- Page 1 INSTALLATION MANUAL LEX9 www.gromaudio.com www.gromaudio.com/support.html...
-
Page 2: Table Of Contents
CONTENTS Package contents......................3 CHAPTER 1 — INSTALLATION.................3 1.1 Before Installation 1.2 Tools 1.3 Vehicle Installation 1.4 Safety Guidelines & Appropriate Use Connect supplied Display Harness Cable to factory Display....5 Connect VLine Interface cable to Factory Head unit......6 Connecting to VLine..................6 Routing the GPS Antenna..................7 Routing the Microphone..................8... -
Page 3: Package Contents
GROM-VLINE VL2 SYSTEM PACKAGE CONTENTS MCFLEX9 Power GV9MF Video WLEX9USB cable VLine module Cable Interface Cable GPS Antenna USB Extension cable CHAPTER 1 — INSTALLATION 1.1 Before Installation Before starting work with any wiring, please wait 90 seconds after turning the Ignition to the OFF position and disconnecting the negative (-) terminal of the battery. -
Page 4: Safety Guidelines & Appropriate Use
wiring installation requires special technical skills and experience. If you do not feel comfortable doing the installation please consult with your local car audio shop or installation professional for instructions or assistance if necessary. Carefully remove the factory Stereo and Display out of the dash cavity with proper tools. -
Page 5: Connect Supplied Display Harness Cable To Factory Display
Connect supplied Display Harness Cable GV9MF to factory display Locate BLUE Display port on rear of Multi Display ECU. If the port is empty, plug in supplied video cable (GV9MF) into port and leave female portion of cable with nothing attached. If there is cable plugged in, disconnect factory display cable (typically blue in color). -
Page 6: Connect Vline Interface Cable To Factory Head Unit
Connect GV9MF video cable, MCFLEX9 Interface cable, and WLEX9USB cable to VLine Route the unused ends of GV9MF Video cable, MCFLEX9 Interface cable, and WLEX9USB cable to the VLine module and connect them to the corresponding ports. -
Page 7: Routing The Gps Antenna
Routing the GPS Antenna The GPS Antenna module is magnetic as well as supplied with double sided tape. It can be mounted to the top of dashboard or to outside of vehicle whichever you prefer. We recommend mounting it inside of vehicle on passenger side of the dashboard as shown below. -
Page 8: Routing The Microphone
Using factory microphone VLine will use factory microphone for its operation. Connect 3.5mm male connector from Power Interface Cable (MFCLEX9) to the microphone port of VLine (see p. 10 for reference). There are no any additional steps needed to connect or operate VLine with the vehicle factory microphone. -
Page 9: Mounting The Vline Module
Mounting the VLine Module Mount module in the location free of any moving parts. We strongly recommend mounting the module in an easily accessible location such as the glove compartment for an easy access to the USB ports and in case of needing to upgrade firmware on the VLine module. -
Page 10: Understanding Vline Ports
Understanding VLine Ports WiFi / Bluetooth Not Used Antenna USB1 iPhone GPS / AV / Camera Input USB 1 HDMI IN HDMI OUT USB 2 CAMERA AV1 HDMI Input MicroSD Card Microphone (Pin side up*) USB2 OTG/USB storage USB1 iPhone or Android connection Any other USB device (Keyboard / Mouse) USB2 USB flash drive... -
Page 11: Chapter 2 - Getting Started
CHAPTER 2 — GETTING STARTED 2.1 Initializing After connecting the VLine module to the stereo, and reconnecting all unplugged connectors back to the vehicle, an ignition cycle will have to be performed for the stereo to discover VLine and allow VLine to self config- ure. - Page 12 Controls available on the mouse pad The VLine is controlled by the mouse in the center area. The following controls are available: MEDIA - press until in VLine mode / iPod USB mode MAP - activates MAP App on VLine, or CC/AA MENU - HOME Button - takes you to the main screen in AA, CP, and GROM mode.
-
Page 13: Support
Unless otherwise prescribed by law, GROM Audio shall not be liable for any personal injury, property damage and or any incidental or consequential damages of any kind (including water damage) resulting from malfunctions, defects, misuse, improper installation or alteration of this product. -
Page 14: Grant Of License
BETWEEN YOU, AS “THE END USER”, AND GROM Audio (“GROM”). PLEASE CAREFULLY READ THE TERMS AND CONDITIONS OF THIS AGREEMENT BEFORE USING THE GROM PRODUCTS. BY USING THE GROM PRODUCT AND THE SOFTWARE INSTALLED ON THE GROM PRODUCT, YOU ARE AGREEING TO BE BOUND BY THE TERMS OF AGREEMENT. -
Page 15: Operational Warning And Safety Instructions
IN CONNECTION WITH ANY BUSINESS, LOSS OF ANY GOODWILL, OR DAMAGES. THE TERM ‘INCIDENTAL DAMAGES’ REFERS TO THE EXPENSES OF TRANSPORTING THE PRODUCTS TO THE GROM AUDIO SERVICE CENTER, LOSS OF THE END-USERS [ORIGINAL PURCHASER’S] TIME, LOSS OF THE USE OF THE PRODUCT, BUS FARES, CAR RENTALS OR OTHER COSTS RELATED TO THE CARE AND CUSTODY OF THE PRODUCT. - Page 16 INJURY OR DEATH. IF YOU, THE END-USER ALLOW ANOTHER PERSON TO USE THE VEHICLE, IT IS YOUR RESPONSIBILITY TO THOROUGHLY BRIEF THAT OTHER USER, ON THE SAFETY REQUIREMENTS FOR OPERATING THE VEHICLE AND THE PRODUCTS INSTALLED THEREIN. (B) SAID DISCLAIMERS SHALL APPLY TO THE USE OF SAID PRODUCTS, EVEN IF GROM HAS BEEN INFORMED OF, KNEW OF, OR SHOULD HAVE KNOWN OF THE LIKELIHOOD OF SUCH DAMAGES.
- Page 17 - in a manner that would distract the driver or that may otherwise cause injury or death to vehicle occupants or bystanders. GROM Audio is not in any way responsible for any such use by you. In all cases, GROM Audio may limit or revoke your use for any reason and at any time.
- Page 18 By using the Third Party Materials, you agree to comply with the use terms of the provider of such Third-Party Materials. GROM AUDIO does not warrant or endorse and does not assume and will not have any liability or responsibility to you or any other person for any Third Party Materials or for any other materials, products, or services of third parties.
- Page 19 A. INDEMNIFICATION OF GROM AUDIO, ITS AGENTS AND EMPLOYEES. By Purchasing, Installing and Using the Products, You, the End- User, agree to indemnify, defend and hold harmless, GROM AUDIO, and it s Affiliates, Directors, Officers, Agents and Employees from any Liabilities, Damage, Loss, Claim and Expense (including reasonable Attorney’s Fees) arising out of the...
- Page 20 Should you experience incompatibility issues, you may contact us via our support page. GROM Audio also carries a standard 30 day return policy. ENGINE/SYSTEM NOISE DISCLAIMER Engine / system noise may occur in some installations and is not easily predictable.
