Summary of Contents for AEG LR6ALPHEN
- Page 1 EN User Manual | Washing Machine LR6ALPHEN...
- Page 2 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
- Page 3 SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
- Page 4 • If a tumble dryer is stacked on the top of the washing machine, make sure to use the correct stacking kit approved by AEG (see more details in chapter "Accessories - Stacking kit"). ENGLISH...
- Page 5 2. SAFETY INSTRUCTIONS 2.1 Installation • WARNING: This appliance is designed to be installed / connected to a grounding connection in the building. • Always use a correctly installed The installation must comply with shockproof socket. relevant national regulations. • Make sure that the parameters on the rating plate are compatible with the •...
- Page 6 • Make sure that there is access to the tap elements, including heat pumps, piping after the installation. and related equipment including hoses, valves, filters and aquastops, printed 2.4 Use circuit boards, electronic displays, pressure switches, thermostats and sensors, software and firmware including WARNING! reset software, door, door hinge and Risk of injury, electric shock, fire, burns...
- Page 7 3.2 Appliance overview 11 12 Worktop Drain hose Detergent dispenser Inlet hose connection Control panel Mains cable Door handle Transit bolts Rating plate Hose support Drain pump filter Feet for levelling the appliance The rating plate reports the model name (A), product number (B), electrical ratings (C) and serial number (D).
- Page 8 Water supply pressure Minimum 0.5 bar (0.05 MPa) Maximum 10 bar (1.0 MPa) Cold water Water supply Maximum Load Cotton 8 kg Spin Speed Maximum spin speed 1551 rpm Connect the water inlet hose to a water tap with a 3/4'' thread. 5.
- Page 9 We recommend that you keep the A correct adjustment of the appliance packaging and the transit bolts for any level prevents the vibration, noise and transport of the appliance. the movement of the appliance when in operation. 5. Put the plastic caps, that you find in the user manual bag, in the holes.
- Page 10 4. Connect the water inlet hose to the cold water tap with 3/4" thread. You can extend the drain hose to maximum 400 cm. Contact the authorized service centre for the other drain hose and the extension. It is possible to connect the drain hose in different ways: 1.
- Page 11 6. Position the hose directly to a built-in drain pipe in the room wall and tighten it with a clamp. 5.6 Electrical connection At the end of installation you can connect the The end of the drain hose must always mains plug to the mains socket.
- Page 12 Read carefully the instructions supplied with the accessory. Only appropriate accessories approved by AEG ensure the safety standards of the appliance. If unapproved parts are used, any claims will be invalidated. 6.2 Fixing plate kit If you install the appliance on a plinth that is not an accessory supplied by AEG, secure the appliance with the fixing plates.
- Page 13 Programme dial Vlekken/Voorwas skipping touch button Display Makkelijk strijken touch button Tijd besparen touch button Extra spoelen touch button Startuitstel touch button Centrifug. reduction touch button Extra skipping touch button • Alleen spoelen option Temperatuur touch button • Centrifugeren/Pompen option Aan/Uit push button Start/Pauze touch button 7.2 Display...
- Page 14 Drum clean indicator. Refer to the 'Cleaning the drum' section in the 'Care and cleaning' paragraph for more details. The Temperature area: Temperature indicator Cold water indicator Extra silent indicator. Rinse hold indicator. The spin area: Spin speed indicator No Spin indicator. Spin phase is off. Pre-wash indicator.
- Page 15 The display shows the indicator . The door stays locked and the drum turns This option is not available with a regularly to reduce creasing. You must temperature lower than 40 °C. drain the water to unlock the door. • Voorwas If you touch the Start/Pauze button, the Use this option to add a pre-wash phase...
- Page 16 8.8 Makkelijk strijken of 30 minutes up to 90' and from 2 hours up to 20 h. The appliance carefully washes and spins the After touching the Start/Pauze button, the laundry to prevent the creases. display shows the indicator and the The appliance decreases the spin speed, selected delay time and the appliance begins uses more water and adapts the programme...
- Page 17 Programme Programme description Outdoor Do not use fabric softener and make sure that there is no soft‐ ener residue in the detergent dispenser. Outdoor clothing, technical, sport fabrics, waterproof and breathable jackets, shell jackets with a removable fleece or inner insulation. The recommended laundry load is 2,5 kg.
- Page 18 Programme Default tempera‐ Reference spin speed Maximum load ture Spin speed range Temperature range 1600 rpm Eco 40-60 8 kg 40 °C 1600 rpm - 400 rpm 40 °C 1600 rpm 8 kg Katoen 95 °C - Cold 1600 rpm - 400 rpm 40 °C 1200 rpm 3 kg...
- Page 19 Programme options compatibility Options ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Centrifug. ■ ■ ■ ■ ■ ■ ■ Rinse Hold ■ ■ ■ ■ ■ ■ Vlekken ■ ■ ■ Voorwas ■ ■ ■ ■ ■ ■...
- Page 20 Universal pow‐ Liquid Uni‐ Liquid for Delicates Programme Special der 1) versal coloureds woollens ▲ ▲ Dekbed ▲ ▲ Outdoor ▲ ▲ ▲ Hygiëne At temperature higher than 60 °C the use of powder detergent is recommended. ▲ = Recommended -- = Not recommended 9.2 Woolmark Wool Care - Blue The wool wash cycle of this machine has been approved...
- Page 21 seconds (within 10 seconds after the 1. Switch the appliance on by pressing switching on. After these 10 seconds, the Aan/Uit button. key combination activates and 2. Turn the programme knob to the third deactivates the acoustic signals). programme. 4. After 3 seconds the total hours operated 3.
- Page 22 Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum indicated level ). This quantity will however guarantee the best washing results. After a washing cycle, if necessary, remove any detergent residue from the CAUTION! detergent dispenser.
- Page 23 indicators come on in the display and the given information changes accordingly. In case a selection is not possible, no indicator comes on and an acoustic signal sounds. 12.6 Starting a programme with the delay start 1. Touch this repeatedly until the display shows the desired delay time.
- Page 24 The related indicator stops flashing and stays The programme starts, the door is locked. About 20 minutes after the programme start, the programme duration could be The display shows the indicator adjusted again depending on the capacity of water absorption of the fabrics.
- Page 25 12.11 Cancelling a running The programme or the delay start continues. programme 4. The door can be opened when the programme is complete, or set spinning 1. Press the button Aan/Uit to cancel the or draining programme/option and than programme and to deactivate the press Start/Pauze button.
- Page 26 1. If necessary, touch the Centrifug. button • You do not use the appliance for 5 to decrease the spin speed proposed by minutes before you touch the Start/Pauze the appliance. button. 2. Touch the Start/Pauze button: Press the Aan/Uit button to activate the appliance again.
- Page 27 wash temperature and hardness of the water used. • Follow the instructions that you find on packaging of the detergents or other treatments without exceeding the indicated maximum level ( • Do not mix different types of detergents. • Use less detergent if: –...
- Page 28 13.5 Water hardness To find out the water hardness in your area, contact your local water authority. If the water hardness in your area is high or Use the correct quantity of additive for water moderate, we recommend that you additive softening.
- Page 29 Clean the drum with special products for stainless steel. Always follow the instructions that you find on the packaging of the product. Always follow the instructions that you 14.5 Maintenance wash find on the packaging of the product. Do not clean the drum with acidic With the low temperature programmes it is descaling products, scouring products possible that some detergent stays in the...
- Page 30 14.9 Cleaning the drain pump After cleaning, put the top part back into position. WARNING! Disconnect the mains plug from the mains socket. Regularly check the drain pump filter and make sure that it is clean. Clean the drain pump if: •...
- Page 31 4. Turn the filter 180 degrees in anti- 10. Clean the filter under the water tap. clockwise direction to open it, without removing. Let the water flow out. 180˚ 11. Put the filter back into the special guides by turning it clockwise. Make sure that 5.
- Page 32 4. When you reconnect the hose to the back 14.10 Cleaning the inlet hose and of the appliance, turn it left or right (not in the valve filter vertical position) depending on the position of your water tap. It is recommended to clean both the filters of the inlet hose and valve occasionally to remove any deposit, collected over the time: 1.
- Page 33 WARNING! Make sure that the temperature is higher than 0 °C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures. 15. TROUBLESHOOTING WARNING! Refer to Safety chapters. 15.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation.
- Page 34 • The programme was not finished properly or the appliance stopped too early. Switch the appliance off and on again. Internal fail. No communica‐ • If the alarm code appears again, contact the Authorised Service Centre. tion between electronic ele‐ ments of the appliance.
- Page 35 Problem Possible solution • Make sure the levelling of the appliance is correct. Refer to "Installation in‐ struction". The appliance makes an un‐ • Make sure that the packaging and/or the transit bolts are removed. Refer to usual noise and vibrates. "Installation instruction".
- Page 36 16.2 Legend Laundry load. hh:mm Programme duration. Energy consumption. °C Temperature in the laundry. Litres Water consumption. Spin speed. Remaining moisture at the end of spinning phase. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture. Values and programme duration may differ depending on different conditions (e.g.
- Page 37 Programme rpm 1) Litres hh:mm °C Katoen 1.750 75.0 3:50 44.00 55.0 1600 60°C Katoen 0.300 75.0 2:50 44.00 20.0 1600 20°C Synthetica 0.600 55.0 2:15 35.00 40.0 1200 40°C Fijne was 0.400 50.0 1:15 35.00 30.0 1200 30°C 0.300 60.0 1:05 30.00...
- Page 38 17.2 Cleaning the drain pump filter 180˚ Clean the filter regularly and, especially, if the alarm code appears on the display. 17.3 Programmes Pro‐ Load Product description grammes Eco 40-60 8 kg White and coloured cottons. Normally soiled garments. 8 kg White cotton and coloured cotton.
- Page 39 18. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office.
- Page 40 135968440-A-072023...
