GROM Interface Installation into FORD / Lincoln / Mercury cars
Tools needed
Wire crimp tool (optional), screwdriver, phillips driver
Preparation
1. Turn off car's engine and remove key from ignition
2.
Take the screwdriver; carefully insert the slothead between the car stereo trim and
dashboard. Gently remove the car stereo trim.
3.
Now you see the stereo and 4 screws at the stereo corners.
FRD
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GROM Audio FRD
Summary of Contents for GROM Audio FRD
- Page 1 GROM Interface Installation into FORD / Lincoln / Mercury cars Tools needed Wire crimp tool (optional), screwdriver, phillips driver Preparation 1. Turn off car’s engine and remove key from ignition Take the screwdriver; carefully insert the slothead between the car stereo trim and dashboard.
- Page 2 1. Take the Phillips driver and unscrew 4 screws at the stereo corners. 5. Gently pull the stereo out, be careful not to disconnect any wires. 6. Open the glovebox. Take the FORD OEM harness (FRD07 in your GROM package) and guide it through the hole in your glovebox to the dashboard. The...
- Page 3 end of FRD07 that connects to the stereo should go inside the dash, and the other end that connects to the GROM box should be left in the glovebox. 7. Locate the power lid (yellow wire with the pink colored quick disconnect terminal on the end).
- Page 4 9. Snap the T-Tap clip (provided with your GROM package) over the red wire on the main harness so it is fastened 10. Connect the power lid to the red power wire on the main harness as shown below. You can simply snap the pink disconnect with the closed T-Tap clip on the red harness.
- Page 5 11. Locate the empty CD changer port and connect the FRD07 harness to it. Make sure that the connection is firm and the harness is securely attached to the port.* 12. Connect your GROM-USB MP3 car kit to the other end of FRD07 harness. You can now start using your GROM-USB! 13.
- Page 6 3. Disclaimer • This product is not affiliated with any of the OEM manufacturers • Modifying the radio may void any existing warranty • The purchase of this product carries no warranties, either expressed or implied • Although every care has been taken to provide a quality product, we cannot guarantee that the GROM USB adapter will function correctly if installation is not done according to the instructions included in this guide.
