- Page 1 INSTRUCTION MANUAL Folding Sewing Craft Table SKY5834 + SKY6212 + SKY6281 + SKY7530 + SKY7531 + SKY7532 SKY7533 Ver. 4...
- Page 2 NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws, and knobs before use. •...
- Page 3 PARTS TABLE TOP LEFT SIDE RIGHT SIDE 1 PC 1 PC 1 PC DOOR SUPPORT BAR SHELF 1 PC 3 PCS 1 PC PEG PANEL STORAGE SIDE I STORAGE BACK I 2 PCS 2 PCS 1 PC STORAGE FRONT I STORAGE BOTTOM 1 PC 2 PCS...
- Page 4 PARTS STORAGE SIDE II STORAGE BACK II STORAGE FRONT II 2 PCS 1 PC 1 PC TIGHTENING CAMLOCKS Screw cam bolt Insert cam bolt and cam lock into Screw cam lock in completely. designated holes. clockwise to secure cam bolt.
- Page 5 PRODUCT ASSEMBLY Attach a part M locking caster and part N caster to part 2 left side with two part E anchor screw sets. Screw five part A cam bolts into the left side.
- Page 6 PRODUCT ASSEMBLY Attach a part M locking caster and part N caster to part 3 right side with two part E anchor screw sets. Attach part K magnetic catch with two part G screws. Screw five part A cam bolts into the right side.
- Page 7 PRODUCT ASSEMBLY Attach three part 5 support bars to the part 3 right side with three part C dowels and three part B cam locks. Attach part 6 shelf with a part C dowel and two part B cam locks.
- Page 8 PRODUCT ASSEMBLY Attach the part 2 left side with four part C dowels and five part B cam locks.
- Page 9 PRODUCT ASSEMBLY Screw four part A cam bolts into the part 1 tabletop. Attach the tabletop with four part C dowels and four part B cam locks.
- Page 10 PRODUCT ASSEMBLY Attach two part 8 storage sides to part 9 storage back with two part C dowels and two D screws. Slide in part 11 storage bottom. Attach part 10 storage front with two part C dowels and two part D screws.
- Page 11 PRODUCT ASSEMBLY Attach two part 13 storage sides to part 14 storage back with two part C dowels and two D screws. Slide in part 11 storage bottom. Attach part 15 storage front with two part C dowels and two part D screws.
- Page 12 PRODUCT ASSEMBLY Attach a part N caster to the part 4 door with one part E screw set. Attach part I knob with a part H screw. Attach part J metal plate with a part F screw.
- Page 13 PRODUCT ASSEMBLY Attach the two storage compartments and two part 7 peg panels with ten part D screws. Insert twenty part 12 pegs into the peg panels.
- Page 14 PRODUCT ASSEMBLY Attach the door to the assembly with two part L hinges and eight part F screws.
- Page 15 PRODUCT ASSEMBLY Flip open the tabletop and secure it with a part C dowel. TOTAL WEIGHT CAPACITY (40 lbs) EXTENSION WEIGHT CAPACITY (5 lbs)
- Page 16 HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
