- Page 1 DFI-7614-01...
-
Page 2: Getting Started
GETTING STARTED 1. The serial number is located on the back of the stove, the serial number is necessary for product warranty registration and customer service. SEE OWNERS MANUAL FOR SERVICE DETAILS MOVABLE HEATER/ WARNING: DISCONNECT POWER BEFORE CLEANING OR SERVICING MEUBLE CHAUFFANT/ CAUTION: CALENTADOR DE MUEBLES... - Page 3 REGISTER YOUR NEW PURCHASE online! Thank you for purchasing our product. Please take a moment to visit tsicustomerservice.com to register your new purchase: tsicustomerservice.com Customer Service Portal Twin-Star Customer Service online resource to Order Parts, Product Registration, and to request Product and General Information Login DON’T FORGET TO REGISTER YOUR PRODUCT...
-
Page 4: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons including the following: 1. Read all instructions before using this appliance. 2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. - Page 5 13. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage the appliance. 14. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft surfaces, like a bed, where opening may become blocked.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Tools Required for Assembly Phillips Head Screwdriver Leg Assembly Bracket 1. Align the mounting tab into the 2. Fasten the leg to the bracket using bracket and lower the leg into the included screws, 3 per leg. place. (Fig 1) 3.Fasten the other 3 legs to the bracket. - Page 7 OPERATION INSTRUCTIONS Remote Receiver Control Panel Location Control Panel Remote Control NOTE: Please operate the remote transmitter at a slow measured pace. Press the remote control buttons with an even motion and gentle pressure. Repeatedly pressing buttons in rapid succession may cause the transmitter to malfunction. B203...
- Page 8 FUNCTION FUNCTION DESCRIPTION ICON POWER The power button supplies power to all of the stove functions. The power button will put the stove in a standby mode. This will turn off all functions at once, but will hold the settings in the memory. By pressing the Power button again, the unit will turn on with the retained settings.
- Page 9 Pressing the timer button will cycle TIMER through the timer settings: 30 minutes, 1 Hour, 2H, 3H, 4H, 5H, 6H, 7H, 8H, 9H and off (00). Press this button to turn on/off HEATER BOOST heater boost. “HI” will appear on the display when it is on and will not display while it is off.
-
Page 10: Troubleshooting
TROUBLESHOOTING PROBLEM ROOT CAUSE CORRECTIVE ACTION Unplug the fireplace, remove Display shows “ ”. The thermostat sensor is the back panel of the broken or disconnected. fireplace and check that the thermostat is plugged into the main circuit board. If this does not solve the problem contact customer service for a replacement thermostat... - Page 11 Replace flame generator Defective flame generator Flames are not moving. drive motor. drive motor. Remove the back panel and Spinner detached from the check to see if “spinner” is motor. correctly mounted to the motor. Press flame button several Logs glow, but no flame Flame effect turned off.
- Page 12 Is it safe to place unit Product Inquiry. It is safe to place unit on carpet, on carpet? but make sure any flammable items are at least 3 feet away from front and sides of the unit. How many square feet Product Inquiry.
-
Page 13: Replacement Parts
REPLACEMENT PARTS PART PART NAME PART NUMBER Door Pull Y19-S280-RH Control Panel Circuit Board Y19-S280-P32 Stove legs Y19-S280-SL Main Circuit Board Y19-S280-P15 Heater/Blower Assembly Y18-S259-P01 Flame Generator Drive Motor Y18-S259-P10 Thermostat Sensor NTC-5010 Remote control P179 EXPLODED VIEW B203... -
Page 14: Fcc/Ic Information
FCC/IC INFORMATION Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 15: Battery Replacement
BATTERY REPLACEMENT NOTE: Do not mix old and new batteries. Do not mix alkaline, standard (carbon zinc), or rechargeable (nicad, ni-mh, etc.) batteries. Note: Note: Battery disposal Battery disposal Please always dispose of batteries Please always dispose of batteries at a suitable recycling point. at a suitable recycling point. -
Page 16: Year Limited Warranty
1-YEAR LIMITED WARRANTY The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. 1. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times. -
Page 17: Customer Service
Before contacting Customer Service, please have this information available: • Serial Number • Model Number • Sales Receipt or Proof of Purchase Manufactured and distributed by Twin-Star International, Inc., under license from Duraflame, Inc. duraflame, the flame symbol and logo are registered trademarks of Duraflame, Inc. 1-800-318-9373 tsicustomerservice.com...
