Duraflame DFS-7515-01 Manual

MODEL: DFS-7515-01, DFS-7515-02, DFS-7515-03, DFS-7515-05,
Go to tsicustomerservice.com for product warranty registration
OPERATING INSTRUCTIONS
Back view
Front view
ICON
FUNCTION
The Power switch supplies power to all of the functions of the Fire Cube including the
ame effect and heater.
Main Power Switch
NOTE:Main Power must be turned to ON for the heat to be used.
Heater Settings The power Switch must be in the ON position to use the heater.
0: Heater off
750W:
1500W:
BULB REPLACEMENT
2
1
2. Remove back panel to access
1. Remove the Phillips head screws.
light bulb.
Light bulb retaining spring
3 4
3. Remove the rotation axis in the 3. Pull away the bulb retaining spring,
direction of the arrow. unscrew the old bulb, and replace
with a new 40w candelabra bulb.
Manufactured and distributed by Twin-Star International, Inc., under license from
Duraflame, Inc. duraflame, the flame symbol and logo are registered trademarks of
Duraflame, Inc.
DFS-7515-D988, DFS-7515-23
Control Panel
Location
Control Panel
DESCRIPTION
Low heat setting, 750 Watts.
High heat setting, 1500 Watts..
PRODUCT SPECIFICATIONS
120 VAC, 60 Hz
VOLTAGE
AMPS
WATTS
For Customer Service:
tsicustomerservice.com
1-888-674-7517
8:30 a.m. - 5:30 p.m., EST, Monday - Friday
Light bulb retaining spring
Note: When rst running the heater there may
be an odor. This is normal as the heater has a
surface coating on the internal parts. For the
rst several hours of operation, the coating
Light bulb retaining spring reacts with the internal parts to permanently
protect them. The odor is safe; if you are
Pull
sensitive to the odor, it is recommended
to run the heater in a well-ventilated area until
the odor dissipates.
Pull
Warning: This is an unvented, electric appliance.
DO NOT attempt to burn wood or manufactured
relogs in or on this appliance or grate.
© 2024, Twin-Star International, Inc.
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the risk of re, electrical shock, injury to persons, and hyperthermia,
including the following:
1. Read all instructions before using this appliance.
2. This appliance is hot when in use. To avoid burns, do not let bare skin touch
hot surfaces. If provided, use handles when moving this appliance. Keep
combustible materials, such as furniture, pillows, bedding, papers, clothes and
curtains at least 3 feet (0.9 m) from the front of this appliance. WARNING: In
order to avoid overheating, do not cover the heater.
3. CAUTION: Never leave the heater operating unattended. Extreme caution is
necessary if unsupervised children or invalids are nearby.
4. The appliance is not to be used by children or persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction.
5. Children being supervised not to play with the appliance.
6. If possible, always unplug this appliance when not in use.
7. Do not operate any heater with a damaged cord or plug or after the
appliance malfunctions, or if it has been dropped or damaged in any manner.
8. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly quali ed persons in order to avoid a hazard.
9. Any repairs to this replace should be carried out by a quali ed service
person.
10. Under no circumstance should this replace be modi ed. Parts having to be
removed for servicing must be replaced prior to operating this replace again.
11. Do not use outdoors.
12. This appliance is not intended for use in bathrooms, laundry areas and similar
indoor locations. Never locate heater where it may fall into a bathtub or other
water container.
13. Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not route cord under furniture or appliances. Arrange
cord away from traf c area and where it will not be tripped over.
14. To disconnect this appliance, turn controls to the off position, then remove plug
from outlet.
15. Connect to properly grounded outlets only.
16. There is a thermostat limiter inside the heater. When the inner temperature
over-heats or abnormal heating occurs, the thermostat protective device would
cut off power supply to prevent damage or risk of re.
17. The heaters must not be located immediately below a socket-outlet.
12.5 Amps
1500 Watts
1-YEAR LIMITED WARRANTY
The manufacturer warrants that your new Electric Stove is free from manufacturing and material defects for a period of one year from date
of puchase, subject to the following conditions and limitations.
1. Install and operate this Electric Stove in accordance with the installation and operating instructions furnished with the product at all times.
Any unauthorized repair, alteration, willful abuse, accident, or misuse of the product shall nullify this warranty.
2. This warranty is non-transferable, and is made to the original owner, provided that the purchase was made through an authorized sup-
plier of the product.
3. The warranty is limited to the repair or replacement of part(s) found to be defective in material or workmanship, provided that such part(s)
have been subjected to normal conditions of use and service, after said defect is con rmed by the manufacturer's inspection.
4. The manufacturer may, at its discretion, fully discharge all obligations with respect to this warranty by refunding the wholesale price of
the defective part(s).
5. Any installation, labor, construction, transportation, or other related costs/expenses arising from defective part(s), repair, replacement, or
otherwise of same, will not be covered by this warranty, nor shall the manufacturer assume responsibility for same.
6. The owner/user assumes all other risks, if any, including the risk of any direct, indirect or consequential loss or damage arising out of the
use, or inability to use the product, except as provided by law.
7. All other warranties – expressed or implied –with respect to the product, its components and accessories, or any obligations/liabilities on
the part of the manufacturer are hereby expressly excluded.
8. The manufacturer neither assumes, nor authorizes any third party to assume on its behalf, any other liabilities with respect to the sale of
the product.
9. The warranties as outlined within this document do not apply to non accessories used in conjunction with the installation of this product.
10.This warranty gives you speci c legal rights, and you may also have other rights which vary from state to state.
This warranty is void if:
a. The replace is subjected to prolonged periods of dampness or condensation.
b. Any unauthorized alteration, willful abuse, accident, or misuse of the product.
c. You do not have the original receipt of purchase.
IF WARRANTY SERVICE IS NEEDED
Contact the manufacturer by calling customer service department at 1-888-674-7517. Our Consumer Service department is available
Monday – Friday 8:30 am – 5:30 pm EST. Make sure you have your warranty, your sales receipt, location of purchase and the model/
serial number of your product.
Boca Raton, FL 33487
18. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as
this may cause an electric shock or re, or damage the appliance.
19. To prevent a possible re, do not block air intakes or exhaust in any manner. Do not
use on soft surfaces, like a bed, where opening may become blocked.
20. This appliance has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, paint, or ammable liquids are used or stored.
21. Use this appliance only as described in the manual. Any other use not recommended
by the manufacturer may cause re, electric shock or injury to persons.
22. This product is equipped with a polarized plug (one blade is wider than the other
blade). To reduce the risk of electrical shock, this plug will t into a polarized outlet
only one way. This is a safety feature. If you are unable to insert the plug into the
electrical outlet, try reversing the plug. If the plug still does not t, contact a quali ed
electrician. Always plug heaters directly into a wall outlet/ receptacle.Never use with
an extension cord or relocatable power tap( oulet/power strip).
23. Hyperthermia can result in death. Symptoms of hyperthermia include high body
temperature, headache, nausea, vomiting, tiredness, dizziness, fainting, and rapid
pulse. If you begin to experience symptoms related to hyperthermia, turn off the heater
and seek medical attention.
24. To avoid excessive room temperatures which can cause hyperthermia: DO NOT leave
product running unattended in a con ned space around infants, or individuals with
reduced physical, sensory, or mental capabilities.
SAVE THESE INSTRUCTIONS
C240
