Everwin MCN40B Operation And Maintenance Manual

Pneumatic joist hanger nailer
Hide thumbs

Advertisement

Quick Links

Download this manual
TOUGHER FASTER SMARTER
Pneumatic Joist Hanger Nailer
Pneumatic Joist Hanger Nailer
MCN40B / MCN65 / MCN65LM
OPERATIONS and MAINTENANCE MANUAL
!
WARNING:
BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD READ AND
STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY
WARNINGS AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE
REV April 22, 2024
TOOL FOR FUTURE REFERENCE.
108684

Advertisement

loading
Need help?

Need help?

Do you have a question about the MCN40B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Everwin MCN40B

Summary of Contents for Everwin MCN40B

  • Page 1 TOUGHER FASTER SMARTER Pneumatic Joist Hanger Nailer Pneumatic Joist Hanger Nailer MCN40B / MCN65 / MCN65LM OPERATIONS and MAINTENANCE MANUAL WARNING: BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD READ AND STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE REV April 22, 2024 TOOL FOR FUTURE REFERENCE.
  • Page 2 NOTE Additional safety measures may be required because of your particular application of the tool. Contact your EVERWIN representative or distributor with any questions concerning the tool and its use.
  • Page 3 (as a gauge for the tool’s age), and photos/videos of the defect for test and evaluation to find root causes. EVERWIN’s analyst will judge the issuance of defective parts and will.
  • Page 4 EVERWIN PNEUMATIC CORP. förklarar härmed att produkten överensstämmer med följande normer och direktiv 2006/42/EC och SS-EN ISO 11148-13:2018. SAMSVARSERKLÆRING / CE Deklaration NORSK EVERWIN PNEUMATIC CORP. erklærer herved att produktet er i samsvar med følgende normer og direktiv 2006/42 EC og NS- EN ISO 11148-13:2018. Todistus CE standardinmukaisuudesta FINSK EVERWIN PNEUMATIC CORP.
  • Page 5 SAFETY INSTRUCTIONS TO AVOID SEVERE PERSONAL INJURY OR PROPERTY DAMAGE Before operating this tool, all operators should read and study this manual to understand and follow the safety warnings and instructions. Failure to follow warnings could result in death or serious injury. Keep these instructions with the tool for future reference.
  • Page 6 SAFETY INSTRUCTIONS FASTENER LOADING When loading the tool: 1.) Never place a hand or any part of body in the fastener discharge area of the tool; 2.) Never point the tool at anyone; 3.) Do not pull the trigger or depress the trip as accidental actuation may occur, causing injury.
  • Page 7 EVERWIN fasteners driving tools consist of: tool and fasteners. In the ．Keep bystanders away (when working in an area where there is a interests of operator and system safety, the tool and fasteners referred to likelihood of through traffic of people).
  • Page 8 EVERWIN PNEUMATIC CORP. ．Wear warm clothing when working in cold conditions, keep your hands ．Use only lubricants recommended by EVERWIN PNEUMATIC CORP. warm and dry. slippery surfaces caused by use of the tool and also trip hazards caused ．If you experience numbness, tingling, pain, or whitening of the skin in...
  • Page 9 SPECIFICATIONS AND TECHNICAL DATA SPECIFICATIONS Model MCN40B MCN65 MCN65LM Height 275mm (10.8") 312mm (12.3") 312mm (12.3") Width 92mm (3.6") 135.5mm (5.35") 141.5mm (5.6") Length 298mm (11.7") 315mm (12.4") 434.5mm (17.1") Weight 2.0 kgs (4.4 lbs) 2.55 kgs (5.61 lbs) 2.8 kgs (6.2 lbs)
  • Page 10 SPECIFICATIONS AND TECHNICAL DATA AIR CONSUMPTION Tool air consumption: MCN40B-1.32 liter/second (2.79 cfm), MCN65,MCN65LM-1.7 liter/second (3.6 cfm) of free air to operate at the rate of 100 nails per minute, at 6.3 bar (90 PSI). NOISE A-weighted single-event sound power level LWA, 1s: MCN40B-108.5, MCN65,MCN65LM-104.3 dBA.
  • Page 11 Refer to Operation Instructions and warnings pages before proceeding to use this tool. There is one available system in these tools : Sequential Trip (available system on : MCN40B-ST, MCN65-ST, MCN65LM-ST) Sequential Trip The Sequential Fire mechanism gets its name from the “sequence” required to drive a Identified by silver Trigger fastener.
  • Page 12 OPERATION : AIR SUPPLY AND CONNECTIONS DO NOT USE OXYGEN, COMBUSTIBLE GASES, OR BOTTLED GASES AS A POWER SOURCE FOR THIS TOOL AS TOOL MAY EXPLODE, POSSIBLY CAUSING INJURY. FITTINGS Install a male plug on the tool which is free flowing and which will release air pressure from the tool when disconnected from the supply source.
  • Page 13 OPERATION : LUBRICATION Frequent, but not excessive, lubrication is required for best performance. Air - tool oil added through the air line connection will lubricate the internal parts. Do not use detergent oil or additives as these lubricants will cause accelerated wear to the seals and bumpers in the tool, resulting in poor tool performance and frequent tool maintenance.
  • Page 14 OPERATION : FASTENER LOADING AND UNLOADING EYE PROTECTION Which conforms to ANSI/ CE specifications and provides protection against flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and others in the work area when connecting to air supply, loading, operating, or servicing this tool.
  • Page 15 OPERATION : FASTENER LOADING AND UNLOADING Unloading the Tool Depress the pusher tab to disengage Slowly slide the pusher forward. pusher from the nails. Remove the nails by releasing the pusher spring and the check pawl located on the side of the nose, then slide the nails backwards. Depress the magazine tab.
  • Page 16 There is one available system in these tools : Sequential Trip (available system on : MCN40B-ST, MCN65-ST, MCN65LM-ST) To operate the tool in this manner, first position the contact trip on the work surface, WITHOUT PULLING THE TRIGGER. Depress the contact trip until the nose touches the work surface and then pull the trigger to drive a fastener. Do not press the tool against the work with extra force.
  • Page 17 OPERATION : TOOL OPERATION CHECK CAUTION Remove all fasteners from tool before performing tool operation check. Sequential Trip Operation a. Press the contact trip against the work surface, without touching the trigger. a. The tool MUST NOT cycle. b. Hold the tool off the work surface, and pull the trigger. b.
  • Page 18 Push and rotate the Trigger Lock Dial to the trigger free position before driving nails. Trigger Lock Dial Trigger Lock Mechaism LOCK (MCN40B only) PUSH UNLOC K Direction of the exhaust air is changed by rotating exhaust cover by hand.
  • Page 19 Always extend the driver the minimum required to allow redressing to restore the driving end; several redressings will be possible before this maximum depth is reached. Standard Length MCN40B : 124.9mm (4.92") MCN65 / MCN65LM : 159.3mm (6.27") TROUBLESHOOTING/REPAIRS The troubleshooting and / or repairs shall be carried out only by the authorized dealer / distributor or by other pneumatic tool specialists.

This manual is also suitable for:

Mcn65Mcn65lm
