Everwin MCN40 Operation And Maintenance Manual

Pneumatic joist hanger nailer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD READ AND STUDY
THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND
INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE
REFERENCE.
MCN40
Pneumatic Joist Hanger Nailer
OPERATIONS and MAINTENANCE MANUAL
CE DECLARATION OF CONFORMITY
Everwin Pneumatic Corp.





19'/3/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCN40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Everwin MCN40

Summary of Contents for Everwin MCN40

  • Page 1     BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD READ AND STUDY   THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE.       19’/3/19 Everwin Pneumatic Corp.

  • Page 2: Table Of Contents

    NOTE: Additional safety measures may be required because of your particular application of the tool. Contact your EVERWIN representative or distributor with any questions concerning the tool and its use. Everwin Pneumatic Corp., Taichung City, Taiwan 41353.

  • Page 3: 1-Year Limited Warranty

    (as a gauge for the tool’s age) and photos/videos of the defect for test and evaluation to find root causes. EVERWIN’s analyst will judge the issuance of defective parts and will replace at no charge if evaluation results show that the root cause is defect in material and/or workmanship.

  • Page 4: Ce Declaration Of Conformity

    Europäischen Richtlinien 2006/42/EC und den Europäischen Norm EN 792-13. CE Déclaration de conformité FRANCAIS EVERWIN PNEUMATIC CORP. déclare et prend sur soi toute la responsabilité de cette déclaration, que le produit est en conformité avec les Directives Européennes 2006/42/EC et avec la norme harmonisée EN 792-13. CE konformiteitsverklaring NEDERLANDS EVERWIN PNEUMATIC CORP.

  • Page 5: Safety Instructions

    SAFETY INSTRUCTIONS TO AVOID SEVERE PERSONAL INJURY OR PROPERTY DAMAGE   BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD READ AND STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. FAILURE TO FOLLOW WARNINGS COULD RESULT IN DEATH OR SERIOUS INJURY. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE.

  • Page 6: Specifications And Technical Data

    SPECIFICATIONS AND TECHNICAL DATA SPECIFICATIONS HEIGHT 10.8" (275 mm) WIDTH 3.6" (92 mm) LENGTH 11.7" (298 mm) WEIGHT 4.4 lbs. (2.0 kg) RECOMMENDED OPER. PRESSURE 70 to 120 PSI (5 to 8 bar) LOADING CAPACITY 33 Nails AIR CONSUMPTION 3.8 cfm (1.8 liter/sec) at 90 PSI (6 bar) press. FASTENER SPECIFICATIONS NAIL LENGTH 1-1/2”...

  • Page 7: Operation

    OPERATION Refer to Operation Instructions and warnings on pages before proceeding to use this tool. THIS TOOL IS EQUIPPED WITH ONE OPERATION MODE   SEQUENTIAL FIRE OPERATION MECHANISM The Sequential Fire mechanism gets its name from the “sequence” required to drive a fastener. To drive a fastener, the operator must first place the tip of the nail into the joist hanger plate hole.

  • Page 8: Air Supply And Connections: Fittings, Hoses, Filters, Air Consumption, Regulators, Supply Source

    AIR SUPPLY AND CONNECTIONS DO NOT USE OXYGEN, COMBUSTIBLE GASES, OR BOTTLED GASES AS A POWER SOURCE FOR THIS TOOL AS TOOL MAY EXPLODE, POSSIBLY CAUSING INJURY. FITTINGS: Install a male plug on the tool which is free flowing and which will release air pressure from the tool when disconnected from the supply source.

  • Page 9: Nail Loading

    NAIL LOADING EYE PROTECTION which conforms to ANSI/ CE specifications and provides protection against flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and others in the work area when connecting to air supply, loading, operating or servicing this tool. Eye protection is required to guard against flying fasteners and debris, which could cause severe eye injury.
  • Page 12 TRIGGER LOCK MECHANISM The tool is equipped with a Trigger Lock mechanism. Push and rotate the Trigger Lock Dial to the trigger free position before driving nails. DIRECTIONAL EXHAUST COVER ALWAYS disconnect air supply before rotating the exhaust cover by hand.

  • Page 13: Tool Operation Check

    TOOL OPERATION CHECK CAUTION: Remove all fasteners from tool before performing tool operation check. SEQUENTIAL FIRE OPERATION: a. Press the contact trip against the work surface, without touching the trigger. THE TOOL MUST NOT CYCLE. b. Hold the tool off the work surface and pull the trigger. THE TOOL MUST NOT CYCLE.

  • Page 14: Maintaining The Pneumatic Tool

    MAINTAINING THE PNEUMATIC TOOL When working on air tools, note the warnings in this manual and use extra care evaluating problem tools. Disconnect air supply and empty the magazine when inspecting or maintaining the tool. REPLACEMENT PARTS: Use only genuine parts from the manufacturer or distributor. Do not use modified parts or parts which will not give equivalent performance to the original equipment.
