Summary of Contents for Franke FCDW60FI
- Page 1 FCDW60FI Please read this manual carefully before using the dishwasher and Keep this manual for future reference.
- Page 2 F r a n k e – U r b a n A p p l i a n c e s E x p r e s s W a r r a n t y Australian Consumer Guarantees Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
- Page 3 that were not installed in accordance with the manufacturer’s installation instructions, by a qualified installer and licensed plumber or in accordance with any applicable standards published by Standards Australia that apply to the Product; or that were purchased second hand, at auction, or from a person other than an authorised representative of PRKS; •...
-
Page 4: Table Of Contents
CONTENTS USING YOUR DISHWASHER Control Panel Preparing And Loading Dishes Function Of The Rinse Aid And Detergent Filling The Rinse Aid Reservoir Filling The Detergent Dispenser PROGRAMMING THE DISHWASHER Wash Cycle Table Starting A Cycle Wash Changing The Program Mid-cycle Forget To Add A Dish? ERROR CODES TECHNICAL INFORMATION... - Page 5 QUICK USER GUIDE Please read the corresponding content on the instruction manual for detailed operating method. Install the dishwasher (Please check the section 5 “INSTALLATION INSTRUCTION ” PART Ⅰ: Generic Version.) Inside Outside Loading the baskets Removing the larger residue on the cutlery Filling the dispenser Selecting a program and running...
-
Page 6: Using Your Dishwasher
USING YOUR DISHWASHER Control Panel Operation (Button) Press this button to turn on your dishwasher, the screen lights up. Power Auto Auto sensing wash, lightly, or heavily soiled crockery, with or with out dried-on food Intensive For heaviest soiled crockery, such as pots, pans, casserole dishes and dishes that have been sitting with dried food on them for a while. - Page 7 Press this button to set the delayed hours for washing. You can delay the start of washing up to 24 hours. One press on this Delay button delays the start of washing by one hour. Press the buttons to select either upper basket or lower basket loaded, and the response indicators will be lit.
-
Page 8: Preparing And Loading Dishes
Preparing And Loading Dishes Consider buying utensils which are identified as dishwasher-proof. For particular items, select a program with the lowest possible temperature. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended. For washing the following cutlery/dishes Are not suitable Cutlery with wooden, horn china or mother-of-pearl handles... - Page 9 Recommendations for loading the dishwasher Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans.It is not necessary to rinse the dishes under running water. For best performance of the dishwasher, follow these loading guidelines. (Features and appearance of baskets and cutlery baskets may vary from your model.) Place objects in the dishwasher in following way:...
- Page 10 Loading the upper basket The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty). Position the dishes and cookware so that they will not get moved by the spray of water.
-
Page 11: Function Of The Rinse Aid And Detergent
Function Of The Rinse Aid And Detergent The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids. WARNING Only use branded rinse aid for dishwasher. -
Page 12: Filling The Rinse Aid Reservoir
Filling The Rinse Aid Reservoir Remove the rinse reservoir cap by lifting up the handle . Pour the rinse aid into the dispenser, being careful not to overfill. Close the cap after all. Adjusting the rinse aid reservoir To achieve a better drying performance with limited rinse aid, the dishwasher is designed to adjust the consumption by user. -
Page 13: Filling The Detergent Dispenser
Filling The Detergent Dispenser Sliding it to the right Press down Add detergent into the larger cavity (A) for the main wash cycle . For better cleaning result, especially if you have very dirt items, pour a small amount of detergent onto the door. The additional detergent will activate during the pre-wash phase. -
Page 14: Programming The Dishwasher
PROGRAMMING THE DISHWASHER Wash Cycle Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. )Means: need to fill rinse into the Rinse-Aid Dispenser. Detergent Energy Water... -
Page 15: Starting A Cycle Wash
Detergent Energy Water Description Running Rinse Program Pre/Main (Kwh) Of Cycle Time(min) Prewash 0.02 Soak NOTE: AS/NZS 2007.1: This program is the test cycle. The information for comparability test in accordance with AS/NZS 2007.1. Starting A Cycle Wash 1. Draw out the lower and upper basket, load the dishes and push them back. It is commended to load the lower basket first, then the upper one. -
Page 16: Forget To Add A Dish
1. Open the door a little to stop the dishwasher, after the spray arm stop working, you can open the door completely. 2. Press Program button more than three seconds the machine will be in stand by state. 3. You can change the program to the desired cycle setting. 4. -
Page 17: Error Codes
ERROR CODES If there is a malfunction, the dishwasher will display error codes to identify these: Meanings Codes Possible Causes Faucets is not opened, or water intake is Longer inlet time. restricted, or water pressure is too low. Not reaching required Malfunction of heating element. -
Page 18: Technical Information
TECHNICAL INFORMATION Height (H) 815mm Width (W) 598mm Depth (D1) 550mm (with the door closed) Depth (D2) 1150mm (with the door opened 90°) - Page 19 Product fiche Product fiche Manufacturer FRANKE Type / Description FCDW60FI Standard place settings Energy efficiency class Water consumption class Standard cleaning cycle Energy consumption of the standard cleaning cycle 0.65 kWh Water consumption of the standard cleaning cycle 12 liter...
