Gorenje GV67261XXLCUS Operating Instructions Manual

4.2–140 psi pressure
Hide thumbs
Table of Contents

Advertisement

Quick Links

AE
OPERATING
INSTRUCTIONS
DISHWASHER
www.gorenje.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV67261XXLCUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gorenje GV67261XXLCUS

Summary of Contents for Gorenje GV67261XXLCUS

  • Page 1 OPERATING INSTRUCTIONS DISHWASHER www.gorenje.com...

  • Page 2: Table Of Contents

    Contents Display panel .................... Important safety instructions ..............Before washing for the first time ............... Loading the dishwasher ................Using the dishwasher ................Settings ..................... Care and maintenance instructions ............Troubleshooting ..................Installation instructions ................Service ...................... Technical information ................Display panel 14 15 Main power switch...

  • Page 3: Important Safety Instructions

    Important safety instructions SAVE THESE INSTRUCTIONS FOR FUTURE WARNING! REFERENCE This product may contain chemicals known to the state WARNING! of California to cause cancer or reproductive harm. When using your dishwasher, follow basic precautions, including the following: Installation Read all instructions before using the dishwasher. •...

  • Page 4: Before Washing For The First Time

    Before washing for the first time The water softener Disposal In order to achieve good dishwashing results, the dishwash- When the machine has reached the end of its service • er needs soft water (water with low mineral content). Hard life and is to be disposed of, it should immediately be water leaves a white coating on dishes and the dishwasher.

  • Page 5: Loading The Dishwasher

    Loading the dishwasher Energy-efficient dishwashing Refill salt indicator Do not start the dishwasher until it is fully loaded to save • When the salt needs topping up, the above symbol lights energy. on the display. Do not rinse under running water. Simply scrape off •...

  • Page 6: Lower Basket

    wine glasses on the wine glass shelf. Place knives in the tines by pressing the catch inward before adjusting their knife stand on the right (if space allows). position. Lower basket Place plates, side plates, serving dishes, and pots in the lower basket.

  • Page 7: Typical Load For 10 Place Settings

    Typical load for 10 place settings Lower basket with 10 place settings AHAM DW-1 Top cutlery tray with 10 place settings AHAM DW-1 Teaspoons Forks Serving cutlery – spoons Serving cutlery – fork Knives Soupspoons Upper basket with 10 place settings AHAM DW-1 NOTE! Ensure that the upper basket is set to its highest position.

  • Page 8: Using The Dishwasher

    Using the dishwasher Add detergent The main power switch Press to open Press and hold the main power switch until the display turns on. Also check that the water supply valve is on. PROGRAMS - Choose program Choose a program to suit the type of dishes and how dirty they are.

  • Page 9: Power Failure

    programs and some options cannot be combined (available options glow dimly). SpeedWash This option shortens the program time, but uses more ener- gy and water. Status light Auto open The dishwasher door opens automatically at the end of the program, which improves the drying results. (If the dishwash- Stopping or changing a program er is built-in, the surrounding furnishings must be resistant If you want to change program after starting the dishwasher,...

  • Page 10: Unloading The Dishwasher

    The dishwasher switches off automatically after the program ends. This program prevents bad odors from dirty dishes left in the dishwasher. Activate the program until a dishwashing To minimize the risk of leaks, we recommend that you turn program is run. The fan and ionizer are activated at intervals off the water supply valve if away from home for an extended for 72 hours.

  • Page 12: Settings

    Settings Open the settings menu: First, open the door. Turn off the machine. Press and hold the main power switch until the display lights up. Within 10 seconds: - press the program button for Auto wash and the option button for SpeedWash. The display shows the settings menu (current setting and its currently set value).
  • Page 13 Settings Options 3:00 (Off) You can activate this setting when using 3-in-1/all-in- (3-in-1/all-in-one detergent) 3:01 (On) one detergent. The dishwashing programs automatically adapt to provide the best possible dishwashing and drying results every time. If this setting is activated, there is no need to add rinse aid since this option dis- ables rinse aid dispensing.

  • Page 14: Care And Maintenance Instructions

    Care and maintenance instructions Coarse filter Spray arms The coarse filter traps larger food particles, which cannot Holes and bearings can become blocked. Remove debris get past the drain pump. Empty the coarse filter as neces- using a needle or similar item. The spray arms have holes sary.
  • Page 15 ment (with no dishes in the machine). See Self-cleaning Turn the pump wheel located behind the drain pump program in the chapter Using the dishwasher. stop by hand. Carefully remove any items. Replace the drain pump stop along with the fine and TIP! coarse filters.

  • Page 16: Troubleshooting

    Troubleshooting Type of fault on the display Action Overfilling Clear the drain pump. See the section Care and maintenance instructions. If the problem persists, call the Customer Care Center. Water outlet fault See “Water remains in the dishwasher above the filters” in the table “Problem” below.

  • Page 17: Delayed Start

    Problem Possible causes Action The dishwasher does not start. The door is not closed properly or was Close the door within four seconds, oth- not closed immediately after starting the erwise the dishwasher will not start. See program. Starting the dishwasher in the chapter Using the dishwasher.
  • Page 18 Problem Possible causes Action Spots or films on the dishes. The water softener is leaking salt. Check that the salt compartment lid is properly tightened. Otherwise call the Customer Care Center. Incorrect water softener setting. See the chapter Settings. Incorrect rinse aid dosage setting. See the chapter Settings.
  • Page 19 Problem Possible causes Action Bad odor in dishwasher. Dirt around the seals and in corners. Clean with dish brush and low foaming cleaner. Low temperature programs have been Run a program with a higher tempera- selected for a prolonged period. ture about once a month.

  • Page 20: Installation Instructions

    Installation instructions '' (mm) 50.87* (1292*) 48.58 (1234) 21.89 (556) 23.79 (604) 22.56 (573) 20.47 (520) 1.20 (31) 2.16 (55) Door length 4.21 (107) Integrated door panel with slide function installed, which means the integrated door panel slides upward when the dishwasher is opened. Nominal dimensions.

  • Page 21: Drain Connection

    Water supply NOTE! The machine can be connected to either a cold or a hot Framed cabinets require additional finished filler material (max. 160 °F (70 °C)) water supply. The water pressure behind the face frame for a proper installation. A minimum should be 4.2-140 psi.

  • Page 22: Service

    Read the chapter Troubleshooting before contacting the Customer Care Center. If you have encountered a problem that you cannot resolve, please contact your nearest dealer, see www.gorenje.com. When making contact, provide the details on the serial number plate. Include the article number (1) and the serial number (2).
  • Page 23 Notes...

  • Page 24: Technical Information

    Technical information Technical data Brand: Gorenje Model designation: GV67261XXLCUS Height: 33.74 - 35.71'' (857-907 mm) Width: 23.79" (604 mm) Depth: 21.89'' (556 mm) Weight: 82 lb (37 kg) Water pressure: 4.2–140 psi Electrical connection: See serial number plate Rated power:...
