INSTALLATION INSTRUCTIONS
CARE AND MAINTENANCE
Tropic Cadet
®
Elongated and Round Front
Models 217AA, 217BA, 217CA, 217DA Series
Thank you for selecting American Standard - the benchmark of fine quality for over 100 years. To ensure this product is installed properly, please read
these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
TANK 4190A
BOWL 3517A, 3517C ELONGATED
BOWL 3517B, 3517D ROUND FRONT
Wax Ring
PRO 2-piece Toilet
SOLD SEPARATELY
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2019
EZ-INSTALL KIT INCLUDED WITH TANK
Tank To Bowl Gasket
Attachment Handles
EZ-INSTALL KIT INCLUDED WITH BOWL
T-Bolts with
Retainer (2)
Also includes Standard Bolt Caps (2)
Water Supply Line
Plastic Washers (2)
with Nuts (2)
Bolt Caps (2)
Bowl-To-Floor
Knobs (2)
Slow Close Toilet Seat
7301951-100 Rev. 2 8/19
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for American Standard Tropic Cadet PRO 217AA Series
Summary of Contents for American Standard Tropic Cadet PRO 217AA Series
- Page 1 Models 217AA, 217BA, 217CA, 217DA Series Thank you for selecting American Standard - the benchmark of fine quality for over 100 years. To ensure this product is installed properly, please read these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes.
- Page 2 BEFORE YOU START: If Removing An Existing Toilet Flush to remove water from tank; Turn Off Water Supply Clean Flange sponge remaining water from bowl before removing toilet. Caution: If leaving floor flange open for more than 1-2 hours, cover flange to prevent escaping sewer gases.
- Page 3 Apply weight evenly. Hand tighten Do not move after only. Do not placement. Water overtighten. tight seal may break. NOTE: 1/4" EZ-BOLT AND CAP SHOWN. IF 5/16" BOLT USE STANDARD DISK AND CAP INCLUDED. Tighten handles alternately until the tank contacts the front and back of the bowl achieving china-to-china...
- Page 4 WARNING: Do not use in-tank cleaners. These products can seriously corrode fittings in the tank. This damage can cause leakage and property damage. American Standard shall not be responsible or liable for any damage caused by the use of in-tank cleaners.
