- Page 1 INSTALLATION MANUAL NIS9 www.gromaudio.com www.gromaudio.com/support.html...
-
Page 2: Table Of Contents
CONTENTS Package contents......................3 CHAPTER 1 — INSTALLATION.................3 1.1 Before Installation 1.2 Tools 1.3 Vehicle Installation 1.4 Safety Guidelines & Appropriate Use Connect VLine Interface Cable to factory headunit ..........5 Display connections ....................6 Connecting to VLine....................6 Routing the GPS Antenna..................7 Routing the Microphone. -
Page 3: Package Contents
GROM-VLINE SYSTEM PACKAGE CONTENTS MFCNIS9 Interface Cable GVNMF WLNISUSB VLine module GPS Antenna Microphone USB Extension cable CHAPTER 1 — INSTALLATION 1.1 Before Installation Before starting work with any wiring, please wait 90 seconds after turning the Ignition to the OFF position and disconnecting the negative (-) terminal of the battery. -
Page 4: Safety Guidelines & Appropriate Use
wiring installation requires special technical skills and experience. If you do not feel comfortable doing the installation please consult with your local car audio shop or installation professional for instructions or assistance if necessary. Carefully remove the factory Stereo and Display out of the dash cavity with proper tools. -
Page 5: Connect Vline Interface Cable To Factory Headunit
Connect VLine interface cable to factory unit Stereo Connections Locate the 20-pin and 32-pin connectors behind the stereo headunit and unplug. Plug in the supplied interface cable (MFCNIS9). Reconnect back what was disconnected from the rear of the stereo into the female plugs of the supplied interface cable. -
Page 6: Display Connections
Display connections Locate 4-pin plug at the rear of the display and unplug. Plug in the supplied interface cable (GVNMF). Reconnect back what was disconnected from the rear of the display into the female plugs of the supplied interface cable. Harness Connection GVNMF... -
Page 7: Routing The Gps Antenna
Routing the GPS Antenna The GPS Antenna module is magnetic as well as supplied with double sided tape. It can be mounted to the top of dashboard or to outside of vehicle whichever you prefer. Route to desired location. We recommend mounting on inside of vehicle on passenger side of the Dashboard as shown below. -
Page 8: Routing The Microphone
Routing the Microphone Route microphone to a location where it will be able to pick up voice clearly. We recommend to mount MIC nearby the rear view mirror but not directly on windshield glass. Avoid sticking to the hard surface as it will pick up more noise. -
Page 9: Mounting The Vline Module
Mounting the VLine Module Mount module in location free of any moving parts. We strongly recommend mounting the module in an easily accessible location such as the glove compartment for easy access to the USB ports and in case of needing to upgrade firmware on the VLine module. -
Page 10: Understanding Vline Ports
Understanding VLine Ports WiFi / Bluetooth Not Used Antenna USB1 iPhone GPS / AV / Camera Input USB 1 HDMI IN HDMI OUT USB 2 CAMERA AV1 HDMI Input MicroSD Card Microphone (Pin side up*) USB2 OTG/USB storage USB1 iPhone connection Any other USB device (Keyboard / Mouse) USB2 USB flash drive... -
Page 11: Chapter 2 - Getting Started
CHAPTER 2 — GETTING STARTED 2.1 Initializing After connecting the VLine module to the stereo, an Ignition Cycle will have to be performed for the stereo to discover Vline and allow Vline to self configure. To INITIALIZE: 1. Put Ignition Switch to “ACC” or “ON” position 2. - Page 12 Press the BACK button to go back to a Previous screen. User Manual Please refer to the User Manual included with your purchase regarding to the next steps required to set up your VLine Infotainment System.
-
