- Page 1 INSTALLATION MANUAL HON1L www.gromaudio.com www.gromaudio.com/support.html...
- Page 2 CONTENTS Package contents......................3 CHAPTER 1 — INSTALLATION.................3 1.1 Before Installation 1.2 Tools 1.3 Vehicle Installation 1.4 Safety Guidelines & Appropriate Use Connect supplied display harness cable to factory display....5 Connect VLine Interface cable to factory head unit......6 Connecting to VLine..................6 Routing the GPS Antenna.
- Page 3 GROM VLINE SYSTEM VLine VL2 PACKAGE CONTENTS VLine module VHADL Display MCFHADD Power Video Cable Interface Cable GPS Antenna Microphone USB Extension cable *NOTE for VLite VT2: The GPS Antenna and the USB Extension Cable are not included in the VLite VT2 package. You can order them separately if desired. CHAPTER 1 —...
- Page 4 wiring installation requires special technical skills and experience. If you do not feel comfortable doing the installation please consult with your local car audio shop or installation professional for instructions or assistance if necessary. Carefully remove the factory stereo and display out of the dash cavity with proper tools.
- Page 5 IMPORTANT: External CD changer, if present, must be disconnected from the car stereo system. Connect supplied video cable VHADL to the factory display. Locate the display port on rear of the car stereo display. If the port is empty, plug in supplied video cable (VHADL) into the port and leave female portion of cable with nothing attached.
- Page 6 Connect VLine power cable MCFHADD to the factory head unit and behind the knob Locate the 10-pin connector behind the knob in the center trim piece. It is usually in green color. Plug the MCFHADD cable there, and replug the factory connector back to the MCFHADD cable male socket.
- Page 7 Connecting to the VLine Route the unused end of video cable VHADL and power interface cable MCF- HADD to the VLine module and connect them to the correctly labeled ports. Video Cable Power Interface Cable Routing the GPS antenna The GPS Antenna module is magnetic and supplied with double-sided tape. It can be mounted to the top of the dashboard or outside of the vehicle, whichever you prefer.
- Page 8 Routing the microphone Route the microphone to a location where it can pick up the voice. We recom- mend mounting the microphone near the rearview mirror but not directly on the windshield glass. Avoid sticking it to a hard surface, as it will pick up more noise.
- Page 9 Testing the VLine operation WARNING: Ensure to reconnect all unplugged connectors to the vehicle before cycling the ignition. Cycle the ignition and press the AUX button to enter the VLine mode. Ensure the VLine appears on the screen and all factory functions, such as climate controls, reverse camera, and AM/FM stereo, are working.
- Page 10 Understanding the VLine p orts H DMI WiFi / Bluetooth Output Antenna USB1 iPhone GPS / AV / Camera Input USB 1 HDMI IN HDMI OUT USB 2 CAMERA AV1 HDMI Input MicroSD Card Microphone (Pin side up*) USB2 OTG/USB storage USB1 iPhone connection Any other USB device (Keyboard / Mouse)
- Page 11 CHAPTER 2 — GETTING STARTED 2.1 Initializing Cycle the ignition and press AUX button to enter the VLine mode of the stereo. 2.2 Functions The GROM VLINE emulates the factory AUX mode of the stereo. Press the AUX button to enter into VLINE interface mode. No factory functions of the stereo will be disabled.
- Page 12 2.3 Forcing the VLine VL2 / VLite VT2 User Interface on the display You can listen to FM radio while seeing the VLine VL2 / VLite VT2 or CarPlay and Android Auto UI. While in FM mode, press and hold MAP button for a few seconds to force the VLine on the screen.
- Page 13 Unless otherwise prescribed by law, GROM Audio shall not be liable for any personal injury, property damage and or any incidental or consequential damages of any kind (including water damage) resulting from malfunctions, defects, misuse, improper installation or alteration of this product.
- Page 14 NOT INHERENTLY DANGEROUS AND DO NOT PROVIDE ANY INHERENT RISKS AND THEREFORE POTENTIAL DAMAGES TO THE END-USER, OTHER THAN ‘Fitness for its Purpose’. As manufacturers continuously develop and modify stereo receiver models, they may cause you to experience some technical difficulties.
- Page 15 IN CONNECTION WITH ANY BUSINESS, LOSS OF ANY GOODWILL, OR DAMAGES. THE TERM ‘INCIDENTAL DAMAGES’ REFERS TO THE EXPENSES OF TRANSPORTING THE PRODUCTS TO THE GROM AUDIO SERVICE CENTER, LOSS OF THE END-USERS [ORIGINAL PURCHASER’S] TIME, LOSS OF THE USE OF THE PRODUCT, BUS FARES, CAR RENTALS OR OTHER COSTS RELATED TO THE CARE AND CUSTODY OF THE PRODUCT.
- Page 16 - a reasonable, safe and appropriate manner considering all the circumstances associated with that use. You agree not to use the GROM Product: - for any illegal, non-personal or unauthorized purpose, - in a manner that could damage or cause risk to GROM Audio business,...
- Page 17 - in a manner that would distract the driver or that may otherwise cause injury or death to vehicle occupants or bystanders. GROM Audio is not in any way responsible for any such use by you. In all cases, GROM Audio may limit or revoke your use for any reason and at any time.
- Page 18 GROM AUDIO does not warrant or endorse and does not assume and will not have any liability or responsibility to you or any other person for any Third Party Materials or for any other materials, products, or services of third parties.
- Page 19 GROM AUDIO. Quantities are subject to availability. E. ENTIRE AGREEMENT. These terms and conditions constitute the entire...
- Page 20 IF YOU DO NOT AGREE WITH THESE TERMS AND PURCHASED DIRECTLY FROM GROM AUDIO PLEASE RETURN THE GROM PRODUCTS IN ORIGINAL CONDITION AND IN ORIGINAL PACKAGE WITHIN FIVE (5) BUSINESS DAYS OF RECEIPT OF THE PRODUCTS FOR A FULL REFUND OF THE PURCHASE PRICE OF GROM PRODUCTS (SHIPPING COSTS NON REFUNDABLE).
