1
2
1
Main power switch
2
Auto wash
3
Intensive wash
4
Eco wash
5
Glass wash
6
1 hour wash
7
SpeedWash
Safety instructions ................................................... 2
Before washing for the first time ............................ 3
Loading the dishwasher .......................................... 6
Using the dishwasher ............................................. 7
Settings..................................................................... 11
Care and cleaning ................................................. 13
Troubleshooting ..................................................... 15
Installation .............................................................. 18
Service .................................................................... 19
Information for test institute .................................. 20
3 4
5
7 8 9 10
6
1
EN
Operating Instructions
Dishwasher
GV5
83C
10
14
12 13
11
Auto open
8
9
Self-clean
Hyg iene
10
Delayed start
11
Display
12
Rinse aid indicator
13
Salt indicator
14
Advertisement
Related Manuals for Gorenje GV583C10
Summary of Contents for Gorenje GV583C10
- Page 1 Operating Instructions Dishwasher 12 13 7 8 9 10 Auto open Main power switch Auto wash Self-clean Hyg iene Intensive wash Delayed start Eco wash Display Glass wash Rinse aid indicator 1 hour wash Salt indicator SpeedWash Safety instructions ........... 2 Before washing for the first time ......
- Page 2 Safety instructions Winter storage/transport General Store the dishwasher where the temperature remains • • Read the operating instructions and keep them above freezing. in a safe place! Avoid long transport distances in very cold weather. • • Never use the dishwasher for any purpose other Transport the dishwasher upright or laying on its back.
- Page 3 Before washing for the first time The water softener Refill salt indicator When the salt needs topping up, the above symbol lights In order to achieve good dishwashing results, the on the display. dishwasher needs soft water (water with low mineral content).
- Page 4 Settings Open the settings menu: 1. First, open the door. Turn on the machine. Press and hold the main power switch until the display lights 2. Within 10 seconds: - press the Auto button selector and the option button for Speed Wash at the same time. 3.
- Page 5 Cup shelf The cup shelf can be folded up or down for better stacking of pots and pans. Make sure the cup shelf is on the correct Economic dishwashing position when folded up as show in the picture. Do not start the dishwasher until it is fully loaded to save •...
- Page 6 Cup shelf Loading the dishwasher of pots and pans. Make sure the cup shelf is on the correct The dishwasher's baskets(EN60436) position when folded up as show in the picture. The dishwasher is equipped with a top cutlery tray, an upper basket and a lower basket.
- Page 7 Using the dishwasher Add detergent Too much detergent can result in less effective Add the detergent to the detergent compartment. dishwashing and also entails greater environmental 1: Please choose an open way according to the actual impact. lid is tight and will not open correctly. situation.
- Page 8 Auto wash The dishwasher can measure how dirty the dishes are and adjust water consumption and temperature accordingly. Press the button once to activate Delayed start. Press When newly installed, the programme needs to be run five the button several times – or hold it in – to set the times before it is fully adapted and can provide the best desired number of hours.
- Page 9 Programme chart(EN50242) PROGRAMS Detergent, EXTRA Prewashes Main wash Number of Final rinse Consumption values compartment 1 rinses - Program - Options Dishwashing Energy Water cons. time (approx. (ml) (approx. kWh) hrs:min) Auto open Auto wash 5 / 20 60 ° C 1:20-2:30 0.790-1.510 9.8~13.1...
- Page 10 Programme chart(EN60436) PROGRAMS Detergent, EXTRA Prewashes Main wash Number of Final rinse Consumption values compartment 1 rinses - Program - Options Dishwashing Energy Water cons. time (approx. (ml) (approx. kWh) hrs:min) Auto open Auto wash 4 / 14 60 ° C 1:20-2:30 0.790-1.510 9.8~13.1...
- Page 11 Settings Open the settings menu: 1. First, open the door. Turn on the machine. Press and hold the main power switch until the display lights 2. Within 10 seconds: - press the Auto button selector and the option button for Speed Wash at the same time. 3.
- Page 12 Open the settings menu: 1. First, open the door. Turn on the machine. Press and hold the main power switch until the display lights 2. Within 10 seconds: - press the Auto button selector and the option button for Speed Wash at the same time. 3.
- Page 13 Open the settings menu: 1. First, open the door. Turn on the machine. Press and hold the main power switch until the display lights 2. Within 10 seconds: Auto button selector a - press the nd the option button for Speed Wash at the same time. 3.
- Page 14 Care and cleaning Filter System The filter prevents larger remnants of food or other objects from getting inside the pump. The residues may block the filter, in this case they must be removed. Fine filter. This filter holds soil and food residues in the sump area prevents them from being redeposited on the dishes during wash cycle.
- Page 15 2 Unscrew the spray arm bearings counterclockwise to Spray arms remove the spray arm from the upper basket. Holes and bearings can sometimes become blocked. Remove any debris using a pin or the like. The spray arms also have holes underneath. Door When cleaning the edge around the door, use only a slightly To facilitate cleaning you can remove the spray arms.
- Page 16 Troubleshooting Type of fault on the display Action Water Inlet Fault Check that the water tap is on. Check that the outer filter on the inlet hose is not blocked. If the problem persists, call the service department. Not reaching required Call the service department.
- Page 17 Problem Possible causes Action The dishes are not clean. The spray arms do not rotate. Remove the arms and clean them. Check that the dishes are not blocking the spray arms. Old detergent. Detergent is a perishable Avoid large packages. product.
- Page 18 Problem Possible causes Action Rattling sound when dishwashing. The dishes are not correctly placed or Check that the dishes are placed the spray arms are not rotating. securely. Spin the spray arms to make sure they can rotate. Water remains in the dishwasher. Blocked drainage hose.
- Page 19 Installation Setup It is important that you read through and follow the instructions and directions below. Conduct installation and The recess and connection dimensions are included in • connection in accordance with the separate installation the separate installation instructions. Check that all instructions.
- Page 20 Service Read the chapter Troubleshooting before contacting the service department. Provide the details on the serial number When the drainage hose is routed to a connection plate in all contact. Include the article number (1) and the nipple on the sink unit's water trap (see illustration 1), serial number (2).
- Page 21 Information for test institute Request test institute information via e-mail dishwashers@appliance-development.com. The request should include the details on the serial number plate. Include the article number (1) and the serial number (2).
