  • Page 1 FDW 614 D10P DOS LP D User manual Dishwasher Bedienungsanleitung Geschirrspüler Manual de usuario Lavavajillas Manuel d‘utilisation Lave-vaisselle Istruzioni per l‘uso Lavastoviglie Gebruiksaanwijzing Vaatwasmachine Manual do utilizador Lava-louças FDW 616 D8P BR...
  • Page 2 Contents Your dishwasher ........................Safety instructions ........................Installation ..........................Overflow guard ......................... Packaging ..........................Disposal ............................ Symbols on the appliance ......................Before washing for the first time ................... 1. Water hardness ........................2. Basic settings ........................Top up with rinse aid ........................ Top up with salt ........................
  • Page 3 Troubleshooting ........................Installation ..........................Safety instructions ........................Setup ............................Drainage connection ......................... Connection to water supply ...................... Electrical connection ......................... Service ............................. Number of program cycles ....................... Technical information ......................Technical data ...........................
  • Page 4 Your dishwasher Install the dishwasher, see the chapter Installation. Then open the door and press The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See the chapter Before washing for the first time. On/Off Start/Stop Display...
  • Page 5 Safety instructions Read the user manual and keep it in a safe place! Number of standard place settings: 16 Never use the dishwasher for any purpose other than that specified in these operating instructions. Do not load the dishwasher door or dishwasher baskets with anything other than dishes.
  • Page 6 WARNING! Children must be supervised – dishwasher detergent is corrosive! Installation See the chapter Installation. Overflow guard The overflow guard starts pumping out the water and turns off the water supply if the water level in the dishwasher exceeds the normal level. If the overflow guard is triggered, F54 (Overfilling water) appears on the display.
  • Page 7 Before washing for the first time 1. Water hardness In order to achieve good dishwashing results, the dishwasher needs soft water (water with low mineral content). Hard water leaves a white coating on dishes and the dishwasher. Checking water hardness Water hardness is specified using German degrees of water hardness (°dH), French degrees of water hardness (°fH), English degrees of water hardness (°eH) or millimoles per litre (mmol/l).
  • Page 8 2. Basic settings The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See page 19. Set up: Rinse aid Water hardness TAB (All-in-one detergent) Top up with rinse aid Drying is faster and a better result is achieved Lift up to open if you use rinse aid.
  • Page 9 Greener dishwashing Save energy and water When using a dishwasher in a residential setting, less energy and water are generally used compared to washing the dishes by hand. Do not rinse under running water Do not rinse the dishes under running water as this will lead to increased energy and water consumption. Simply scrape off large food particles before loading the dishwasher.
  • Page 10 Loading the dishwasher Fragile dishes Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high heat, others can be damaged by dishwasher detergent. Exercise caution with, for example, handmade items, fragile decoration, crystal/glassware, silver, copper, tin, aluminium, wood and plastic.
  • Page 11 Upper basket Place glasses, cups, bowls, side plates and saucers in the upper basket. All dirty surfaces should face inwards and downwards! Wine glasses are placed on the wine glass shelf and knives are placed in the knife stand on the right. 3 positions Knife stand Raising and lowering the upper basket...
  • Page 12 Adjustable plate supports The adjustable plate supports can be folded down to make it easier to load pots, bowls and glasses. Lower basket Place plates, side plates, serving dishes and pots in the lower basket. Adjustable plate supports The adjustable plate supports can be folded down to make it easier to load pots and bowls. NOTE! Check that the spray arms can rotate freely.
  • Page 13 Using the dishwasher Add detergent Follow the instructions on the detergent packaging. This dishwasher is fitted with a water softener, so use detergent and rinse aid doses suitable for soft water. Too much detergent can result in less effective dishwashing and also entails greater environmental impact.
  • Page 14 On/Off Start/Stop Display NOTE! The control panel only reacts to use when the door is open. On/Off Open the door and press . Also turn on the water tap if it is turned off. Select program Select a program to suit the type of dishes and how dirty they are. Press the desired program until it is activated, which is indicated by an indicator light.
  • Page 15 Hygiene 70° This program is ideal to use where demands on hygiene are extra high, e.g. for baby bottles and cutting boards. The temperature is high both in the main wash and in the final rinse. Night 55° A quieter dishwashing program, suitable for running at night. The program time is extended. Quick 35°...
  • Page 16 Press to activate the option, which is indicated by an indicator light. The Automatic door opening option is pre-selected for some programs. Not available for: Hygiene 70°, Self-clean NOTE! For the best drying results, do not close the door before the drying phase has finished and the machine has automatically switched off.
  • Page 17 If you want to load more dishes Open the door. The dishwasher stops automatically. Add the dishes and close the door. After a while, the dishwasher continues the program. Power failure If the dishwasher is turned off due to a power failure when a dishwashing program is running, the program continues when power is restored.
  • Page 19 Settings 1. Open the door and press 2. To open the dishwasher's settings menu, press and hold until SEt is shown on the display. 3. Press to step through the settings menu. 4. Press to step through the alternatives. 5. Confirm the selected setting by pressing 6.
  • Page 20 Settings Alternatives 5:00 (Off) Activate this setting when using an all-in-one detergent that (All-in-one detergent) 5:01 (On) contains rinse aid. This setting reduces the rinse aid dosage and affects how often the dishwasher's built-in softener is regenerated. Pre-selected at factory: 5:00 Error readout Any error messages.
  • Page 21 Care and cleaning Top up with rinse aid When the rinse aid needs topping up, the above symbol lights on the display. Lift up to open Press to close 1. Open the rinse aid compartment lid. 2. Carefully top up with rinse aid to the level marked MAX. 3.
  • Page 22 Clean the filter The filter traps larger food particles, which cannot get past the drainage pump. Empty the filter when necessary. It should be cleaned at regular intervals depending on how often the dishwasher is used. 1. Turn the locking ring anticlockwise and lift the filter straight up. 2.
  • Page 23 Lower spray arm Pull the lower spray arm straight up to release it. Clean the outside of the dishwasher Door and door seal Open the door. Clean the sides of the door and the door seal regularly with a slightly damp cloth. Clean the door seal at the lower front edge of the dishwasher with a washing-up brush.
  • Page 24 7. Plug the machine in again. Drainage pump stop NOTE! Do not forget to refit the drainage pump stop. Unblocking the inlet hose filter If the water supply contains small particles, the outer filter on the inlet hose may become blocked, which results in the Water inlet fault error message.
  • Page 25 Troubleshooting Error messages Action Overfilling water Unblocking the drainage pump. See the chapter Care and cleaning. If the problem persists, contact your nearest service centre. Water outlet fault See "Water remains in the dishwasher" under "Problem" in the table below. If the problem persists, contact your nearest service centre.
  • Page 26 Problem Possible causes Action The control panel requires calib- Turn off the water tap. Remove ration. the plug from the wall socket and wait for 60 seconds. Then plug the appliance back into the wall socket and turn on the wa- ter tap.
  • Page 27 Problem Possible causes Action Spray arm holes or bearings Clean the spray arms. See the blocked. chapter Care and cleaning. Unsuitable dishwashing pro- Select a program with a high gram. temperature to dissolve grease on very dirty dishes, such as In- tensive 70°.
  • Page 28 Problem Possible causes Action Salt compartment empty. Top up with salt. See the chapter Before washing for the first time. Incorrect water softener setting. See Water hardness in the chapter Settings. The water softener is leaking Check that the salt compart- salt.
  • Page 29 Problem Possible causes Action Blocked drainage hose. Disconnect the drainage hose where it connects to the sink unit's water trap. Check that no debris has fastened and that the connection has an inner diamet- er of at least 14 mm. Bad odour in dishwasher.
  • Page 30 Installation It is important that you read through and follow the instructions and directions below. Conduct installation and connection in accordance with the separate installation instructions. [mm] Remove the plastic strips if the recess dimension is 596-598 mm. Exercise caution! The edges may be sharp. Wear protective gloves! Cover door length.
  • Page 31 If the dishwasher is built-in the surrounding furnishings must be resistant to any condensation from the dishwasher. Mount the protective film beneath the worktop and up around the edge. The function of the protective film is to protect the worktop from moisture. (The protective film is in the enclosed plastic bag.) Check that the machine is installed such that the door opens freely, otherwise door lock functionality may be disrupted.
  • Page 32 Service Read the chapter Troubleshooting before contacting the service centre. If you have encountered a problem that you cannot resolve, please contact your nearest service centre for professional help. When making contact, provide the details on the serial number plate. Include the article number (1) and the serial number (2).
  • Page 33 Technical information Technical data Height: 816-890 mm Width: 598 mm Depth: 555 mm Weight: 30 kg Water pressure: 0.03-1.0 MPa Electrical connection: See the serial number plate Rated power: See the serial number plate Noise emissions: 42 dB(A) re 1 pW 1) Weight can vary due to different specifications.
  • Page 34 Your notes...
  • Page 35 Your notes...
  • Page 36 EN - DE - ES - FR - IT - NL - P 933240-a4 We reserve the right to make changes.
