  • Page 1 User manual Dishwasher GV693C60UVBR...

  • Page 2: Table Of Contents

    Contents Your dishwasher ........................Safety instructions ........................Installation ..........................Overflow guard function ......................Winter storage/transport ......................Packaging ..........................Disposal ............................ Symbols ............................ Before washing for the first time ................... Water hardness ......................... Basic settings ........................... Top up with rinse aid ........................ Greener dishwashing ......................
  • Page 3 Care and cleaning ........................Top up with rinse aid ........................ Clean the filter ........................... Cleaning the spray arms ......................Clean the outside of the dishwasher ..................CLn - Run the Self-clean program ................... Remove blockages ........................Troubleshooting ........................General ............................WiFi ............................

  • Page 4: Your Dishwasher

    Your dishwasher Install the dishwasher, see the chapter Installation. Then open the door and press The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See the chapter Before washing for the first time. On/Off WiFi Start/Stop...

  • Page 5: Safety Instructions

    Safety instructions Read the operating instructions and keep them in a safe place! Never use the dishwasher for any purpose other than that specified in these operating instructions. Do not load the dishwasher door or dishwasher baskets with anything other than dishes. Never leave the dishwasher door open as someone may trip on it.

  • Page 6: Installation

    WARNING! Knives and other pointed items must be placed horizontally in the dishwasher's special cutlery baskets. WARNING! Children must be supervised – dishwasher detergent is corrosive! Installation See the chapter Installation. Overflow guard function The overflow guard starts pumping out the machine and turns off the water supply if the water level in the dishwasher exceeds the normal level.

  • Page 7: Symbols

    Symbols Explanation of symbols appearing on the appliance. Read the user manual.

  • Page 8: Before Washing For The First Time

    Before washing for the first time Water hardness In order to achieve good dishwashing results, the dishwasher needs soft water (water with low mineral content). Hard water leaves a white coating on dishes and the dishwasher. Checking water hardness Contact the local waterworks to check the water hardness in your area. This is important as regards how much detergent and rinse aid to use.

  • Page 9: Greener Dishwashing

    Greener dishwashing Save energy and water When using a dishwasher in a residential setting, less energy and water are generally used compared to washing the dishes by hand. Do not rinse under running water Do not rinse the dishes under running water as this will lead to increased energy and water consumption. Simply scrape off large food particles before loading the dishwasher.

  • Page 10: Loading The Dishwasher

    Loading the dishwasher Fragile dishes Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high heat, others can be damaged by dishwasher detergent. Exercise caution with, for example, handmade items, fragile decoration, crystal/glassware, silver, copper, tin, aluminium, wood and plastic.

  • Page 11: Upper Basket

    Upper basket Place glasses, cups, bowls, side plates and saucers in the upper basket. All dirty surfaces should face inwards and downwards! Wine glasses are placed on the wine glass shelf and knives are placed in the knife stand on the right. 3 positions Knife stand Raising and lowering the upper basket...

  • Page 12: Lower Basket

    Adjustable plate supports The adjustable plate supports can be folded down to make it easier to load pots, bowls and glasses. Lower basket Place plates, side plates, serving dishes and pots in the lower basket. Adjustable plate supports The adjustable plate supports can be folded down to make it easier to load pots and bowls.

  • Page 13: Using The Dishwasher

    Using the dishwasher Add detergent Follow the instructions on the detergent packaging. Too much detergent can result in less effective dishwashing and also entails greater environmental impact. Detergent compartment The detergent compartment must be dry when adding detergent. If powder or liquid dishwasher detergent is Prewash detergent Main wash detergent used, add a small amount of the detergent to...

  • Page 14: On/Off

    On/Off WiFi Start/Stop Display NOTE! The control panel only reacts to use when the door is open. On/Off Open the door and press . Also turn on the water tap if it is turned off. Select program Select a program to suit the type of dishes and how dirty they are. Press the desired program until it is activated, which is indicated by an indicator light.

  • Page 15: Select Option

    Hygiene 70° This program is ideal to use where demands on hygiene are extra high, e.g. for baby bottles and cutting boards. The temperature is high both in the main wash and in the final rinse. Night 55° A quieter dishwashing program, suitable for running at night. The program time is extended. Remote (WiFi) You can remote control this dishwasher with your smartphone/tablet.

  • Page 16: Start/Stop

    TotalDry The dishwasher door opens automatically, which shortens the program time and improves the drying results. Wait until the dishwasher indicates that the program has ended and the dishes have cooled before unloading the dishwasher. (If the dishwasher is built-in the surrounding furnishings must be resistant to any condensation from the dishwasher.) The drying time of the TotalDry option varies (from 5 to 90 minutes) depending on the model, program and temperature of the final rinse.

  • Page 17: Status Ledlight

    Status LedLight The status light on the bottom part of the dishwasher indicates that a program has started. Flashing light A flashing light indicates that the door has been opened while a program is in progress. If it flashes when the door is closed, an error has occurred. See the chapter Troubleshooting. Status light If you want to load more dishes Open the door.

  • Page 18: Unloading The Dishwasher

    Unloading the dishwasher Hot porcelain is more fragile. Leave the dishes to cool in the dishwasher before unloading them. Unload the lower basket first to avoid any water drops from the upper basket falling onto the dishes in the lower basket.

  • Page 20: Wifi Connection

    WiFi connection ConnectLife You can remote control this dishwasher with your smartphone/tablet. Connect the dishwasher to your wireless network to be able to remote control and start the dishwasher using the ConnectLife app. The app can be used to find information, change settings, start a program and monitor the dishwasher. (The dishwasher can always be used without the app.) On/Off WiFi...

  • Page 21: Remote Control The Dishwasher

    Network symbol on the display Flashing 0.5 sec on/off The dishwasher is ready to be connected to your wireless network or paired with your smartphone/tablet. Flashing 1.0 sec on/off The dishwasher is connected to your wireless network. Glows The dishwasher is connected to your wireless network and the cloud. Remote control the dishwasher The dishwasher's network symbol is shown on the display when the dishwasher is paired with a...

  • Page 22: Settings

    Settings 1. Open the door and press 2. To open the dishwasher's settings menu, press and hold until SEt is shown on the display. 3. Press to step through the settings menu. 4. Press to step through the alternatives. 5. Confirm the selected setting by pressing 6.
  • Page 23 Settings Alternatives Restore factory de- Restores all settings to the factory defaults. faults Select rSt and confirm by pressing Exit To exit the dishwasher's settings menu, select End and press (The menu closes automatically after three seconds.)

  • Page 24: Care And Cleaning

    Care and cleaning Top up with rinse aid When the rinse aid needs topping up, the above symbol lights on the display. Lift up to open Press to close 1. Open the rinse aid compartment lid. 2. Carefully top up with rinse aid to the level marked MAX. 3.

  • Page 25: Cleaning The Spray Arms

    NOTE! Dishwashing results may be affected if the filter is fitted incorrectly. The dishwasher must not be used without the filter in place! Check that the yellow drainage pump stop (on the right in the bottom drain) is in place. Cleaning the spray arms Holes and bearings can sometimes become blocked.

  • Page 26: Clean The Outside Of The Dishwasher

    Clean the outside of the dishwasher Door and door seal Open the door. Clean the sides of the door and the door seal regularly with a slightly damp cloth. Clean the door seal at the lower front edge of the dishwasher with a washing-up brush. Control panel Keep the control panel clean.
  • Page 27 4. Carefully remove the outer filter from the inlet hose and clean it. 5. Refit the filter and check that the gasket is correctly positioned. 6. Screw the inlet hose firmly into place. 7. Plug the machine into the wall socket and turn on the water tap. Allow the pressure to settle for a while and check that the connection is watertight.

  • Page 28: Troubleshooting

    Troubleshooting Error messages Action Overfilling water Unblocking the drainage pump. See the chapter Care and cleaning. If the problem persists, contact your nearest service centre. Water outlet fault See "Water remains in the dishwasher" under "Problem" in the table below. If the problem persists, contact your nearest service centre.
  • Page 29 Problem Possible causes Action Check that the dishes are not blocking the baskets from slid- ing properly into place. The door lock does not click in- Check the door lock. If it does to place and lock. not click into place and lock, open the door.
  • Page 30 Problem Possible causes Action Old detergent. Detergent is a Avoid large packages. perishable product. Dishes loaded incorrectly. Do not cover porcelain with large bowls or the like. Avoid placing very tall glasses in the corners of the baskets. See the chapter Loading the dishwash- Glasses and cups have toppled Place dishes to sit steady.
  • Page 31 Problem Possible causes Action Detergent residue in the deter- The detergent compartment The detergent compartment gent compartment after dish- was damp when adding deter- must be dry when adding deter- washing. gent. gent. The detergent compartment has Check that the dishes are not been blocked.
  • Page 32 Problem Possible causes Action Rinse aid needs topping up or Top up with rinse aid or in- dosage is set too low. crease the rinse aid dosage setting. The setting TAB is activated and Switch all-in-one detergents or all-in-one detergent with insuffi- deactivate the TAB setting and cient drying effect is being used.

  • Page 33: Wifi

    WiFi Problem Possible causes Action The dishwasher's network sym- The dishwasher is not connec- Connect the dishwasher to your ted to your wireless network. wireless network. See the does not appear on the chapter WiFi connection. display. The WiFi connection is deactiv- Activate the WiFi connection.

  • Page 34: Installation

    Installation It is important that you read through and follow the instructions and directions below. Conduct installation and connection in accordance with the separate installation instructions. [mm] Remove the plastic strips if the recess dimension is 596-598 mm. Exercise caution! The edges may be sharp. Wear protective gloves! Cover door length.

  • Page 35: Drainage Connection

    Make sure the area on which the dishwasher is to be installed is firm. Adjust the adjustable feet so that the dishwasher is level. If the dishwasher is built-in the surrounding furnishings must be resistant to any condensation from the dishwasher. Mount the protective film beneath the worktop and up around the edge.

  • Page 36: Electrical Connection

    Electrical connection Information about the electrical connection can be found on the serial number plate. This specification must match the electricity supply. The dishwasher must be connected to an earthed socket. The electric wall socket must be placed outside of the installation area to be easily accessible after installing the dishwasher.

  • Page 37: Service

    Service Read the chapter Troubleshooting before contacting the service centre. If you have encountered a problem that you cannot resolve, please contact your nearest service centre for professional help. When making contact, provide the details on the serial number plate. Include the article number (1) and the serial number (2).

  • Page 38: Technical Information

    Technical information Technical data Height: 816-890 mm Width: 598 mm Depth: 555 mm Weight: 30 kg Water pressure: 0.03-1.0 MPa Electrical connection: See the serial number plate Rated power: See the serial number plate Noise emissions: 42 dB(A) re 1 pW 1) Weight can vary due to different specifications.
  • Page 39 GORENJE gospodinjski aparati, d.o.o. Naslov: Partizanska 12, 3320 Velenje, Slovenija Telefon: +386 (0)3 899 10 00 Faks: +386 (0)3 899 28 00 www.gorenje.com 881077-a2 We reserve the right to make changes.
