Page 1 O&M MANUAL HAMPTON INN & SUITES - AUGUSTA AUGUSTA, GA Ferguson - Atlanta 11600 Wills Rd. Alpharetta, GA 30004 ©2013 Ferguson Enterprises, Inc. All Rights Reserved. 0413 15417 QUOTE #B107-16-229100...
Page 2 Page REVISED P3B P1 WATER CLOSET A3517C101020 AMERICAN CADET PRO EL BOWL WHT STANDARD A4188A104020 AMERICAN 1.28 GALLONS PER FLUSH 12 TANK CADET STANDARD COMPLETE WHITE B1655SSCT000 BEMIS WHITE ELONGATED OPEN FRONT SEAT W/ S/S SELF-SUSTAINING CHECK HINGE, L/ COVER BOCR19XC BRASSCRAFT LF 1/2"...
Page 3 P3 ADA LAVATORY A0355012020 AMERICAN 21 X 18 4 VITREOUS CHINA LAVATORY WHITE STANDARD LUCERN WHITE D23C343 DELTA CCN LEAD LAW COMPLIANT 1.5 2 LEVER LAVATORY THREE HOLE WITHOUT POP UP 23T ZZ8743PC ZURN SLD TOP OPEN GRID PULL OUT PL PFPTB300 PROFLO 1-1/4 22GA P TRAP CP...
Page 4 P6A ADA BATHTUB A2391202020 AMERICAN 60 X 30 RIGHT HAND BATH AMERICA WHITE STANDARD DR10000UN DELTA 1 HANDLE PRESSURE BALANCE UNIVERSAL VALVE ONLY DT13420 DELTA CCY 2.0 1 HANDLE LEVER TUB AND SHOWER FAUCET TRIM PRESSURE BALANCE P6 SHOWER VALVE DR10000UN DELTA 1 HANDLE PRESSURE BALANCE UNIVERSAL...
Page 5 FD2 FLOOR DRAIN ZZN4153NL7I ZURN FLOOR AND SHOWER DRAIN, D.C.C.I. BODY ASSEMBLY WITH POLISHED NICKEL BRONZE TOP - 3" NEO LOC FD3 FLOOR DRAIN ZZN4154NL6G ZURN FLOOR AND SHOWER DRAIN, D.C.C.I. BODY ASSEMBLY WITH POLISHED NICKEL BRONZE TOP - 4" NEO LOC FS1 FLOOR SINK ZZ17503NL2 ZURN...
Page 6 UCB UTILITY CONNECTION BOX I82355 IPS CORP FR WALL MOUNTOB W/SWT QT VALVE UCB1 BOX S6963F SIOUX CHIEF 2 OX BOX DRAIN BX W/FRM S696CF SIOUX CHIEF OX BX SEC DRG FUN S6963F SIOUX CHIEF 2 OX BOX DRAIN BX W/FRM TP1 AUTOMATIC TRAP PRIMER PFPR500 PROFLO...
Page 7 REVISED P3B Page: 7 / 395...
Page 8 P1 WATER CLOSET A3517C101020 AMERICAN CADET PRO EL BOWL WHT STANDARD A4188A104020 AMERICAN 1.28 GALLONS PER FLUSH 12 TANK CADET COMPLETE WHITE STANDARD B1655SSCT000 BEMIS WHITE ELONGATED OPEN FRONT SEAT W/ S/S SELF-SUSTAINING CHECK HINGE, L/ COVER BOCR19XC BRASSCRAFT LF 1/2" NOM COMP INLET X 3/8" OD COMP OUTLET PFX146472 PROFLO LEAD LAW COMPLIANT 3/8 C X 7/8 12 STAINLESS STEEL CLOSET...
Page 9 P1 WATER CLOSET 3517C101020 ÿ Page: 9 / 395...
Page 10 P1 WATER CLOSET ✄ ☎ ✆ ✝ ✞ ✟ ✠ ✡ ✌ ❇ ÿ ✌ ✌ ❇ ❆ ÿ ❉ ☛ ☞ ÿ ❉ ☛ ✌ ☞ ÿ ÿ ÿ ÿ ✷ ✷ ✍ ✍ ✷ ✷ ...
Page 11 P1 WATER CLOSET Page: 11 / 395...
Page 12 P1 WATER CLOSET Page: 12 / 395...
Page 13 P1 WATER CLOSET 4188A104020 ÿ Page: 13 / 395...
Page 14 P1 WATER CLOSET ✄ ☎ ✆ ✝ ✞ ✟ ✠ ✡ ✌ ❇ ÿ ✌ ✌ ❇ ❆ ÿ ❉ ☛ ☞ ÿ ❉ ☛ ✌ ☞ ÿ ÿ ÿ ÿ ✷ ✷ ✍ ✍ ✷ ✷ ...
Page 15 P1 WATER CLOSET Page: 15 / 395...
Page 16 P1 WATER CLOSET Page: 16 / 395...
Page 17 P1 WATER CLOSET Page: 17 / 395...
Page 18 P1A WATER CLOSET ADA A3517A101020 AMERICAN CADET PRO RIGHT HEIGHT ELONG BOWL WHITE STANDARD A4188A104020 AMERICAN 1.28 GALLONS PER FLUSH 12 TANK CADET COMPLETE WHITE STANDARD B1655SSCT000 BEMIS WHITE ELONGATED OPEN FRONT SEAT W/ S/S SELF-SUSTAINING CHECK HINGE, L/ COVER BOCR19XC BRASSCRAFT LF 1/2"...
Page 19 P1A WATER CLOSET ADA 3517A101020 Page: 19 / 395...
Page 20 P1A WATER CLOSET ADA Page: 20 / 395...
Page 21 P1A WATER CLOSET ADA Page: 21 / 395...
Page 22 P1A WATER CLOSET ADA Page: 22 / 395...
Page 23 P1A WATER CLOSET ADA Page: 23 / 395...
Page 24 P1A WATER CLOSET ADA Page: 24 / 395...
Page 25 P1A WATER CLOSET ADA 4188A104020 ÿ Page: 25 / 395...
Page 26 P1A WATER CLOSET ADA ✄ ☎ ✆ ✝ ✞ ✟ ✠ ✡ ✌ ❇ ÿ ✌ ✌ ❇ ❆ ÿ ❉ ☛ ☞ ÿ ❉ ☛ ✌ ☞ ÿ ÿ ÿ ÿ ✷ ✷ ✍ ✍ ✷ ✷ ...
Page 27 P1A WATER CLOSET ADA Page: 27 / 395...
Page 28 P1A WATER CLOSET ADA Page: 28 / 395...
Page 29 P1A WATER CLOSET ADA Page: 29 / 395...
Page 30 P1C ADA WATER CLOSET A3461001020 AMERICAN MADERA EC 16-1/2 UN BOWL TOP SPUD WHITE STANDARD ZZER6000PLHETCP ZURN EZ FLUSH BATTERY EXP 1.28 GPF C B1655SSCT000 BEMIS WHITE ELONGATED OPEN FRONT SEAT W/ S/S SELF-SUSTAINING CHECK HINGE, L/ COVER PFWR PROFLO WAX RING PFC54A10 PROFLO...
Page 31 P1C ADA WATER CLOSET 3461001020 ÿ ÿ ÿ ÿ ÿ ÿ Page: 31 / 395...
Page 32 P1C ADA WATER CLOSET ✣ ✖ ✕ ✙ ✔ ✛ ✩ ◆ ✥ ❚ ◆ ✆ ÿ ✔ ✕ ✖ ✗ ✘ ✙ ✚ ✕ ✛ ✜ ✢ ✘ ❚ ✁ ÿ ✂ ÿ ✄ ❲ ❚ ☎ ÿ ✂...
Page 33 P1C ADA WATER CLOSET ® AquaSense ZER Series Automatic Sensor-Operated, Battery-Powered Flushometer Installation, Operation, Maintenance, and Parts Manual Patented and Patents Pending ZER6000AV-CP ZER6000AV-CPM Sensor-Operated, Battery-Powered Closet/Urinal Systems ZER6003AV-CP ZER6000AV-CPM ZER6003AV-CPM ZER6000AV-WS1-CPM ZER6001AV-CPM ZER6001AV-WS1-CPM ZER6003AV-CPM ZER6003AV-WS1-CPM LIMITED WARRANTY All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the date of purchase.
Page 34 P1C ADA WATER CLOSET IMPORTANT: PRIOR TO INSTALLATION • ALL PLUMBING IS TO BE INSTALLED IN ACCORDANCE WITH APPLICABLE CODES AND REGULATIONS. Prior to installing the ZER Flushometer, install the • WATER SUPPLY LINES MUST BE SIZED TO PROVIDE AN items listed below: ADEQUATE VOLUME OF WATER FOR EACH FIXTURE.
Page 35 P1C ADA WATER CLOSET 6.) ACTIVATION Using supplied battery compartment wrench, remove battery compartment from the E-Z Flush™ unit. Load batteries into compartment tray (note position of batteries in tray), and reinstall battery tray into the E-Z Flush unit. Secure tray with battery compartment wrench. The last three turns of the wrench will activate the E-Z Flush unit.
Page 36 P1C ADA WATER CLOSET Before the supply water is turned on, be sure all stop valves to 10.) The ZER flush valves are preset for fixture volume as marked the flush valves are closed off tight. The stop valves can be on the valve cartons.
Page 37 P1C ADA WATER CLOSET WIRING DIAGRAM Delay Flush = User must leave the sensor range for 3 seconds before a flush is generated. 24 Hour Flush = Unit will automatically flush 24 hours after the last use. TROUBLE SHOOTING GUIDE PROBLEM CAUSE SOLUTION...
Page 38 P1C ADA WATER CLOSET ® AquaVantage Exposed E-Z Flush Repair Kits Part Identification 1. Seal 2. Collar Gasket 3. Sensor Module 4. Manual Overide Push Button 5. Replacement Sensor Lens 6. Chrome Plastic Cover 7. Chrome Metal Cover 8. Battery Drawer 9.
Page 39 P3 ADA LAVATORY A0355012020 AMERICAN 21 X 18 4 VITREOUS CHINA LAVATORY WHITE LUCERN WHITE STANDARD D23C343 DELTA CCN LEAD LAW COMPLIANT 1.5 2 LEVER LAVATORY THREE HOLE WITHOUT POP UP 23T ZZ8743PC ZURN SLD TOP OPEN GRID PULL OUT PL PFPTB300 PROFLO 1-1/4 22GA P TRAP CP...
Page 40 P3 ADA LAVATORY ✜ ✢ ✣ ✣ ✤ ✥ ✣ ✦ ✣ ✥ ✥ ÿ ÿ ✁ ✂ ✄ ☎ ✆ ✝ ✄ ✞ ✁ ✟ ✆ ✂ ✠ ✆ ✁ ✄ ✡ ✆ ☛ ✆ ✆ ✁ ✄ ✝ ☞ ✌ ✆ ✠ ✍ ☛...
Page 41 P3 ADA LAVATORY ÿ ÿ ✁ ✂ ✄ ☎ ✆ ☎ ✆ ✝ ✆ ✞ ✆ ✟ ✠ ✆ ☎ ✟ ✡ ✂ ☛ ✂ ☛ ☎ ✆ ☞ ✂ ✝ ☎ ✆ ✌ ✂ ✆ ✍ ✝ ☛ ✞ ✍...
Page 42 P3 ADA LAVATORY ÿ ÿ ÿ ÿ ÿ ÿ ÿ Page: 42 / 395...
Page 43 P3 ADA LAVATORY ❂ ❃ ❂ ❄ ❂ ❅ ❅ ❄ ❃ ❅ ÿ ÿ ✁ ✂ ✄ ☎ ✆ ✝ ✝ ✁ ✄ ✞ ✝ ✟ ☎ ✄ ✝ ✄ ✆ ✠ ✠ ☎ ✡ ÿ ÿ ✝ ☛ ✆...
Page 44 P3 ADA LAVATORY ÿ ❙ ✿ ✯ ✁ ✂ ✄ ☎ ✆ ✁ ✝ ☎ ✆ ✆ ✞ ✝ ✟ ☎ ✠ ✝ ✡ ☛ ✝ ☞ ✌ ✍ ✁ ✝ ☎ ✝ ✠ ✆ ✎ ✏ ✏ ☛ ✁ ✄ ✆ ✌ ☎ ✑ ✏ ✒ ✍ ✡ ✌ ✏ ✌ ✡ ✄ ✆ ✎ ✓ ✓ ✄ ✆ ✍ ✄ ✔ ✏...
Page 45 P3 ADA LAVATORY ✵ ✹ ✺ ✺ ✿ ❀ ✺ ❁ ✺ ❀ ❀ ✭ ✁ ✞ ✂ ❆ ✠ ✭ ✁ ✞ ✂ ❆ ✠ € ✍ ✄ ❈ ✆ ✂ ✄ ❙ ☎ ❚ ✞ ✠ ✡ ✍ ❚ ✟ ✝ ❚ ÿ...
Page 46 MOUNTING SCREW HOLES (4) EXAMPLE: For Lucerne: HOLES FOR 32"-1"=31" ANCHOR SCREWS HEIGHT For Ledgewood: IN BACK POSITIONING DRAPERY SCREW SLOTS (2) 32"+2-7/8"=34-7/8" SUPPLIES AS REQUIRED WASTE FINISHED FLOOR © American Standard Inc. 2003 730427-100 Rev. B Page: 46 / 395...
Page 47 American Standard. American Standard's option to repair or exchange the product under this warranty does not cover any labor or other costs of removal or installation, nor shall American Standard be responsible for any other incidental or consequential damages attributable to a product defect or to the repair or exchange of a defective product, all of which are expressly excluded from this warranty.
Page 48 P3 ADA LAVATORY Page: 48 / 395...
Page 49 P3 ADA LAVATORY Page: 49 / 395...
Page 50 P3 ADA LAVATORY Page: 50 / 395...
Page 51 P3 ADA LAVATORY Page: 51 / 395...
Page 52 P3 ADA LAVATORY Page: 52 / 395...
Page 53 P3 ADA LAVATORY Page: 53 / 395...
Page 54 P3 ADA LAVATORY Page: 54 / 395...
Page 55 P3 ADA LAVATORY Page: 55 / 395...
Page 56 P3A ADA LAVATORY A0496221020 AMERICAN 19 X 16 VITREOUS CHINA UNDERCOUNTER MOUNT LAVATORY STANDARD *OVALYN WHITE D23C343 DELTA CCN LEAD LAW COMPLIANT 1.5 2 LEVER LAVATORY THREE HOLE WITHOUT POP UP 23T ZZ8743PC ZURN SLD TOP OPEN GRID PULL OUT PL ZZ8804XLLRLKPC ZURN LEAD LAW COMPLIANT 1/2 NOMINAL X 3/8 OD W/LCK LAVATORY...
Page 57 P3A ADA LAVATORY 0496221020 ÿ ✁ ✂ ② ✄ ÿ ② ❛ ÿ ❛ ❛ ✐ ✂ ✐ ✂ ÿ ✳ ❉ ◆ ☎ ❚ ✆ ✥ ❋ ✝ ✞ ✟ ✠ ✡ ☛ ✕ ☎ ✖ ✗ ☎ ☎ ❖ ❈ ☎ ✘ ◆ ❚ ✆ ✖ ❚ ☎ € ✕...
Page 58 P3A ADA LAVATORY Page: 58 / 395...
Page 59 P3A ADA LAVATORY Page: 59 / 395...
Page 60 P3A ADA LAVATORY Page: 60 / 395...
Page 61 P3A ADA LAVATORY Page: 61 / 395...
Page 62 P3A ADA LAVATORY Page: 62 / 395...
Page 63 P3A ADA LAVATORY Page: 63 / 395...
Page 64 P3A ADA LAVATORY Page: 64 / 395...
Page 65 P3A ADA LAVATORY Page: 65 / 395...
Page 66 P3A ADA LAVATORY Page: 66 / 395...
Page 67 P3A ADA LAVATORY Page: 67 / 395...
Page 68 P3B ADA LAVATORY A0476028020 AMERICAN 20 X 17 VITREOUS CHINA 4 LAVATORY AQUALY WHITE STANDARD D520DST DELTA CCY LEAD LAW COMPLIANT 1.2 GALLONS PER MINUTE CENTER SET BATH FAUCET SINGLE HANDLE ZZ8743PC ZURN SLD TOP OPEN GRID PULL OUT PL BOCR19XC BRASSCRAFT LF 1/2"...
Page 69 Drill a clearance hole inside the perimeter line of the template. Perimeter of template Perimeter Cut opening around the of template perimeter of the template. © American Standard Inc. 2003 730236-100 Rev. D Page: 69 / 395...
Page 70 American Standard. American Standard's option to repair or exchange the product under this warranty does not cover any labor or other costs of removal or installation, nor shall American Standard be responsible for any other incidental or consequential damages attributable to a product defect or to the repair or exchange of a defective product, all of which are expressly excluded from this warranty.
Page 71 P3B ADA LAVATORY 54195 SINGLE HANDLE LAVATORY CENTERSET FAUCETS LLAVES MONOCONTROL DE MONTURA DE CENTRO PARA LAVAMANOS ROBINETS À ENTRAXE COURT À UNE POIGNÉE Write purchased model number here. Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici. You may need/Usted puede necesitar/ Articles dont vous pouvez avoir besoin: For easy installation of your Delta...
Page 72 P3B ADA LAVATORY WARNING: CLEANING AND CARE ® ® Scrubbing Bubbles Bathroom Cleaner and Lysol Basin Tub and Tile Cleaner LIFETIME FAUCET AND FINISH LIMITED WARRANTY ® In the United States: In Canada: ® ® ® LIMPIEZA Y CUIDADO DE SU LLAVE ¡ADVERTENCIA! ®...
Page 73 P3B ADA LAVATORY Maintenance If faucet exhibits very low flow: If leak persists * WARNING: Failure to securely tighten bonnet nut with a wrench could result in water damage. Note: If faucet leaks from spout outlet If faucet leaks from under handle: Mantenimiento * AVISO: Si no aprieta ﬁjamente la tuerca Si la lave de agua exhibe muy poco flujo:...
Page 74 P3B ADA LAVATORY 500-DST, 501-DST, 502-DST, 520-DST 521-DST & 522-DST 501M-DST & 520M-MPU-DST RP54899 501M-DST & 520M-MPU-DST Series 500-DST, 501-DST, 502-DST, 520-DST 521-DST & 522-DST Series Option: If sink is uneven, use Option: If sink is uneven, silicone under the gasket. use silicone under the gasket.
Page 75 P3B ADA LAVATORY Standard Connections Custom Fit Connections Conexiones Estándares Conexiones Especiales Branchements Standard Branchements Spéciaux NOTICE: If you determine the PEX supply tubing for Potential Problems and Remedies ● Tubing is not cut perpendicular to the axis of this faucet is too long and must be shorter to create an acceptable installation, be sure to read the the tube: Note: Recom-...
Page 76 P3B ADA LAVATORY Custom Fit Connections - Plastic Sleeve Installation Instructions Conexiones Especiales - Instructions d’installations de le manchon en plastique Spéciaux Branchement - Instrucciones para la Instalación del la Manga Plástica Correct method Incorrect Installation Método Correcto Instalación Incorrecta Installation Incorrecte Bonne méthode Do not...
Page 77 P3B ADA LAVATORY (Follow the instructions for the type of pop-up included with your model.) Metal Pop-Up (Siga las instrucciones para el tipo de incluido desagüe automático con su modelo.) Desagüe Automático de Metal (Suivez les instructions pour le type d’inclus renvoi mécanique avec votre modèle.) Renvoi Mécanique en Métal Page: 77 / 395...
Page 78 P3B ADA LAVATORY (Follow the instructions for the type of pop-up included with your model.) Pop-Up with Metal Flange and Plastic Tail Piece (Siga las instrucciones para el tipo de incluido desagüe automático con su modelo.) Drenaje automático con brida de metal y la pieza de cola plástica (Suivez les instructions pour le type d’inclus renvoi mécanique avec votre modèle.) Renvoi mécanique avec collerette en métal et raccord droit de vidange en plastique Page: 78 / 395...
Page 79 P3B ADA LAVATORY (Follow the instructions for the type of pop-up included with your model.) Plastic Pop-Up Important: This flushes away any debris that could cause damage to internal parts. (Siga las instrucciones para el tipo de incluido desagüe automático con su modelo.) Desagüe automático plástico Importante: Esto limpia cualquier escombro que pudiera causar daño a las partes internas.
Page 80 P3B ADA LAVATORY Setting The Handle Limit Stop (Optional) To change positions of the handle limit stop: Fijando la parada de límite de la manija (opcional) Para cambiar las posiciones de la manija que limitan la temperatura: Plaçant l’arrêt de limite de poignée (facultatif) Pour modiﬁer la position de la butée de température maximale de la manette : Page: 80 / 395...
Page 81 P3B ADA LAVATORY RP53457▲ RP17446 RP52220 RP152 RP52221 RP53458 RP52833▲ RP63263 RP152 RP51502▲ RP73192 RP51503 RP50587 RP6146▲ RP60730 RP51505 ✱ Aerator Aereador ▲ Aérateur RP6092 RP60729 RP60983 RP71111 RP54977 RP54899 .5 GPM 1.5 GPM .5 GPM 1.5 GPM RP53531 ✱ If you are unsure of the manufacture date, please order both aerators in the ﬂow rate you desire.
Page 82 P3B ADA LAVATORY RP26533▲ RP27575▲ RP6146▲ RP5648▲ RP5648▲ RP12516 RP12516 RP23060▲ RP12517 RP6142 RP6142 RP6132 RP6140 RP6140 RP33037 RP12517 RP6130 RP6130 ▲ RP34953 RP6146▲ RP5648▲ RP12517 Page: 82 / 395...
Page 83 P4A WATER COOLER EEZTL8LC ELKAY 8G BI-LEVEL ADA WATER COOLER ZZ8804XLPC ZURN LEAD LAW COMPLIANT 1/2 NOMINAL X 3/8 OD ANGLE ST ZZ8700PC ZURN 1-1/4X10 CAST BDY PTRAP Page: 83 / 395...
Page 84 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G INSTALLATION, CARE & USE MANUAL Manual de Instalación, Cuidado y Utilización Manuel d’installation/entretien/utilisation EZTL & LZTL Series Versatile Bi-Level Water Coolers ™ ™ ™ ™ EZTL & LZTL Serie versátil bi-nivel enfriadores de agua ™...
Page 85 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G Note: Danger! Electrical shock hazard. Disconnect power before servicing unit. Nota: peligro! Peligro de descarga eléctrica. Desconecte antes de reparar la unidad l’appareil. Remarque : Danger ! Risque de choc électrique. Débrancher avant de réparer Uses HFC-134A refrigerant Usa refrigerante HFC-134A Utilise du fluide frigorigéne HFC-134A...
Page 86 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G FIG. 2 PAGE 3 1000003093 (Rev. A - 02/16) Page: 86 / 395...
Page 87 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G FIG. 3 1000003093 (Rev. A - 02/16) PAGE 4 Page: 87 / 395...
Page 88 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G HANGER BRACKETS & TRAP INSTALLATION DES SUPPORTS INSTALACIÓN DE LOS SOPORTES DE SUSPENSION ET DU SIPHON FIJADORES Y EL PURGADOR INSTALLATION 1) Retirez le support de suspension fixé au dos du Retire el soporte fijador que se encuentra conectado 1) Remove hanger brackets (Item 29) fastened to back refroidisseur en retirant une (1) vis.
Page 89 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G Service Instructions Lower and Upper Shroud To access the refrigeration system and plumbing connections, remove four screws from bottom of cooler to remove the lower shroud. To remove the upper shroud for access to the pushbars, regulator, solenoid valve or other components located in the top of the unit, remove lower shroud, disconnect drain, remove four screws from tabs along lower edge of upper shroud, unplug two wires and water tube.
Page 90 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G Basin Estanque Bassin Locknut Tuerca de Fijación Écrou de Blocage BUBBLER DETAIL VANDAL RESISTANT BUBBLER DETAIL DETALLE DEL GRIFO DETALLE DEL GRIFO RESISTENTE AL VANDALISMO DESCRIPTION DU BARBOTEUR RESISTANT AU VANDALISME DETAIL DU BARBOTEUR FIG.
Page 91 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G Fig. 8 WATERSENTRY Filter Detail ® Detalle WATERSENTRY Filtro ® Description WATERSENTRY Filtrage ® WATERSENTRY FILTER PARTS LIST LISTA DE PIEZAS DEL FILTRO LISTE DES PIÈCES DU ® (See Fig. 8) (Vea la Fig. 8) FILTRE (Voir Fig.
Page 92 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G 220V PARTS LIST/ 220V LISTA DE PIEZAS/ 220V LISTE DES PIÈCES ITEM PART NO. DESCRIPTION DESCRIPCIÓN DESCRIPTION 0000000802 Kit - Solenoid Valve/Regulator Assy Kit - Montaje del Regulador/Válvula Soleoide Kit - Solénoide de la Vanne/Régulateur 0000000245 Kit - Fan Motor Assy/Blade/Motor/Shroud/ Kit - Ventilador Motor Montaje/Hoja/Motor/...
Page 93 P4A WATER COOLER EZF(S)TL8*1G, 2G LZF(S)TL8*1G, 2G 115V PARTS LIST/ 115V LISTA DE PIEZAS/ 115V LISTE DES PIÈCES ITEM PART NO. DESCRIPTION DESCRIPCIÓN DESCRIPTION 28401C Hanger Bracket Soporte colgante Support de suspension 56229C Assy - Shroud - Upper Cubierta - Superior Enveloppe de Protection - Supérieure (Front Side Push) (Frontal Lateral Presión)
Page 94 P4A WATER COOLER LIMITED PRODUCT WARRANTY SOFTWARE LICENSE FIRST YEAR - - The Manufacturer warrants every cooler, bottle filling station, packaged water chiller, fountain and accessory to be free from defects in materials and workmanship under normal use for one (1) year from date of install or eighteen (18) months from date of shipment from factory, whichever occurs first. SECOND THROUGH FIFTH YEARS - The Manufacturer warrants the compressor and hermetically sealed refrigeration system, including cooling coils or tank assembly when part of the hermetically sealed refrigeration system, to be free from defects in material and workmanship under normal use for an additional four (4)
Page 95 P4A WATER COOLER GARANTÍA LIMITADA DEL PRODUCTO LICENCIA DE SOFTWARE PRIMER AÑO: El fabricante garantiza que todo enfriador de agua, estación llenadora de botellas, enfriador de agua empaquetado, fuente de agua potable y accesorio sea libre de defectos de material y mano de obra bajo uso normal durante un (1) año a partir de la fecha de instalación o dieciocho (18) meses a partir de la fecha de envío de la fabrica, lo que ocurra primero.
Page 96 P4A WATER COOLER ________________________________ STANDARD ANGLE STOPS Z8804-XL-PC TO Z8804-XL-LK-PC TAG _______ Engineering Specification: Zurn Z8804-XL-PC to Z8804-XL-LK-PC - Zurn chrome plated, solid brass angle stop compression to compression fitting with round wheelhandle or loose key as specified. Zurn Lead Compliant* “XL” products are a line of durable, high quality brass faucets and fixtures that are designed and manufactured to comply with state laws and local codes that mandate lead content levels.
Page 97 P5A BREAK ROOM SINK ELRAD2022603 ELKAY 20X22X6 3H 1B ADA SS SINK D100LFHDF DELTA CCY LEAD LAW COMPLIANT 1.5 CLASSIC 1 HANDLE CENTER SET KITCHEN FAUCET ZZ8741SS ZURN SS HD BASKET STRAINER W/ 4 TAILPIECE ZZ8804XLLRPC ZURN LEAD LAW COMPLIANT 1/2 NOMINAL X 3/8 OD LAVATORY SUPPLY STANDARD ZZ8702PC ZURN...
Page 98 P5A BREAK ROOM SINK Page: 98 / 395...
Page 99 P5A BREAK ROOM SINK Page: 99 / 395...
Page 100 P5A BREAK ROOM SINK Page: 100 / 395...
Page 101 P5A BREAK ROOM SINK Page: 101 / 395...
Page 102 P5A BREAK ROOM SINK ® CERTIFICADO DE GARANTÍA LIMITADA DE POR VIDA DE FREGADEROS ELKAY Elkay garantiza al comprador inicial de fregaderos de acero inoxidable Elkay que reemplazará sin cargo todo producto que falle debido a defectos de fabricación durante todo el período normal de uso residencial.
Page 103 P5A BREAK ROOM SINK ® LIMITED LIFETIME SINK WARRANTY Elkay warrants to the original purchaser of an Elkay stainless steel sink, that Elkay will, at its option, replace, without charge, such product if it fails due to a manufacturing defect for a lifetime of normal residential use.
Page 104 P5A BREAK ROOM SINK SINGLE HANDLE KITCHEN FAUCET 64085 LLAVE DE COCINA DE PALANCA ROBINET DE CUISINE À UNE MANETTE ® ® ASME A112.18.1 / CSA B125.1 Models/Modelos/Modèles 100LF-HDF, 101LF-HDF & 400LF-HDF Series/Series/Seria Write purchased model number here. Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici.
Page 105 P5A BREAK ROOM SINK Cleaning and Care durable, it can be damaged by harsh abrasives or polish. To clean, simply wipe gently with a damp cloth and blot dry with a soft towel. Delta Commercial Faucet Limited Warranty All parts of the Delta ®...
Page 106 P5A BREAK ROOM SINK RP54687 RP152 Handle with Set Screw RP60097 Set Screw Manija con Tornillo de Ajuste Spray & Hose Assembly Tornillo de Ajuste Manette avec Vis de Calage Rociador Vis de Calage Douchette RP51502 Casquillo Embase RP6015 Support Assembly RP51503 Ensamble del Soporte Bonnet...
Page 107 P5A BREAK ROOM SINK 100 Series 101 Series 100 Series 101 Series SHUT OFF WATER SUPPLIES. Remove old faucet. Make sure base, spacer SHUT OFF WATER SUPPLIES. Remove old faucet. Slide gasket (1) and gasket (1) are properly positioned under new faucet. Feed tubes and over tubes (2) and install onto bottom of faucet.
Page 108 P5A BREAK ROOM SINK 400 Series 400 Series 400 Series SHUT OFF WATER SUPPLIES. Remove old faucet. Slide gasket (1) Mount the spray support (1) in far right hole in sink. Hand tighten nut (2). over tubes (2) and install onto bottom of faucet. NOTE: If surface is Insert spray hose (3) down through support assembly.
Page 109 P5A BREAK ROOM SINK For Sprayer Models Only Keeping clip (1) disengaged, insert diverter hose end (2) into diverter Pull on clip (1) until disengaged. Pull down on diverter plug (2) to housing (3) until seated. Push in clip (1) until it snaps. Pull down remove.
Page 110 P5A BREAK ROOM SINK FLUSH YOUR SYSTEM: Water Line Connections position. Turn on hot and cold water supplies (3) and flush water lines for Ensure all fittings and end connections are free of debris. Faucet fittings (1) one minute. Important: This flushes away any debris that could cause are 3/8"...
Page 111 P5A BREAK ROOM SINK Maintenance If faucet exhibits very low flow: A. Remove and clean Aerator (1), or B. SHUT OFF WATER SUPPLIES. Replace valve cartridge (2). When reinstall- ing parts, make sure bonnet nut (4) is tightened securely with a wrench.* If faucet leaks from under handle: Remove handle and unthread trim cap (3).
Page 112 P6A ADA BATHTUB A2391202020 AMERICAN 60 X 30 RIGHT HAND BATH AMERICA WHITE STANDARD DR10000UN DELTA 1 HANDLE PRESSURE BALANCE UNIVERSAL VALVE ONLY DT13420 DELTA CCY 2.0 1 HANDLE LEVER TUB AND SHOWER FAUCET TRIM PRESSURE BALANCE Page: 112 / 395...
Page 113 P6A ADA BATHTUB 2391202020 ÿ ÿ Page: 113 / 395...
Page 114 P6A ADA BATHTUB ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ✕ ■ ✎ ① ✏ ✑ ✄ ❛ ❞ ✒ ▼ ② ✾ ✈ ✆ ✁ ☞ ☞ ❛ ...
Page 115 P6A ADA BATHTUB Page: 115 / 395...
Page 116 P6A ADA BATHTUB MULTICHOICE ROUGH-IN BODY ® 50353 PIEZAS PARA LA INSTALACIÓN INTERNA MULTICHOICE ® CORPS DE ROBINET MULTICHOICE ® ® ® ASME A112.18.1 / CSA B125.1 Model/Modelo/Modèle R10000 Series/Series/Seria Write purchased model number here. Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici.
Page 117 P6A ADA BATHTUB DIVERTER SHUT OFF WATER SUPPLIES. Distance (1) from the stringer (2) The ﬁgure illustrates the diverter to the front of the plasterguard is and MultiChoice installed in the Consider the type and thickness of 2 3/4" ± 1/4" (70 mm ± 6 mm). same ﬁnished wall.
Page 118 P6A ADA BATHTUB Copper Tubing Tubería de Cobre Cuivre Iron Pipe Hierro If you are making a back to back or Remove bonnet (1) and test cap Connect valve body to water supplies reverse installation (hot on right and (2) before soldering. Leave screen using the proper fittings for your valve (3) installed.
Page 119 P6A ADA BATHTUB 8" - 18" (203 mm-457 mm) 8 po - 18 po PRESSURE TESTING & FLUSHING THE INSTALLATION Connect top outlet (1) to shower pipe with proper fittings. Connect bottom outlet (2) to Prior to testing, remove cover (1), bonnet (2) and cap (3). Ensure O-ring (4) tub spout pipe with proper fittings.
Page 120 P6A ADA BATHTUB Replacement Parts Piezas de Repuesto Pièces de rechange RP46078 Test Cap Tapa de Prueba Capuchon d’essai RP22734 Bonnet Capuchón Chapeau RP46077 Screen Filtro de malla RP46075 Tamis Plasterguard Protector de yeso Protecteur RP46076 Cover Cubierta Couvercle RP50366 Stop RP46079 Tope...
Page 121 P6A ADA BATHTUB LIFETIME FAUCET AND FINISH LIMITED WARRANTY All parts and finishes of the Delta ® faucet are warranted to the original consumer AS ANY OTHER KIND OF LOSS OR DAMAGES ARE EXCLUDED. Proof of purchase purchaser to be free from defects in material & workmanship for as long as the original (original sales receipt) from the original consumer purchaser must be made available to consumer purchaser owns their home.
Page 122 P6A ADA BATHTUB IMPORTANT DOCUMENTS ENCLOSED CAUTION: To reduce the risk of injury due to hot water burns, make sure the enclosed labels are DOCUMENTOS IMPORTANTES INCLUIDOS AVISO: Para reducir el riesgo de lesión por quemaduras de agua caliente , asegúrese que las etiquetas incluidas se han aplicado donde MISE EN GARDE : apposer les étiquettes fournies aux endroits...
Page 123 P6A ADA BATHTUB NOTICE TO INSTALLER: Place this label on the water heater NOTICE TO INSTALLER: WARNING WARNING: Water temperature changes due to seasonal or other inlet variations, such as changing the setting on the hot water heater may require adjustment of the rotational limit stop (13/14/17 Series) or If the temperature setting of the temperature knob (17T Series) on your tub/shower valve to ensure a safe maximum temperature.
Page 124 P6A ADA BATHTUB ® MultiChoice Valve Trim Installation Instructions Owners Manual 13/14 Series ASME A112.18.1 / CSA B125.1 ASSE 1016 (Type -P- or -T-) Write purchased model number here. You May Need Table of Contents: Warranties ................. Page 2 Clean and care................Page 8 Maintenance ................
Page 125 P6A ADA BATHTUB Lifetime Faucet and Finish Limited Warranty Cartridge Installation Parts and Finish In the United States and Mexico: All parts (other than electronic parts and batteries) and Product Service ® faucet are warranted to the original 55 E. 111th Street consumer purchaser to be free from defects in material Indianapolis, IN 46280 and workmanship for as long as the original consumer...
Page 126 P6A ADA BATHTUB Installation Showerhead and Tub Spout Installation Showerhead and Tub Spout Installation FOR SHOWERHEAD INSTALLATION: Connect top FOR TUB SPOUT INSTALLATION: use PEX tubing for tub spout drop. arm into riser connection. Thread showerhead (4) onto shower arm. Apply plumber tape to pipe threads on both Slip- The c copp...
Page 127 P6A ADA BATHTUB Installation Adjusting the Rotational Limit Stop Trim Installation Stem 1st Position Rotational Limit Stop IMPORTANT: for a comfortable bath or shower is typically The Rotational Limit Stop is used to limit the amount of hot water available such that, if set properly, the user will not be scalded if the handle cold as it will get and hot water is as hot as Slide O-ring (1) over cartridge and the...
Page 128 P6A ADA BATHTUB Clean and Care ® Care should be given to the cleaning Warning: Scrubbing Bubbles Bathroom ® Cleaner and Lysol Basin Tub and Tile extremely durable, it can be damaged by Cleaner must not be used on the clear knob harsh abrasives or polish.
Page 129 P6A ADA BATHTUB Garantía Limitada De Por Vida de la Llave y su Acabado Instalación del Cartucho Piezas y acabado En los Estados Unidos y México: Todas las piezas (excepto las piezas electrónicas y las ® Product Service 55 E. 111th Street están garantizados al consumidor comprador original de estar libres de defectos en material y fabricación Indianapolis, IN 46280...
Page 130 P6A ADA BATHTUB Instalación Instalación de la Cabeza de la Regadera y el Surtidor de la Bañera Instalación de la Cabeza de la Regader PARA LAS INSTALACIONES DE LAS CABEZAS PARA LA INSTALACIÓN DEL SURTIDOR DE LA BACERA DE REGADERA: Conecte la toma de salida de instalación suministradas con su surtidor.
Page 131 P6A ADA BATHTUB Instalación El Ajuste del Tope que Limita la Rotación Instalación Final Más Caliente Unidad Posición Primera IMPORTANTE: El Ajuste del Tope que Limita la Rotación peraturas variadas en el agua de salida. Una se usa para limitar la cantidad de agua temperatura de agua para un baño o ducha caliente disponible de manera que, si ajustado apropiadamente, el usuario no se...
Page 132 P6A ADA BATHTUB Limpieza y Cuidado de su Llave Tenga cuidado al ir a limpiar este producto. ¡ADVERTENCIA! No se puede usar ® Aunque su acabado es sumamente durable, SCRUBBING BUBBLES BATHROOM ® puede ser afectado por agentes de limpieza CLEANER o LYSOL BASIN TUB AND TILE o para pulir abrasivos.
Page 133 P6A ADA BATHTUB Installation de la cartouche Product Service ® 55 E. 111th Street et les vices de fabrication par une garantie qui est Indianapolis, IN 46280 St. consentie au premier acheteur et qui demeure valide tant customerservice@deltafaucet.com Au Canada: utilisation commerciale, la garantie est de 5 ans à...
Page 134 P6A ADA BATHTUB Installation Installation de la pomme de douche et du bec de baignoire Installation de la pomme de douche et INSTALLATION DE LA POMME DE DOUCHE : INSTALLATION DU BEC DE BAIGNOIRE : mur » de celui-ci dans la collerette (3) avant de le visser dans le raccord du tuyau vertical.
Page 135 P6A ADA BATHTUB Installation Réglage de la butée anti-échaudage Plus chaude Obturateurs 1ère Position IMPORTANT: froide que possible et aussi chaude que possible. Placez ensuite la manette sur la sous la douche ou dans la baignoire. La et il stabilise le manchon; il doit se trouver première position est celle qui laisse passer tournez la manette dans le sens antihoraire plage.
Page 136 P6A ADA BATHTUB Instructions de nettoyage 58045 & 58065 Models / M ® Il faut le nettoyer avec soin. Même si son de Baignoires et de Carreaux Lysol 58045 transparentes. Ces produits peuvent faire ou des produits de polissage. Il faut RP40592 simplement le frotter doucement avec un Pestaña de la Regadera...
Page 137 P6A ADA BATHTUB T13020, T13022, T13120, T13122, T13220, T13220-H2O, T13090, T13091, T13290, T13291, T T13222, T13220-SHCCER, T13420-SHCCER, T13420, Models / Modelos / Modèles T13420-H2O& T13422 Models / Modelos / Modèles RP38452 RP38357 RP40594 RP43381 RP38357 RP43381 Showerhead Showerhead Showerhead Showerhead Pestaña de RP46384 RP6023...
Page 138 P6A ADA BATHTUB T14038, T14238, T14238-H2O, T14 T14130, T14230 & T14430 Models / Modelos / Modèles Models / Modelos / Modèles RP38452 Pestaña de la Rogadora RP54752 RP41589 RP6023 RP6023 RP40594 Collerette Showerhead Showerhead Shower Arm Shower Arm Showerhead Cabeza de Rogadora Cabeza de Rogadora Brazo de la Rog Brazo de la Rogadora...
Page 139 P6A ADA BATHTUB T14051, T14251, T14251-H2O, T14451 & T14451-H2O T14053, T14253, T14253-H2O, T144 Models / Modelos / Modèles Models / Modelos / Modèles RP62283 RP52144 RP6023 Showerhead Shower Arm Cabeza de Rogadora Pestaña dela Rogadora RP62955 Brazo de la Rogadora Collerette Showerhead Cabeza de Rogadora...
Page 140 P6A ADA BATHTUB T14155, T14255-LHP, T14255-H2OLHP, T14455-LHP T14178, T14278-LHP, T14278-H2OLHP, T1 & T14455-H2OLHP Models / Modelos / Modèles T14478-H2OLHP & 14478-SHCCER Model RP34355 RP71072 RP6023 RP34356 Showerhead Showerhead Shower Arm Cabeza de Rogadora Cabeza de Rogadora Brazo de la Rogadora Pestaña dela Rogadora RP41589 RP54752...
Page 141 P6A ADA BATHTUB T14059, T14259 & T14459 Models / Modelos / Modèles T14061, T14261 & T14461 Model RP6025 Pestaña dela Rogadora Collerette RP6023 RP6023 Shower Arm RP70175 Shower Arm RP73373 Brazo de la Rogadora Showerhead Brazo de la Rogadora Escutcheon RP70175 Cabeza de Rogadora Roseta...
Page 142 P6A ADA BATHTUB T14086, T14186, T14286, T14286-SH T14082, T14085, T14185, T14282, T14285, T14285-H2O,T 14482, SHQ Models / Modelos / Modèles T14485 & T14485-H2O Models / Modelos / Modèles RP46870 Shower Arm Brazo de la Rogadora Tuyau de Pomme RP40592 RP40593 Shower Arm RP46870 Pestaña dela Rogadora...
Page 143 P6A ADA BATHTUB T14092, T14292 & T14492 Models / Modelos / Modèles T14092, T14292 & T14492 Model RP6023 RP61266 RP61265 Shower Arm RP6023 Showerhead RP51305 Brazo de la Rogadora Pestaña dela Rogadora RP54752 Shower A Cabeza de Rogadora Showerhead Tuyau de Pomme Collerette Showerhead Brazo de...
Page 144 P6A ADA BATHTUB Notes / Notas / Notes T14092, T14292 & T14492 Models / Modelos / Modèles RP72562 RP70172 RP40593 Pestaña dela Rogadora Showerhead Shower Arm Collerette Cabeza de Rogadora Brazo de la Rogadora Tuyau de Pomme RP72563 Escutcheon RP49037 Roseta Trim Screws/Atornillos de RP46074...
Page 145 P6A ADA BATHTUB Notes / Notas / Notes Notes / Notas / Notes Page: 145 / 395...
Page 146 P6A ADA BATHTUB Product Service 55 E. 111th Street Indianapolis, IN 46280 Page: 146 / 395...
Page 147 P6 SHOWER VALVE DR10000UN DELTA 1 HANDLE PRESSURE BALANCE UNIVERSAL VALVE ONLY DT13420 DELTA CCY 2.0 1 HANDLE LEVER TUB AND SHOWER FAUCET TRIM PRESSURE BALANCE Page: 147 / 395...
Page 148 P6 SHOWER VALVE MULTICHOICE ROUGH-IN BODY ® 50353 PIEZAS PARA LA INSTALACIÓN INTERNA MULTICHOICE ® CORPS DE ROBINET MULTICHOICE ® ® ® ASME A112.18.1 / CSA B125.1 Model/Modelo/Modèle R10000 Series/Series/Seria Write purchased model number here. Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici.
Page 149 P6 SHOWER VALVE DIVERTER SHUT OFF WATER SUPPLIES. Distance (1) from the stringer (2) The ﬁgure illustrates the diverter to the front of the plasterguard is and MultiChoice installed in the Consider the type and thickness of 2 3/4" ± 1/4" (70 mm ± 6 mm). same ﬁnished wall.
Page 150 P6 SHOWER VALVE Copper Tubing Tubería de Cobre Cuivre Iron Pipe Hierro If you are making a back to back or Remove bonnet (1) and test cap Connect valve body to water supplies reverse installation (hot on right and (2) before soldering. Leave screen using the proper fittings for your valve (3) installed.
Page 151 P6 SHOWER VALVE 8" - 18" (203 mm-457 mm) 8 po - 18 po PRESSURE TESTING & FLUSHING THE INSTALLATION Connect top outlet (1) to shower pipe with proper fittings. Connect bottom outlet (2) to Prior to testing, remove cover (1), bonnet (2) and cap (3). Ensure O-ring (4) tub spout pipe with proper fittings.
Page 152 P6 SHOWER VALVE Replacement Parts Piezas de Repuesto Pièces de rechange RP46078 Test Cap Tapa de Prueba Capuchon d’essai RP22734 Bonnet Capuchón Chapeau RP46077 Screen Filtro de malla RP46075 Tamis Plasterguard Protector de yeso Protecteur RP46076 Cover Cubierta Couvercle RP50366 Stop RP46079 Tope...
Page 153 P6 SHOWER VALVE LIFETIME FAUCET AND FINISH LIMITED WARRANTY All parts and finishes of the Delta ® faucet are warranted to the original consumer AS ANY OTHER KIND OF LOSS OR DAMAGES ARE EXCLUDED. Proof of purchase purchaser to be free from defects in material & workmanship for as long as the original (original sales receipt) from the original consumer purchaser must be made available to consumer purchaser owns their home.
Page 154 P6 SHOWER VALVE IMPORTANT DOCUMENTS ENCLOSED CAUTION: To reduce the risk of injury due to hot water burns, make sure the enclosed labels are DOCUMENTOS IMPORTANTES INCLUIDOS AVISO: Para reducir el riesgo de lesión por quemaduras de agua caliente , asegúrese que las etiquetas incluidas se han aplicado donde MISE EN GARDE : apposer les étiquettes fournies aux endroits...
Page 155 P6 SHOWER VALVE NOTICE TO INSTALLER: Place this label on the water heater NOTICE TO INSTALLER: WARNING WARNING: Water temperature changes due to seasonal or other inlet variations, such as changing the setting on the hot water heater may require adjustment of the rotational limit stop (13/14/17 Series) or If the temperature setting of the temperature knob (17T Series) on your tub/shower valve to ensure a safe maximum temperature.
Page 156 P6 SHOWER VALVE ® MultiChoice Valve Trim Installation Instructions Owners Manual 13/14 Series ASME A112.18.1 / CSA B125.1 ASSE 1016 (Type -P- or -T-) Write purchased model number here. You May Need Table of Contents: Warranties ................. Page 2 Clean and care................Page 8 Maintenance ................
Page 157 P6 SHOWER VALVE Lifetime Faucet and Finish Limited Warranty Cartridge Installation Parts and Finish In the United States and Mexico: All parts (other than electronic parts and batteries) and Product Service ® faucet are warranted to the original 55 E. 111th Street consumer purchaser to be free from defects in material Indianapolis, IN 46280 and workmanship for as long as the original consumer...
Page 158 P6 SHOWER VALVE Installation Showerhead and Tub Spout Installation Showerhead and Tub Spout Installation FOR SHOWERHEAD INSTALLATION: Connect top FOR TUB SPOUT INSTALLATION: use PEX tubing for tub spout drop. arm into riser connection. Thread showerhead (4) onto shower arm. Apply plumber tape to pipe threads on both Slip- The c copp...
Page 159 P6 SHOWER VALVE Installation Adjusting the Rotational Limit Stop Trim Installation Stem 1st Position Rotational Limit Stop IMPORTANT: for a comfortable bath or shower is typically The Rotational Limit Stop is used to limit the amount of hot water available such that, if set properly, the user will not be scalded if the handle cold as it will get and hot water is as hot as Slide O-ring (1) over cartridge and the...
Page 160 P6 SHOWER VALVE Clean and Care ® Care should be given to the cleaning Warning: Scrubbing Bubbles Bathroom ® Cleaner and Lysol Basin Tub and Tile extremely durable, it can be damaged by Cleaner must not be used on the clear knob harsh abrasives or polish.
Page 161 P6 SHOWER VALVE Garantía Limitada De Por Vida de la Llave y su Acabado Instalación del Cartucho Piezas y acabado En los Estados Unidos y México: Todas las piezas (excepto las piezas electrónicas y las ® Product Service 55 E. 111th Street están garantizados al consumidor comprador original de estar libres de defectos en material y fabricación Indianapolis, IN 46280...
Page 162 P6 SHOWER VALVE Instalación Instalación de la Cabeza de la Regadera y el Surtidor de la Bañera Instalación de la Cabeza de la Regader PARA LAS INSTALACIONES DE LAS CABEZAS PARA LA INSTALACIÓN DEL SURTIDOR DE LA BACERA DE REGADERA: Conecte la toma de salida de instalación suministradas con su surtidor.
Page 163 P6 SHOWER VALVE Instalación El Ajuste del Tope que Limita la Rotación Instalación Final Más Caliente Unidad Posición Primera IMPORTANTE: El Ajuste del Tope que Limita la Rotación peraturas variadas en el agua de salida. Una se usa para limitar la cantidad de agua temperatura de agua para un baño o ducha caliente disponible de manera que, si ajustado apropiadamente, el usuario no se...
Page 164 P6 SHOWER VALVE Limpieza y Cuidado de su Llave Tenga cuidado al ir a limpiar este producto. ¡ADVERTENCIA! No se puede usar ® Aunque su acabado es sumamente durable, SCRUBBING BUBBLES BATHROOM ® puede ser afectado por agentes de limpieza CLEANER o LYSOL BASIN TUB AND TILE o para pulir abrasivos.
Page 165 P6 SHOWER VALVE Installation de la cartouche Product Service ® 55 E. 111th Street et les vices de fabrication par une garantie qui est Indianapolis, IN 46280 St. consentie au premier acheteur et qui demeure valide tant customerservice@deltafaucet.com Au Canada: utilisation commerciale, la garantie est de 5 ans à...
Page 166 P6 SHOWER VALVE Installation Installation de la pomme de douche et du bec de baignoire Installation de la pomme de douche et INSTALLATION DE LA POMME DE DOUCHE : INSTALLATION DU BEC DE BAIGNOIRE : mur » de celui-ci dans la collerette (3) avant de le visser dans le raccord du tuyau vertical.
Page 167 P6 SHOWER VALVE Installation Réglage de la butée anti-échaudage Plus chaude Obturateurs 1ère Position IMPORTANT: froide que possible et aussi chaude que possible. Placez ensuite la manette sur la sous la douche ou dans la baignoire. La et il stabilise le manchon; il doit se trouver première position est celle qui laisse passer tournez la manette dans le sens antihoraire plage.
Page 168 P6 SHOWER VALVE Instructions de nettoyage 58045 & 58065 Models / M ® Il faut le nettoyer avec soin. Même si son de Baignoires et de Carreaux Lysol 58045 transparentes. Ces produits peuvent faire ou des produits de polissage. Il faut RP40592 simplement le frotter doucement avec un Pestaña de la Regadera...
Page 169 P6 SHOWER VALVE T13020, T13022, T13120, T13122, T13220, T13220-H2O, T13090, T13091, T13290, T13291, T T13222, T13220-SHCCER, T13420-SHCCER, T13420, Models / Modelos / Modèles T13420-H2O& T13422 Models / Modelos / Modèles RP38452 RP38357 RP40594 RP43381 RP38357 RP43381 Showerhead Showerhead Showerhead Showerhead Pestaña de RP46384 RP6023...
Page 170 P6 SHOWER VALVE T14038, T14238, T14238-H2O, T14 T14130, T14230 & T14430 Models / Modelos / Modèles Models / Modelos / Modèles RP38452 Pestaña de la Rogadora RP54752 RP41589 RP6023 RP6023 RP40594 Collerette Showerhead Showerhead Shower Arm Shower Arm Showerhead Cabeza de Rogadora Cabeza de Rogadora Brazo de la Rog Brazo de la Rogadora...
Page 171 P6 SHOWER VALVE T14051, T14251, T14251-H2O, T14451 & T14451-H2O T14053, T14253, T14253-H2O, T144 Models / Modelos / Modèles Models / Modelos / Modèles RP62283 RP52144 RP6023 Showerhead Shower Arm Cabeza de Rogadora Pestaña dela Rogadora RP62955 Brazo de la Rogadora Collerette Showerhead Cabeza de Rogadora...
Page 172 P6 SHOWER VALVE T14155, T14255-LHP, T14255-H2OLHP, T14455-LHP T14178, T14278-LHP, T14278-H2OLHP, T1 & T14455-H2OLHP Models / Modelos / Modèles T14478-H2OLHP & 14478-SHCCER Model RP34355 RP71072 RP6023 RP34356 Showerhead Showerhead Shower Arm Cabeza de Rogadora Cabeza de Rogadora Brazo de la Rogadora Pestaña dela Rogadora RP41589 RP54752...
Page 173 P6 SHOWER VALVE T14059, T14259 & T14459 Models / Modelos / Modèles T14061, T14261 & T14461 Model RP6025 Pestaña dela Rogadora Collerette RP6023 RP6023 Shower Arm RP70175 Shower Arm RP73373 Brazo de la Rogadora Showerhead Brazo de la Rogadora Escutcheon RP70175 Cabeza de Rogadora Roseta...
Page 174 P6 SHOWER VALVE T14086, T14186, T14286, T14286-SH T14082, T14085, T14185, T14282, T14285, T14285-H2O,T 14482, SHQ Models / Modelos / Modèles T14485 & T14485-H2O Models / Modelos / Modèles RP46870 Shower Arm Brazo de la Rogadora Tuyau de Pomme RP40592 RP40593 Shower Arm RP46870 Pestaña dela Rogadora...
Page 175 P6 SHOWER VALVE T14092, T14292 & T14492 Models / Modelos / Modèles T14092, T14292 & T14492 Model RP6023 RP61266 RP61265 Shower Arm RP6023 Showerhead RP51305 Brazo de la Rogadora Pestaña dela Rogadora RP54752 Shower A Cabeza de Rogadora Showerhead Tuyau de Pomme Collerette Showerhead Brazo de...
Page 176 P6 SHOWER VALVE Notes / Notas / Notes T14092, T14292 & T14492 Models / Modelos / Modèles RP72562 RP70172 RP40593 Pestaña dela Rogadora Showerhead Shower Arm Collerette Cabeza de Rogadora Brazo de la Rogadora Tuyau de Pomme RP72563 Escutcheon RP49037 Roseta Trim Screws/Atornillos de RP46074...
Page 177 P6 SHOWER VALVE Notes / Notas / Notes Notes / Notas / Notes Page: 177 / 395...
Page 178 P6 SHOWER VALVE Product Service 55 E. 111th Street Indianapolis, IN 46280 Page: 178 / 395...
Page 179 P6B SHOWER DR10000UN DELTA 1 HANDLE PRESSURE BALANCE UNIVERSAL VALVE ONLY DT13H153 DELTA CCY 1.5 1 HANDLE LEVER SHOWER TRIM ONLY CHROME Page: 179 / 395...
Page 180 P6B SHOWER MULTICHOICE ROUGH-IN BODY ® 50353 PIEZAS PARA LA INSTALACIÓN INTERNA MULTICHOICE ® CORPS DE ROBINET MULTICHOICE ® ® ® ASME A112.18.1 / CSA B125.1 Model/Modelo/Modèle R10000 Series/Series/Seria Write purchased model number here. Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici.
Page 181 P6B SHOWER DIVERTER SHUT OFF WATER SUPPLIES. Distance (1) from the stringer (2) The ﬁgure illustrates the diverter to the front of the plasterguard is and MultiChoice installed in the Consider the type and thickness of 2 3/4" ± 1/4" (70 mm ± 6 mm). same ﬁnished wall.
Page 182 P6B SHOWER Copper Tubing Tubería de Cobre Cuivre Iron Pipe Hierro If you are making a back to back or Remove bonnet (1) and test cap Connect valve body to water supplies reverse installation (hot on right and (2) before soldering. Leave screen using the proper fittings for your valve (3) installed.
Page 183 P6B SHOWER 8" - 18" (203 mm-457 mm) 8 po - 18 po PRESSURE TESTING & FLUSHING THE INSTALLATION Connect top outlet (1) to shower pipe with proper fittings. Connect bottom outlet (2) to Prior to testing, remove cover (1), bonnet (2) and cap (3). Ensure O-ring (4) tub spout pipe with proper fittings.
Page 184 P6B SHOWER Replacement Parts Piezas de Repuesto Pièces de rechange RP46078 Test Cap Tapa de Prueba Capuchon d’essai RP22734 Bonnet Capuchón Chapeau RP46077 Screen Filtro de malla RP46075 Tamis Plasterguard Protector de yeso Protecteur RP46076 Cover Cubierta Couvercle RP50366 Stop RP46079 Tope Reusable Test Plug...
Page 185 P6B SHOWER LIFETIME FAUCET AND FINISH LIMITED WARRANTY All parts and finishes of the Delta ® faucet are warranted to the original consumer AS ANY OTHER KIND OF LOSS OR DAMAGES ARE EXCLUDED. Proof of purchase purchaser to be free from defects in material & workmanship for as long as the original (original sales receipt) from the original consumer purchaser must be made available to consumer purchaser owns their home.
Page 186 P6B SHOWER T13H__ __ __ - __ __ Write purchase model number here for future reference Pour réference future, inscrivez ci-dessus le n˚ de modèle du produit achete Escriba el número del modelo comprado aqui para réferencia futura Please Leave This Instruction Sheet With The Installed Valve CAUTION: This system/device must be set by the installer to ensure safe, After installation and adjustment, you must affix your name, company name maximum temperature.
Page 187 P6B SHOWER Installation / Installation / Instalación Cartridge Installation Installation de la cartouche Instalación del Cartucho Rotate the cartridge (1) so the words “hot side” Turn off water supplies. Remove cover (1), (2) appear on the left. Insert cartridge into bonnet nut (2) and test cap (3) from the body.
Page 188 P6B SHOWER Installation / Installation / Instalación Cartridge Installation Installation de la cartouche Instalación del Cartucho Back to back Installation / Installation dos à dos / Instalación de Espalda a Espalda Normal Installation (changes not required) Installation normale (Non modifiée) Instalación Normal (No serequerá...
Page 189 P6B SHOWER Installation / Installation / Instalación Showerhead and Tub Spout Installation Installation de la pomme de douche et du bec de baignoire Instalación de la Cabeza de la Regadera y el Surtidor de la Bañera INSTALLATION DE LA POMME DE DOUCHE: Raccordez la sortie supérieure (1) au tuyau d’alimenta- tion de la pomme de douche (2) à...
Page 190 P6B SHOWER Installation / Installation / Instalación Adjusting the Rotational Limit Stop Hotter Plus chaude Más Caliente Disc Disque Disco Stem Obturateurs Unidad del Vàstago 1st Position 1ère Position Rotational Limit Stop Posición Primera Butée Pivotante Tope de Limite de Girar IMPORTANT temperature for a comfortable bath or shower is typically between 90°F - 110°F.
Page 191 P6B SHOWER Installation / Installation / Instalación Réglage de la butée anti-échaudage IMPORTANT: La butée antiéchaudage sert à limiter la quantité d’eau chaude température idéale pour la douche ou le bain se situe générale- disponible de sorte que l’utilisateur ne risque pas d’être ébouillanté si la ment entre 90°F - 110°F.
Page 192 P6B SHOWER Installation / Installation / Instalación Trim Installation Installation des pièces de finition Instalación Final Slide O-ring (1) over cartridge and the bonnet nut (2). If your model requires a spacer (1), insert it into the The O-ring, which acts as a spacer to steady the sleeve (2) and push it to the front.
Page 193 P6B SHOWER Cleaning and Care / Instructions de nettoyage / Limpieza y Cuidado de su Llave Care should be given to the cleaning of this product. Although its finish is extremely durable, it can be damaged by harsh abrasives or polish. To clean, simply wipe gently with a damp cloth and blot dry with a soft towel. Il faut le nettoyer avec soin.
Page 194 P6B SHOWER Maintenance Le robinet fuit par le bec ou la pomme de douche: d’environ 1/4 de tour après contact des butées. Soulever la cartouche pour la retirer du corps. COUPER L’EAU. Remplacer les sièges et les ressorts (kit de réparation RP4993).
Page 195 P6B SHOWER Caution CAUTION! Use of enhanced water efficient showerheads (restricting water flow below 2.5 gpm @ 80 psi) may result in unexpected temperature changes that might startle – or could even burn – the bather if the water supply pressure changes.
Page 196 P6B SHOWER T13H Models / Modèles / Modelos 060890A RP43381 RP46384 061048A 061011A Showerhead Showerhead Showerhead Showerhead (1.5 GPM) Showerhead (1.5 GPM) Pomme de Douche Pomme de Douche Pomme de Douche Pomme de Douche Pomme de Douche Cabeza de Rogadora Cabeza de Rogadora Cabeza de Rogadora (1,5 gal/min)
Page 197 P6B SHOWER T13H Models / Modèles / Modelos HANDSHOWER PARTS / PIÈCES DE DOUCHE DE MAIN / PIEZAS DE LA DUCHO DE MANO 061049A Handshower Head (1.5 GPM) La douchette (1,5 gal/min) De la ducha de mano (1.5 gpm) RP12504 Brass Wallmount Bracket Support mural Abrazadera de Montura para...
Page 198 P6B SHOWER Delta Commercial Faucet Limited Warranty All parts of the Delta® HDF® and TECK® faucets are warranted to the original consumer purchaser to be free from defects in material, finish and workmanship for a period of five (5) years unless otherwise specifically stated in the catalogue and price book. This warranty is made to the original consumer purchaser and shall be effective from date of purchase as shown on purchaser’s receipt.
Page 199 P7A MOP SINK PFMB2424 PROFLO 24X24X10 MOP BASIN W/ DRAIN D28T9 DELTA NOT FOR POTABLE USE 2 HANDLE CROSS WALL MOUNT SERVICE SINK FAUCET ROUGH CHROME PFSSHE PROFLO 5/8 X 30 SERVICE SINK HOSE PF296 PROFLO SINGLE HOSE BRACKET F/ SERVICE SINK PF245 PROFLO 24 S/S WALL MTD MOP HANGER...
Page 200 P7A MOP SINK Installation Instructions ® Mop Service Basin Models PFMB2424 To ensure this product is installed properly, please read these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes. SECTION THROUGH DRAIN CONNECTION SECTION THROUGH DRAIN CONNECTION RECOMMENDED INSTALLATION...
Page 201 P7A MOP SINK INSTRUCTIONS D’INSTALLATION ® CUVETTE D’ENTRETIEN POUR VADROUILLE Modèles PFMB2424 Afin de s’assurer que ce produit est correctement installé, veuillez attentivement ces instructions avant de commencer. (Certaines installations peuvent exiger de l’aide professionnelle.) Assurez-vous également que votre installation est conforme aux codes locaux. SECTION THROUGH DRAIN CONNECTION SECTION THROUGH DRAIN CONNECTION RECOMMENDED INSTALLATION...
Page 202 P7A MOP SINK INSTRUCCIONES DE INSTALACIÓN ® TARJA DE SERVICIO PARA TRAPEADOR Modelos PFMB2424 To ensure this product is installed properly, please read these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes. SECTION THROUGH DRAIN CONNECTION SECTION THROUGH DRAIN CONNECTION RECOMMENDED INSTALLATION...
Page 203 P7A MOP SINK 28T9, 28T9-AC, 28C9LH & 28C9LH-AC Write purchase model number here for future reference. Pour réference future, inscrivez ci-dessus le n° de modèle du produit acheté Escriba el número del modelo comprado aqui para referencia futura Please Leave This Instruction Sheet With The Installed Faucet Maintenance When performing routine maintenance, do not void your warranty by installing non-genuine parts.
Page 204 P7A MOP SINK Service Sink Faucet DESCRIPTION PART 061127A Lever handle with screw, red and blue index (28C9LH) 061128A Stem structure complete (28C9LH) 060027A Cross handle with screw, red and blue index (28T9) Stem structure complete with renewable seat (28T9) 060034A 060056A Pail brace complete...
Page 205 P7A MOP SINK Specific to 28T9 Détail à 28T9 Específico a 28T9 Specific to 28C9LH Détail à 28C9LH Específico a 28C9LH NOTE: Cartridges are not interchangeable as the bodies between the “T” & “C” series are machined differently. REMARQUE : Les cartouche ne sont pas interchangeables, le corp du robinet entre la serie «T»...
Page 206 P7A MOP SINK 28T9-AC Support rod must be anchored into structural wood or concrete. 28C9LH-AC Tige de support doit être ancré dans le bois ou le béton. Varilla de suporte debe estar anclado en la madera o el concreto estructural. - GARDEN HOSE END THREAD - FILETS DE BOYAU...
Page 207 P7A MOP SINK For further technical assistance, call Delta Commercial Technical Service at 1-800-387-8277. Pour obtenir de l’assistance technique, appelez le Service Technique de Delta Commercial au 1-800-387-8277. Por la asistencia técnica adicional, llame al servicio técnico de Delta Comercial al 1-800-387-8277. www.deltacommercialfaucets.com Page: 207 / 395...
Page 208 P7B UTILITY SINK PFLT2024 PROFLO ECON SGL LAUNDRY SINK W/LEGS D2121LF DELTA LEAD LAW COMPLIANT 2 HANDLE BLADE TWO HOLE LAUNDRY FAUCET ADA WITH HOSE ZZ8804XLLRPC ZURN LEAD LAW COMPLIANT 1/2 NOMINAL X 3/8 OD LAVATORY SUPPLY STANDARD ZZ8702PC ZURN 1-1/2 17 GA P TRAP SEMI-CAST Page: 208 / 395...
Page 209 P7B UTILITY SINK Installation Instructions Installation Instructions ® ® Laundry Tubs Laundry Tubs Models PFLT2123, PFLT2024 & PFLT4024 Models PFLT2123, PFLT2024 & PFLT4024 To ensure this product is installed properly, please read these instructions carefully To ensure this product is installed properly, please read these instructions carefully Warranty Warranty before you begin.
Page 210 P7B UTILITY SINK Installation Instructions Installation Instructions ® ® Laundry Tubs Laundry Tubs Models PFLT2123, PFLT2024 & PFLT4024 Models PFLT2123, PFLT2024 & PFLT4024 DRAIN ASSEMBLY AND PACKING LISTS Drain Assembly and Packing Lists IMPORTANT NOTICE: The Gasket / Washers supplied with the drain assembly should provide adequate water seal. If additional IMPORTANT NOTICE: The Gasket / Washers supplied with the drain assembly should provide adequate water seal.
Page 211 P7B UTILITY SINK Installation Instructions Installation Instructions INSTRUCTIONS D’INSTALLATION ® Installation Instructions ® ® Laundry Tubs Laundry Tubs CUVES À LESSIVE ® Models PFLT2123, PFLT2024 & PFLT4024 Laundry Tubs Models PFLT2123, PFLT2024 & PFLT4024 MODÈLES PFLT2123, PFLT2024 et PFLT4024 Models PFLT2123, PFLT2024 & PFLT4024 To ensure this product is installed properly, please read these instructions carefully Warranty To ensure this product is installed properly, please read these instructions carefully...
Page 212 P7B UTILITY SINK Installation Instructions INSTRUCTIONS D’INSTALLATION ® ® Laundry Tubs CUVES À LESSIVE Models PFLT2123, PFLT2024 & PFLT4024 MODÈLES PFLT2123, PFLT2024 et PFLT4024 DRAIN ASSEMBLY AND PACKING LISTS ASSEMBLAGE DU DRAIN ET BORDEREAUX D’EMBALLAGE IMPORTANT NOTICE: The Gasket / Washers supplied with the drain assembly should provide adequate water seal. If additional AVIS IMPORTANT : Le joint d’étanchéité...
Page 213 P7B UTILITY SINK Installation Instructions INSTRUCCIONES DE INSTALACIÓN Installation Instructions ® Installation Instructions ® ® Laundry Tubs TINAS DE LAVANDERÍA Laundry Tubs ® Models PFLT2123, PFLT2024 & PFLT4024 Laundry Tubs MODELOS PFLT2123, PFLT2024 Y PFLT4024 Models PFLT2123, PFLT2024 & PFLT4024 Models PFLT2123, PFLT2024 &...
Page 214 P7B UTILITY SINK INSTRUCCIONES DE INSTALACIÓN Installation Instructions ® ® TINAS DE LAVANDERÍA Laundry Tubs MODELOS PFLT2123, PFLT2024 Y PFLT4024 Models PFLT2123, PFLT2024 & PFLT4024 CONJUNTO DE DRENAJE Y LISTAS DE EMPAQUE DRAIN ASSEMBLY AND PACKING LISTS AVISO IMPORTANTE: La Junta / Arandelas proporcionadas con el conjunto de drenaje deben proporcionar un sello adecuado para el agua. Si se desea IMPORTANT NOTICE: The Gasket / Washers supplied with the drain assembly should provide adequate water seal.
Page 215 P7B UTILITY SINK 66060 ® ® ASM A112.18.1 / B125.1 Models/Modelos/Modèles 2121, 2123, 2131, 2133 Series/Series/Seria Write purchased model number here. Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici. You may need / Usted puede necesitar / Articles dont vous pouvez avoir besoin: For easy installation of your Delta faucet you will need: To READ ALL the instructions completely...
Page 216 P7B UTILITY SINK 1/2"-14 NPSM Position faucet (1) on sink. Hand tighten nuts (2). Make connnections to water lines. Use 1/2" IPS faucet connections (A) or OPTION: If sink is uneven, use silicone under the escutcheon (3). use the supplied coupling nuts (1) with 3/8" O.D. ball-nose risers (B). Coloque la llave (1) en el lavamanos.
Page 217 P7B UTILITY SINK Remove stream straightener (1) on models 2123, 2133. Turn Maintenance faucet handles (2) all the way on. Turn on hot and cold water supplies (3) and flush water lines for one minute. Important: If faucet leaks from spout outlet–Shut off water supplies - This flushes away any debris that could cause damage to Replace Seats and Springs (1).
Page 218 P7B UTILITY SINK Specify Finish/Especifíque el Acabado/Précisez le fini 2121 Series/Series/Seria RP43997 Hot & Cold Lever Handles w/Buttons & Screws Manijas en Palanca con botonesy tornillos de agua fría y caliente Manettes-leviers d’eau chaude et d’eau froide avec boutonset vis RP64454 Spout Bonnet Bonete del Tubo de Salida...
Page 219 P7B UTILITY SINK Specify Finish/Especifíque el Acabado/Précisez le fini 2131 Series/Series/Seria RP43997 Hot & Cold Lever Handles w/Buttons & Screws Manijas en Palanca con botonesy tornillos de agua fría y caliente Manettes-leviers d’eau chaude et d’eau froide avec boutonset vis RP44116 Snap Ring &...
Page 220 P7B UTILITY SINK CLEANING AND CARE Care should be given to the cleaning of this product. Although its finish is extremely durable, it can be damaged by harsh abrasives or polish. To clean, simply wipe gently with a damp cloth and blot dry with a soft towel.
Page 221 P20 EM EYEWASH GG1825 GUARDIAN PED MT EMERGENCY EYE WASH W/ SS BOWL GG3600LF GUARDIAN LEAD LAW COMPLIANT 1/2 6 GPM TSAT MIX VALVE Page: 221 / 395...
Page 222 P20 EM EYEWASH Parts List Eyewashes (2 GS-Plus™ Spray Heads) Item Part Number Description Bowls 100-009ORG-R Orange ABS Plastic Bowl 100-009GRN-R Green ABS Plastic Bowl 100-009YEL-R Yellow ABS Plastic Bowl 100-008R Stainless Steel Bowl AP100-011A Stn. Stl. Flanged Bowl For Deck Mount Drain Plate Assemblies AP150-012A Drain Plate Assembly for Plastic Bowls...
Page 223 P20 EM EYEWASH Parts List GS-Plus™ Spray Heads This guardian equipment product is equipped with GS-Plus™ spray heads. Each head features: • Tough polypropylene plastic construction • Highly visible integrated nylon dust cover • Easily accessible 1.8 GPM flow control •...
Page 224 P20 EM EYEWASH Installation, Operation and Maintenance Guide G3600LF Series Thermostatic Mixing Valves Note: Please provide valve serial number (stamped on cover of valve) when ordering parts. Thermometer Angle Checkstop Angle Checkstop 1/2" OD Copper Tube Inlets Hot Water Cold Water Inlet Inlet G3600LF...
Page 225 P20 EM EYEWASH Installation, Operation and Maintenance Guide G3600LF Series Thermostatic Mixing Valves Adjustment and Service Guardian Equipment thermostatic mixing valves may be easily Note: Thermostatic water mixing valves are regulating mechanisms which must be regularly maintained to provide best performance. Local water quality cleaned, adjusted and repaired.
Page 226 P20 EM EYEWASH Installation, Operation and Maintenance Guide G3600LF Series Thermostatic Mixing Valves Required Piping Method Required when hot water must be circulated to a thermostatic mixing valve that is a substantial distance from the hot water source. Recommended hot water inlet temperature is 135°F (57°C). Thermometer Angle Checkstop Angle Checkstop...
Page 227 P20 EM EYEWASH Installation, Operation and Maintenance Guide G3600LF Series Thermostatic Mixing Valves To Dismantle Valve: Figure 1 Turn off hot and cold water supplies to valve. Remove four Cover Thermostat Base Stud Screws Group Stop Handle cover screws and remove cover and thermostat group. (Figure 1) After replacing parts, lockable dial must be reset to obtain correct temperature range from Cold to Hot.
Page 228 P20 EM EYEWASH Installation, Operation and Maintenance Guide G3600LF Series Thermostatic Mixing Valves Thermostatic Mixing Valve Parts Checkstop Parts Thermostat Group RK3600B RK3600A Repair Kit* Repair Kit * Includes parts to repair both hot and cold checkstops Lockable Dial Set Screw Notes: 1.
Page 229 P20 EM EYEWASH Installation, Operation and Maintenance Guide G3600LF Series Thermostatic Mixing Valves Flow Capacities G3600LF 37.5 12.5 Flow Rate (GPM) MINIMUM SYSTEM PRESSURE DROP INTERNAL FLOW COLD WATER MODEL (GPM) BYPASS MINIMUM L/MIN G3600LF 1/2" 1/2" L/MIN MAXIMUM FLOW CAPACITY G3600LF HAS 1/2"...
Page 230 FCO FLOOR CLEANOUT ZZN14004NL ZURN LEVEL-TROL HEAVY-DUTY ADJUSTABLE FLOOR CLEANOUT, NICKEL BRONZE TOP - 4" NEO LOC Page: 230 / 395...
Page 231 FD1 FLOOR DRAIN ZZN4153NL6B ZURN FLOOR AND SHOWER DRAIN, D.C.C.I. BODY ASSEMBLY WITH 6" ROUND POLISHED NICKEL BRONZE TOP - 3" NEO LOC Page: 231 / 395...
Page 232 FD2 FLOOR DRAIN ZZN4153NL7I ZURN FLOOR AND SHOWER DRAIN, D.C.C.I. BODY ASSEMBLY WITH POLISHED NICKEL BRONZE TOP - 3" NEO LOC Page: 232 / 395...
Page 233 FD3 FLOOR DRAIN ZZN4154NL6G ZURN FLOOR AND SHOWER DRAIN, D.C.C.I. BODY ASSEMBLY WITH POLISHED NICKEL BRONZE TOP - 4" NEO LOC Page: 233 / 395...
Page 234 FS1 FLOOR SINK ZZ17503NL2 ZURN 12" X 12" SANI-FLOR RECEPTOR 6" SUMP DEPTH, TYPE 304 (CF8) STAINLESS STEEL (POA) - 3" NEO LOC, 1/2 GRATE Page: 234 / 395...
Page 235 SD1 ROOF DRAIN ZZC1003NHDPEA ZURN 15" DIAMETER MAIN ROOF DRAIN, D.C.C.I. BODY WITH CAST IRON DOME - 3" NO HUB, DECK PLATE, ADJUSTABLE EXTENSION (1-4") ZURN EA - EACH INCH OF ADJUSTABLE EXTENSION GREATER THAN 4" Page: 235 / 395...
Page 236 ESD1 ROOF DRAIN ZZC1004NHDPEAW ZURN 15" DIAMETER MAIN ROOF DRAIN, D.C.C.I. BODY WITH CAST IRON DOME - 4" NO HUB, DECK PLATE, ADJUSTABLE EXTENSION (1-4"), 2" INTERNAL WATER DAM ZURN EA - EACH INCH OF ADJUSTABLE EXTENSION GREATER THAN 4" Page: 236 / 395...
Page 237 AD1 PROMENADE DRAIN ZZ1504NH85R ZURN 14" SQUARE TOP PROM-DECK DRAIN, D.C.C.I. BODY WITH TOP - 4" NO HUB, SS PERFORATED EXTENSION, SUMP RECEIVER ZURN 85 - PERFORATED EXTENSION, EACH 1" GREATER THAN 4" Page: 237 / 395...
Page 238 MV1 MIXING VALVE L6625RG LAWLER 66-25 MIX VALVE Page: 238 / 395...
Page 239 MV1 MIXING VALVE w w w F w # v v F $ s § ¨ © © § w § © § § w § w S ' ' ( ) 0 1 2 3 S t 4 5 2 6 7 7 2 8 9 @ A 0 9 0 B C D A 1 E 8 9 @ A 0 9 0 G H 3 I P...
Page 240 MV1 MIXING VALVE Checking Cold Water Shut-Off (Cont.) Figure A 1. Place a wooden dow el © rod into center of ther mo- b. Spring #13 has lost its strength and should stat then place in 85°F be replaced. wa ter. Make a ref er ence mark on the rod as shown Note: Lack of water ﬂ...
Page 241 MV1 MIXING VALVE Series 66 Repair Parts Item Description Part No. Screw 7628-00 Adjusting Screw 8737-00 Bonnet Gasket ¡ ¢ £ ¤ ¥ Series 66 cut-away Dome — Liner O-Ring Liner Plunger/ Piston Liner Assembly Figure C* Valve Spring —...
Page 242 MV1 MIXING VALVE Typical Installation Figure 1 Install the mixing valve below the hot water tank or heat er. If this is not possible, pipe in a heat trap as Typical Installation shown in Figure 1 with an approximate 27 drop. Connect a tempered water return line as shown in When used in a single tem per a ture Figure 1.
Page 243 HB1 HOSE BIBB ZZ1341P12PC ZURN 1/2 FPT WALL MOUNT FAUCET L/K CHROME Page: 243 / 395...
Page 244 HB1 HOSE BIBB Z1341 SPECIFICATION SHEET Wall Faucet TAG _______ Dimensional Data (inches and [ mm ]) are Subject to Manufacturing Tolerances and Change Without Notice ENGINEERING SPECIFICATION: Z1341 Approx. Inlet Inlet Description Exposed, anti-siphon, wall faucet for use in moderate Wt.
Page 245 HB2 WALL HYDRANT ZZ133034X8 ZURN 3/4" INLET ENCASED, ANTI-SIPHON, AUTOMATIC DRAINING, MODERATE CLIMATE WALL HYDRANT - 8" WALL Page: 245 / 395...
Page 246 HB2 WALL HYDRANT Page: 246 / 395...
Page 247 HB2 WALL HYDRANT ÿ ÿ ¡ ¢ ƒ Page: 247 / 395...
Page 248 HB2 WALL HYDRANT ¤ ¨ ¨ ¨ ¨ ¨ ¨ ¨ ÿ ¢ § g ƒ ƒ ¡ ¢ £ g ¤ ¥ £ e ƒ ¤ § ¤ g £ ƒ e e ¨ ¢ e X ¢...
Page 249 HB3 ROOF DRAIN WSRHMS WOODFORD SANITARY ROOF HYDRANT COMPLETE Page: 249 / 395...
Page 250 HB3 ROOF DRAIN For more information contact… WOODFORD MANUFACTURING COMPANY 2121 Waynoka Road, Colorado Springs, Colorado 80915 • Phone: (800) 621-6032 • Fax: (800) 765-4115 To view our complete product line visit: www.woodfordmfg.com or email: sales@woodfordmfg.com A Division of WCM Industries, Inc. SRH-MS Rev 06/10 Form No.
Page 251 HB3 ROOF DRAIN For more information contact… WOODFORD MANUFACTURING COMPANY 2121 Waynoka Road, Colorado Springs, Colorado 80915 • Phone: (800) 621-6032 • Fax: (800) 765-4115 To view our complete product line visit: www.woodfordmfg.com or email: sales@woodfordmfg.com A Division of WCM Industries, Inc. RHMS Rev 06/10 Form No.
Page 252 HB3 ROOF DRAIN For more information contact… WOODFORD MANUFACTURING COMPANY 2121 Waynoka Road, Colorado Springs, Colorado 80915 • Phone: (800) 621-6032 • Fax: (800) 765-4115 To view our complete product line visit: www.woodfordmfg.com or email: sales@woodfordmfg.com A Division of WCM Industries, Inc. SRH-MS Rev 06/10 Form No.
Page 253 HB3 ROOF DRAIN TERMS AND CONDITIONS OF SALE Selling Policy - Possession of our price list or jobber Limited Warranty - All goods are sold with a limited discounts is not an offer to sell. All orders are subject warranty for one year against defects in material and to acceptance by the home office in Colorado Springs, workmanship.
Page 254 UCB UTILITY CONNECTION BOX I82355 IPS CORP FR WALL MOUNTOB W/SWT QT VALVE Page: 254 / 395...
Page 255 UCB1 BOX S6963F SIOUX CHIEF 2 OX BOX DRAIN BX W/FRM S696CF SIOUX CHIEF OX BX SEC DRG FUN S6963F SIOUX CHIEF 2 OX BOX DRAIN BX W/FRM Page: 255 / 395...
Page 256 TP1 AUTOMATIC TRAP PRIMER PFPR500 PROFLO 1/2 PRIME RITE TRAP PRMR PFPDUU PROFLO 4 OPG DIST UNIT W/O FTG PLAS BODY Page: 256 / 395...
Page 257 SP1 OIL MINDER PUMP Z9400007 ZOELLER 115 VOLTS 1/2 HP MAN EFFLUENT PUMP WITH SWITCH Z300100 ZOELLER 1-1/2 PVC BALL VALVE / CHECK VALVE / UNION COMBINATION Page: 257 / 395...
Page 258 SP1 OIL MINDER PUMP Notice to installing contractor: Instructions must remain with installation. SECTION: 6.10.002 Your Peace of Mind is Our Top Priority ® FM2676 1011 ® Product information presented Supersedes of publication. Consult factory regarding discrepancies or inconsistencies. MAIL TO: visit our web site: SHIP TO: www.zoeller.com...
Page 259 SP1 OIL MINDER PUMP Limited Warranty Manufacturer warrants, to the purchaser and subsequent owner during the warranty we do not authorize any representative or other person to assume for us any other period, every new product to be free from defects in material and workmanship under liability in connection with our products.
Page 260 SP1 OIL MINDER PUMP RECOMMENDED INSTALLATION FOR ALL APPLICATIONS requirements. according to any and all codes. preferably just above the basin to allow easy removal of the pump for below cover installation is required use 30-0164 on 1½" pipe, 30-0152 NOTE: FOR AUTOMATIC PUMPS, USE DEWATERING INSTALLATION SKETCH.
Page 261 SP1 OIL MINDER PUMP WD & WH MODEL INSTALLATION Determining Pumping Range in Inches (1 inch - 2.5 cm) WHITE 5 10 15 20 22 GREEN BLACK max. min. BLACK 9 13.5 18 22 24 WHITE Use only as a guide. Due to weight of CAPACITOR cable, pumping range above horizontal 5"...
Page 262 SP1 OIL MINDER PUMP Aviso al contratista instalador: Las instrucciones deberán permanecer con la instalación. FM2676S Su Tranquilidad es Nuestra Prioridad ® La siguiente información sobre ® ciones existentes en la fecha de publicación. Se debe consultar a la fábrica cualquier discrepancia o inconsistencia que existiera.
Page 263 SP1 OIL MINDER PUMP GARANTÍA LIMITADA bajo condiciones de uso y servicio normales, cuando se usa y mantiene correctamente, que asuma por nosotros ninguna otra responsabilidad con respecto a nuestros productos. EL FABRICANTE EXPRESAMENTE RECHAZA RESPONSABILIDAD POR DAÑOS remanufacturadas a opción del Fabricante, con la condición sin embargo de que por hacerlo ESPECIALES, EMERGENTES O INCIDENTALES O POR INCUMPLIMIENTO DE no estemos en la obligación de reemplazar un ensamblaje completo, el mecanismo entero LA GARANTÍA EXPRESA O IMPLÍCITA;...
Page 264 SP1 OIL MINDER PUMP INSTALACIÓN RECOMENDADA PARA TODAS LAS APLICACIONES 9. El estanque debe estar limpio y libre de escombros después de la instalación. Eléctrico Nacional y todos los otros requisitos eléctricos locales y estatales aplicables. bola y instalarla de acuerdo con cualesquiera y todos los códigos. NOTA: o achique requieren instalación de carga elevada o por debajo de la tapa, use 12.
Page 265 SP1 OIL MINDER PUMP INSTRUCCIONES PARA LA INSTALACIÓN DE LOS MODELOS WD Y WH Determinación del rango de bombeo en pulgadas (1 pulg. = 2,5 cm) BLANCO Longitud de la atadura VERDE NEGRO NEGRO 13.5 CAPACITOR BLANCO el rango de bombeo sobre la horizontal no es igual al rango de bombeo debajo de la horizontal.
Page 266 SP1 OIL MINDER PUMP Avis à l'installateur - Les instructions doivent rester avec l'installation. FM2676F Que vous dormiez en paix est notre priorité ® Les renseignements présentés ® l’usine en cas de contradiction ou d’inconsistance. www.zoeller.com ADRESSE POSTALE : ADRESSE PHYSIQUE : TÉL : +1 FAX +1 DATE D’INSTALLATION :...
Page 267 SP1 OIL MINDER PUMP GARANTIE LIMITÉE garantie, tout produit neuf contre tout vice de matériel et de main-d’œuvre, en utilisation accepter la responsabilité en notre nom pour nos produits. normale et quand utilisé et entretenu correctement, pendant une période de 3 ans de garantie, et que des inspections prouvent contenir des vices de fabrication ou de main- remplacement ou des renseignements supplémentaires concernant la garantie.
Page 268 SP1 OIL MINDER PUMP INSTALLATION RECOMMANDÉE POUR TOUTES APPLICATIONS codes. de préférence juste au-dessus du puits pour permettre la dépose de la pompe REMARQUE - pour les pompes automatiques, utiliser le schéma d’installation pour l’assèchement ci- dessous. avoir des joints étanches. éviter les chutes accidentelles.
Page 269 SP1 OIL MINDER PUMP Installation des modèles WD et WH pouces (1 pouce = 2,5 cm) BLANC Longueur du 10 15 20 22 bras d’attache VERT min. max. NOIR Plage de 9 13.5 18 22 24 pompage NOIR BLANC CONDENSATEUR la plage DE PASSAGE de pompage au-dessus de l’horizontale n’est...
Page 270 SP1 OIL MINDER PUMP Notice to Installer: Instructions must remain with installation. SECTION: 6.10.108 Your Peace of Mind is Our Top Priority ® FM2468 1012 ® Product information presented Supersedes of publication. Consult factory 0211 regarding discrepancies or inconsistencies. MAIL TO: visit our web site: SHIP TO: www.zoeller.com...
Page 271 SP1 OIL MINDER PUMP FIGURE 1 FIGURE 3 Mounting for 1-1/2" Pipe. Typical Installation of Oil Smart Pump ® Switch and Alarm Panel. PVC Cap Quick Mount Bracket Attached to side of basin. 1 1/2" PVC Pipe Provided By Others Quick Mount Bracket Quick...
Page 272 SP1 OIL MINDER PUMP Page: 272 / 395...
Page 273 SP1 OIL MINDER PUMP Page: 273 / 395...
Page 274 LI1 LINT INTERCEPTOR ZZ118510 ZURN 100 GPM LINT INTERCEPTOR, ACID RESISTANT COATED FABRICATED STEEL Page: 274 / 395...
Page 275 NAT GAS WATER HEATER SSUF100199NEE STATE 100G 199.9MBH NAT WATER HEATER ALUM DIVCVENT3 DIVERSITEC 3 CONC VENT Page: 275 / 395...
Page 276 NAT GAS WATER HEATER Instruction Manual COMMERCIAL GAS WATER HEATERS MODELS SUF 60120 THRU SUF 100250 SERIES 200 & 201 INSTALLATION - OPERATION - SERVICE 500 Tennessee Waltz Parkway - MAINTENANCE - LIMITED WARRANTY Ashland City, TN 37015 WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death.
Page 277: Table Of Contents
NAT GAS WATER HEATER TABLE OF CONTENTS Polypropylene Installations .............. 28 SAFE INSTALLATION, USE AND SERVICE.......... 3 AL29-4C ® Vent Installations ............29 APPROVALS ..................3 Concentric Termination Installation ..........30 GENERAL SAFETY INFORMATION ............4 4 Inch Concentric Termination Installation ........31 Precautions ..................
Page 278: Safe Installation, Use And Service
NAT GAS WATER HEATER SAFE INSTALLATION, USE AND SERVICE The proper installation, use and servicing of this water heater is extremely important to your safety and the safety of others. Many safety-related messages and instructions have been provided in this manual and on your own water heater to warn you and others of a potential injury hazard.
Page 279: General Safety Information
NAT GAS WATER HEATER GENERAL SAFETY INFORMATION PRECAUTIONS HYDROGEN GAS FLAMMABLE DO NOT USE THIS WATER HEATER IF ANY PART HAS BEEN EXPOSED TO FLOODING OR WATER DAMAGE. Immediately call a qualified service agency to inspect the water heater and to make a determination on what steps Explosion Hazard should be taken next.
Page 280 NAT GAS WATER HEATER GENERAL SAFETY INFORMATION Fire or Explosion Hazard Fire Hazard For continued protection against Do not store or use gasoline or other flammable vapors and risk of fire: liquids in the vicinity of this or any other appliance. Do not install water heater on Avoid all ignition sources if you smell gas.
Page 281: Introduction
NAT GAS WATER HEATER INTRODUCTION Thank You for purchasing this water heater. Properly installed Detailed installation diagrams are also found in this manual. and maintained, it should give you years of trouble free service. These diagrams will serve to provide the installer with a reference.
Page 282: Features And Components
NAT GAS WATER HEATER FEATURES AND COMPONENTS BASIC OPERATION MODULATION The water heaters covered in this manual have a helical coil The water heaters covered by this manual are capable of shaped heat exchanger that is submerged in the storage tank. modulating their firing rate.
Page 283: Top View
NAT GAS WATER HEATER TOP VIEW FRONT TOP VIEW OF ALL MODELS Figure 3 on a rise in pressure. This switch is used to insure supply COMPONENTS (All Models) gas pressure is above minimum requirements. The control IMPORTANT. The Enable/Disable switch listed in this manual is system monitors this switch and will disable heating operation NOT an "on/off"...
Page 284: Side Views
NAT GAS WATER HEATER LEFT SIDE RIGHT SIDE Figure 4 SIDE VIEWS 9. Temperature-Pressure Relief Valve discharge pipe - see T&P Valve Discharge Pipe Requirements: on page 15. 1. Cleanout access panel, covers water heater cleanout 10. Lower Temperature Probe, 1 of 2 temperature probes. The opening.
Page 285: Installation Considerations
NAT GAS WATER HEATER INSTALLATION CONSIDERATIONS ROUGH IN DIMENSIONS SUPPLY GAS CONNECTION INTAKE AIR CONNECTION 3 INCH PVC WATER OUTLET HEIGHT T & P VALVE FRONT BACK 3/4” NPT RECIRCULATION RETURN LOWER VENT TEMPERATURE CONNECTION PROBE 3 INCH PVC (exhaust elbow) 1 1/2”...
Page 286: Locating The Water Heater
NAT GAS WATER HEATER GAS LINE CONNECTION SIZE STORAGE CAPACITIES TABLE 1 TABLE 2 † MODEL SERIES NATURAL GAS PROPANE GAS MODEL U. S. GALLONS LITERS 200/201 SUF 60120 3/4 "NPT 3/4 "NPT SUF 60120 200/201 SUF 100150 3/4 "NPT 3/4 "NPT SUF 100150 200/201...
Page 287: Extended Vent Terminations
NAT GAS WATER HEATER There is a risk in using fuel burning appliances such as gas Contact your local distributor or call the parts department phone water heaters in rooms, garages or other areas where gasoline, number listed on the back cover of this manual to order 4 inch other flammable liquids or engine driven equipment or vehicles termination(s).
Page 288: Installation Requirements
NAT GAS WATER HEATER • DO NOT cover the instruction manual. Keep it on the side of combustion, potentially resulting in fire, asphyxiation, serious personal injury or death. the water heater or nearby for future reference. • DO NOT apply insulation to the top of the water heater, as •...
Page 289: Mixing Valves
NAT GAS WATER HEATER MIXING VALVES HOT WATER OUTLET Water temperature over 125°F (52°C) can cause severe burns instantly 12” TO 15” resulting in severe injury or death. (30-38 cm) Children, the elderly and the TEMPERED WATER physically or mentally disabled are at OUTLET highest risk for scald injury.
Page 290: Temperature-Pressure Relief Valve
NAT GAS WATER HEATER TEMPERATURE-PRESSURE RELIEF VALVE water in adequate quantities should circumstances demand. If the discharge pipe is not connected to a drain or other suitable means, the water flow may cause property damage. CAUTION Explosion Hazard Water Damage Hazard Temperature-Pressure Relief Valve must comply with ANSI Z21.22- •...
Page 291: Condensate Drain
NAT GAS WATER HEATER CONDENSATE DRAIN line, such as copper, to the water heater for this reason. See Condensate Drain Installation on page 39. The water heaters covered in this manual are condensing appliances and require a building drain to be located in close COMBUSTIBLE MATERIAL STORAGE proximity to allow the condensate to drain safely.
Page 292: Air Requirements
NAT GAS WATER HEATER AIR REQUIREMENTS UNUSUALLY TIGHT CONSTRUCTION In unconfined spaces in buildings, infiltration may be adequate to provide air for combustion, ventilation and dilution of flue gases. However, in buildings of unusually tight construction (for example, weather stripping, heavily insulated, caulked, vapor barrier, etc.) additional air must be provided using the methods Breathing Hazard - Carbon Monoxide Gas described in the Confined Space section that follows.
Page 293: Fresh Air Openings For Confined Spaces
NAT GAS WATER HEATER FRESH AIR OPENINGS FOR CONFINED SPACES Alternatively a single permanent opening, commencing within 12 inches (300 mm) of the top of the enclosure, shall be provided. The following instructions shall be used to calculate the size, See Figure 10.
Page 294 NAT GAS WATER HEATER OUTDOOR AIR THROUGH TWO VERTICAL DUCTS When ducts are used, they shall be of the same cross sectional area as the free area of the openings to which they connect. The illustrations shown in this section of the manual are a The minimum dimension of rectangular air ducts shall be not less reference for the openings that provide fresh air into confined than 3 inches (7.62 cm).
Page 295: Installation Requirements - Commonwealth Of Massachusetts
NAT GAS WATER HEATER INSTALLATION REQUIREMENTS - COMMONWEALTH OF MASSACHUSETTS COMMONWEALTH OF MASSACHUSETTS INSPECTION The state or local gas inspector of the side wall horizontally For all side wall terminated, horizontally vented power vent, direct vented gas fueled equipment shall not approve the installation vent, and power direct vent gas fueled water heaters installed in unless, upon inspection, the inspector observes carbon every dwelling, building or structure used in whole or in part for...
Page 296: Venting Installation
NAT GAS WATER HEATER VENTING INSTALLATION discharge all flue gases to the outdoor atmosphere through a sealed vent (exhaust) pipe. Direct Vent configurations have two pipes connected to the water heater, one vent pipe and one intake air pipe. Direct Vent configurations can be terminated in Breathing Hazard - Carbon Monoxide Gas one of seven different arrangements.
Page 297: Intake Air Connection
NAT GAS WATER HEATER 18. Stress levels in pipe/fittings can be significantly increased by The intake air Tee fitting is factory installed with the 1/2 inch improper installation. If rigid pipe clamps are used to hold branch and hose barb angled to the right at approximately 130° the pipe in place, or if the pipe cannot move freely through a when viewed from the end, see Figure 15.
Page 298: Venting Installation Sequence
NAT GAS WATER HEATER NOTE: Refer to Tables 9 and 10 on page 29 for the equivalent FACTORY SUPPLIED FITTINGS linear pipe length of AL29-4C® 45° and 90° elbows. The water heater ships with two (2) factory supplied 3 inch PRIMER AND CEMENT terminations (PVC 45°...
Page 299: Direct Vent Installation
NAT GAS WATER HEATER If the vent piping will terminate vertically, through a roof, see If a concentric termination(s) will be used see Concentric Vertical Termination Installation on page 25. Termination Installation on page 30. If the vent piping will terminate horizontally, through a If a low-profile termination will be used see Low Profile sidewall, see Sidewall Termination Installation on page 27.
Page 300: Vertical Termination Installation
NAT GAS WATER HEATER VERTICAL TERMINATION INSTALLATION INTAKE AIR SCREEN 1. Determine the location for the termination(s). 2. If installing only the vent (exhaust) piping in a Power Vent configuration vertically through the roof; ensure that all exterior vertical clearance requirements shown in Figure 22 and Figure 23 on page 26 are being maintained.
Page 301 NAT GAS WATER HEATER 8. Suspend the pipe(s) through center of hole using field IF LESS THAN supplied metal strapping or equivalent support materials as 10 FEET (3 m) shown in Figure 22 on page 26. 9. Slide a roof boot or equivalent flashing over the pipe and secure roof boot or equivalent flashing to roof and seal around the flashing as shown in Figure 22, Figure 23 and 24 INCHES (60 cm)
Page 302: Sidewall Termination Installation
NAT GAS WATER HEATER SIDEWALL TERMINATION INSTALLATION 18. Cut a 4 inch (10 cm) diameter hole for 3 inch pipe or 5 inch (13 cm) diameter hole for 4 inch pipe where the pipe(s) will 12. Determine the location for the termination(s). pass through the wall.
Page 303: Polypropylene Installations
NAT GAS WATER HEATER POLYPROPYLENE INSTALLATIONS Polypropylene vent systems do not use cement to connect the pipe and elbow sections but use a push together gasket The water heater has been approved to be installed with seal method. Do not attempt to connect Polypropylene with Polypropylene vent material as shown in Tables 7 and 8.
Page 304: Al29-4C ® Vent Installations
NAT GAS WATER HEATER AL29-4C ® VENT INSTALLATIONS The water heaters covered by this manual are approved to be installed using the approved vent terminations shown (AL29-4C® is a registered trademark of Allegheny Technologies, Inc.) in this manual. This means that, the installer must use the The water heaters covered by this manual are approved adapter listed in Tables 9 and 10 and a short piece of PVC to be installed with AL29-4C®...
Page 305: Concentric Termination Installation
NAT GAS WATER HEATER CONCENTRIC TERMINATION INSTALLATION NOTE: If this required 10 foot (3 m) distance to a parapet, vertical wall or structure cannot be maintained, standard 1. Concentric terminations must be ordered separately. terminations must be used. See Vertical Termination SUF 60120 thru SUF 100250 models must use the 4 inch Installation on page 25.
Page 306: Inch Concentric Termination Installation
NAT GAS WATER HEATER 4 INCH CONCENTRIC TERMINATION INSTALLATION When installing 4 inch intake air and vent pipe - connect the piping to the concentric termination using field supplied 4" x INTAKE AIR CONNECTION INTAKE AIR PIPE 3" reducer couplings and short sections of 3 inch pipe (18 3 INCH PVC inches or less) pipe.
Page 307 NAT GAS WATER HEATER MULTIPLE CONCENTRIC TERMINATION CLEARANCES Four Concentric Terminations When installing multiple concentric terminations vertically through 1. When installing four concentric terminations through a roof or a roof or horizontally through a sidewall ensure the required through a sidewall in close proximity they may be arranged clearances (separation) between terminations are maintained.
Page 308 NAT GAS WATER HEATER MULTIPLE CONCENTRIC TERMINATION ARRANGEMENTS SIDEWALL The illustrations on this page show some of the installation arrangements for multiple concentric terminations that are allowed. See Multiple Concentric Termination Clearances on page 32 for detailed information on clearances and additional arrangement options.
Page 309: Low Profile Vent Installation
NAT GAS WATER HEATER LOW PROFILE VENT INSTALLATION To Heater Intake Air Connection This water heater is certified for sidewall direct venting with IPEX System 636 Low Profile Vent Kit. Follow instructions below for From Heater Vent proper installations. Pipe Connection All termination kits must be located and installed in accordance with locl building code and CSA B149.1 Natural Gas and Propane 12”...
Page 310: Venting Arrangements
NAT GAS WATER HEATER VENTING ARRANGEMENTS Power Vent Vertical Power Vent Horizontal Direct Vent Vertical Figure 42 Figure 43 Figure 44 Direct Vent Horizontal Direct Vent Vertical Vent Direct Vent Horizontal Vent Horizontal Intake Vertical Intake Figure 45 Figure 46 Figure 47 Page: 310 / 395...
Page 311 NAT GAS WATER HEATER VENTING ARRANGEMENTS Direct Vent Vertical Concentric Direct Vent Horizontal Concentric Direct Vent Horizontal Low Profile Figure 48 Figure 49 Figure 50 Page: 311 / 395...
Page 312: Termination Clearances Sidewall Power Vent
NAT GAS WATER HEATER TERMINATION CLEARANCES SIDEWALL POWER VENT POWER VENT (using room air for combustion) EXTERIOR CLEARANCES FOR SIDEWALL VENT TERMINATION F IX E D C LO S E D O P E R A B LE F IX E D C LO S E D O P E R A B LE VENT TERMINAL...
Page 313: Termination Clearances Sidewall Direct Vent
NAT GAS WATER HEATER TERMINATION CLEARANCES SIDEWALL DIRECT VENT DIRECT VENT (using outdoor air for combustion) EXTERIOR CLEARANCES FOR SIDEWALL VENT TERMINATION F IX E D C LO S E D O P E R A B LE F IX E D C LO S E D O P E R A B LE VENT TERMINAL...
Page 314: Water Heater Installation
NAT GAS WATER HEATER WATER HEATER INSTALLATION CONDENSATE DRAIN INSTALLATION 3. Terminate the condensate drain piping with an elbow above the drain. Ensure that any discharge will exit the condensate Installation must conform with these instructions and local drain line no more than 6 inches (15.2 cm) above a suitable building codes.
Page 315: Supply Gas Line Installation
NAT GAS WATER HEATER SUPPLY GAS LINE INSTALLATION GAS LINE SIZING Depending on the developed equivalent length and/or the number Contact your local gas utility company to ensure that adequate of appliances connected to a common main, the size of supply gas gas service is available and to review applicable installation lines may have to be increased.
Page 316: Gas Line Leak Testing
NAT GAS WATER HEATER GAS LINE CONNECTION NOTE: Should overheating occur or the gas supply fail to shut off, turn off the Main Gas Shutoff valve to the water heater. 1. The water heaters covered by this manual are shipped from the factory with 3/4 inch supply gas connections.
Page 317: Enable / Disable Circuit (For Building Management Systems)
NAT GAS WATER HEATER POWER SUPPLY CONNECTIONS heating operation during periods when the building is unoccupied or there is no demand for hotwater. Read the requirements for the Power Supply on page 13 before connecting power. To use the enable/disable circuit it must first be activated by selecting the “Use External Enable”...
Page 318: Water Line Connections
NAT GAS WATER HEATER WATER LINE CONNECTIONS T&P VALVE DISCHARGE PIPE The water piping installation must conform to these instructions and to all local and national code authority having jurisdiction. Good practice requires that all heavy piping be supported. Read and observe all requirements in the following sections Explosion Hazard before installation of the water piping begins: 1.
Page 319: Temperature Regulation
NAT GAS WATER HEATER TEMPERATURE REGULATION HIGH TEMPERATURE LIMIT CONTROL (ECO) TABLE 13 Time for Permanent Burns This water heater is equipped with an ECO (energy cut out) non Water Temperature Time for 1st Degree Burn 2nd & 3rd Degree °F (°C) (Less Severe Burns) adjustable high temperature limit switch.
Page 320: Control System Operation
NAT GAS WATER HEATER CONTROL SYSTEM OPERATION OVERVIEW user input buttons; an up, down and three (3) multi functional operational buttons below the LCD, see Figure 59. The water heaters covered in this manual are equipped with an User Input Buttons electronic control system that regulates water temperature inside •...
Page 321 NAT GAS WATER HEATER STATUS ICONS The Status Icons are displayed on the Desktop screen and convey operational and diagnostic information. The icons are described in the table below. See Figure 59 on page 45 and the Sequence Of Operation on page 57. TABLE 14 Icon Description...
Page 322 NAT GAS WATER HEATER OPERATING STATES The current operational state of the water heater is displayed on the Desktop screen as the "Status." The common operational states are described in the table below. See Figure 59 on page 45 and the Sequence Of Operation on page 57. TABLE 15 State Description...
Page 323: User Settings & Control System Menus
NAT GAS WATER HEATER USER SETTINGS & CONTROL SYSTEM MENUS TEMPERATURES MENU Operating Set Point And Differential Adjustment The Operating Set Point is adjustable from 90°F (42°C) to 180°F (82°C). The factory setting is 120°F (49°C). The Differential is adjustable from 2° to 20°. The factory setting is 8°. These user settings are accessed from the Temperatures menu. The following instructions will explain how to adjust these settings and navigate the control system menus.
Page 324 NAT GAS WATER HEATER TEMPERATURES MENU (CONT) DESCRIPTION/ACTION DISPLAY • Differential - Adjustable user setting that changes the tank temperature differential with a range of 2° to 20°F. The Temperatures factory setting is 8°F. Operating Set Point 140°F • Tank Temperature - non adjustable - control system Differential 8°F sensed temperature (averaged from upper and lower...
Page 325 NAT GAS WATER HEATER DISPLAY SETTINGS DESCRIPTION/ACTION DISPLAY Select Display Settings from the Main Menu and press the Display Settings Operational Button under "SELECT" to enter this menu. This menu contains adjustable display options for viewing information Temperature Units °F on the UIM’s LCD screen.
Page 326 NAT GAS WATER HEATER CURRENT FAULT DESCRIPTION/ACTION DISPLAY Select Current Fault from the Main Menu and press the Operational Button under "SELECT" to enter this menu. This menu contains non adjustable operational information. Use the Blocked Exhaust Up & Down Buttons to navigate the menu. Fault occurred 2 mins ago This menu contains the current Fault or Alert error message.
Page 327 NAT GAS WATER HEATER SERVICE CONTACT INFORMATION The control system has a discrete menu that Installing contractors and/or service agents can access to enter contact information for their customers. This contact information will be displayed with all Fault and Alert messages. DESCRIPTION/ACTION DISPLAY From the Desktop Screen (see Figure 59 on page 45) press...
Page 328: Start Up
NAT GAS WATER HEATER START UP PRIOR TO START UP port one full turn only; turn the needle valve screw counter- clockwise to open the valve. Slide the manometer sensing Installation and start up of this water heater requires abilities tube over the top of the test port, see Figure 60 and Figure and skills equivalent to that of a licensed tradesman in the field involved, see Qualifications on page 6.
Page 329: Lighting & Operation Labels
NAT GAS WATER HEATER LIGHTING THE WATER HEATER LIGHTING & OPERATION LABELS The instruction label below is affixed to the water heater's covered by this manual at the factory and must be followed when lighting and operating the water heater. FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or...
Page 330 NAT GAS WATER HEATER SUPPLY GAS PRESSURE ADJUSTMENT with other gas fired appliances; the supply gas pressures shall be measured at each water heater with all gas fired appliances connected to a common main firing at full capacity. On multiple water heater installations the supply gas line Fire and Explosion Hazard regulators shall be adjusted to provide gas pressure to each water heater within the minimum and maximum supply pressure...
Page 331: Checking The Firing Rate
NAT GAS WATER HEATER CHECKING THE FIRING RATE HIGH ALTITUDE INSTALLATIONS If firing rate adjustment is required follow these instructions to determine the actual firing rate of the water heater: NOTE: The heaters covered by this manual are capable of Fire and Explosion Hazard modulating their firing rate.
Page 332: Troubleshooting
NAT GAS WATER HEATER TROUBLESHOOTING SEQUENCE OF OPERATION INSTALLATION CHECKLIST Read the Sequence of Operation below before attempting to The list below represents some of the most critical installation requirements that, when overlooked, often result correct any operational problems. Refer to the Features And Components section beginning on page 7 for the location in operational problems, down time and needless parts of various water heater components described below.
Page 333: Sequence Of Operation Flow Chart
NAT GAS WATER HEATER SEQUENCE OF OPERATION FLOW CHART Sequence is shown with Enable/Disable Switch in the Enable position If tank temperature drops below Operating Set Point minus Differential setting a heating cycle is activated Control System performs diagnostic checks Normal State of all pressure switches and ECO are checked Control System Locks Out Blower Prover pressure switch verified open...
Page 334: Operational Problems
NAT GAS WATER HEATER OPERATIONAL PROBLEMS • Vent (exhaust) gas recirculation at the vent and intake air pipe terminations on Direct Vent installations - see Direct Vent Installation on page 24. • Excessive equivalent lengths of intake air and/or vent (exhaust) piping installed - see Venting Requirements on Read and understand this instruction page 22.
Page 335: Fault And Alert Conditions
NAT GAS WATER HEATER • Sediment or lime scale accumulation may be affecting mark. The water heater will continue to operate during an Alert water heater operation. See Maintenance on page 63 for condition but the water heater must be serviced by a qualified sediment and lime scale removal procedures.
Page 336 NAT GAS WATER HEATER FAULT AND ALERT MESSAGES Call the technical support phone number listed on the back cover for further technical assistance or to locate a qualified service agent in your area. POSSIBLE CAUSES - CHECK/REPAIR DISPLAYED FAULT/ALERT MESSAGE •...
Page 337 NAT GAS WATER HEATER FAULT AND ALERT MESSAGES (CONT) Call the technical support phone number listed on the back cover for further technical assistance or to locate a qualified service agent in your area. POSSIBLE CAUSES - CHECK/REPAIR DISPLAYED FAULT/ALERT MESSAGE •...
Page 338: Maintenance
NAT GAS WATER HEATER MAINTENANCE GENERAL MAINTENANCE SCHEDULE TABLE 17 Do not have any combustible materials (such as gasoline, flammable liquids or flammable vapors) within the water heater COMPONENT OPERATION INTERVAL REQUIRED area. See Locating The Water Heater on page 11. Sediment Tank Semi Annually...
Page 339: Filling The Water Heater
NAT GAS WATER HEATER 5. Ensure the drain hose is secured before and during the entire flushing procedure. Flushing is performed with system water CLEANOUT pressure applied to the water heater. ACCESS PANEL TANK 6. Open the water heater drain valve to flush the storage tank. CLEANOUT CLEANOUT OPENING...
Page 340: Powered Anode Rods
NAT GAS WATER HEATER TABLE 18 TEMPERATURE-PRESSURE UN-LIME® PROFESSIONAL DELIMER RELIEF VALVE Part Number Description 9005416105 4 - 1 gallon (case) 9005417105 1 - 5 gallon POWERED ANODE RODS To insure a long, trouble-free operating life, the water heaters DISCHARGE PIPE covered in this manual are factory equipped with a powered anode system.
Page 341: Diagrams
NAT GAS WATER HEATER DIAGRAMS CCB - CENTRAL CONTROL BOARD LAYOUT Figure 66 Page: 341 / 395...
Page 342: Wiring Diagram
NAT GAS WATER HEATER WIRING DIAGRAM Blower 24Vureg 1 White / Brown Speed f-back Spark 2 White / Orange Module 24Vureg 4 White / Blue 1 White/Brown PWM Signal PWM Signal Neutral Brown Neutral 2 White/Blue 5 White / Green Dgnd Neutral 1 Red...
Page 343: Circulation Pump Wiring Diagrams
NAT GAS WATER HEATER CIRCULATION PUMP WIRING DIAGRAMS CIRCULATING PUMP WIRING DIAGRAM STORAGE TANK OR BUILDING RECIRCULATION FIELD SUPPLIED TEMPERATURE CONTROL INSTALLED IN THE STORAGE TANK OR CIRCULATING LOOP RETURN LINE NOTE: USE SEPARATE 120 VAC POWER SUPPLY FOR PUMP CIRCUIT. DO NOT SHARE POWER WITH WATER HEATER AS THIS MAY CAUSE ELECTRICAL LINE NOISE AND LEAD TO ERRATIC CONTROL...
Page 344 NAT GAS WATER HEATER Page: 344 / 395...
Page 345 NAT GAS WATER HEATER Page: 345 / 395...
Page 346 NAT GAS WATER HEATER Page: 346 / 395...
Page 347 NAT GAS WATER HEATER Page: 347 / 395...
Page 348 NAT GAS WATER HEATER Page: 348 / 395...
Page 349 NAT GAS WATER HEATER Page: 349 / 395...
Page 350 NAT GAS WATER HEATER Page: 350 / 395...
Page 351: Notes
NAT GAS WATER HEATER NOTES Page: 351 / 395...
Page 352 NAT GAS WATER HEATER NOTES Page: 352 / 395...
Page 353 NAT GAS WATER HEATER NOTES Page: 353 / 395...
Page 354: Service Inquiries
NAT GAS WATER HEATER COMMERCIAL WATER HEATER LIMITED WARRANTY EFFECTIVE WHAT'S NOT COVERED For 3 Years, in the event of a tank leak, we will repair or, at our • Problems caused by improper: gas supply line sizing, gas type, discretion, replace the defective water heater.
Page 355 NAT GAS WATER HEATER 500 Tennessee Waltz Parkway, Ashland City, TN 37015 Tech Support: 800-365-0024 Parts: 800-821-2017 www.statewaterheaters.com Copyright © 2014 State Water Heaters, All rights reserved. Page: 355 / 395...
Page 356 NAT GAS WATER HEATER 9 5 2 4 7 1 0 7 4 1 Page: 356 / 395...
Page 357 EXPANSION TANK PFXT12 PROFLO LF 4.4 GAL THERMAL EXPANSION TANK Page: 357 / 395...
Page 358 EXPANSION TANK Installation Instructions Installation Instructions PFXT5 and PFXT12 PFXT5 and PFXT12 Water Heater Safety Tanks Water Heater Safety Tanks PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. FOR USE ONLY WITH POTABLE WATER INSTALLER: LEAVE THIS MANUAL WITH THE OWNER PFXT12 PRE-INSTALLATION THIS IS THE SAFETY ALERT SYMBOL.
Page 359 EXPANSION TANK One Year Limited Installation Instructions Warranty PFXT5 and PFXT12 Water Heater Safety Tanks ONE YEAR LIMITED WARRANTY 1. WARRANTY: Subject to the limitations herein, Seller warrants that items manufactured by Seller (“Product”) shall be free from defects in design, material and workmanship under Normal Use for a period of one (1) year from the date of sale (“Warranty Period”).
Page 360 CP1 CIRC PUMP B103401LF B&G LF 1/6HP BRZ NBF36 CIRC PUMP 115V B101011LF B&G LF FLANGE 3/4 100 BRONZE B113224 B&G AQS-3/4 AQUASTAT CONTROL B113210 B&G TC-1 AUTO TIMER KIT Page: 360 / 395...
Page 361 CP1 CIRC PUMP Page: 361 / 395...
Page 362 CP1 CIRC PUMP Page: 362 / 395...
Page 363 CP1 CIRC PUMP Page: 363 / 395...
Page 364 CP1 CIRC PUMP FIG. 2 WARNING: ELECTRICAL SHOCK HAZARD WARNING: ELECTRICAL SHOCK HAZARD WIRING INSTRUCTIONS TYPICAL WIRING INSTALLATION SCHEMATIC 1Ø POWER SOURCE FUSIBLE DISCONNECT OR CIRCUIT BREAKER BY OTHERS TO REMOTE CONTROL IF REQUIRED PUMP MOTOR NOTE: IMPEDANCE PUMP PROTECTED MOTOR NOTE: FIG.
Page 365 CP2 CIRC PUMP B103252LF B&G LF 1/25HP BRZ NBF22 CIRC PUMP 115V B101011LF B&G LF FLANGE 3/4 100 BRONZE B113224 B&G AQS-3/4 AQUASTAT CONTROL B113210 B&G TC-1 AUTO TIMER KIT Page: 365 / 395...
Page 366 CP2 CIRC PUMP Installation, Operation, and Maintenance Manual ™ -25,36,45/ ™ -25,36, and 45 Circulator Page: 366 / 395...
Page 367 CP2 CIRC PUMP Page: 367 / 395...
Page 368 CP2 CIRC PUMP Table of Contents Table of Contents Introduction and Safety........................2 Introduction..........................2 Safety.............................2 Safety terminology and symbols................... 2 User safety..........................3 Environmental safety.......................4 Product warranty........................5 Transportation and Storage......................6 Inspect the delivery........................6 Inspect the package........................ 6 Inspect the unit........................6 Pump storage requirements......................
Page 369: Introduction And Safety
CP2 CIRC PUMP Introduction and Safety Introduction and Safety Introduction Purpose of this manual The purpose of this manual is to provide necessary information for: • Installation • Operation • Maintenance CAUTION: Read this manual carefully before installing and using the product. Improper use of the product can cause personal injury and damage to property, and may void the warranty.
Page 370: User Safety
CP2 CIRC PUMP Introduction and Safety • Personal accidents and health problems • Damage to the product • Product malfunction Hazard levels Hazard level Indication A hazardous situation which, if not avoided, will result in DANGER: death or serious injury A hazardous situation which, if not avoided, could result WARNING: in death or serious injury...
Page 371: Environmental Safety
CP2 CIRC PUMP Introduction and Safety • Protective gloves • Gas mask • Hearing protection • First-aid kit • Safety devices NOTICE: Never operate a unit unless safety devices are installed. Also see specific information about safety devices in other chapters of this manual. Electrical connections Electrical connections must be made by certified electricians in compliance with all international, national, state, and local regulations.
Page 372: Product Warranty
CP2 CIRC PUMP Introduction and Safety WARNING: Radiation Hazard. Do NOT send the product to Xylem if it has been exposed to any nuclear radiation. Electrical installation For electrical installation recycling requirements, consult your local electric utility. Recycling guidelines Always follow local laws and regulations regarding recycling. Product warranty Coverage Xylem undertakes to remedy defects in products from Xylem under these conditions:...
Page 373: Transportation And Storage
CP2 CIRC PUMP Transportation and Storage Transportation and Storage Inspect the delivery Inspect the package 1. Inspect the package for damaged or missing items upon delivery. 2. Note any damaged or missing items on the receipt and freight bill. 3. File a claim with the shipping company if anything is out of order. If the product has been picked up at a distributor, make a claim directly to the distributor.
Page 374: Product Description
CP2 CIRC PUMP Product Description Product Description General description The NRF/NBF circulator pump has these features: • System liquid lubricated bearings • Non-overloading permanent split capacitor motor with thermal or impedance protection • Quiet operation • Nonsubmersible Pump application WARNING: California Proposition 65 warning! This product contains chemicals known to the state of California to cause cancer and birth defects or other reproductive harm.
Page 375: Installation
CP2 CIRC PUMP Installation Installation Pump location guidelines Guideline Explanation/comment Make sure that the space This facilitates ventilation, inspection, maintenance, and service. Xylem around the pump is sufficient. recommends that the service valves on the suction and discharge of all circulators are installed so they can be serviced or replaced without draining the system.
Page 376: Install Suction And Discharge Flange Connectors On The Pipe Ends
CP2 CIRC PUMP Installation Install suction and discharge flange connectors on the pipe ends WARNING: • Burn hazard. Make sure that each flange gasket remains seated in the flange groove during and after installation. • Burn hazard. Do NOT re-use old gaskets. When disassembling a gasketed joint, always use a new gasket upon reassembly.
Page 377: Wiring Diagram
CP2 CIRC PUMP Installation 1. Remove the screws that secure the conduit box cover. 2. Lift off the cover. 3. Attach the appropriately sized connector to the hole in the side of the conduit box. 4. Wire the motor to a single phase power source that matches the electrical rating on the pump nameplate.
Page 378 CP2 CIRC PUMP Installation 1. Insert the O-ring end of the check valve into the discharge port of the pump body. 2. Hand press the check valve body into place until it snaps into position. NOTICE: CAUTION: PROPERTY DAMAGE HAZARD. It is not advisable to install circulators in an attic or upper floor over finished living space.
Page 379: Commissioning, Startup, Operation, And Shutdown
CP2 CIRC PUMP Commissioning, Startup, Operation, and Shutdown Commissioning, Startup, Operation, and Shutdown Pump operation precautions WARNING: • Do NOT exceed the maximum working pressure of the pump. This information is listed on the nameplate of the pump. • The heating of water and other fluids causes volumetric expansion. The associated forces can cause the failure of system components and the release of high- temperature fluids.
Page 380: Performance Characteristic Curve
CP2 CIRC PUMP Commissioning, Startup, Operation, and Shutdown Minimum speed Medium speed Maximum speed Performance characteristic curve Select the speed that best matches the design performance for the system or loop for which you are installing the pump. (kPa) (M) (FT) CENTRIFUGAL PUMP SERIES NRF-36 SPEED 3 SPEED 2...
Page 381 CP2 CIRC PUMP Commissioning, Startup, Operation, and Shutdown (kPa) (M) (FT) CENTRIFUGAL PUMP SERIES NRF-36 SPEED 3 SPEED 2 SPEED 1 (gpm) (m3/hr ) (l/s) Figure 6: Centrifugal pump series NRF-25 with check valve (kPa) (M) (FT) CENTRIFUGAL PUMP SERIES NRF-36 SPEED 3 SPEED 2 SPEED 1...
Page 382: Maintenance
CP2 CIRC PUMP Maintenance Maintenance Periodic inspection • It is recommended that periodic inspections be made to check for potential problems with the pump. • If any leaks or evidence of leakage is present, repair or replace the unit. Remove the pump from an existing system WARNING: •...
Page 383: Troubleshooting
CP2 CIRC PUMP Troubleshooting Troubleshooting Pumping system troubleshooting Symptom Cause Remedy There is no circulation Air-bound system Vent the system The impeller or piping is clogged. Locate and remove the obstruction. The system valve is closed. Open The electrical circuit for the pump is Check all related low and line voltage broken.
Page 384 CP2 CIRC PUMP Troubleshooting NOTICE: Cavitation is identified by low rumbling or sharp rattling noises. This situation is created by the lack of available net positive suction head (NPSH). The pressure at some point in the pump falls below the vapor pressure of the water causing flashing and the formation of bubbles, which are carried into the volute where the higher pressure causes them to implode.
Page 385 CP2 CIRC PUMP Xylem |’zīləm| 1) The tissue in plants that brings water upward from the roots 2) A leading global water technology company We're 12,000 people unified in a common purpose: creating innovative solutions to meet our world's water needs. Developing new technologies that will improve the way water is used, conserved, and re-used in the future is central to our work.
Page 386 CP2 CIRC PUMP TERMS AND CONDITIONS OF SALE – XYLEM AMERICAS Page 1 of 3 (June 2015) Agreement, Integration and Conflict of Terms. These terms and decline to make delivery of goods, except upon receipt of satisfactory security conditions, together with any special conditions expressly incorporated thereto or cash payments in advance, or Seller may terminate the order upon written in the quotation or sales form, are to govern any sale between the Seller and notice to Buyer without further obligation to Buyer whatsoever.
Page 387 CP2 CIRC PUMP TERMS AND CONDITIONS OF SALE – XYLEM AMERICAS Page 2 of 3 (June 2015) REGARD TO SELLER’S ACTS OR OMISSIONS OR NEGLIGENCE Except as otherwise provided by law, Seller shall, at its option and at no cost STRICT LIABILITY PERFORMANCE...
Page 388 CP2 CIRC PUMP TERMS AND CONDITIONS OF SALE – XYLEM AMERICAS Page 3 of 3 (June 2015) U.N. CONVENTION ON CONTRACTS FOR THE INTERNATIONAL 13. Proprietary Information, Injunction. Seller’s designs, illustrations, SALE OF GOODS. drawings, specifications, technical data, catalogues, “know-how”, economic or other business or manufacturing information (collectively “Proprietary 20.
Page 389 PRV PRESSURE REDUCER VALVE W500XLM WILKINS LF 3 PRESSURE REDUCING VALVE IPS 25-75 W500XLJ WILKINS LF 1-1/2 PRV IPS 25-75 Page: 389 / 395...
Page 390 PRV PRESSURE REDUCER VALVE ÿ ÿ Page: 390 / 395...
Page 391 PRV PRESSURE REDUCER VALVE ➤ ÿ ÿ ✁ ✂ ✄ ☎ ✆ Page: 391 / 395...
Page 392 PRV PRESSURE REDUCER VALVE Model 500XL LEAD-FREE* ® Pressure Reducing Valve with Integral By-pass company ® (1/2”, 3/4”, 1”, 1 1/4”, 1 1/2”, 2”, 2 1/2” & 3”) *This product contains a weighted average lead content less than 0.25% for wetted surfaces. Installation Testing Maintenance Instructions...
Page 393 PRV PRESSURE REDUCER VALVE Troubleshooting in an attempt to eliminate such a condition, may reduce pipe line rying capacity to maintain adequate pressure at the most remote capacities below that which is adequate for maximum probable use. When high service pressures are in effect, either continu- minimum adequate pressure is generally 8 to 15 lbs.
Page 394 ÿ ¡ ÿ ÿ ÿ ÿ ÿ ¢ £ ¡ ÿ ÿ ÿ — ¤ ¢ Page: 394 / 395...
Page 395 Page: 395 / 395...

This manual is also suitable for:

Cadet pro 215ba series Cadet pro 215ab series Cadet pro 215b series Cadet pro 215fa series Cadet pro 215fc series Cadet pro 215ca series ... Show all

American Standard Cadet PRO 215AA Series Installation Instructions Care And Maintenance

Table of Contents

Cp2 Circ Pump

Quick Links

Chapters

Troubleshooting

Related Manuals for American Standard Cadet PRO 215AA Series

Summary of Contents for American Standard Cadet PRO 215AA Series

This manual is also suitable for:

Table of Contents
