate of session establishment attempts. Both TCP and UDP half-open sessions are counted in the total number and rate measurements. Measurements are made once a minute. When the number of existing half-open sessions rises above a threshold (max-incomplete high), the Prestige starts deleting half-open sessions as required to accommodate new connection requests.
Page 154: Figure 12-2 Attack Alert
Prestige 653HWI Series User’s Guide Figure 12-2 Attack Alert The following table describes the fields in this screen. Table 12-1 Attack Alert LABEL DESCRIPTION Generate alert Select this check box to generate an alert whenever an attack is detected. when attack detected Denial of Services Thresholds One Minute Low...
Page 155 Prestige 653HWI Series User’s Guide Table 12-1 Attack Alert LABEL DESCRIPTION Maximum This is the number of existing half-open sessions (default "80") that causes the Incomplete Low firewall to stop deleting half-open sessions. The Prestige continues to delete half-open requests as necessary, until the number of existing half-open sessions drops below this number.
Page 157: Chapter 13 Creating Custom Rules
Prestige 653HWI Series User’s Guide Chapter 13 Creating Custom Rules This chapter contains instructions for defining both Local Network and Internet rules. 13.1 Rules Overview Firewall rules are subdivided into “Local Network” and “Internet”. By default, the Prestige’s stateful packet inspection allows all communications to the Internet that originate from the local network, and blocks all traffic to the LAN that originates from the Internet.
Page 158: Security Ramifications
Prestige 653HWI Series User’s Guide 3. What is the direction connection: from the LAN to the Internet, or from the Internet to the LAN? 4. What IP services will be affected? 5. What computers on the LAN are to be affected (if any)? 6.
Page 159: Connection Direction
Prestige 653HWI Series User’s Guide Source Address What is the connection’s source address; is it on the LAN or WAN? Is it a single IP, a range of IPs or a subnet? Destination Address What is the connection’s destination address; is it on the LAN or WAN? Is it a single IP, a range of IPs or a subnet? 13.3 Connection Direction This section talks about configuring firewall rules for connections going from LAN to WAN and WAN to...
Page 160: Figure 13-1 Lan To Wan Traffic
Prestige 653HWI Series User’s Guide Figure 13-1 LAN to WAN Traffic 13.3.2 WAN to LAN Rules The default rule for WAN to LAN traffic blocks all incoming connections (WAN to LAN). If you wish to allow certain WAN users to have access to your LAN, you will need to create custom rules to allow it. See the following figure.
Page 161: Logs
Prestige 653HWI Series User’s Guide Figure 13-2 WAN to LAN Traffic 13.4 Logs A log is a detailed record that you create for packets that either match a rule, don’t match a rule or both when you are creating/editing a firewall rule (see Figure 13-4). You can also choose not to create a log for a rule in this screen.
Page 162: Figure 13-3 Firewall Rules Summary: First Screen
Prestige 653HWI Series User’s Guide Figure 13-3 Firewall Rules Summary: First Screen The following table describes the fields in this screen. Table 13-1 Firewall Rules Summary: First Screen LABEL DESCRIPTION The default action for Use the drop-down list box to select whether to Block (silently discard) or packets not matching Forward (allow the passage of) packets that do not match the following rules.
Page 163: Predefined Services
Prestige 653HWI Series User’s Guide Table 13-1 Firewall Rules Summary: First Screen LABEL DESCRIPTION This is your firewall rule number. The ordering of your rules is important as rules are applied in turn. The Move field below allows you to reorder your rules. Click a rule’s number to edit the rule.
Page 164: Table 13-2 Predefined Services
24032) DNS(UDP/TCP:53) Domain Name Server, a service that matches web names (e.g. ) to IP numbers. www.zyxel.com FINGER(TCP:79) Finger is a UNIX or Internet related command that can be used to find out if a user is logged on. FTP(TCP:20.21) File Transfer Program, a program to enable fast transfer of files, including large files that may not be possible by e-mail.
Page 165 Prestige 653HWI Series User’s Guide Table 13-2 Predefined Services SERVICE DESCRIPTION NNTP(TCP:119) Network News Transport Protocol is the delivery mechanism for the USENET newsgroup service. PING(ICMP:0) Packet INternet Groper is a protocol that sends out ICMP echo requests to test whether or not a remote host is reachable. POP3(TCP:110) Post Office Protocol version 3 lets a client computer get e-mail from a POP3 server through a temporary connection (TCP/IP or other).
Page 166: Creating/Editing Firewall Rules
Prestige 653HWI Series User’s Guide Table 13-2 Predefined Services SERVICE DESCRIPTION TACACS(UDP:49) Login Host Protocol used for (Terminal Access Controller Access Control System). TELNET(TCP:23) Telnet is the login and terminal emulation protocol common on the Internet and in UNIX environments. It operates over TCP/IP networks. Its primary function is to allow users to log into remote host systems.
Page 167: Figure 13-4 Creating/Editing A Firewall Rule
Prestige 653HWI Series User’s Guide Figure 13-4 Creating/Editing A Firewall Rule The following table describes the fields in this screen. Table 13-3 Creating/Editing A Firewall Rule LABEL DESCRIPTION Source Address Click SrcAdd to add a new address, SrcEdit to edit an existing one or SrcDelete to delete one.
Page 168: Source And Destination Addresses
Prestige 653HWI Series User’s Guide Table 13-3 Creating/Editing A Firewall Rule LABEL DESCRIPTION Destination Click DestAdd to add a new address, DestEdit to edit an existing one or Address DestDelete to delete one. Services Select a service in the Available Services box on the left, then click >> to select. The selected service shows up on the Selected Services box on the right.
Page 169: Timeout
Prestige 653HWI Series User’s Guide Figure 13-5 Adding/Editing Source and Destination Addresses The following table describes the fields in this screen. Table 13-4 Adding/Editing Source and Destination Addresses LABEL DESCRIPTION Address Type Do you want your rule to apply to packets with a particular (single) IP address, a range of IP addresses (e.g., 192.168.1.10 to 192.169.1.50), a subnet or any IP address? Select an option from the drop-down list box that includes: Single Address, Range Address, Subnet Address and Any Address.
Page 170: Figure 13-6 Timeout
Prestige 653HWI Series User’s Guide 13.8.1 Factors Influencing Choices for Timeout Values The factors influencing choices for timeout values are the same as the factors influencing choices for threshold values – see section 12.3.2. Click Timeout for either Local Network or Internet. Figure 13-6 Timeout The following table describes the fields in this screen.
Page 171 Prestige 653HWI Series User’s Guide Table 13-5 Timeout LABEL DESCRIPTION Back Click Back to return to the previous screen. Apply Click Apply to save your customized settings and exit this screen. Cancel Click Cancel to return to the previous configuration. Creating Custom Rules 13-15...
Page 173: Chapter 14 Customized Services
Prestige 653HWI Series User’s Guide Chapter 14 Customized Services This chapter covers creating, viewing and editing custom services. 14.1 Introduction to Customized Services Configure customized services and port numbers not predefined by the Prestige (see Figure 13-4). For a comprehensive list of port numbers and services, visit the IANA (Internet Assigned Number Authority) website.
Page 174: Creating/Editing A Customized Service
Prestige 653HWI Series User’s Guide Table 14-1 Customized Services LABEL DESCRIPTION Customized Services This is the number of your customized port. Click a rule’s number of a service to go to the Firewall Customized Services Config screen to configure or edit a customized service.
Page 175: Example Custom Service Firewall Rule
Prestige 653HWI Series User’s Guide Table 14-2 Creating/Editing A Customized Service LABEL DESCRIPTION Service Name Type a unique name for your custom port. Service Type Choose the IP port (TCP, UDP or TCP/UDP) that defines your customized port from the drop down list box. Port Configuration Type Click Single to specify one port only or Range to specify a span of ports that define...
Page 176: Figure 14-3 Configure Source Ip Example
Prestige 653HWI Series User’s Guide Figure 14-3 Configure Source IP Example Step 5. Click Edit Available Service in the Edit rule screen and then click a rule number to bring up the Firewall Customized Services Config screen. Configure as follows. Figure 14-4 Customized Service for MyService Example Customized services show up with an “*”...
Page 177: Figure 14-5 Syslog Rule Configuration Example
Prestige 653HWI Series User’s Guide Step 6. Follow the procedures outlined earlier in this chapter to configure all your rules. Configure the rule configuration screen like the one below and apply it. This is the address range of the MyService computers. This is your MyService custom port.
Page 178: Figure 14-6 Rule Summary Example
Prestige 653HWI Series User’s Guide Step 7. On completing the configuration procedure for these Internet firewall rules, the Rule Summary screen should look like the following. Don’t forget to click Apply when you have finished configuring your rule(s) to save your settings back to the Prestige. This rule allows a MyService connection from the WAN.
Page 179: Chapter 15 Content Filtering Screens
Prestige 653HWI Series User’s Guide Chapter 15 Content Filtering Screens This chapter covers how to configure content filtering. 15.1 Content Filtering Overview Internet content filtering allows you to create and enforce Internet access policies tailored to your needs. Content filtering gives you the ability to block web sites that contain key words (that you specify) in the URL.
Page 180: Figure 15-1 Content Filter: Keyword
Prestige 653HWI Series User’s Guide Figure 15-1 Content Filter: Keyword The following table describes the fields in this screen. Table 15-1 Content Filter: Keyword LABEL DESCRIPTION Enable Keyword Blocking Select this check box to enable this feature. Block Websites that This box contains the list of all the keywords that you have configured the Prestige contain these keywords in to block.
Page 181: Configuring The Schedule
Prestige 653HWI Series User’s Guide Table 15-1 Content Filter: Keyword LABEL DESCRIPTION Add Keyword Click Add Keyword after you have typed a keyword. Repeat this procedure to add other keywords. Up to 64 keywords are allowed. When you try to access a web page containing a keyword, you will get a message telling you that the content filter is blocking this request.
Page 182: Configuring Trusted Computers
Prestige 653HWI Series User’s Guide Table 15-2 Content Filter: Schedule LABEL DESCRIPTION Days to Block: Select a check box to configure which days of the week (or everyday) you want the content filtering to be active. Time of Day to Use the 24-hour format to configure which time of the day (or select the All day check box) Block: you want the content filtering to be active.
Page 183 Prestige 653HWI Series User’s Guide Table 15-3 Content Filter: Trusted LABEL DESCRIPTION Type the ending IP address of a specific range of users on your LAN that you want to exclude from content filtering. Leave this field blank if you want to exclude an individual computer.
Page 184: Vpn/Ipsec
VPN/IPSec Part V: VPN/IPSec This part provides information about configuring VPN/IPSec for secure communications.
Page 185: Chapter 16 Introduction To Ipsec
Prestige 653HWI Series User’s Guide Chapter 16 Introduction to IPSec This chapter introduces the basics of IPSec VPNs. 16.1 VPN Overview A VPN (Virtual Private Network) provides secure communications between sites without the expense of leased site-to-site lines. A secure VPN is a combination of tunneling, encryption, authentication, access control and auditing technologies/services used to transport traffic over the Internet or any insecure network that uses the TCP/IP protocol suite for communication.
Page 186: Figure 16-1 Encryption And Decryption
Prestige 653HWI Series User’s Guide Figure 16-1 Encryption and Decryption Data Confidentiality The IPSec sender can encrypt packets before transmitting them across a network. Data Integrity The IPSec receiver can validate packets sent by the IPSec sender to ensure that the data has not been altered during transmission.
Page 187: Figure 16-2 Vpn Application
Prestige 653HWI Series User’s Guide Figure 16-2 VPN Application Introduction to IPSec 16-3...
Page 188: Ipsec Architecture
Prestige 653HWI Series User’s Guide 16.2 IPSec Architecture The overall IPSec architecture is shown as follows. Figure 16-3 IPSec Architecture 16.2.1 IPSec Algorithms The ESP (Encapsulating Security Payload) Protocol (RFC 2406) and AH (Authentication Header) protocol (RFC 2402) describe the packet formats and the default standards for packet structure (including implementation algorithms).
Page 189: Encapsulation
Prestige 653HWI Series User’s Guide 16.3 Encapsulation The two modes of operation for IPSec VPNs are Transport mode and Tunnel mode. Figure 16-4 Transport and Tunnel Mode IPSec Encapsulation 16.3.1 Transport Mode Transport mode is used to protect upper layer protocols and only affects the data in the IP packet. In Transport mode, the IP packet contains the security protocol (AH or ESP) located after the original IP header and options, but before any upper layer protocols contained in the packet (such as TCP and UDP).
Page 190: Table 16-1 Vpn And Nat
Prestige 653HWI Series User’s Guide A NAT device in between the IPSec endpoints will rewrite either the source or destination address with one of its own choosing. The VPN device at the receiving end will verify the integrity of the incoming packet by computing its own hash value, and complain that the hash value appended to the received packet doesn't match.
Page 191: Chapter 17 Vpn Screens
Prestige 653HWI Series User’s Guide Chapter 17 VPN Screens This chapter introduces the VPN screens. See the Logs chapter for information on viewing logs and the appendices for IPSec log descriptions. 17.1 VPN/IPSec Overview Use the screens documented in this chapter to configure rules for VPN connections and manage VPN connections.
Page 192: My Ip Address
Prestige 653HWI Series User’s Guide Table 17-1 AH and ESP Select DES for minimal security and 3DES for maximum. Select MD5 for minimal security and SHA-1 for Select NULL to set up a tunnel without encryption. maximum security. DES (default) MD5 (default) Data Encryption Standard (DES) is a widely used method MD5 (Message Digest 5) produces a 128-bit...
Page 193: Vpn Summary Screen
Prestige 653HWI Series User’s Guide for telecommuters initiating a VPN tunnel to the company network. See section 17.16 for configuration examples. The Secure Gateway IP Address may be configured as 0.0.0.0 only when using IKE key management and not Manual key management. 17.5 VPN Summary Screen The following figure helps explain the main fields in the web configurator.
Page 194: Figure 17-2 Vpn Summary
Prestige 653HWI Series User’s Guide Figure 17-2 VPN Summary The following table describes the fields in this screen. Table 17-2 VPN Summary LABEL DESCRIPTION This is the VPN policy index number. Click a number to edit VPN policies. Name This field displays the identification name for this VPN policy. This field displays whether the VPN policy is active or not.
Page 195: Keep Alive
Prestige 653HWI Series User’s Guide Table 17-2 VPN Summary LABEL DESCRIPTION Secure Gateway This is the IP address of the remote IPSec router. This must be a fixed, public IP address for traffic going through the Internet. Back Click Back to return to the previous screen. 17.6 Keep Alive When you initiate an IPSec tunnel with keep alive enabled, the Prestige automatically renegotiates the tunnel when the IPSec SA lifetime period expires (see section 17.10 for more on the IPSec SA lifetime).
Page 196: Table 17-3 Local Id Type And Content Fields
Prestige 653HWI Series User’s Guide Table 17-3 Local ID Type and Content Fields LOCAL ID TYPE= CONTENT= Type the IP address of your computer or leave the field blank to have the Prestige automatically use its own IP address. Type a domain name (up to 31 characters) by which to identify this Prestige. E-mail Type an e-mail address (up to 31 characters) by which to identify this Prestige.
Page 197: Pre-Shared Key
Prestige 653HWI Series User’s Guide The two Prestiges in this example cannot complete their negotiation because Prestige B’s Local ID type is IP, but Prestige A’s Peer ID type is set to E-mail. An “ID mismatched” message displays in the IPSEC LOG.
Page 198: Figure 17-3 Vpn Ike
Prestige 653HWI Series User’s Guide Figure 17-3 VPN IKE 17-8 VPN Screens...
Page 199: Table 17-7 Vpn Ike
Prestige 653HWI Series User’s Guide The following table describes the fields in this screen. Table 17-7 VPN IKE LABEL DESCRIPTION IPSec Setup Active Select this check box to activate this VPN policy. Select either Yes or No from the drop-down list box. Select Yes to have the Prestige automatically reinitiate the SA after the SA lifetime Keep Alive times out, even if there is no traffic.
Page 200 Prestige 653HWI Series User’s Guide Table 17-7 VPN IKE LABEL DESCRIPTION When the Local Address Type field is configured to Single, enter the IP address in the IP Address Start field again here. When the Local Address Type field is configured to Range, enter the end (static) IP address, in a range of computers on End / Subnet Mask the LAN behind your Prestige.
Page 201 Prestige 653HWI Series User’s Guide Table 17-7 VPN IKE LABEL DESCRIPTION When you select IP in the Local ID Type field, type the IP address of your computer or leave the field blank to have the Prestige automatically use its own IP address.
Page 202 Prestige 653HWI Series User’s Guide Table 17-7 VPN IKE LABEL DESCRIPTION Security Protocol Select ESP if you want to use ESP (Encapsulation Security Payload). The ESP protocol (RFC 2406) provides encryption as well as some of the services offered VPN Protocol by AH.
Page 203: Ike Phases
Prestige 653HWI Series User’s Guide 17.10 IKE Phases There are two phases to every IKE (Internet Key Exchange) negotiation – phase 1 (Authentication) and phase 2 (Key Exchange). A phase 1 exchange establishes an IKE SA and the second one uses that SA to negotiate SAs for IPSec.
Page 204: Configuring Advanced Ike Settings
Prestige 653HWI Series User’s Guide 17.10.1 Negotiation Mode The phase 1 Negotiation Mode you select determines how the Security Association (SA) will be established for each connection through IKE negotiations. Main Mode ensures the highest level of security when the communicating parties are negotiating authentication (phase 1).
Page 205: Figure 17-5 Vpn Ike: Advanced
Prestige 653HWI Series User’s Guide Figure 17-5 VPN IKE: Advanced The following table describes the fields in this screen. Table 17-8 VPN IKE: Advanced LABEL DESCRIPTION VPN - IKE Enter 1 for ICMP, 6 for TCP, 17 for UDP, etc. 0 is the default and signifies any Protocol protocol.
Page 206 Prestige 653HWI Series User’s Guide Table 17-8 VPN IKE: Advanced LABEL DESCRIPTION As a VPN setup is processing intensive, the system is vulnerable to Denial of Enable Replay Service (DoS) attacks The IPSec receiver can detect and reject old or duplicate packets to protect against replay attacks.
Page 207 Prestige 653HWI Series User’s Guide Table 17-8 VPN IKE: Advanced LABEL DESCRIPTION Select DES or 3DES from the drop-down list box. When DES is used for data communications, both sender and receiver must know the same secret key, which can be used to encrypt and decrypt the message or to Encryption Algorithm generate and verify a message authentication code.
Page 208: Manual Key Setup
Prestige 653HWI Series User’s Guide Table 17-8 VPN IKE: Advanced LABEL DESCRIPTION Select SHA1 or MD5 from the drop-down list box. MD5 (Message Digest 5) and Authentication SHA1 (Secure Hash Algorithm) are hash algorithms used to authenticate packet Algorithm data. The SHA1 algorithm is generally considered stronger than MD5, but is slower.
Page 209: Configuring Manual Key
Prestige 653HWI Series User’s Guide Current ZyXEL implementation assumes identical outgoing and incoming SPIs. 17.13 Configuring Manual Key You only configure VPN Manual Key when you select Manual in the Key Management field on the VPN IKE screen. This is the VPN Manual Key screen as shown next.
Page 210 Prestige 653HWI Series User’s Guide Table 17-9 VPN Manual Setup LABEL DESCRIPTION Active Select this check box to activate this VPN policy. Type up to 32 characters to identify this VPN policy. You may use any character, Name including spaces, but the Prestige drops trailing spaces. Select IKE or Manual from the drop-down list box.
Page 211 Prestige 653HWI Series User’s Guide Table 17-9 VPN Manual Setup LABEL DESCRIPTION Use the drop-down menu to choose Single, Range, or Subnet. Select Single with a Remote Address single IP address. Select Range for a specific range of IP addresses. Select Subnet to Type specify IP addresses on a network by their subnet mask.
Page 212: Viewing Sa Monitor
Prestige 653HWI Series User’s Guide Table 17-9 VPN Manual Setup LABEL DESCRIPTION Select DES, 3DES or NULL from the drop-down list box. When DES is used for data communications, both sender and receiver must know the same secret key, which can be used to encrypt and decrypt the message or to Encapsulation generate and verify a message authentication code.
Page 213: Figure 17-7 Sa Monitor
Prestige 653HWI Series User’s Guide When there is outbound traffic but no inbound traffic, the SA times out automatically after two minutes. A tunnel with no outbound or inbound traffic is "idle" and does not timeout until the SA lifetime period expires. See section 17.6 on keep alive to have the Prestige renegotiate an IPSec SA when the SA lifetime expires, even if there is no traffic.
Page 214: Configuring Global Setting
Prestige 653HWI Series User’s Guide Table 17-10 SA Monitor LABEL DESCRIPTION Refresh Click Refresh to display the current active VPN connection(s). 17.15 Configuring Global Setting To change your Prestige’s global settings, click VPN and then Global Setting. The screen appears as shown. Figure 17-8 Global Setting The following table describes the fields in this screen.
Page 215: Telecommuter Vpn/Ipsec Examples
Prestige 653HWI Series User’s Guide 17.16 Telecommuter VPN/IPSec Examples The following examples show how multiple telecommuters can make VPN connections to a single Prestige at headquarters from remote IPSec routers that use dynamic WAN IP addresses. 17.16.1 Telecommuters Sharing One VPN Rule Example Multiple telecommuters can use one VPN rule to simultaneously access a Prestige at headquarters.
Page 216: Figure 17-9 Telecommuters Sharing One Vpn Rule Example
Prestige 653HWI Series User’s Guide Figure 17-9 Telecommuters Sharing One VPN Rule Example 17.16.2 Telecommuters Using Unique VPN Rules Example With aggressive negotiation mode (see section 17.10.1), the Prestige can use the ID types and contents to distinguish between VPN rules. Telecommuters can each use a separate VPN rule to simultaneously access a Prestige at headquarters.
Page 217: Vpn And Remote Management
Prestige 653HWI Series User’s Guide Figure 17-10 Telecommuters Using Unique VPN Rules Example 17.17 VPN and Remote Management If a VPN tunnel uses a remote management service port (Telnet, FTP, WWW SNMP, DNS or ICMP) and terminates at the Prestige’s LAN or WAN port, configure remote management to allow access for that service.
Page 218 Prestige 653HWI Series User’s Guide If the VPN tunnel terminates at the Prestige’s WAN IP address, configure remote management for WAN server access (or LAN & WAN or LAN & WAN & DMZ). 17-28 VPN Screens...
Page 220: Remote Management, Upnp And Logs
Remote Management, UPnP and Logs Part VI: Remote Management, UPnP and Logs This part contains information on how to configure the Prestige for remote management, setting up Universal Plug and Play (UPnP) and setting up and displaying logs.
Page 221: Chapter 18 Remote Management Configuration
Prestige 653HWI Series User’s Guide Chapter 18 Remote Management Configuration This chapter provides information on configuring remote management. 18.1 Remote Management Overview Remote management allows you to determine which services/protocols can access which Prestige interface (if any) from which computers. When you configure remote management to allow management from the WAN, you still need to configure a firewall rule to allow access.
Page 222: Telnet
Prestige 653HWI Series User’s Guide 6. There is a web remote management session running with a Telnet session. A Telnet session will be disconnected if you begin a web session; it will not begin if there already is a web session. 18.1.2 Remote Management and NAT When NAT is enabled: Use the Prestige’s WAN IP address when configuring from the WAN.
Page 223: Ftp
Prestige 653HWI Series User’s Guide 18.3 FTP You can upload and download Prestige firmware and configuration files using FTP. To use this feature, your computer must have an FTP client. 18.4 Web You can use the Prestige’s embedded web configurator for configuration and file management. See the online help for details.
Page 224 Prestige 653HWI Series User’s Guide Table 18-1 Remote Management LABEL DESCRIPTION Secured The default 0.0.0.0 allows any client to use this service to remotely manage the Prestige. Type Client IP an IP address to restrict access to a client with a matching IP address. Apply Click Apply to save your settings back to the Prestige.
Page 225: Chapter 19 Universal Plug-And-Play (Upnp)
Prestige 653HWI Series User’s Guide Chapter 19 Universal Plug-and-Play (UPnP) This chapter introduces the UPnP feature in the web configurator. 19.1 Introducing Universal Plug and Play Universal Plug and Play (UPnP) is a distributed, open networking standard that uses TCP/IP for simple peer- to-peer network connectivity between devices.
Page 226: Upnp And Zyxel
UPnP if this is not your intention. 19.2 UPnP and ZyXEL ZyXEL has achieved UPnP certification from the Universal Plug and Play Forum Creates UPnP™ Implementers Corp. (UIC). ZyXEL's UPnP implementation supports IGD 1.0 (Internet Gateway Device). At the time of writing ZyXEL's UPnP implementation supports Windows Messenger 4.6 and 4.7 while Windows Messenger 5.0 and Xbox are still being tested.
Page 227: Installing Upnp In Windows Example
Prestige 653HWI Series User’s Guide Table 19-1 Configuring UPnP LABEL DESCRIPTION Allow users to make Select this check box to allow UPnP-enabled applications to automatically configuration changes configure the Prestige so that they can communicate through the Prestige, for through UPnP example by using NAT traversal, UPnP applications automatically reserve a NAT forwarding port in order to communicate with another UPnP enabled device;...
Page 228 Prestige 653HWI Series User’s Guide Step 3. In the Communications window, select the Universal Plug and Play check box in the Components selection box. Step 4. Click OK to go back to the Add/Remove Programs Properties window and click Next. Step 5.
Page 229: Using Upnp In Windows Xp Example
Prestige 653HWI Series User’s Guide Step 5. In the Networking Services window, select the Universal Plug and Play check box. Step 6. Click OK to go back to the Windows Optional Networking Component Wizard window and click Next. 19.4 Using UPnP in Windows XP Example This section shows you how to use the UPnP feature in Windows XP.
Page 230 Prestige 653HWI Series User’s Guide Step 3. In the Internet Connection Properties Step 4. You may edit or delete the port window, click Settings to see the port mappings or click Add to mappings there were automatically created. manually add port mappings. When the UPnP-enabled device is disconnected from your computer, all port mappings will be deleted automatically.
Page 231 Prestige 653HWI Series User’s Guide Step 6. Double-click on the icon to display your current Internet connection status. Web Configurator Easy Access With UPnP, you can access the web-based configurator on the Prestige without finding out the IP address of the Prestige first.
Page 232 Prestige 653HWI Series User’s Guide Step 4. An icon with the description for each UPnP-enabled device displays under Local Network. Step 5. Right-click on the icon for your Prestige and select Invoke. The web configurator login screen displays. Step 6. Right-click on the icon for your Prestige and select Properties.
Page 233: Chapter 20 Logs Screens
Prestige 653 HWI User’s Guide Chapter 20 Logs Screens This chapter contains information about configuring general log settings and viewing the Prestige’s logs. Refer to the appendices for example log message explanations. 20.1 Logs Overview The web configurator allows you to choose which categories of events and/or alerts to have the Prestige log and then display the logs or have the Prestige send them to an administrator (as e-mail) or to a syslog server.
Page 234: Figure 20-1 Log Settings
Prestige 653HWI Series User’s Guide Figure 20-1 Log Settings The following table describes the fields in this screen. 20-2 Logs Screens...
Page 235: Table 20-1 Log Settings
Prestige 653 HWI User’s Guide Table 20-1 Log Settings LABEL DESCRIPTION Address Info Mail Server Enter the server name or the IP address of the mail server for the e-mail addresses specified below. If this field is left blank, logs and alert messages will not be sent via e-mail.
Page 236: Displaying The Logs
Prestige 653HWI Series User’s Guide Table 20-1 Log Settings LABEL DESCRIPTION Select the categories of logs that you want to record. Logs include alerts. Send Immediate Alert Select the categories of alerts for which you want the Prestige to instantly e-mail alerts to the e-mail address specified in the Send Alerts To field.
Page 237: Smtp Error Messages
Prestige 653 HWI User’s Guide Table 20-2 View Logs LABEL DESCRIPTION Message This field states the reason for the log. Source This field lists the source IP address and the port number of the incoming packet. Destination This field lists the destination IP address and the port number of the incoming packet. Notes This field displays additional information about the log entry.
Page 238: Figure 20-3 E-Mail Log Example
Subject: You may edit the Firewall Alert From Prestige subject title Date: Fri, 07 Apr 2000 10:05:42 From: The date format here user@zyxel.com is Day-Month-Year. user@zyxel.com 1|Apr 7 00 |From:192.168.1.1 To:192.168.1.255 |default policy The date format here |forward is Month-Day-Year.
Page 240: Bandwidth Management
Bandwidth Management Part VII: Bandwidth Management This part provides information on the functions and configuration of Bandwidth Management.
Page 241: Chapter 21 Bandwidth Management
Prestige 653HWI Series User’s Guide Chapter 21 Bandwidth Management This chapter describes the functions and configuration of bandwidth management. 21.1 Bandwidth Management Overview Bandwidth management allows you to allocate an interface’s outgoing capacity to specific types of traffic. It can also help you make sure that the Prestige forwards certain types of traffic (especially real-time applications) with minimum delay.
Page 242: Proportional Bandwidth Allocation
Prestige 653HWI Series User’s Guide The total of the configured bandwidth budgets for child-classes cannot exceed the configured bandwidth budget speed of the parent class. 21.3 Proportional Bandwidth Allocation Bandwidth management allows you to define how much bandwidth each class gets; however, the actual bandwidth allotted to each class decreases or increases in proportion to actual available bandwidth.
Page 243: Figure 21-2 Subnet-Based Bandwidth Management Example
Prestige 653HWI Series User’s Guide Figure 21-2 Subnet-based Bandwidth Management Example 21.4.3 Application and Subnet-based Bandwidth Management Example The following example uses bandwidth classes based on LAN subnets and applications (specific applications in each subnet are allotted bandwidth). Table 21-1 Application and Subnet-based Bandwidth Management Example TRAFFIC TYPE FROM SUBNET A FROM SUBNET B...
Page 244: Scheduler
Prestige 653HWI Series User’s Guide Figure 21-3 Application and Subnet-based Bandwidth Management Example 21.5 Scheduler The scheduler divides up an interface’s bandwidth among the bandwidth classes. The Prestige has two types of scheduler: fairness-based and priority-based. 21.5.1 Priority-based Scheduler With the priority-based scheduler, the Prestige forwards traffic from bandwidth classes according to the priorities that you assign to the bandwidth classes.
Page 245: Maximize Bandwidth Usage Example
Prestige 653HWI Series User’s Guide When you enable maximize bandwidth usage, the Prestige first makes sure that each bandwidth class gets up to its bandwidth allotment. Next, the Prestige divides up an interface’s available bandwidth (bandwidth that is unbudgeted or unused by the classes) depending on how many bandwidth classes require more bandwidth and on their priority levels.
Page 246: Figure 21-4 Bandwidth Allotment Example
Prestige 653HWI Series User’s Guide Figure 21-4 Bandwidth Allotment Example The following figure shows the bandwidth usage with the maximize bandwidth usage option enabled. The Prestige divides up the unbudgeted 2 Mbps among the classes that require more bandwidth. If the administration department only uses 1 Mbps of the budgeted 2 Mbps, the Prestige also divides the remaining 1 Mbps among the classes that require more bandwidth.
Page 247: Bandwidth Borrowing
Prestige 653HWI Series User’s Guide 21.7 Bandwidth Borrowing Bandwidth borrowing allows a child-class to borrow unused bandwidth from its parent class, whereas maximize bandwidth usage allows bandwidth classes to borrow any unused or unbudgeted bandwidth on the whole interface. Enable bandwidth borrowing on a child-class to allow the child-class to use its parent class’s unused bandwidth.
Page 248: Figure 21-6 Bandwidth Borrowing Example
Prestige 653HWI Series User’s Guide Figure 21-6 Bandwidth Borrowing Example The Bill class can borrow unused bandwidth from the Sales USA class because the Bill class has bandwidth borrowing enabled. The Bill class can also borrow unused bandwidth from the Sales class because the Sales USA class also has bandwidth borrowing enabled.
Page 249: Configuring Summary
Prestige 653HWI Series User’s Guide The Bill class cannot borrow unused bandwidth from the Root class because the Sales class has bandwidth borrowing disabled. The Amy class cannot borrow unused bandwidth from the Sales USA class because the Amy class has bandwidth borrowing disabled.
Page 250: Figure 21-7 Bandwidth Manager: Summary
Prestige 653HWI Series User’s Guide Figure 21-7 Bandwidth Manager: Summary The following table describes the labels in this screen. Table 21-2 Bandwidth Manager: Summary LABEL DESCRIPTION These read-only labels represent the physical interfaces. WLAN Active Select an interface’s check box to enable bandwidth management on that interface. Speed (kbps) Enter the amount of bandwidth for this interface that you want to allocate using bandwidth management.
Page 251: Configuring Class Setup
Prestige 653HWI Series User’s Guide Table 21-2 Bandwidth Manager: Summary LABEL DESCRIPTION Scheduler Select either Priority-Based or Fairness-Based from the drop-down menu to control the traffic flow. Select Priority-Based to give preference to bandwidth classes with higher priorities. Select Fairness-Based to treat all bandwidth classes equally. See section 21.5. Maximize Select this check box to have the Prestige divide up all of the interface’s unallocated Bandwidth...
Page 252: Figure 21-8 Bandwidth Manager: Class Setup
Prestige 653HWI Series User’s Guide Figure 21-8 Bandwidth Manager: Class Setup The following table describes the labels in this screen. Table 21-3 Bandwidth Manager: Class Setup LABEL DESCRIPTION Interface Select an interface from the drop-down list box for which you wish to set up classes. Back Click Back to go to the main BW Manager screen.
Page 253 Prestige 653HWI Series User’s Guide Table 21-3 Bandwidth Manager: Class Setup LABEL DESCRIPTION Statistics Click Statistics to display the status of the selected class. 21.9.1 Bandwidth Manager Class Configuration Configure a bandwidth management class in the Class Configuration screen. You must use the Bandwidth Manager - Summary screen to enable bandwidth management on an interface before you can configure classes for that interface.
Page 254: Figure 21-9 Bandwidth Manager: Class Configuration
Prestige 653HWI Series User’s Guide Figure 21-9 Bandwidth Manager: Class Configuration The following table describes the labels in this screen. Table 21-4 Bandwidth Manager: Class Configuration LABEL DESCRIPTION Class Name Use the auto-generated name or enter a descriptive name of up to 20 alphanumeric characters, including spaces.
Page 255 Prestige 653HWI Series User’s Guide Table 21-4 Bandwidth Manager: Class Configuration LABEL DESCRIPTION BW Budget (kbps) Specify the maximum bandwidth allowed for the class in kbps. The recommendation is a setting between 20 kbps and 20000 kbps for an individual class.
Page 256: Table 21-5 Services And Port Numbers
Prestige 653HWI Series User’s Guide Table 21-4 Bandwidth Manager: Class Configuration LABEL DESCRIPTION Source IP Address Enter the source IP address. A blank source IP address means any source IP address. Source Subnet Mask Enter the source subnet mask. This field is N/A if you do not specify a Source IP Address.
Page 257: Figure 21-10 Bandwidth Management Statistics
Prestige 653HWI Series User’s Guide 21.9.2 Bandwidth Management Statistics Use the Bandwidth Management Statistics screen to view network performance information. Click the Statistics button in the Class Setup screen to open the Statistics screen. Figure 21-10 Bandwidth Management Statistics The following table describes the labels in this screen. Table 21-6 Bandwidth Management Statistics LABEL DESCRIPTION...
Page 258: Configuring Monitor
Prestige 653HWI Series User’s Guide Table 21-6 Bandwidth Management Statistics LABEL DESCRIPTION Set Interval Click Set Interval to apply the new update period you entered in the Update Period field above. Stop Update Click Stop Update to stop the browser from refreshing bandwidth management statistics.
Page 259 Prestige 653HWI Series User’s Guide Table 21-7 Bandwidth Manager Monitor LABEL DESCRIPTION Back Click Back to go to the main BW Manager screen. Refresh Click Refresh to update the page. Bandwidth Management 21-19...
Page 260: Maintenance
Maintenance Part VIII: Maintenance This part covers the maintenance screens. VIII...
Page 261: Chapter 22 Maintenance
Prestige 653HWI Series User’s Guide Chapter 22 Maintenance This chapter displays system information such as ZyNOS firmware, port IP addresses and port traffic statistics. 22.1 Maintenance Overview The maintenance screens can help you view system information, upload new firmware, manage configuration and restart your Prestige.
Page 262: Figure 22-1 System Status
Prestige 653HWI Series User’s Guide Figure 22-1 System Status 22-2 Maintenance...
Page 263: Table 22-1 System Status
System Status System Name This is the name of your Prestige. It is for identification purposes. ZyNOS Firmware This is the ZyNOS firmware version and the date created. ZyNOS is ZyXEL's Version proprietary Network Operating System design. DSL FW Version This is the DSL firmware version associated with your Prestige.
Page 264: Figure 22-2 System Status: Show Statistics
Prestige 653HWI Series User’s Guide Table 22-1 System Status LABEL DESCRIPTION Show Statistics Click Show Statistics to see router performance statistics such as number of packets sent and number of packets received for each port. 22.2.1 System Statistics Click Show Statistics in the System Status screen to open the following screen. Read-only information here includes port status and packet specific statistics.
Page 265: Table 22-2 System Status: Show Statistics
Prestige 653HWI Series User’s Guide The following table describes the fields in this screen. Table 22-2 System Status: Show Statistics LABEL DESCRIPTION System up Time This is the elapsed time the system has been up. CPU Load This field specifies the percentage of CPU utilization. DSL Port Statistics This is the DSL port.
Page 266: Dhcp Table Screen
Prestige 653HWI Series User’s Guide Table 22-2 System Status: Show Statistics LABEL DESCRIPTION Set Interval Click this button to apply the new poll interval you entered in the Poll Interval field above. Stop Click this button to halt the refreshing of the system statistics. 22.3 DHCP Table Screen DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows individual clients to obtain TCP/IP configuration at start-up from a server.
Page 267: Wireless Screens
Prestige 653HWI Series User’s Guide Table 22-3 DHCP Table LABEL DESCRIPTION This field displays the MAC (Media Access Control) address of the computer with the displayed Address host name. Every Ethernet device has a unique MAC address. The MAC address is assigned at the factory and consists of six pairs of hexadecimal characters, for example, 00:A0:C5:00:00:02.
Page 268: Figure 22-5 Channel Usage Table
Prestige 653HWI Series User’s Guide Table 22-4 Association List LABEL DESCRIPTION Association This field displays how long a wireless client has been associated to the Prestige. Time Back Click Back to return to the previous screen. Refresh Click Refresh to renew the information in the table. 22.4.2 Channel Usage Table This screen displays the state of the channels within the Prestige’s transmission range.
Page 269: Diagnostic Screens
Prestige 653HWI Series User’s Guide Table 22-5 Channel Usage Table LABEL DESCRIPTION Channel This is the index number of the channel. Activity This field displays Yes if another AP or Ad-hoc network is using the channel within the Prestige’s transmission range. Back Click Back to return to the previous screen.
Page 270: Figure 22-6 Diagnostic General
Prestige 653HWI Series User’s Guide Figure 22-6 Diagnostic General The following table describes the fields in this screen. Table 22-6 Diagnostic General LABEL DESCRIPTION TCP/IP Type the IP address of a computer that you want to ping in order to test a connection. Address Ping Click this button to ping the IP address that you entered.
Page 271: Figure 22-7 Diagnostic Dsl Line
Prestige 653HWI Series User’s Guide 22.5.2 Diagnostic DSL Line Screen Click Diagnostic and then DSL Line to open the screen shown next. Figure 22-7 Diagnostic DSL Line The following table describes the fields in this screen. Table 22-7 Diagnostic DSL Line LABEL DESCRIPTION Reset ADSL...
Page 272 Prestige 653HWI Series User’s Guide Table 22-7 Diagnostic DSL Line LABEL DESCRIPTION ATM Loopback Click this button to start the ATM loopback test. Make sure you have configured at least Test one PVC with proper VPIs/VCIs before you begin this test. The Prestige sends an OAM F5 packet to the DSLAM/ATM switch and then returns it (loops it back) to the Prestige.
Page 273: Figure 22-8 Diagnostic Isdn Line
Prestige 653HWI Series User’s Guide Figure 22-8 Diagnostic ISDN Line The following table describes the fields in this screen. Table 22-8 Diagnostic ISDN Line LABEL DESCRIPTION Reset IDSN This command re-initializes the ISDN link to the telephone company. Line Maintenance 22-13...
Page 274: Firmware Screen
Click this button to go back to the main Diagnostic screen. 22.6 Firmware Screen Find firmware at www.zyxel.com in a file that (usually) uses the system model name with a "*.bin" extension, e.g., "Prestige.bin". The upload process uses FTP (File Transfer Protocol) and may take up to two minutes.
Page 275: Figure 22-9 Firmware Upgrade
Prestige 653HWI Series User’s Guide Figure 22-9 Firmware Upgrade The following table describes the fields in this screen. Table 22-9 Firmware Upgrade LABEL DESCRIPTION File Path Type in the location of the file you want to upload in this field or click Browse ... to find it. Browse...
Page 276: Figure 22-10 Network Temporarily Disconnected
Prestige 653HWI Series User’s Guide Figure 22-10 Network Temporarily Disconnected After two minutes, log in again and check your new firmware version in the System Status screen. If the upload was not successful, the following screen will appear. Click Back to go back to the Firmware screen.
Page 277: Smt General Configuration
SMT General Configuration Part IX: SMT General Configuration This part covers System Management Terminal configuration for general setup, WAN backup, LAN setup, wireless LAN setup, Internet access, remote node, static route, NAT and enabling the firewall. See the web configurator parts of this guide for background information on features configurable by web configurator and SMT.
Page 279: Chapter 23 Introducing The Smt
Prestige 653HWI Series User’s Guide Chapter 23 Introducing the SMT This chapter explains how to access and navigate the System Management Terminal and gives an overview of its menus. 23.1 SMT Introduction The Prestige’s SMT (System Management Terminal) is a menu-driven interface that you can access from a terminal emulator through the console port or over a telnet connection.
Page 280: Figure 23-1 Login Screen
Prestige 653HWI Series User’s Guide Please note that if there is no activity for longer than five minutes after you log in, your Prestige will automatically log you out. Enter Password : **** Figure 23-1 Login Screen 23.1.4 Prestige SMT Menu Overview The following figure gives you an overview of the various SMT menu screens of your Prestige.
Page 281: Navigating The Smt Interface
Prestige 653HWI Series User’s Guide Figure 23-2 Prestige 653 SMT Menu Overview 23.2 Navigating the SMT Interface The SMT (System Management Terminal) is the interface that you use to configure your Prestige. Several operations that you should be familiar with before you attempt to modify the configuration are listed in the table below.
Page 282: Table 23-1 Main Menu Commands
Prestige 653HWI Series User’s Guide Table 23-1 Main Menu Commands OPERATION KEYSTROKE DESCRIPTION Move down to [ENTER] To move forward to a submenu, type in the number of the desired another menu submenu and press [ENTER]. Move up to a [ESC] Press [ESC] to move back to the previous menu.
Page 283: Figure 23-3 Smt Main Menu
Prestige 653HWI Series User’s Guide After you enter the password, the SMT displays the main menu, as shown next. Copyright (c) 1994 - 2003 ZyXEL Communications Corp. Prestige 653HWI Main Menu Getting Started Advanced Management 1. General Setup 21. Filter and Firewall Setup 2, WAN Backup Setup 22.
Page 284: Changing The System Password
Prestige 653HWI Series User’s Guide Table 23-2 Main Menu Summary MENU TITLE DESCRIPTION System Maintenance This menu provides system status, diagnostics, software upload, etc. IP Routing Policy Setup Use this menu to configure your IP routing policy. Schedule Setup Use this menu to schedule outgoing calls. VPN/ IPSec Setup Use this menu to configure VPN connections.
Page 285: Chapter 24 Menu 1 General Setup
Prestige 653HWI Series User’s Guide Chapter 24 Menu 1 General Setup Menu 1 - General Setup contains administrative and system-related information. 24.1 General Setup Menu 1 — General Setup contains administrative and system-related information (shown next). The System Name field is for identification purposes. However, because some ISPs check this name you should enter your computer's "Computer Name".
Page 286: Figure 24-1 Menu 1 General Setup
Domain Name Enter the domain name (if you know it) here. If you leave this field zyxel.com.tw blank, the ISP may assign a domain name via DHCP. You can go to menu 24.8 and type "sys domainname" to see the current domain name used by your gateway.
Page 287: Figure 24-2 Menu 1.1 Configure Dynamic Dns
Prestige 653HWI Series User’s Guide 24.2.1 Procedure to Configure Dynamic DNS If you have a private WAN IP address, then you cannot use Dynamic DNS. Step 1. To configure Dynamic DNS, go to Menu 1 — General Setup and select Yes in the Edit Dynamic DNS field.
Page 289: Chapter 25 Menu 2 Wan Backup Setup
Prestige 653HWI Series User’s Guide Chapter 25 Menu 2 WAN Backup Setup This chapter describes how to configure traffic redirect and ISDN dial-backup using menu 2, 2.1, 2.2, 2.2.1 and 2.2.2. 25.1 Introduction to WAN Backup Setup This chapter explains how to configure the Prestige for traffic redirect and dial backup connections. 25.2 ISDN Dial Backup To set up the ISDN port for use in the event that the regular WAN connection is dropped, first make sure you have set up the port connection and then configure:...
Page 290: Figure 25-1 Menu 2 Wan Backup Setup
Prestige 653HWI Series User’s Guide Menu 2 - Wan Backup Setup Check Mechanism = DSL Link Check WAN IP Address1 = 0.0.0.0 Check WAN IP Address2 = 0.0.0.0 Check WAN IP Address3 = 0.0.0.0 KeepAlive Fail Tolerance = 0 Recovery Interval(sec) = 0 ICMP Timeout(sec) = 0 Traffic Redirect = No Dial Backup = No...
Page 291: Figure 25-2 Menu 2.1Traffic Redirect Setup
Prestige 653HWI Series User’s Guide Table 25-1 Menu 2 WAN Backup Setup FIELD DESCRIPTION Recovery When the Prestige is using a lower priority connection (usually a WAN backup Interval(sec) connection), it periodically checks to whether or not it can use a higher priority connection.
Page 292: Configuring Isdn Dial Backup Setup
Prestige 653HWI Series User’s Guide Table 25-2 Menu 2.1Traffic Redirect Setup FIELD DESCRIPTION Active Press [SPACE BAR] and select Yes (to enable) or No (to disable) traffic redirect setup. The default is No. Configuration: Backup Enter the IP address of your backup gateway in dotted decimal notation. Gateway IP The Prestige automatically forwards traffic to this IP address if the Prestige’s Address...
Page 293: Isdn Advanced Setup Menus
Prestige 653HWI Series User’s Guide The following table describes the fields in this menu. Table 25-3 Menu 2 ISDN Dial Backup Setup FIELD DESCRIPTION Active Press [SPACE BAR] and select Yes (to enable) or No (to disable) dial-backup. The default is No. Switch Type This read only field displays your switch type, DSS-1.
Page 294 Prestige 653HWI Series User’s Guide Calling Line Indication The Calling Line Indication, or caller ID, determines whether the other party can see your number when you call. If set to Enable, the router sends the caller ID and the party you call can see your number; if it is set to Disable, the caller ID is blocked.
Page 295: Figure 25-4 Router Behind A Pabx
Prestige 653HWI Series User’s Guide Figure 25-4 Router Behind a PABX Data Link Connection There are two types of ISDN Data Link Connection namely: point-to-multipoint and point-to-point. When you select point-to-multipoint, the TE1 value will be assigned by negotiation with the switch. When you select point-to-point, the TE1 value will be assigned a unique value of 0.
Page 296: Netcapi Setup Menu
Prestige 653HWI Series User’s Guide Menu 2.2.1 - ISDN Advanced Setup Calling Line Indication= Enable PABX Outside Line Prefix= PABX Number (Include S/T Bus Number) for Loopback= Outgoing Calling Party Number: ISDN Data = 80010029 Data Link Connection= point-to-multipoint Press ENTER to Confirm or ESC to Cancel: Figure 25-5 Menu 2 ISDN Setup for DSS1 When you are finished, press [ENTER] at the message: ‘Press ENTER to confirm’, the router uses the information that you entered to initialize the ISDN line.
Page 297: Figure 25-7 Menu 2.2.2 Netcapi Setup
Prestige 653HWI Series User’s Guide Menu 2.2.2 - NetCAPI Setup Active= No Max Number of Registered Users= 1 Incoming Data Call Number Matching= Multiple Subscriber Number (MSN) Access List: Start IP End IP Operation 0.0.0.0 0.0.0.0 None 0.0.0.0 0.0.0.0 None 0.0.0.0 0.0.0.0 None...
Page 298: Isdn Remote Node Profile
Prestige 653HWI Series User’s Guide Table 25-4 Menu 2.2.2 NetCAPI Setup FIELD DESCRIPTION Start IP Refers to the first IP address of a group of NetCAPI clients. Each group contains contiguous IP addresses. End IP Refers to the last IP address in a NetCAPI client group. Operation Select Incoming if you wish to grant incoming calls permission.
Page 299 Prestige 653HWI Series User’s Guide FIELD DESCRIPTION EXAMPLE Rem Node Enter a descriptive name for the remote node. This field can be up to eight BackupISP Name characters. Active Press [SPACE BAR] and then [ENTER] to select Yes to activate or No to deactivate this node.
Page 300: Editing Ppp Options
Prestige 653HWI Series User’s Guide Table 25-5 Menu 11.1 ISDN Remote Node Profile FIELD DESCRIPTION EXAMPLE Rem IP Leave the field set to 0.0.0.0 (default) if the remote gateway has a dynamic 0.0.0.0 Addr IP address. Enter the remote gateway’s IP address here if it is static. (default) Edit IP This field leads to a “hidden”...
Page 301: Figure 25-9 Menu 11.2 Remote Node Ppp Options
Prestige 653HWI Series User’s Guide The Prestige’s dial back-up feature uses PPP. To edit the remote node PPP Options, move the cursor to the Edit PPP Options field in Menu 11.1 - Remote Node Profile (Backup ISP), and use the space bar to select [Yes].
Page 302: Editing Tcp/Ip Options
Prestige 653HWI Series User’s Guide Table 25-6 Menu 11.2 Remote Node PPP Options Base Trans Select the base data transfer rate for this remote node in kilobits Rate(Kbps) per second. There are two choices for this field: 64 where only one channel is used or, 128 where two channels are used as soon as a packet triggers a call.
Page 303: Table 25-7 Menu 11.2 Remote Node Ppp Options
Prestige 653HWI Series User’s Guide Table 25-7 Menu 11.2 Remote Node PPP Options FIELD DESCRIPTION EXAMPLE IP Address Press [SPACE BAR] and then [ENTER] to select Dynamic if the remote Dynamic node is using a dynamically assigned IP address or Static if it is using a Assignment static (fixed) IP address.
Page 304: Editing Login Script
Prestige 653HWI Series User’s Guide Table 25-7 Menu 11.2 Remote Node PPP Options None Press [SPACE BAR] and then [ENTER] to select the RIP Direction. Direction Options are Both, In Only, Out Only or None. RIP-1 Version Press [SPACE BAR] and then [ENTER] to select the RIP version. Options are RIP-1, RIP-2B or RIP-2M.
Page 305: Figure 25-11 Menu 11.4 Remote Node Setup Script
Prestige 653HWI Series User’s Guide ‘Expect’ and the ‘Send’ fields of the current set are empty, the Prestige will terminate the script processing and start PPP negotiation. This implies two things: first, the sets must be contiguous; the sets after an empty one are ignored.
Page 306: Remote Node Filter
Prestige 653HWI Series User’s Guide Table 25-8 Menu 11.4 Remote Node Setup Script Set 1-6: Enter an Expect string to match. After matching the Expect string, the Expect Prestige returns the string in the Send field. Set 1-6: Enter a string to send out after the Expect string is matched. 0.0.0.0 Send 25.11 Remote Node Filter...
Page 307: Figure 25-13 Menu 11.5 Dial Backup Remote Node Filter
Prestige 653HWI Series User’s Guide Menu 11.5 - Remote Node Filter Input Filter Sets: protocol filters= device filters= Output Filter Sets: protocol filters= device filters= Call Filter Sets: protocol filters= device filters= Enter here to CONFIRM or ESC to CANCEL: Figure 25-13 Menu 11.5 Dial Backup Remote Node Filter Menu 2 WAN Backup Setup 25-19...
Page 309: Chapter 26 Menu 3 Lan Setup
Prestige 653HWI Series User’s Guide Chapter 26 Menu 3 LAN Setup This chapter covers how to configure your wired Local Area Network (LAN) settings. 26.1 LAN Setup This section describes how to configure the Ethernet using Menu 3 — LAN Setup. From the main menu, enter 3 to display menu 3.
Page 310: Protocol Dependent Ethernet Setup
Prestige 653HWI Series User’s Guide 26.2 Protocol Dependent Ethernet Setup Depending on the protocols for your applications, you need to configure the respective Ethernet Setup, as outlined below. For TCP/IP Ethernet setup refer to the Internet Access Application chapter. For bridging Ethernet setup refer to the Bridging Setup chapter. 26.3 TCP/IP Ethernet Setup and DHCP Use menu 3.2 to configure your Prestige for TCP/IP.
Page 311: Table 26-1 Dhcp Ethernet Setup Menu Fields
Prestige 653HWI Series User’s Guide Table 26-1 DHCP Ethernet Setup Menu Fields FIELD DESCRIPTION EXAMPLE DHCP Setup DHCP If set to Server, your Prestige can assign IP addresses, an IP default gateway and DNS servers to Windows 95, Windows NT and Server other systems that support the DHCP client.
Page 312 Prestige 653HWI Series User’s Guide Table 26-2 TCP/IP Ethernet Setup Menu Fields FIELD DESCRIPTION EXAMPLE Multicast IGMP (Internet Group Multicast Protocol) is a network-layer protocol None used to establish membership in a Multicast group. The Prestige (default) supports both IGMP version 1 (IGMP-v1) and version 2 (IGMP-v2). SPACE BAR] Press the [ to enable IP Multicasting or select None...
Page 313: Chapter 27 Wireless Lan Setup
Prestige 653HWI Series User’s Guide Chapter 27 Wireless LAN Setup This chapter covers how to configure wireless LAN settings in SMT menu 3.5 27.1 Wireless LAN Overview Refer to the chapter on the wireless LAN screens for wireless LAN background information. For PCMCIA Wireless LAN Card installation, refer to the Compact Guide.
Page 314: Table 27-1 Menu 3.5 - Wireless Lan Setup
Prestige 653HWI Series User’s Guide Table 27-1 Menu 3.5 - Wireless LAN Setup FIELD DESCRIPTION EXAMPLE The ESSID (Extended Service Set IDentifier) identifies the service set the Wireless wireless station is to connect to. Wireless stations associating to the Access ESSID Point must have the same ESSID.
Page 315: Figure 27-2 Menu 3.5.1 Wlan Mac Address Filtering
Prestige 653HWI Series User’s Guide Table 27-1 Menu 3.5 - Wireless LAN Setup FIELD DESCRIPTION EXAMPLE When you have completed this menu, press [ENTER] at the prompt “Press ENTER to confirm or ESC to cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen. 27.2.1 Wireless LAN MAC Address Filter The next layer of security is MAC address filter.
Page 316 Prestige 653HWI Series User’s Guide Table 27-2 Menu 3.5.1 WLAN MAC Address Filtering FIELD DESCRIPTION Define the filter action for the list of MAC addresses in the MAC address filter table. To deny access to the Prestige, press [SPACE BAR] to select Deny Association and press [ENTER].
Page 317: Chapter 28 Internet Access
Prestige 653HWI Series User’s Guide Chapter 28 Internet Access This chapter shows you how to configure the LAN and WAN of your Prestige for Internet access 28.1 Internet Access Overview Refer to the chapters on the web configurator’s wizard, LAN and WAN screens for more background information on fields in the SMT screens covered in this chapter.
Page 318: Ip Alias Setup
Prestige 653HWI Series User’s Guide Figure 28-1 Physical Network Figure 28-2 Partitioned Logical Networks Use menu 3.2.1 to configure IP Alias on your Prestige. 28.4 IP Alias Setup Use menu 3.2 to configure the first network. Move the cursor to Edit IP Alias field and press [SPACEBAR] to choose Yes and press [ENTER] to configure the second and third network.
Page 319: Figure 28-3 Menu 3.2 Tcp/Ip And Dhcp Setup
Prestige 653HWI Series User’s Guide Menu 3.2 - TCP/IP and DHCP Setup DHCP Setup: DHCP= Server Client IP Pool Starting Addres= 192.168.1.33 Size of Client IP Pool= 32 Primary DNS Server= 0.0.0.0 Secondary DNS Server= 0.0.0.0 Remote DHCP Server= N/A TCP/IP Setup: IP Address= 192.168.1.1 IP Subnet Mask= 255.255.255.0...
Page 320: Route Ip Setup
Prestige 653HWI Series User’s Guide Table 28-1 Menu 3.2.1 IP Alias Setup FIELD DESCRIPTION EXAMPLE IP Alias Choose Yes to configure the LAN network for the Prestige. IP Address Enter the IP address of your Prestige in dotted decimal notation 192.168.2.1 IP Subnet Mask Your Prestige will automatically calculate the subnet mask based on 255.255.255.0...
Page 321: Internet Access Configuration
Prestige 653HWI Series User’s Guide 28.6 Internet Access Configuration Menu 4 allows you to enter the Internet Access information in one screen. Menu 4 is actually a simplified setup for one of the remote nodes that you can access in menu 11. Before you configure your Prestige for Internet access, you need to collect your Internet account information.
Page 322 Prestige 653HWI Series User’s Guide Table 28-2 Menu 4 Internet Access Setup FIELD DESCRIPTION EXAMPLE Multiplexing SPACE BAR LLC-based Press [ ] to select the method of multiplexing used by your ISP. Choices are VC-based or LLC-based. VPI # Enter the Virtual Path Identifier (VPI) assigned to you. VCI # Enter the Virtual Channel Identifier (VCI) assigned to you.
Page 323: Chapter 29 Remote Node Configuration
Prestige 653HWI Series User’s Guide Chapter 29 Remote Node Configuration This chapter covers remote node configuration. 29.1 Remote Node Setup Overview This section describes the protocol-independent parameters for a remote node. A remote node is required for placing calls to a remote gateway. A remote node represents both the remote gateway and the network behind it across a WAN connection.
Page 324: Figure 29-1 Menu 11 Remote Node Setup
Prestige 653HWI Series User’s Guide Menu 11 - Remote Node Setup 1. My ISP (ISP, SUA) 2. ________ 3. ________ 4. ________ 5. ________ 6. ________ 7. ________ 8. ________ 9. (ISDN_DIALBACKUP) 10. (ISDN_DIALIN) Figure 29-1 Menu 11 Remote Node Setup 29.2.2 Encapsulation and Multiplexing Scenarios For Internet access you should use the encapsulation and multiplexing methods used by your ISP.
Page 325: Figure 29-2 Menu 11.1 Remote Node Profile
Prestige 653HWI Series User’s Guide Menu 11.1 - Remote Node Profile Edit IP/Bridge Options Rem Node Name= ChangeMe Route= IP in menu 11.3. Active= Yes Bridge= No Encapsulation= ENET ENCAP Edit IP/Bridge= No Multiplexing= LLC-based Edit ATM Options= No Edit ATM Options in Service Name= N/A Incoming: Telco Option:...
Page 326 Prestige 653HWI Series User’s Guide Table 29-1 Menu 11.1 Remote Node Profile FIELD DESCRIPTION EXAMPLE Rem Login Type the login name that this remote node will use to call your Prestige. The login name and the Rem Password will be used to authenticate this node.
Page 327: Remote Node Network Layer Options
Prestige 653HWI Series User’s Guide Table 29-1 Menu 11.1 Remote Node Profile FIELD DESCRIPTION EXAMPLE Schedule Sets This field is only applicable for PPPoE and PPPoA encapsulation. You can apply up to four schedule sets here. For more details please refer to the Call Schedule Setup chapter.
Page 328: Figure 29-3 Menu 11.3 Remote Node Network Layer Options
Prestige 653HWI Series User’s Guide Step 2. Move the cursor to the Edit IP/Bridge field, press [SPACE BAR] to select Yes, then press [ENTER] to display Menu 11.3 – Remote Node Network Layer Options. Menu 11.3 - Remote Node Network Layer Options IP Options: Bridge Options: IP Address Assignment= Dynamic...
Page 329: My Wan Addr Sample Ip Addresses
Prestige 653HWI Series User’s Guide Table 29-2 Menu 11.3 Remote Node Network Layer Options FIELD DESCRIPTION EXAMPLE Select SUA Only if you have just one public WAN IP address for your Prestige. The SMT uses Address Mapping Set 255 (menu 15.1 - see section 32.3.1).
Page 330: Remote Node Filter
Prestige 653HWI Series User’s Guide The following figure uses sample IP addresses to help you understand the field of My Wan Addr in menu 11.3. Refer to the previous Figure 5-1 LAN and WAN IP Addresses for a brief review of what a WAN IP is.
Page 331: Editing Atm Layer Options
Prestige 653HWI Series User’s Guide Note that spaces are accepted in this field. The Prestige has a prepackaged filter set, NetBIOS_WAN, that blocks NetBIOS packets. Include this in the call filter sets if you want to prevent NetBIOS packets from triggering calls to a remote node.
Page 332: Figure 29-7 Menu 11.6 For Vc-Based Multiplexing
Prestige 653HWI Series User’s Guide 29.5.1 VC-based Multiplexing (non-PPP Encapsulation) For VC-based multiplexing, by prior agreement, a protocol is assigned a specific virtual circuit, for example, VC1 will carry IP. Separate VPI and VCI numbers must be specified for each protocol. Menu 11.6 - Remote Node ATM Layer Options VPI/VCI (VC-Multiplexing) VC Options for IP:...
Page 333: Figure 29-9 Menu 11.1 Remote Node Profile(Isdn Dial Backup)
Prestige 653HWI Series User’s Guide 29.5.3 Remote Node Profile(ISDN Dial Backup) In menu 11, enter 9 to configure the built-in profile - ISDN_DIALBACKUP. Menu 11.1 - Remote Node Profile Rem Node Name= ? Edit PPP Options= No Active= Yes Rem IP Addr= ? Call Direction= Both Edit IP= No Incoming:...
Page 334 Prestige 653HWI Series User’s Guide 29-12 Remote Node Profile...
Page 335: Chapter 30 Static Route Setup
Prestige 653HWI Series User’s Guide Chapter 30 Static Route Setup This chapter shows how to setup IP static routes. 30.1 IP Static Route Overview Static routes tell the Prestige routing information that it cannot learn automatically through other means. This can arise in cases where RIP is disabled on the LAN or a remote network is beyond the one that is directly connected to a remote node.
Page 336: Configuration
Prestige 653HWI Series User’s Guide 30.2 Configuration Step 1. To configure an IP static route, use Menu 12 – Static Route Setup (shown next). Menu 12 - Static Route Setup 1. IP Static Route 3. Bridge Static Route Please enter selection: Figure 30-2 Menu 12 Static Route Setup Step 2.
Page 337: Figure 30-4 Menu12.1.1 Edit Ip Static Route
Prestige 653HWI Series User’s Guide Menu 12.1.1 - Edit IP Static Route Route #: 1 Route Name= ? Active= No Destination IP Address= ? IP Subnet Mask= ? Gateway IP Address= ? Metric= 2 Private= No Press ENTER to Confirm or ESC to Cancel: Figure 30-4 Menu12.1.1 Edit IP Static Route The following table describes the fields for Menu 12.1.1 –...
Page 338 Prestige 653HWI Series User’s Guide Table 30-1 Menu12.1.1 Edit IP Static Route FIELD DESCRIPTION Private This parameter determines if the Prestige will include the route to this remote node in its RIP broadcasts. If set to Yes, this route is kept private and is not included in RIP broadcasts.
Page 339: Chapter 31 Bridging Setup
Prestige 653HWI Series User’s Guide Chapter 31 Bridging Setup This chapter shows you how to configure the bridging parameters of your Prestige. 31.1 Bridging in General Bridging bases the forwarding decision on the MAC (Media Access Control), or hardware address, while routing does it on the network layer (IP) address.
Page 340: Figure 31-1 Menu 11.1 Remote Node Profile
Prestige 653HWI Series User’s Guide Menu 11.1 - Remote Node Profile Rem Node Name= ? Route= IP Bridge= Yes Active= Yes Edit IP/Bridge= No Encapsulation= ENET ENCAP Multiplexing= VC-based Edit ATM Options= No Service Name= N/A Incoming: Telco Option: Rem Login= N/A Allocated Budget(min)= N/A Rem Password= N/A Period(hr)= N/A...
Page 341: Figure 31-3 Menu 12.3.1 Edit Bridge Static Route
Prestige 653HWI Series User’s Guide Table 31-1 Remote Node Network Layer Options : Bridge Fields FIELD DESCRIPTION Bridge (menu 11.1) Make sure this field is set to Yes. Edit IP/Bridge (menu Press [SPACE BAR] to select Yes and press [ENTER] to display menu 11.3. 11.1) Ethernet Addr Timeout Type the time (in minutes) for the Prestige to retain the Ethernet Address...
Page 342 Prestige 653HWI Series User’s Guide FIELD DESCRIPTION Active Indicates whether the static route is active (Yes) or not (No). Ether Address Type the MAC address of the destination computer that you want to bridge the packets to. IP Address If available, type the IP address of the destination computer that you want to bridge the packets to.
Page 343: Chapter 32 Network Address Translation (Nat)
Prestige 653HWI Series User’s Guide Chapter 32 Network Address Translation (NAT) This chapter discusses how to configure NAT on the Prestige. 32.1 Using NAT You must create a firewall rule in addition to setting up SUA/NAT, to allow traffic from the WAN to be forwarded through the Prestige. 32.1.1 SUA (Single User Account) Versus NAT SUA (Single User Account) is a ZyNOS implementation of a subset of NAT that supports two types of mapping, Many-to-One and Server.
Page 344: Figure 32-1 Menu 4 Applying Nat For Internet Access
Prestige 653HWI Series User’s Guide Menu 4 - Internet Access Setup ISP's Name= MyISP Encapsulation= RFC 1483 Multiplexing= LLC-based VPI #= 8 VCI #= 35 Service Name= N/A My Login= N/A My Password= N/A NAT= SUA Only Address Mapping Set= N/A IP Address Assignment= Static IP Address= 0.0.0.0 ENET ENCAP Gateway= N/A...
Page 345: Nat Setup
Prestige 653HWI Series User’s Guide Menu 11.3 - Remote Node Network Layer Options IP Options: Bridge Options: IP Address Assignment = Dynamic Ethernet Addr Timeout(min)= N/A Rem IP Addr = 0.0.0.0 Rem Subnet Mask= 0.0.0.0 My WAN Addr= N/A NAT= SUA Only Address Mapping Set= N/A Metric= 2 Private= No...
Page 346: Figure 32-3 Menu 15 Nat Setup
Prestige 653HWI Series User’s Guide on NAT web configurator screens for further information on these menus. To configure NAT, enter 15 from the main menu to bring up the following screen. Menu 15 — NAT Setup Address Mapping Sets NAT Server Sets Enter Menu Selection Number: Figure 32-3 Menu 15 NAT Setup 32.3.1 Address Mapping Sets...
Page 347: Figure 32-5 Menu 15.1.255 Sua Address Mapping Rules
Prestige 653HWI Series User’s Guide Menu 15.1.255 - Address Mapping Rules Set Name= Local Start IP Local End IP Global Start IP Global End IP Type --------------- --------------- --------------- --------------- ------ 0.0.0.0 255.255.255.255 0.0.0.0 0.0.0.0 Server Press ENTER to Confirm or ESC to Cancel: Figure 32-5 Menu 15.1.255 SUA Address Mapping Rules The following table explains the fields in this menu.
Page 348: Figure 32-6 Menu 15.1.1 First Set
Prestige 653HWI Series User’s Guide User-Defined Address Mapping Sets Now let’s look at option 1 in menu 15.1. Enter 1 to bring up this menu. We’ll just look at the differences from the previous menu. Note the extra Action and Select Rule fields mean you can configure rules in this screen.
Page 349: Table 32-3 Menu 15.1.1 First Set
Prestige 653HWI Series User’s Guide Now if you delete rule 4, rules 5 to 7 will be pushed up by 1 rule, so as old rule 5 becomes rule 4, old rule 6 becomes rule 5 and old rule 7 becomes rule 6. FIELD DESRIPTION EXAMPLE...
Page 350: Figure 32-7 Menu 15.1.1.1 Editing/Configuring An Individual Rule In A Set
Prestige 653HWI Series User’s Guide Figure 32-7 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set Menu 15.1.1.1 Address Mapping Rule Type= One-to-One Local IP: Start= = N/A Global IP: Start= = N/A Server Mapping Set= N/A Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle.
Page 351: Configuring A Server Behind Nat
Prestige 653HWI Series User’s Guide Table 32-4 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set When you have completed this menu, press [ENTER] at the prompt “Press ENTER to confirm or ESC to cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen. 32.4 Configuring a Server behind NAT Follow these steps to configure a server behind NAT: Step 1.
Page 352: Figure 32-9 Menu 15.2.1 Nat Server Setup
Prestige 653HWI Series User’s Guide Menu 15.2.1 - NAT Server Setup Rule Start Port No. End Port No. IP Address --------------------------------------------------- Default Default 0.0.0.0 192.168.1.33 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 Press ENTER to Confirm or ESC to Cancel: Figure 32-9 Menu 15.2.1 NAT Server Setup Step 4.
Page 353: General Nat Examples
Prestige 653HWI Series User’s Guide You assign the private network IP addresses. The NAT network appears as a single host on the Internet. Figure 32-10 Multiple Servers Behind NAT Example 32.5 General NAT Examples The following are some examples of NAT configuration. 32.5.1 Example 1: Internet Access Only In the following Internet access example, you only need one rule where your ILAs (Inside Local addresses) all map to one dynamic IGA (Inside Global Address) assigned by your ISP.
Page 354: Figure 32-11 Nat Example 1
Prestige 653HWI Series User’s Guide Figure 32-11 NAT Example 1 Menu 4 - Internet Access Setup ISP's Name= MyISP Encapsulation= RFC 1483 Multiplexing= LLC-based VPI #= 8 VCI #= 35 Service Name= N/A My Login= N/A My Password= N/A NAT= SUA Only Address Mapping Set= N/A IP Address Assignment= Static IP Address= 0.0.0.0...
Page 355: Figure 32-13 Nat Example 2
Prestige 653HWI Series User’s Guide 32.5.2 Example 2: Internet Access with an Inside Server The dynamic Inside Global Address is assigned by the ISP. Figure 32-13 NAT Example 2 In this case, you do exactly as above (use the convenient pre-configured SUA Only set) and also go to menu 15.2 to specify the Inside Server behind the NAT as shown in the next figure.
Page 356: Figure 32-15 Nat Example 3
Prestige 653HWI Series User’s Guide 32.5.3 Example 3: Multiple Public IP Addresses With Inside Servers In this example, there are 3 IGAs from our ISP. There are many departments but two have their own FTP server. All departments share the same router. The example will reserve one IGA for each department with an FTP server and all departments use the other IGA.
Page 357: Figure 32-16 Example 3: Menu 11.3
Prestige 653HWI Series User’s Guide Step 1. In this case you need to configure Address Mapping Set 1 from Menu 15.1 - Address Mapping Sets. Therefore you must choose the Full Feature option from the Network Address Translation field (in menu 4 or menu 11.3) in Figure 32-16. Step 2.
Page 358: Figure 32-17 Example 3: Menu 15.1.1.1
Prestige 653HWI Series User’s Guide Menu 15.1.1.1 Address Mapping Rule Type= One-to-One Local IP: Start= 192.168.1.10 = N/A Global IP: Start= 10.132.50.1 = N/A Server Mapping Set= N/A Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle. Figure 32-17 Example 3: Menu 15.1.1.1 Menu 15.1.1 - Address Mapping Rules Set Name= Example3...
Page 359: Figure 32-19 Nat Example 4
Prestige 653HWI Series User’s Guide Menu 15.2.1 - NAT Server Setup Rule Start Port No. End Port No. IP Address --------------------------------------------------- Default Default 0.0.0.0 192.168.1.21 192.168.1.20 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 Press ENTER to Confirm or ESC to Cancel: Example 3: Menu 15.2.1 32.5.4 Example 4: NAT Unfriendly Application Programs Some applications do not support NAT Mapping using TCP or UDP port address translation.
Page 360: Figure 32-20 Example 4: Menu 15.1.1.1 Address Mapping Rule
Prestige 653HWI Series User’s Guide Other applications such as some gaming programs are NAT unfriendly because they embed addressing information in the data stream. These applications won’t work through NAT even when using One-to-One and Many-to-Many No Overload mapping types. Follow the steps outlined in example 3 to configure these two menus as follows.
Page 361: Chapter 33 Enabling The Firewall
Prestige 653HWI Series User’s Guide Chapter 33 Enabling the Firewall This chapter shows you how to get started with the Prestige firewall. 33.1 Remote Management and the Firewall When SMT menu 24.11 is configured to allow management (see the Remote Management chapter) and the firewall is enabled: •...
Page 362: Figure 33-1 Menu 21.2 Firewall Setup
Prestige 653HWI Series User’s Guide Menu 21.2 - Firewall Setup The firewall protects against Denial of Service (DOS) attacks when it is active. The default Policy sets 1. allow all sessions originating from the LAN to the WAN and 2. deny all sessions originating from the WAN to the LAN You may define additional Policy rules or modify existing ones but please exercise extreme caution in doing so Active: Yes...
Page 364: Smt Advanced Management
SMT Advanced Management Part X: SMT Advanced Management This part discusses filtering setup, SNMP, system security, system information and diagnosis, firmware and configuration file maintenance, system maintenance, remote management, IP Policy Routing and call scheduling. See the web configurator parts of this guide for background information on features configurable by web configurator and SMT.
Page 365: Chapter 34 Filter Configuration
Prestige 653HWI Series User’s Guide Chapter 34 Filter Configuration This chapter shows you how to create and apply filters. 34.1 About Filtering Your Prestige uses filters to decide whether or not to allow passage of a data packet and/or to make a call. There are two types of filter applications: data filtering and call filtering.
Page 366: Figure 34-1 Outgoing Packet Filtering Process
Prestige 653HWI Series User’s Guide Call Filtering Active Data match Built-in User-defined match match Outgoing Initiate call default Call Filters Data Packet if line not up Call Filters (if applicable) Send packet and reset Idle Timer Match Match Match Drop Drop packet Drop packet packet...
Page 367: Figure 34-2 Filter Rule Process
Prestige 653HWI Series User’s Guide Start Packet intoFilter Fetch First Filter Set Filter Set Fetch Next Fetch First Filter Set Filter Rule Fetch Next Filter Rule Next filter Next Filter Set Rule Active? Available? Available? Execute Filter Rule Check Next Rule Forward Drop...
Page 368: Configuring A Filter Set For The Prestige
Prestige 653HWI Series User’s Guide For incoming packets, your Prestige applies data filters only. Packets are processed depending on whether a match is found. The following sections describe how to configure filter sets. The Filter Structure of the Prestige A filter set consists of one or more filter rules. Usually, you would group related rules, for example, all the rules for NetBIOS, into a single set and give it a descriptive name.
Page 369: Figure 34-4 Netbios_Wan Filter Rules Summary
Prestige 653HWI Series User’s Guide Menu 21.1.2 - Filter Rules Summary # A Type Filter Rules M m n - - ---- --------------------------------------------------------------- - - - 1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=137 N D N 2 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=138 N D N 3 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=139...
Page 370: Figure 34-7 Menu 21 Filter Set Configuration
Prestige 653HWI Series User’s Guide 34.3 Configuring a Filter Set for the Prestige To configure a filter set, follow the steps shown next. Step 1. Enter 21 in the main menu to display Menu 21 – Filter and Firewall Setup. Step 2.
Page 371: Filter Rules Summary Menus
Prestige 653HWI Series User’s Guide Menu 21.1.4 - Filter Rules Summary # A Type Filter Rules M m n - - ---- --------------------------------------------------------------- - - - 1 Y Gen Off=12, Len=2, Mask=ffff, Value=8863 N F N 2 Y Gen Off=12, Len=2, Mask=ffff, Value=8864 N F D Enter Filter Rule Number (1-6) to Configure: Figure 34-8 PPPoE Filter Rules Summary...
Page 372: Configuring A Filter Rule
Prestige 653HWI Series User’s Guide Table 34-1 Abbreviations Used in the Filter Rules Summary Menu FIELD DESCRIPTION More. “Y” means there are more rules to check which form a rule chain with the present rule. An action cannot be taken until the rule chain is complete. “N”...
Page 373: Figure 34-10 Menu 21.1.X.1 Tcp/Ip Filter Rule
Prestige 653HWI Series User’s Guide There are two types of filter rules: TCP/IP and Generic. Depending on the type of rule, the parameters for each type will be different. Use [SPACE BAR] to select the type of rule that you want to create in the Filter Type field and press [ENTER] to open the respective menu.
Page 374 Prestige 653HWI Series User’s Guide Table 34-3 Menu 21.1.x.1 TCP/IP Filter Rule FIELD DESCRIPTION EXAMPLE Filter # This is the filter set, filter rule coordinates, for instance, 2, 3 refers to the second filter set and the third filter rule of that set.
Page 375 Prestige 653HWI Series User’s Guide Table 34-3 Menu 21.1.x.1 TCP/IP Filter Rule FIELD DESCRIPTION EXAMPLE TCP Estab This applies only when the IP Protocol field is 6, TCP. If Yes, the rule matches packets that want to establish TCP (default) connection(s) (SYN=1 and ACK=0);...
Page 376: Figure 34-11 Executing An Ip Filter
Prestige 653HWI Series User’s Guide Packet into IP Filter Filter Active? Apply SrcAddrMask to Src Addr Check Src Not Matched IP Addr Matched Apply DestAddrMask to Dest Addr Check Dest Not Matched IP Addr Matched Check Not Matched IP Protocol Matched Check Src &...
Page 377: Figure 34-12 Menu 21.1.5.1 Generic Filter Rule
Prestige 653HWI Series User’s Guide 34.5.2 Generic Filter Rule This section shows you how to configure a generic filter rule. The purpose of generic rules is to allow you to filter non-IP packets. For IP, it is generally easier to use the IP rules directly. For generic rules, the Prestige treats a packet as a byte stream as opposed to an IP packet.
Page 378: Table 34-4 Menu 21.1.5.1 Generic Filter Rule
Prestige 653HWI Series User’s Guide Table 34-4 Menu 21.1.5.1 Generic Filter Rule FIELD DESCRIPTION EXAMPLE Filter # This is the filter set, filter rule coordinates, for instance, 2, 3 refers to the second filter set and the third rule of that set. Filter Type Press [SPACE BAR] and then [ENTER] to select a type of rule.
Page 379: Filter Types And Nat
Prestige 653HWI Series User’s Guide 34.6 Filter Types and NAT There are two classes of filter rules, Generic Filter Device rules and Protocol Filter (TCP/IP) rules. Generic Filter rules act on the raw data from/to LAN and WAN. Protocol Filter rules act on IP packets. When NAT (Network Address Translation) is enabled, the inside IP address and port number are replaced on a connection-by-connection basis, which makes it impossible to know the exact address and port on the wire.
Page 380: Figure 34-14 Sample Telnet Filter
Prestige 653HWI Series User’s Guide Figure 34-14 Sample Telnet Filter Step 1. Enter 1 in the menu 21 to display Menu 21.1 — Filter Set Configuration. Step 2. Enter the index number of the filter set you want to configure (in this case 6) Step 3.
Page 381: Figure 34-15 Menu 21.1.6.1 Sample Filter
Prestige 653HWI Series User’s Guide Step 4. Press [ENTER] at the message Press [ENTER] to confirm or [ESC] to cancel” to open Menu “ 21.1.6 — Filter Rules Summary. Step 5. Type 1 to configure the first filter rule. Make the entries in this menu as shown next. When you press [ENTER] to confirm, the following screen appears.
Page 382: Applying Filters And Factory Defaults
Prestige 653HWI Series User’s Guide Menu 21.1.6 - Filter Rules Summary # A Type Filter Rules M m n - - ---- --------------------------------------------------------------- - - - 1 Y IP Pr=6, SA=0.0.0.0, DA=0.0.0.0, DP=23 N D F Enter Filter Rule Number (1-6) to Configure: 1 This shows you that you have M = N means an action can be taken immediately.
Page 383: Figure 34-17 Filtering Ethernet Traffic
Prestige 653HWI Series User’s Guide Table 34-5 Filter Sets Table FILTER SETS DESCRIPTION Input Filter Sets: Apply filters for incoming traffic. You may apply protocol or device filter rules. See earlier in this chapter for information on filters. Output Filter Sets: Apply filters for traffic leaving the Prestige.
Page 384: Figure 34-18 Filtering Remote Node Traffic
Prestige 653HWI Series User’s Guide Apply filter 6 to block Menu 11.5 - Remote Node Filter Tel, FTP and Web Input Filter Sets: protocol filters= 6 traffic from the WAN. device filters= Output Filter Sets: protocol filters= 2 device filters= Call Filter Sets: Apply filter 2 to block Protocol filters=...
Page 385: Chapter 35 Snmp Configuration
Prestige 653HWI Series User’s Guide Chapter 35 SNMP Configuration This chapter explains SNMP Configuration menu 22. 35.1 About SNMP Simple Network Management Protocol is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite. Your Prestige supports SNMP agent functionality, which allows a manager station to manage and monitor the Prestige through the network.
Page 386: Supported Mibs
Trap - Used by the agent to inform the manager of some events. 35.2 Supported MIBs The Prestige supports RFC-1215 and MIB II as defined in RFC-1213 as well as ZyXEL private MIBs. The focus of the MIBs is to let administrators collect statistic data and monitor status and performance.
Page 387: Figure 35-2 Menu 22 Snmp Configuration
Prestige 653HWI Series User’s Guide Menu 22 - SNMP Configuration SNMP: Get Community= public Set Community= public Trusted Host= 0.0.0.0 Trap: Community= public Destination= 0.0.0.0 Press ENTER to Confirm or ESC to Cancel: Figure 35-2 Menu 22 SNMP Configuration The following table describes the SNMP configuration parameters. Table 35-1 Menu 22 SNMP Configuration FIELD DESCRIPTION...
Page 388: Snmp Traps
A trap is sent to the manager when receiving any SNMP RFC-1215) gets or sets requirements with wrong community (password). whyReboot (defined in ZYXEL- A trap is sent with the reason of restart before rebooting MIB) when the system is going to restart (warm start).
Page 389: Chapter 36 System Security
Prestige 653HWI Series User’s Guide Chapter 36 System Security This chapter describes how to configure the system security on the Prestige. 36.1 System Security You can configure the system password, an external RADIUS server and IEEE802.1x in menu 23. 36.1.1 System Password Enter 23 in the main menu to display Menu 23 –...
Page 390: Figure 36-3 Menu 23.2 System Security : Radius Server
Prestige 653HWI Series User’s Guide Menu 23.2 - System Security - RADIUS Server Authentication Server: Active= No Server Address= 10.11.12.13 Port #= 1812 Shared Secret= ******** Accounting Server: Active= No Server Address= 10.11.12.13 Port #= 1813 Shared Secret= ******** Press ENTER to Confirm or ESC to Cancel: Figure 36-3 Menu 23.2 System Security : RADIUS Server The following table describes the fields in this menu.
Page 391: Figure 36-4 Menu 23 System Security
Prestige 653HWI Series User’s Guide Table 36-1 Menu 23.2 System Security : RADIUS Server FIELD DESCRIPTION EXAMPLE Port The default port of the RADIUS server for accounting is 1813. 1813 You need not change this value unless your network administrator instructs you to do so with additional information. Shared Secret Specify a password (up to 31 alphanumeric characters) as the key to be shared between the external accounting server and the...
Page 392: Figure 36-5 Menu 23.4 System Security : Ieee802.1X
Prestige 653HWI Series User’s Guide Menu 23.4 - System Security - IEEE802.1x Wireless Port Control= Authentication Required ReAuthentication Timer (in second)= 1800 Idle Timeout (in second)= 3600 Authentication Databases= Local User Database Only Press ENTER to Confirm or ESC to Cancel: Figure 36-5 Menu 23.4 System Security : IEEE802.1x The following table describes the fields in this menu.
Page 393: Creating User Accounts On The Prestige
Prestige 653HWI Series User’s Guide Table 36-2 Menu 23.4 System Security : IEEE802.1x FIELD DESCRIPTION Authentication This field is activated only when you select Authentication Required in the Wireless Port Control field. Databases The authentication database contains wireless station login information. The local user database is the built-in database on the Prestige.
Page 394: Figure 36-6 Menu 14 Dial-In User Setup
Prestige 653HWI Series User’s Guide Menu 14 - Dial-in User Setup 1. ________ ________ 17. ________ 25. ________ 2. ________ 10. ________ 18. ________ 26. ________ 3. ________ 11. ________ 19. ________ 27. ________ 4. ________ 12. ________ 20. ________ 28.
Page 395: Chapter 37 System Information And Diagnosis
Prestige 653HWI Series User’s Guide Chapter 37 System Information and Diagnosis This chapter covers the information and diagnostic tools in SMT menus 24.1 to 24.4. These tools include updates on system status, port status, log and trace capabilities and upgrades for the system software.
Page 396: Figure 37-2 Menu 24.1 System Maintenance: Status
Prestige 653HWI Series User’s Guide Menu 24.1 - System Maintenance – Status hh:mm:ss Sat. Jan. 01, 2000 Up Time Node-Lnk Status TxPkts RxPkts Errors Tx B/s Rx B/s 1-1483 0:26:20 0:00:00 0:00:00 0:00:00 0:00:00 0:00:00 0:00:00 0:00:00 ISDN-B1 Idle 0:00:00 ISDN-B2 Idle 0:00:00...
Page 397: System Information
Prestige 653HWI Series User’s Guide Table 37-1 Menu 24.1 System Maintenance: Status FIELD DESCRIPTION My WAN IP This is the IP address of the ISP remote node. (from ISP) Ethernet This shows statistics for the LAN. Status This shows the current status of the LAN. Tx Pkts This is the number of transmitted packets to the LAN.
Page 398: Figure 37-4 Menu 24.2.1 System Maintenance : Information
Menu 1 – General Setup. Routing Refers to the routing protocol used. ZyNOS F/W Version Refers to the ZyNOS (ZyXEL Network Operating System) system firmware version. ZyNOS is a registered trademark of ZyXEL Communications Corporation. ADSL Chipset Vendor Displays the vendor of the ADSL chipset and DSL version.
Page 399: Log And Trace
Prestige 653HWI Series User’s Guide Table 37-2 Menu 24.2.1 System Maintenance : Information FIELD DESCRIPTION DHCP This field shows the DHCP setting (None, Relay or Server) of the Prestige. 37.2.2 Console Port Speed You can set up different port speeds for the console port through Menu 24.2.2 – System Maintenance – Console Port Speed.
Page 400: Figure 37-6 Menu 24.3 System Maintenance : Log And Trace
Prestige 653HWI Series User’s Guide Figure 37-6 Menu 24.3 System Maintenance : Log and Trace Step 3. Enter 1 from Menu 24.3 — System Maintenance — Log and Trace to display the error log in the system. After the Prestige finishes displaying the error log, you will have the option to clear it. Samples of typical error and information messages are presented in the next figure.
Page 401: Table 37-3 Menu 24.3.2 System Maintenance : Syslog And Accounting
L02 Call Terminated C02 Call Terminated Jul 19 11:19:27 192.168.102.2 ZYXEL: board 0 line 0 channel 0, call 1, C01 Outgoing Call dev=2 ch=0 40002 Jul 19 11:19:32 192.168.102.2 ZYXEL: board 0 line 0 channel 0, call 1, C02 OutCall Connected 64000 40002 Jul 19 11:20:06 192.168.102.2 ZYXEL: board 0 line 0 channel 0, call 1, C02 Call Terminated...
Page 402: Diagnostic
Dst: Destination Address prot: Protocol (“TCP”, ”UDP”, ”ICMP”) spo: Source port dpo: Destination port Jul 19 14:43:55 192.168.102.2 ZYXEL: IP [Src=202.132.154.123 Dst=255.255.255.255 UDP spo=0208 dpo=0208]} S03>R01mF Jul 19 14:44:00 192.168.102.2 ZYXEL: IP [Src=192.168.102.20 Dst=202.132.154.1 UDP spo=05d4 dpo=0035]} S03>R01mF Jul 19 14:44:04 192.168.102.2 ZYXEL: IP [Src=192.168.102.20 Dst=202.132.154.1 UDP spo=05d4 dpo=0035]} S03>R01mF...
Page 403: Figure 37-9 Menu 24.4 System Maintenance : Diagnostic
Prestige 653HWI Series User’s Guide Menu 24.4 - System Maintenance – Diagnostic ADSL System Reset ADSL 21. Reboot System Hang Up B1 Call 22. Command Mode Hang Up B2 Call Reset ISDN ISDN Connection Test Enter Menu Selection Number: Host IP Address= N/A Figure 37-9 Menu 24.4 System Maintenance : Diagnostic The following table describes the diagnostic tests available in menu 24.4 for and the connections.
Page 405: Chapter 38 Firmware And Configuration File Maintenance
The configuration file (often called the romfile or rom-0) contains the factory default settings in the menus such as password, DHCP Setup, TCP/IP Setup, etc. It arrives from ZyXEL with a “rom” filename extension. Once you have customized the Prestige's settings, they can be saved back to your computer under a filename of your choosing.
Page 406: Backup Configuration
Prestige 653HWI Series User’s Guide Table 38-1 Filename Conventions FILE TYPE INTERNAL NAME EXTERNAL NAME DESCRIPTION Configuration Rom-0 This is the configuration filename on the *.rom File Prestige. Uploading the rom-0 file replaces the entire ROM file system, including your Prestige configurations, system-related data (including the default password), the error log and the trace log.
Page 407: Figure 38-1 Telnet In Menu 24.5
Prestige 653HWI Series User’s Guide 38.2.1 Backup Configuration Follow the instructions as shown in the next screen. Menu 24.5 - System Maintenance - Backup Configuration To transfer the configuration file to your workstation, follow the procedure below: 1. Launch the FTP client on your workstation. 2.
Page 408: Figure 38-2 Ftp Session Example
331 Enter PASS command Password: 230 Logged in ftp> bin 200 Type I OK ftp> get rom-0 zyxel.rom 200 Port command okay 150 Opening data connection for STOR ras 226 File received OK ftp: 16384 bytes sent in 1.10Seconds 297.89Kbytes/sec.
Page 409: Backup Configuration Using Tftp
Prestige 653HWI Series User’s Guide 3. The IP address in the Secured Client IP field in menu 24.11 does not match the client IP. If it does not match, the Prestige will disconnect the Telnet session immediately. 4. You have an SMT console session running. 38.2.6 Backup Configuration Using TFTP The Prestige supports the up/downloading of the firmware and the configuration file using TFTP (Trivial File Transfer Protocol) over LAN.
Page 410: Figure 38-3 Menu 24.5 System Maintenance : Backup Configuration
Prestige 653HWI Series User’s Guide 38.2.8 GUI-based TFTP Clients The following table describes some of the fields that you may see in GUI-based TFTP clients. Table 38-3 General Commands for GUI-based TFTP Clients COMMAND DESCRIPTION Host Enter the IP address of the Prestige. 192.168.1.1 is the Prestige’s default IP address when shipped.
Page 411: Restore Configuration
Prestige 653HWI Series User’s Guide Step 3. Run the HyperTerminal program by clicking Transfer, then Receive File as shown in the following screen. Type a location for storing the configuration file or click Browse to look for one. Choose the Xmodem protocol. Then click Receive.
Page 412: Figure 38-7 Telnet Into Menu 24.6
Prestige 653HWI Series User’s Guide WARNING! DO NOT INTERRUPT THE FILE TRANSFER PROCESS AS THIS MAY PERMANENTLY DAMAGE YOUR PRESTIGE. 38.3.1 Restore Using FTP For details about backup using (T)FTP please refer to earlier sections on FTP and TFTP file upload in this chapter.
Page 413: Figure 38-8 Restore Using Ftp Session Example
Prestige 653HWI Series User’s Guide 38.3.2 Restore Using FTP Session Example ftp> put config.rom rom-0 200 Port command okay 150 Opening data connection for STOR rom-0 226 File received OK 221 Goodbye for writing flash ftp: 16384 bytes sent in 0.06Seconds 273.07Kbytes/sec. ftp>quit Figure 38-8 Restore Using FTP Session Example Refer to section 38.2.5 to read about configurations that disallow TFTP and FTP over WAN.
Page 414: Uploading Firmware And Configuration Files
Prestige 653HWI Series User’s Guide Type the configuration file’s location, or click Browse to search for it. Choose the Xmodem protocol. Then click Send. Figure 38-11 Restore Configuration Example Step 4. After a successful restoration you will see the following screen. Press any key to restart the Prestige and return to the SMT menu.
Page 415: Figure 38-13 Telnet Into Menu 24.7.1 Upload System Firmware
Prestige 653HWI Series User’s Guide Menu 24.7.1 - System Maintenance - Upload System Firmware To upload the system firmware, follow the procedure below: 1. Launch the FTP client on your workstation. 2. Type "open" and the IP address of your system. Then type "root" and SMT password as requested.
Page 416: Figure 38-15 Ftp Session Example Of Firmware File Upload
Prestige 653HWI Series User’s Guide 38.4.3 FTP File Upload Command from the DOS Prompt Example Step 1. Launch the FTP client on your computer. Step 2. Enter “open”, followed by a space and the IP address of your Prestige. Step 3. Press [ENTER] when prompted for a username.
Page 417: Tftp Upload Command Example
Prestige 653HWI Series User’s Guide To use TFTP, your computer must have both telnet and TFTP clients. To transfer the firmware and the configuration file, follow the procedure shown next. Step 1. Use telnet from your computer to connect to the Prestige and log in. Because TFTP does not have any security checks, the Prestige records the IP address of the telnet client and accepts TFTP requests only from this address.
Page 418: Figure 38-16 Menu 24.7.1 As Seen Using The Console Port
Prestige 653HWI Series User’s Guide 38.4.8 Uploading Firmware File Via Console Port Step 1. Select 1 from Menu 24.7 – System Maintenance – Upload Firmware to display Menu 24.7.1 – System Maintenance – Upload System Firmware, then follow the instructions as shown in the following screen.
Page 419: Figure 38-18 Menu 24.7.2 As Seen Using The Console Port
Prestige 653HWI Series User’s Guide 38.4.10 Uploading Configuration File Via Console Port Step 1. Select 2 from Menu 24.7 – System Maintenance – Upload Firmware to display Menu 24.7.2 – System Maintenance – Upload System Configuration File. Follow the instructions as shown in the next screen.
Page 420: Figure 38-19 Example Xmodem Upload
Prestige 653HWI Series User’s Guide Type the configuration file’s location, or click Browse to search for it. Choose the Xmodem protocol. Then click Send. Figure 38-19 Example Xmodem Upload After the configuration upload process has completed, restart the Prestige by entering “atgo”. 38-16 Firmware and Configuration File Maintenance...
Page 421: Chapter 39 System Maintenance
SMT, while adding some low-level setup and diagnostic functions. Enter the CI from the SMT by selecting menu 24.8. See the included disk or the zyxel.com web site for more detailed information on CI commands. Enter 8 from Menu 24 — System Maintenance. A list of valid commands can be found by typing help or ? at the command prompt.
Page 422: Call Control Support
Prestige 653HWI Series User’s Guide Copyright (c) 1994 - 2003 ZyXEL Communications Corp. 653HWI> ? Valid commands are: exit device ether wlan isdn ipsec bridge hdap radius 8021x Figure 39-2 Valid Commands 39.2 Call Control Support Call Control Support is only applicable when Encapsulation is set to PPPoE in menu 4 or menu 11.1.
Page 423: Figure 39-4 Menu 24.9.1 System Maintenance : Budget Management
Prestige 653HWI Series User’s Guide Menu 24.9.1 - System Maintenance - Budget Management Remote Node Connection Time/Total Budget Elapsed Time/Total Period 1.ChangeMe No Budget No Budget 2.-------- 3.-------- 4.-------- 5.-------- 6.-------- 7.-------- 8.-------- Reset Node (0 to update screen): Figure 39-4 Menu 24.9.1 System Maintenance : Budget Management The total budget is the time limit on the accumulated time for outgoing calls to a remote node.
Page 424: Time And Date Setting
Prestige 653HWI Series User’s Guide 39.3 Time and Date Setting The Prestige keeps track of the time and date. There is also a software mechanism to set the time manually or get the current time and date from an external server when you turn on your Prestige. Menu 24.10 allows you to update the time and date settings of your Prestige.
Page 425: Table 39-2 Menu 24.10 System Maintenance: Time And Date Setting
Prestige 653HWI Series User’s Guide Table 39-2 Menu 24.10 System Maintenance: Time and Date Setting FIELD DESCRIPTION Use Time Server Enter the time service protocol that your time server sends when you turn on the when Bootup Prestige. Not all time servers support all protocols, so you may have to check with your ISP/network administrator or use trial and error to find a protocol that works.
Page 427: Chapter 40 Remote Management
Prestige 653HWI Series User’s Guide Chapter 40 Remote Management This chapter covers remote management (SMT menu 24.11). 40.1 Remote Management Overview Remote management allows you to determine which services/protocols can access which Prestige interface (if any) from which computers. When you configure remote management to allow management from the WAN, you still need to configure a firewall rule to allow access.
Page 428: Figure 5-2 Lan
Prestige 653HWI Series User’s Guide Menu 24.11 - Remote Management Control TELNET Server: Server Port = 23 Server Access = LAN only Secured Client IP = 0.0.0.0 FTP Server: Server Port = 21 Server Access = LAN only Secured Client IP = 0.0.0.0 Web Server: Server Port = 80 Server Access = LAN only...
Page 429: Remote Management And Nat
Prestige 653HWI Series User’s Guide 1. A filter in menu 3.1 (LAN) or in menu 11.5 (WAN) is applied to block a Telnet, FTP or Web service. 2. You have disabled that service in menu 24.11. 3. The IP address in the Secured Client IP field (menu 24.11) does not match the client IP address. If it does not match, the Prestige will disconnect the session immediately.
Page 431: Chapter 41 Ip Policy Routing
Prestige 653HWI Series User’s Guide Chapter 41 IP Policy Routing This chapter covers setting and applying policies used for IP routing. 41.1 IP Policy Routing Overview Traditionally, routing is based on the destination address only and the IAD takes the shortest path to forward a packet.
Page 432: Ip Routing Policy Setup
Prestige 653HWI Series User’s Guide IPPR follows the existing packet filtering facility of RAS in style and in implementation. The policies are divided into sets, where related policies are grouped together. A user defines the policies before applying them to an interface or a remote node, in the same fashion as the filters. There are 12 policy sets with six policies in each set.
Page 433: Figure 41-2 Menu 25.1 Ip Routing Policy Setup
Prestige 653HWI Series User’s Guide Menu 25.1 - IP Routing Policy Setup Criteria/Action - - -------------------------------------------------------------------------- 1 Y SA=1.1.1.1-1.1.1.1,DA=2.2.2.2-2.2.2.5 SP=20-25,DP=20-25,P=6,T=NM,PR=0 |GW=192.168.1.1,T=MT,PR=0 2 N __________________________________________________________________________ __________________________________________________________________________ 3 N __________________________________________________________________________ __________________________________________________________________________ 4 N __________________________________________________________________________ __________________________________________________________________________ 5 N __________________________________________________________________________ __________________________________________________________________________ 6 N __________________________________________________________________________ __________________________________________________________________________ Enter Policy Rule Number (1-6) to Configure: Figure 41-2 Menu 25.1 IP Routing Policy Setup...
Page 434: Figure 41-3 Menu 25.1.1 Ip Routing Policy
Prestige 653HWI Series User’s Guide Type a number from 1 to 6 to display Menu 25.1.1 – IP Routing Policy (see the next figure). This menu allows you to configure a policy rule. Menu 25.1.1 - IP Routing Policy Policy Set Name= test Active= Yes Criteria: IP Protocol...
Page 435: Applying An Ip Policy
Prestige 653HWI Series User’s Guide Table 41-2 Menu 25.1.1 IP Routing Policy FIELD DESCRIPTION Len Comp Press [SPACE BAR] and then [ENTER] to choose from Equal, Not Equal, Less, Greater, Less or Equal or Greater or Equal. Source: addr start / end Source IP address range from start to end.
Page 436: Figure 41-4 Menu 3.2 Tcp/Ip And Dhcp Ethernet Setup
Prestige 653HWI Series User’s Guide Menu 3.2 - TCP/IP and DHCP Ethernet Setup DHCP Setup: DHCP= None Client IP Pool Starting Address= N/A Size of Client IP Pool= N/A Primary DNS Server= N/A Secondary DNS Server= N/A Remote DHCP Server= N/A TCP/IP Setup: Type IP IP Address= 192.168.1.1...
Page 437: Ip Policy Routing Example
Prestige 653HWI Series User’s Guide 41.6 IP Policy Routing Example If a network has both Internet and remote node connections, you can route Web packets to the Internet using one policy and route FTP packets to a remote network using another policy. See the next figure. Figure 41-6 Example of IP Policy Routing To force Web packets coming from clients with IP addresses of 192.168.1.33 to 192.168.1.64 to be routed to the Internet via the WAN port of the Prestige, follow the steps as shown next.
Page 438: Figure 41-7 Ip Routing Policy Example
Prestige 653HWI Series User’s Guide Menu 25.1.1 - IP Routing Policy Policy Set Name= set1 Active= Yes Criteria: IP Protocol Type of Service= Don't Care Packet length= 10 Precedence = Don't Care Len Comp= N/A Source: addr start= 192.168.1.2 end= 192.168.1.64 port start= 0 end= N/A Destination:...
Page 439: Figure 41-8 Ip Routing Policy Example
Prestige 653HWI Series User’s Guide Menu 25.1.1 - IP Routing Policy Policy Set Name= set2 Active= Yes Criteria: IP Protocol Type of Service= Don't Care Packet length= 10 Precedence = Don't Care Len Comp= N/A Source: addr start= 0.0.0.0 end= N/A port start= 0 end= N/A Destination:...
Page 441: Chapter 42 Call Scheduling
Prestige 653HWI Series User’s Guide Chapter 42 Call Scheduling Call scheduling (applicable for PPPoA or PPPoE encapsulation only) allows you to dictate when a remote node should be called and for how long. 42.1 Introduction The call scheduling feature allows the Prestige to manage a remote node and dictate when a remote node should be called and for how long.
Page 442: Figure 42-2 Menu 26.1 Schedule Set Setup
Prestige 653HWI Series User’s Guide To delete a schedule set, enter the set number and press [SPACE BAR] and then [ENTER] (or delete) in the Edit Name field. To setup a schedule set, select the schedule set you want to setup from menu 26 (1-12) and press [ENTER] to see Menu 26.1 —...
Page 443 Prestige 653HWI Series User’s Guide Table 42-1 Menu 26.1 Schedule Set Setup FIELD DESCRIPTION EXAMPLE Should this schedule set recur weekly or be used just once Once Often only? Press the [SPACE BAR] and then [ENTER] to select Once or Weekly. Both these options are mutually exclusive. If Once is selected, then all weekday settings are N/A.
Page 444: Figure 42-3 Applying Schedule Set(S) To A Remote Node (Pppoe)
Prestige 653HWI Series User’s Guide Menu 11.1 - Remote Node Profile Rem Node Name= ChangeMe Route= IP Active= Yes Bridge= No Encapsulation= PPPoE Edit IP/Bridge= No Multiplexing=VC-based Edit ATM Options= No Service Name= Telco Option: Incoming Allocated Budget(min)= 0 Rem Login= Period(hr)= 0 Apply your schedule Rem Password= ********...
Page 446: Smt Vpn/Ipsec And Internal Sptgen
SMT VPN/IPSec and Internal SPTGEN Part XI: SMT VPN/IPSec and Internal SPTGEN This part provides information about configuring VPN/IPSec for secure communications and Internal SPTGEN for configuration of multiple Prestiges. See the web configurator parts of this guide for background information on features configurable by web configurator and SMT.
Page 447: Chapter 43 Vpn/Ipsec Setup
Prestige 653HWI Series User’s Guide Chapter 43 VPN/IPSec Setup This chapter introduces the VPN SMT menus. 43.1 VPN/IPSec Overview The VPN/IPSec main SMT menu has these main submenus: 1. Define VPN policies in menu 27.1 submenus, including security policies, endpoint IP addresses, peer IPSec router IP address and key management.
Page 448: Ipsec Summary Screen
172.16.2.40 172.16.2.46 193.81.13.2 zw50 1.1.1.1 1.1.1.1 Tunnel AH SHA1 4.4.4.4 255.255.0.0 zw50test.zyxel. China 192.168.1.40 192.168.1.42 Tunnel ESP DES MD5 0.0.0.0 Select Command= None Select Rule= N/A Press ENTER to Confirm or ESC to Cancel: Figure 43-3 Menu 27.1 IPSec Summary...
Page 449: Table 43-1 Menu 27.1 Ipsec Summary
Prestige 653HWI Series User’s Guide Table 43-1 Menu 27.1 IPSec Summary FIELD DESCRIPTION EXAMPLE This is the VPN policy index number. Name This field displays the unique identification name for this VPN rule. The Taiwan name may be up to 32 characters long but only 10 characters will be displayed here.
Page 450 Prestige 653HWI Series User’s Guide Table 43-1 Menu 27.1 IPSec Summary FIELD DESCRIPTION EXAMPLE IPSec This field displays the security protocols used for an SA. ESP provides ESP DES MD5 Algorithm confidentiality and integrity of data by encrypting the data and encapsulating it into IP packets.
Page 451 Prestige 653HWI Series User’s Guide Table 43-1 Menu 27.1 IPSec Summary FIELD DESCRIPTION EXAMPLE Remote When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to 172.16.2.46 Addr End Single, this is the same (static) IP address as in the Remote Addr Start field.
Page 452: Ipsec Setup
Name= Taiwan Active= Yes Keep Alive= No Local ID type Content: My IP Addr= 0.0.0.0 Peer ID type Content: Secure Gateway Address= zw50test.zyxel.com.tw Protocol= 0 Local: Addr Type= SINGLE IP Addr Start= 1.1.1.1 End/Subnet Mask= N/A Port Start= 0 End= N/A...
Page 453 Prestige 653HWI Series User’s Guide Table 43-2 Menu 27.1.1 IPSec Setup FIELD DESCRIPTION EXAMPLE Keep Alive Press [SPACE BAR] to choose either Yes or No. Choose Yes and press [ENTER] to have the Prestige automatically re-initiate the SA after the SA lifetime times out, even if there is no traffic.
Page 454 Prestige 653HWI Series User’s Guide Table 43-2 Menu 27.1.1 IPSec Setup FIELD DESCRIPTION EXAMPLE Content When you select IP in the Peer ID Type field, type the IP address of the computer with which you will make the VPN connection or leave the field blank to have the Prestige automatically use the address in the Secure Gateway Address field.
Page 455 Prestige 653HWI Series User’s Guide Table 43-2 Menu 27.1.1 IPSec Setup FIELD DESCRIPTION EXAMPLE IP Addr Start When the Addr Type field is configured to Single, enter a static IP 192.168.1.35 address on the LAN behind your Prestige. When the Addr Type field is configured to Range, enter the beginning (static) IP address, in a range of computers on your LAN behind your Prestige.
Page 456 Prestige 653HWI Series User’s Guide Table 43-2 Menu 27.1.1 IPSec Setup FIELD DESCRIPTION EXAMPLE IP Addr Start When the Addr Type field is configured to Single, enter a static IP 4.4.4.4 address on the network behind the remote IPSec router. When the Addr Type field is configured to Range, enter the beginning (static) IP address, in a range of computers on the network behind the remote IPSec router.
Page 457: Ike Setup
Prestige 653HWI Series User’s Guide Table 43-2 Menu 27.1.1 IPSec Setup FIELD DESCRIPTION EXAMPLE Press [SPACE BAR] to choose either IKE or Manual and then press Management [ENTER]. Manual is useful for troubleshooting if you have problems using IKE key management. Press [SPACE BAR] to change the default No to Yes and then press Edit Key Management...
Page 458: Table 43-3 Menu 27.1.1.1 Ike Setup
Prestige 653HWI Series User’s Guide Table 43-3 Menu 27.1.1.1 IKE Setup FIELD DESCRIPTION EXAMPLE Phase 1 Negotiation Press [SPACE BAR] to choose from Main or Aggressive and then press Main Mode [ENTER]. See earlier for a discussion of these modes. Multiple SAs connecting through a secure gateway must have the same negotiation mode.
Page 459: Manual Setup
Prestige 653HWI Series User’s Guide Table 43-3 Menu 27.1.1.1 IKE Setup FIELD DESCRIPTION EXAMPLE Active Protocol Press [SPACE BAR] to choose from ESP or AH and then press [ENTER]. See earlier for a discussion of these protocols. Encryption Press [SPACE BAR] to choose from NULL, 3DES or DES and then press [ENTER].
Page 460: Figure 43-6 Menu 27.1.1.2 Manual Setup
Prestige 653HWI Series User’s Guide 43.5.2 Security Parameter Index (SPI) To edit this menu, move the cursor to the Edit Manual Setup field in Menu 27.1.1 – IPSec Setup press [SPACE BAR] to select Yes and then press [ENTER] to go to Menu 27.1.1.2 – Manual Setup. Menu 27.1.1.2 –...
Page 461 Prestige 653HWI Series User’s Guide Table 43-5 Menu 27.1.1.2 Manual Setup FIELD DESCRIPTION EXAMPLE Key2 Enter a unique eight-character key. It can be comprised of any character including spaces (but trailing spaces are truncated). Key3 Enter a unique eight-character key. It can be comprised of any character including spaces (but trailing spaces are truncated).
Page 463: Chapter 44 Sa Monitor
Prestige 653HWI Series User’s Guide Chapter 44 SA Monitor This chapter teaches you how to manage your SAs by using the SA Monitor in SMT menu 27.2. 44.1 SA Monitor Overview A Security Association (SA) is the group of security settings related to a specific VPN tunnel. This menu (shown next) displays active VPN connections.
Page 464 Prestige 653HWI Series User’s Guide The following table describes the fields in this menu. Table 44-1 Menu 27.2 SA Monitor FIELD DESCRIPTION EXAMPLE This is the security association index number. Name This field displays the identification name for this VPN policy. This name is Taiwan unique for each connection where the secure gateway IP address is a public static IP address.
Page 465: Chapter 45 Internal Sptgen
Prestige 653HWI Series User’s Guide Chapter 45 Internal SPTGEN 45.1 Internal SPTGEN Overview Internal SPTGEN (System Parameter Table Generator) is a configuration text file useful for efficient configuration of multiple Prestiges. Internal SPTGEN lets you configure, save and upload multiple menus at the same time using just one configuration text file –...
Page 466: Figure 45-1 Configuration Text File Format: Column Descriptions
Prestige 653HWI Series User’s Guide This is the name of This is the Field Name column. One “=” sign, followed by one the menu. This is the name of the field as seen in space, must precede the corresponding SMT screen. everything you input.
Page 467: Internal Sptgen Ftp Download Example
Prestige 653HWI Series User’s Guide field value is not legal error:-1 ROM-t is not saved, error Line ID:10000000 reboot to get the original configuration Bootbase Version: V2.02 | 2/22/2001 13:33:11 RAM: Size = 8192 Kbytes FLASH: Intel 8M *2 Figure 45-2 Invalid Parameter Entered: Command Line Example The Prestige will display the following if you enter parameter(s) that are valid.
Page 468: Internal Sptgen Ftp Upload Example
Prestige 653HWI Series User’s Guide You can rename your “rom-t” file when you save it to your computer but it must be named “rom-t” when you upload it to your Prestige. 45.4 Internal SPTGEN FTP Upload Example c:\ftp 192.168.1.1 220 PPP FTP version 1.0 ready at Sat Jan 1 03:22:12 1.
Page 470: Appendices And Index
Part XII: Appendices and Index This part contains additional background information and an index or key terms.
Page 471: Appendix A Troubleshooting
Prestige 653HWI Series User’s Guide Appendix A Troubleshooting This chapter covers potential problems and the corresponding remedies. Problems Starting Up the Prestige Chart A-1 Troubleshooting the Start-Up of Your Prestige PROBLEM CORRECTIVE ACTION None of the Make sure that the Prestige’s power adaptor is connected to the Prestige and plugged in to LEDs turn on an appropriate power source.
Page 472 Prestige 653HWI Series User’s Guide Chart A-3 Troubleshooting the DSL LED PROBLEM CORRECTIVE ACTION The xDSL LED is off. Check the telephone wire and connections between the Prestige DSL port and the wall jack. Make sure that the telephone company has checked your phone line and set it up for DSL service.
Page 473: Problems With Internet Access
Prestige 653HWI Series User’s Guide Problems with the WAN Interface Chart A-5 Troubleshooting the WAN Interface PROBLEM CORRECTIVE ACTION I cannot get a WAN The ISP provides the WAN IP address after authenticating you. Authentication may IP address from the be through the user name and password, the MAC address or the host name.
Page 474 Prestige 653HWI Series User’s Guide Problems with the Password Chart A-7 Troubleshooting the Password PROBLEM CORRECTIVE ACTION I cannot access the The username is “admin”. The default password is “1234”. The Password and Prestige. Username fields are case-sensitive. Make sure that you enter the correct password and username using the proper casing.
Page 475 Prestige 653HWI Series User’s Guide Problems with Remote Management Chart A-9 Troubleshooting Remote Management PROBLEM CORRECTIVE ACTION I cannot remotely Refer to the Remote Management Limitations section in the Firmware and manage the Configuration File Management chapter (SMT) for scenarios when remote Prestige from the management may not be possible.
Page 477 Prestige 653HWI Series User’s Guide Appendix B IP Subnetting IP Addressing Routers “route” based on the network number. The router that delivers the data packet to the correct destination host uses the host ID. IP Classes An IP address is made up of four octets (eight bits), written in dotted decimal notation, for example, 192.168.1.1.
Page 478: Appendix B Ip Subnetting
Prestige 653HWI Series User’s Guide Since the first octet of a class “A” IP address must contain a “0”, the first octet of a class “A” address can have a value of 0 to 127. Similarly the first octet of a class “B” must begin with “10”, therefore the first octet of a class “B” address has a valid range of 128 to 191.
Page 479 Prestige 653HWI Series User’s Guide Since the mask is always a continuous number of ones beginning from the left, followed by a continuous number of zeros for the remainder of the 32 bit mask, you can simply specify the number of ones instead of writing the value of each octet.
Page 480 Prestige 653HWI Series User’s Guide In the following charts, shaded/bolded last octet bit values indicate host ID bits “borrowed” to form network ID bits. The number of “borrowed” host ID bits determines the number of subnets you can have. The remaining number of host ID bits (after “borrowing”) determines the number of hosts you can have on each subnet.
Page 481 Prestige 653HWI Series User’s Guide The above example illustrated using a 25-bit subnet mask to divide a class “C” address space into two subnets. Similarly to divide a class “C” address into four subnets, you need to “borrow” two host ID bits to give four possible combinations of 00, 01, 10 and 11.
Page 482 Prestige 653HWI Series User’s Guide IP Address 192.168.1. IP Address (Binary) 11000000.10101000.00000001. 11000000 Subnet Mask (Binary) 11111111.11111111.11111111. 11000000 Subnet Address: 192.168.1.192 Lowest Host ID: 192.168.1.193 Broadcast Address: 192.168.1.255 Highest Host ID: 192.168.1.254 Example Eight Subnets Similarly use a 27-bit mask to create 8 subnets (001, 010, 011, 100, 101, 110). The following table shows class C IP address last octet values for each subnet.
Page 483 Prestige 653HWI Series User’s Guide 255.255.255.192 (/26) 255.255.255.224 (/27) 255.255.255.240 (/28) 255.255.255.248 (/29) 255.255.255.252 (/30) 255.255.255.254 (/31) Subnetting With Class A and Class B Networks. For class “A” and class “B” addresses the subnet mask also determines which bits are part of the network number and which are part of the host ID.
Page 484 Prestige 653HWI Series User’s Guide Chart B-13 Class B Subnet Planning NO. “BORROWED” HOST BITS SUBNET MASK NO. SUBNETS NO. HOSTS PER SUBNET (/27) 255.255.255.240 4096 (/28) 255.255.255.248 8192 (/29) 255.255.255.252 16384 (/30) 255.255.255.254 32768 (/31) IP Subnetting...
Page 485 Prestige 653HWI Series User’s Guide Appendix C Wireless LAN and IEEE 802.11 A wireless LAN (WLAN) provides a flexible data communications system that you can use to access various services (navigating the Internet, email, printer services, etc.) without the any expensive network-cabling infrastructure.
Page 486: Infrastructure Wireless Lan Configuration
Prestige 653HWI Series User’s Guide Ad-hoc Wireless LAN Configuration The simplest WLAN configuration is an independent (Ad-hoc) WLAN that connects a set of computers with wireless nodes or stations (STA), which is called a Basic Service Set (BSS). In the most basic form, a wireless LAN connects a set of computers with wireless adapters.
Page 487 Prestige 653HWI Series User’s Guide Diagram C-2 ESS Provides Campus-Wide Coverage Wireless LAN and IEEE 802.11...
Page 489: Appendix D Antenna Selection And Positioning Recommendation
Prestige 653HWI Series User’s Guide Appendix D Antenna Selection and Positioning Recommendation An antenna couples RF signals onto air. A transmitter within a wireless device sends an RF signal to the antenna, which propagates the signal through the air. The antenna also operates in reverse by capturing RF signals from the air.
Page 490: Positioning Antennas
Prestige 653HWI Series User’s Guide • Directional antennas concentrate the RF signal in a beam, like a flashlight. The angle of the beam width determines the direction of the coverage pattern; typically ranges from 20 degrees (less directional) to 90 degrees (very directional). The directional antennas are ideal for hallways and outdoor point-to-point applications.
Page 491: Appendix Epppoe
Prestige 653HWI Series User’s Guide Appendix E PPPoE PPPoE in Action An ADSL modem bridges a PPP session over Ethernet (PPP over Ethernet, RFC 2516) from your PC to an ATM PVC (Permanent Virtual Circuit) that connects to a xDSL Access Concentrator where the PPP session terminates (see the next figure).
Page 492 Prestige 653HWI Series User’s Guide Diagram E-1 Single-PC per Router Hardware Configuration How PPPoE Works The PPPoE driver makes the Ethernet appear as a serial link to the PC and the PC runs PPP over it, while the modem bridges the Ethernet frames to the Access Concentrator (AC). Between the AC and an ISP, the AC is acting as a L2TP (Layer 2 Tunneling Protocol) LAC (L2TP Access Concentrator) and tunnels the PPP frames to the ISP.
Page 493 Prestige 653HWI Series User’s Guide Diagram E-2 Prestige as a PPPoE Client PPPoE...
Page 495: Appendix F Virtual Circuit Topology
Prestige 653HWI Series User’s Guide Appendix F Virtual Circuit Topology ATM is a connection-oriented technology, meaning that it sets up virtual circuits over which end systems communicate. The terminology for virtual circuits is as follows: • Virtual Channel Logical connections between ATM switches •...
Page 497: Appendix G Power Adaptor Specifications
Prestige 653HWI Series User’s Guide Appendix G Power Adaptor Specifications Prestige 653 HWI NORTH AMERICAN PLUG STANDARDS AC Power Adapter Model DV-1215A Input Power AC120Volts/60Hz/30W Output Power AC16Volts/1.25A Power Consumption 14 W Safety Standards UL, CUL, CSA (UL 1310, CSA C22.2 No.223) NORTH AMERICAN PLUG STANDARDS AC Power Adapter Model AA-121A25...
Page 498 Prestige 653HWI Series User’s Guide Power Consumption Safety Standards ITS-GS, CE (EN 60950) Power Adaptor Specifications...
Page 499: Appendix H Example Internal Sptgen Screens
Prestige 653HWI Series User’s Guide Appendix H Example Internal SPTGEN Screens This appendix covers Prestige Internal SPTGEN screens. Abbreviations Used in the Example Internal SPTGEN Screens Table ABBREVIATION MEANING Field Identification Number (not seen in SMT screens) Field Name Parameter Values Allowed INPUT An example of what you may enter The following are Internal SPTGEN screens associated with the SMT screens of your Prestige.
Page 500 Prestige 653HWI Series User’s Guide / MENU 3.1 GENERAL ETHERNET SETUP (SMT MENU 3.1) INPUT 30100001 = Input Protocol filters Set 1 30100002 = Input Protocol filters Set 2 = 256 30100003 = Input Protocol filters Set 3 = 256 The valid 30100004 = Input Protocol filters Set 4...
Page 501 Prestige 653HWI Series User’s Guide 30200008 = IP Address = 172.21.2.200 30200009 = IP Subnet Mask = 16 This 30200010 = RIP Direction <0(None) | 1(Both) | value 2(In Only) | 3(Out must be Only)> between 0-32. 30200011 = Version <0(Rip-1) | 1(Rip-2B) |2(Rip-2M)>...
Page 502 Prestige 653HWI Series User’s Guide 30201010 = IP Alias #1 Outgoing protocol filters = 256 Set 1 30201011 = IP Alias #1 Outgoing protocol filters = 256 Set 2 30201012 = IP Alias #1 Outgoing protocol filters = 256 Set 3 30201013 = IP Alias #1 Outgoing protocol filters = 256...
Page 503 Prestige 653HWI Series User’s Guide 30500002 = Hide ESSID <0(No) | 1(Yes)> 30500003 = Channel ID <1|2|3|4|5|6|7|8|9|10| 11|12|13> 30500004 = RTS Threshold <0 ~ 2432> = 2432 30500005 = FRAG. Threshold <256 ~ 2432> = 2432 30500006 = <0(DISABLE) | 1(64- bit WEP) | 2(128-bit WEP)>...
Page 504 Prestige 653HWI Series User’s Guide 40000005 = Multiplexing <1(LLC-based) | This 2(VC-based) value 40000006 = VPI # must be between 40000007 = VCI # = 35 0-32. 40000008 = Service Name <Str> = any This value 40000009 = My Login <Str>...
Page 505 Prestige 653HWI Series User’s Guide 40000031= RIP Direction <0(None) | 1(Both) | 2(In Only) | 3(Out Only)> 40000032= RIP Version <0(Rip-1) | 1(Rip-2B) |2(Rip-2M)> 40000033= Nailed-up Connection <0(No) |1(Yes)> / MENU 12.1.1 IP STATIC ROUTE SETUP (SMT MENU 12.1.1) INPUT 120101001 = IP Static Route set #1, Name <Str>...
Page 506 Prestige 653HWI Series User’s Guide 120103002 = IP Static Route set #3, Active <0(No) |1(Yes)> 120103003 = IP Static Route set #3, Destination IP = 0.0.0.0 address 120103004 = IP Static Route set #3, Destination IP subnetmask 120103005 = IP Static Route set #3, Gateway = 0.0.0.0 120103006 = IP Static Route set #3, Metric...
Page 507 Prestige 653HWI Series User’s Guide / MENU 12.1.6 IP STATIC ROUTE SETUP (SMT MENU 12.1.6) INPUT 120106001 = IP Static Route set #6, Name <Str> 120106002 = IP Static Route set #6, Active <0(No) |1(Yes)> 120106003 = IP Static Route set #6, Destination IP = 0.0.0.0 address 120106004 =...
Page 508 Prestige 653HWI Series User’s Guide 120108005 = IP Static Route set #8, Gateway = 0.0.0.0 120108006 = IP Static Route set #8, Metric 120108007 = IP Static Route set #8, Private <0(No) |1(Yes)> / MENU 12.1.9 IP STATIC ROUTE SETUP (SMT MENU 12.1.9) INPUT 120109001 = IP Static Route set #9, Name...
Page 509 Prestige 653HWI Series User’s Guide 120111003 = IP Static Route set #11, Destination = 0.0.0.0 IP address 120111004 = IP Static Route set #11, Destination IP subnetmask 120111005 = IP Static Route set #11, Gateway = 0.0.0.0 120111006 = IP Static Route set #11, Metric 120111007 = IP Static Route set #11, Private <0(No) |1(Yes)>...
Page 510 Prestige 653HWI Series User’s Guide INPUT 120114001 = IP Static Route set #14, Name <Str> 120114002 = IP Static Route set #14, Active <0(No) |1(Yes)> 120114003 = IP Static Route set #14, Destination = 0.0.0.0 IP address 120114004 = IP Static Route set #14, Destination IP subnetmask 120114005 = IP Static Route set #14, Gateway...
Page 511 Prestige 653HWI Series User’s Guide 120116006 = IP Static Route set #16, Metric 120116007 = IP Static Route set #16, Private <0(No) |1(Yes)> / MENU 15 SUA SERVER SETUP (SMT MENU 15) INPUT 150000001 = SUA Server IP address for default = 0.0.0.0 port 150000002 =...
Page 512 Prestige 653HWI Series User’s Guide 150000021 = SUA Server #5 Local IP address = 0.0.0.0 150000022 = SUA Server #6 Active <0(No) | 1(Yes)> = 0 150000023 = SUA Server #6 Protocol <0(All)|6(TCP)|17(U DP)> 150000024 = SUA Server #6 Port Start 150000025 = SUA Server #6 Port End 150000026 =...
Page 513 Prestige 653HWI Series User’s Guide 150000046 = SUA Server #10 Local IP address = 0.0.0.0 150000047 = SUA Server #11 Active <0(No) | 1(Yes)> 150000048 = SUA Server #11 Protocol <0(All)|6(TCP)|17(U DP)> 150000049 = SUA Server #11 Port Start 150000050 = SUA Server #11 Port End 150000051 = SUA Server #11 Local IP address...
Page 514 Prestige 653HWI Series User’s Guide 210101009 = IP Filter Set 1,Rule 1 Src Subnet Mask 210101010 = IP Filter Set 1,Rule 1 Src Port 210101011 = IP Filter Set 1,Rule 1 Src Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)> 210101013 = IP Filter Set 1,Rule 1 Act Match <1(check next)|2(forward)|3(dr op)>...
Page 515 Prestige 653HWI Series User’s Guide 210102013 = IP Filter Set 1,Rule 2 Act Match <1(check next)|2(forward)|3(dr op)> 210102014 = IP Filter Set 1,Rule 2 Act Not Match <1(check next)|2(forward)|3(dr op)> / MENU 21.1.1.3 SET #1, RULE #3 (SMT MENU 21.1.1.3) INPUT 210103001 = IP Filter Set 1,Rule 3 Type...
Page 516 Prestige 653HWI Series User’s Guide INPUT 210104001 = IP Filter Set 1,Rule 4 Type <2(TCP/IP)> 210104002 = IP Filter Set 1,Rule 4 Active <0(No)|1(Yes)> 210104003 = IP Filter Set 1,Rule 4 Protocol = 17 210104004 = IP Filter Set 1,Rule 4 Dest IP address = 0.0.0.0 210104005 = IP Filter Set 1,Rule 4 Dest Subnet...
Page 517 Prestige 653HWI Series User’s Guide 210105006 = IP Filter Set 1,Rule 5 Dest Port = 138 210105007 = IP Filter Set 1,Rule 5 Dest Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)> 210105008 = IP Filter Set 1,Rule 5 Src IP Address = 0.0.0.0 210105009 = IP Filter Set 1,Rule 5 Src Subnet Mask...
Page 518 Prestige 653HWI Series User’s Guide 210106010 = IP Filter Set 1,Rule 6 Src Port 210106011 = IP Filter Set 1,Rule 6 Src Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)> 210106013 = IP Filter Set 1,Rule 6 Act Match <1(check next)|2(forward)|3(dr op)> 210106014 = IP Filter Set 1,Rule 6 Act Not Match <1(check next)|2(forward)|3(dr...
Page 519 Prestige 653HWI Series User’s Guide 210201011 = IP Filter Set 2, Rule 1 Src Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)> 210201013 = IP Filter Set 2, Rule 1 Act Match <1(check next)|2(forward)|3(dr op)> 210201014 = IP Filter Set 2, Rule 1 Act Not Match <1(check next)|2(forward)|3(dr op)>...
Page 520 Prestige 653HWI Series User’s Guide 210202014 = IP Filter Set 2, Rule 2 Act Not Match <1(check next)|2(forward)|3(dr op)> / MENU 21.1.2.3 FILTER SET #2, RULE #3 (SMT MENU 21.1.2.3) INPUT 210203001 = IP Filter Set 2, Rule 3 Type <0(none)|2(TCP/IP)>...
Page 521 Prestige 653HWI Series User’s Guide 210204002 = IP Filter Set 2, Rule 4 Active <0(No)|1(Yes)> = 1 210204003 = IP Filter Set 2, Rule 4 Protocol = 17 210204004 = IP Filter Set 2, Rule 4 Dest IP = 0.0.0.0 address 210204005 = IP Filter Set 2, Rule 4 Dest Subnet...
Page 522 Prestige 653HWI Series User’s Guide 210205006 = IP Filter Set 2, Rule 5 Dest Port = 138 210205007 = IP Filter Set 2, Rule 5 Dest Port <0(none)|1(equal)|2( Comp equal)|3(less)|4(great er)> 210205008 = IP Filter Set 2, Rule 5 Src IP address = 0.0.0.0 210205009 = IP Filter Set 2, Rule 5 Src Subnet...
Page 523 Prestige 653HWI Series User’s Guide 210206009 = IP Filter Set 2, Rule 6 Src Subnet Mask 210206010 = IP Filter Set 2, Rule 6 Src Port 210206011 = IP Filter Set 2, Rule 6 Src Port Comp <0(none)|1(equal)|2( equal)|3(less)|4(great er)> 210206013 = IP Filter Set 2,Rule 6 Act Match <1(check...
Page 524: Command Examples
Prestige 653HWI Series User’s Guide 230400003 = Idle Timeout (in second) = 999 230400004 = Authentication Databases <0(Local User Database Only) |1(RADIUS Only) |2(Local,RADIUS) |3(RADIUS,Local)> / MENU 24.11 REMOTE MANAGEMENT CONTROL (SMT MENU 24.11) INPUT These 241100001 = TELNET Server Port = 23 values must be...
Page 525: Appendix I Setting Up Your Computer's Ip Address
Prestige 653HWI Series User’s Guide Appendix I Setting up Your Computer’s IP Address All computers must have a 10M or 100M Ethernet adapter card and TCP/IP installed. Windows 95/98/Me/NT/2000/XP, Macintosh OS 7 and later operating systems and all versions of UNIX/LINUX include the software components you need to install and use TCP/IP on your computer.
Page 526: Installing Components
Prestige 653HWI Series User’s Guide Installing Components The Network window Configuration tab displays a list of installed components. You need a network adapter, the TCP/IP protocol and Client for Microsoft Networks. If you need the adapter: In the Network window, click Add. Select Adapter and then click Add.
Page 527 Prestige 653HWI Series User’s Guide Click the IP Address tab. -If your IP address is dynamic, select Obtain an IP address automatically. -If you have a static IP address, select Specify an IP address and type your information into the IP Address and Subnet Mask fields. Click the DNS Configuration tab.
Page 528: Verifying Settings
Prestige 653HWI Series User’s Guide Click the Gateway tab. -If you do not know your gateway’s IP address, remove previously installed gateways. -If you have a gateway IP address, type it in the New gateway field and click Add. Click OK to save and close the TCP/IP Properties window. Click OK to close the Network window.
Page 529 Prestige 653HWI Series User’s Guide Windows 2000/NT/XP For Windows XP, click start, Control Panel. In Windows 2000/NT, click Start, Settings, Control Panel. For Windows XP, click Network Right-click Local Area Connection and Connections. For Windows 2000/NT, click then click Properties. Network and Dial-up Connections.
Page 530 Prestige 653HWI Series User’s Guide Select Internet Protocol (TCP/IP) (under the General tab in Win XP) and click Properties. The Internet Protocol TCP/IP Properties window opens (the General tab in Windows XP). -If you have a dynamic IP address click Obtain an IP address automatically.
Page 531 Prestige 653HWI Series User’s Guide -If you do not know your gateway's IP address, remove any previously installed gateways in the IP Settings tab and click OK. Do one or more of the following if you want to configure additional IP addresses: -In the IP Settings tab, in IP addresses, click Add.
Page 532 Prestige 653HWI Series User’s Guide In the Internet Protocol TCP/IP Properties window (the General tab in Windows XP): -Click Obtain DNS server address automatically if you do not know your DNS server IP address(es). -If you know your DNS server IP address(es), click Use the following DNS server addresses, and type them in the Preferred DNS server and Alternate DNS server fields.
Page 533 Prestige 653HWI Series User’s Guide Macintosh OS 8/9 Click the Apple menu, Control Panel and double-click TCP/IP to open the TCP/IP Control Panel. Select Ethernet built-in from the Connect via list. Setting up Your Computer’s IP Address...
Page 534 Prestige 653HWI Series User’s Guide For dynamically assigned settings, select Using DHCP Server from the Configure: list. For statically assigned settings, do the following: -From the Configure box, select Manually. -Type your IP address in the IP Address box. -Type your subnet mask in the Subnet mask box. -Type the IP address of your Prestige in the Router address box.
Page 535 Prestige 653HWI Series User’s Guide Click Network in the icon bar. - Select Automatic from the Location list. - Select Built-in Ethernet from the Show list. - Click the TCP/IP tab. For dynamically assigned settings, select Using DHCP from the Configure list. For statically assigned settings, do the following: -From the Configure box, select Manually.
Page 537: Appendix J Splitters And Microfilters
Prestige 653HWI Series User’s Guide Appendix J Splitters and Microfilters This appendix tells you how to install a POTS splitter or a telephone microfilter. Connecting a POTS Splitter When you use the Full Rate (G.dmt) ADSL standard, you can use a POTS (Plain Old Telephone Service) splitter to separate the telephone and ADSL signals.
Page 538 Prestige 653HWI Series User’s Guide Step 1. Connect a phone cable from the wall jack to the single jack end of the Y- Connector. Step 2. Connect a cable from the double jack end of the Y-Connector to the “wall side” of the microfilter. Step 3.
Page 539 Prestige 653HWI Series User’s Guide Splitters and Microfilters...
Page 541: Appendix K Log Descriptions
Prestige 653HWI Series User’s Guide Appendix K Log Descriptions This appendix provides descriptions of example log messages Chart K-1 System Maintenance Logs LOG MESSAGE DESCRIPTION Time calibration is The router has adjusted its time based on information from the time server.
Page 542 Prestige 653HWI Series User’s Guide Chart K-2 UPnP Logs LOG MESSAGE DESCRIPTION UPnP pass through UPnP packets can pass through the firewall. Firewall For the content filtering logs “(Destination)” means the destination IP address or domain name. Chart K-3 Content Filtering Logs MESSAGE NOTE DESCRIPTION...
Page 543 Prestige 653HWI Series User’s Guide Chart K-4 Attack Logs LOG MESSAGE DESCRIPTION attack (Protocol) The firewall detected an attack. The log may also display the protocol (for example TCP or UDP). land Protocol) The firewall detected a land attack. The log may also display the protocol (for example TCP or UDP).
Page 544 Prestige 653HWI Series User’s Guide Chart K-5 Access Logs LOG MESSAGE DESCRIPTION Firewall default Access matched the default policy and the Prestige blocked or forwarded it according to the configuration of the default firewall policy (Protocol, policy. Direction) Firewall rule match Access matched a firewall rule and the Prestige blocked or forwarded it according to the rule’s configuration.
Page 545 Prestige 653HWI Series User’s Guide Chart K-5 Access Logs LOG MESSAGE DESCRIPTION Out of order TCP The router blocked a TCP handshake packet that came out of the proper order handshake packet blocked (Protocol) Unsupported/out-of- The Prestige generates this log after it drops an ICMP packet due to one of the following two reasons: order ICMP (Protocol) 1.
Page 546 Prestige 653HWI Series User’s Guide Chart K-7 ICMP Notes TYPE CODE DESCRIPTION A packet that needed fragmentation was dropped because it was set to Don't Fragment (DF) Source route failed Source Quench A gateway may discard internet datagrams if it does not have the buffer space needed to queue the datagrams for output to the next network on the route to the destination network.
Page 547 Prestige 653HWI Series User’s Guide Chart K-7 ICMP Notes TYPE CODE DESCRIPTION Information reply message VPN/IPSec logs To view the IPSec and IKE connection log, type 3 in menu 27 and press [ENTER] to display the IPSec log as shown next. The following figure shows a typical log from the initiator of a VPN connection. Index: Date/Time: Log:...
Page 548 Prestige 653HWI Series User’s Guide Index: Date/Time: Log: ------------------------------------------------------------ 01 Jan 08:08:07 Recv Main Mode request from <192.168.100.100> 01 Jan 08:08:07 Recv:<SA> 01 Jan 08:08:08 Send:<SA> 01 Jan 08:08:08 Recv:<KE><NONCE> 01 Jan 08:08:10 Send:<KE><NONCE> 01 Jan 08:08:10 Recv:<ID><HASH> 01 Jan 08:08:10 Send:<ID><HASH>...
Page 549 Prestige 653HWI Series User’s Guide Chart K-8 Sample IKE Key Exchange Logs LOG MESSAGE DESCRIPTION Start Phase 2: Quick Mode Phase 2 negotiation is begins by using Quick Mode. !! IKE Negotiation is in process The Prestige has begun negotiation with the peer for the connection already, but the IKE key exchange has not finished yet.
Page 550 Prestige 653HWI Series User’s Guide Chart K-8 Sample IKE Key Exchange Logs LOG MESSAGE DESCRIPTION !! Too many errors! Deleting SA The Prestige deletes an SA when too many errors occur. !! ID type mismatch The ID type of an incoming packet does not match the local's peer ID type.
Page 551 Prestige 653HWI Series User’s Guide Chart K-9 Sample IPSec Logs During Packet Transmission LOG MESSAGE DESCRIPTION !! Discard REPLAY packet If the Prestige receives a packet with the wrong sequence number it will discard it. !! Inbound packet The authentication configuration settings are incorrect. Please authentication failed check them.
Page 553: Appendix L Index
Prestige 653HWI Series User’s Guide Appendix L Index 802.1x Configuration ........6-10 Backup ............38-2 Bandwidth Borrowing ........21-7 Bandwidth Class ..........21-1 Bandwidth Filter ......... 21-1, 21-15 Action for Matched Packets ......13-12 Bandwidth Management ......1-4, 21-1 Active..........25-11, 25-13 Bandwidth Management Statistics....
Page 554 Prestige 653HWI Series User’s Guide PPPoE............42-3 Precedence..........42-1 data compression ..........1-3 Precedence Example....See precedence Data decryption ..........6-4 caller ID ............25-6 Data encryption ..........6-4 Calling Line Indication ........25-6 Data Filtering..........34-1 CDR............... 37-7 Data Link Connection........25-7 CDR (Call Detail Record)......37-6 Default Policy Log .........13-6 Channel ID.............
Page 555 Prestige 653HWI Series User’s Guide Sample ............. 34-17 SUA............34-15 EAP..............6-8 TCP/IP Filter Rule........34-9 EAP Authentication Sequence ......6-9 Filter Configuration ........34-1 ECHO............... 8-7 Filter Log ..........37-7, 37-8 Edit IP ............25-12 Filter Rule ............ 34-10 E-mail Filter Rule Process.........
Page 556 Prestige 653HWI Series User’s Guide SMT Menus..........33-1 IEEE 802.11 ............ C-1 Types ............11-1 IGMP..............5-3 When To Use........... 11-13 IGMP support ........25-16, 29-7 Firewalls ............11-1 IKE ..............13-8 Firmware File IKE Setup .............43-11 Maintenance ..........22-14 Incoming Call Support ........1-4 Fragment Threshold........
Page 557 Prestige 653HWI Series User’s Guide IP Policies ............41-5 IP Policy Routing (IPPR)......1-6, 28-1 LAN............... 37-3 Applying an IP Policy........ 41-5 LAN Configuration.......... 5-4 Ethernet IP Policies........41-5 LAN Interface Gateway ............. 41-5 Troubleshooting...........A-2 IP Pool Setup..........3-12 LAN Setup..........5-1, 26-1 IP Ports..........
Page 558 Prestige 653HWI Series User’s Guide Microfilters ............J-1 Networking Compatibility........1-6 MSN .............. 13-8 NEWS.............13-8 Multicast .......5-3, 5-5, 25-16, 29-7 NFS..............13-8 MULTICAST ..........13-8 NNTP ............. 8-7, 13-9 Multilink ..........1-3, 7-6, 7-9 Multiple PVC........... 1-5 Multiplexing One-Minute High ...........12-3 LLC-based ........... 3-2 Outgoing Calling Party Number.....25-6 VC-based .............
Page 559 Prestige 653HWI Series User’s Guide PPP Multilink........... 1-3 Remote Management Setup ......40-1 PPPoA............29-2 Remote Node ........29-1, 37-2 PPPoE ..............E-1 Network Layer........... 29-5 PPPoE Support (RFC2516)......1-4 Remote Node Profile ......... 29-3 PPTP ............8-7, 13-9 Remote Node Setup......29-1, 29-2 PPTP TUNNEL ..........
Page 560 Prestige 653HWI Series User’s Guide SPTGEN Screens ..........H-1 SQL-NET ............13-9 SA Monitor ............ 44-1 SSH..............13-9 Sample IP Addresses ........29-8 Stac data compression ........1-3 Saving the State ..........11-7 Start-Up Schedule Sets Troubleshooting ..........A-1 Duration............. 42-2 Stateful Inspection ..1-2, 11-1, 11-2, 11-7, 11-8 Scheduler ..........
Page 561 Prestige 653HWI Series User’s Guide System Parameter Table Generator....45-1 System Status ..........37-2 UDP/ICMP Security ........11-10 System Timeout ........18-2, 40-3 Universal Plug and Play......... 19-1 Application ..........19-1 Security issues ........... 19-1 TACACS............13-10 Universal Plug and Play (UPnP)...... 1-4 TCP Maximum Incomplete......
Page 562 WEP..............6-4 WEP..............6-4 ZyNOS ..........38-1, 38-2 WEP Encryption ..........27-2 ZyNOS F/W Version........38-1 Windows 2000/NT/XP ........I-5 ZyXEL Limited Warranty Windows 95/98/Me .......... I-1 Note..............iv WIRED EQUIVALENT PRIVACY ....6-3 ZyXEL’s Firewall Wireless Channel ..........6-1 Introduction..........11-2 Wireless LAN .........

This manual is also suitable for:

Prestige 653hwi series
