Gasoline Engine

Owner's Manual

1P61FA 1P65FA 1P61FE 1P65FE

1P68FA 1P70F

1P70FA 1P75F

Need help?

Do you have a question about the 1P65FA and is the answer not in the manual?

Questions and answers

Summary of Contents for LONCIN 1P65FA

Page 1 Gasoline Engine Owner’s Manual 1P61FA 1P65FA 1P61FE 1P65FE 1P68FA 1P70F 1P70FA 1P75F...
Page 2 BEFORE OPERATING ENGINE Read entire Operating ＆ Maintenance Instructions AND  the instructions for the equipment this engine powers. Failure to follow instructions could result in serious injury  or death. THE OPERATING ＆ MAINTENANCE INSTRUCTIONS CONTAIN SAFETY INFORMATION TO Make you aware of hazards associated with engines ...
Page 3 HAZARD SYMBOLS AND MEANINGS...
Page 4 CONTENTS CONTENTS 1. ENGINE SAFETY ………………………………………………………………………………… 2 2. COMPONENTS & CONTROL LOCATIONS …………………………………………………… 5 3. CONTROLS ………………………………………………………………………………………… 7 4. MAINTENANCE ………………………………………………………………………………… 10 5. STORAGE/TRANSPORTING …………………………………………………………………… 15 6. TROUBLESHOOTING …………………………………………………………………………… 18 7. TECHNICAL & CONSUMER INFORMATION ………………………………………………… 19 8. SPECIFICATIONS………………………………………………………………………………… 20...
Page 5 ENGINE SAFETY 1. ENGINE SAFETY IMPORTANT SAFETY INFORMATION Most accidents with engines can be prevented if you follow all instructions in this manual and on the engine. Some of the most common hazards are discussed below, along with the best way to protect yourself and others. Owner Responsibilities ...
Page 6 ENGINE SAFETY WARNING Starting engine creates sparking. Sparking can ignite nearby flammable gases. Explosion and fire could result.  If there is natural or gas leakage in area, do not start engine.  Do not use pressurized starting fluids because vapors are flammable. WARNING Rapid retraction of starter cord (kickback) will pull hand and arm toward engine faster than you can let go.
Page 7 ENGINE SAFETY WARNING Running engines produce heat. Engine parts, especially muffler, become extremely hot. Severe thermal burns can occur on contact. Combustible debris, such as leaves, grass, brush, etc. can catch fire.  Allow muffler, engine cylinder and fins to cool before touching. ...
Page 8 2. COMPONENTS & CONTROL LOCATIONS STARTER GRIP FUEL TANK CAP SPARK PLUG FUEL TANK OIL FILLER CAP/ CARBURETOR AIR CLEANER MUFFLER DISPTICK 1P61FA、1P65FA、1P68FA、1P70F、1P70FA FUEL TANK CAP STARTER GRIP SPARK PLUG FUEL TANK MUFFLER OIL FILLERCAP/ CARBURETOR AIR CLEANER DISPTICK 1P61FA、1P65FA...
Page 9 COMPONENTS & CONTROL LOCATIONS FUEL TANK CAP STARTER GRIP FUEL TANK AIR CLEANER SPARK PLUG OIL FILLERCAP/ MUFFLER DISPTICK CARBURETOR 1P61FE、1P65FE FUEL TANK FUEL TANK CAP STARTER GRIP OIL FILLERCAP/ DISPTICK SPARK PLUG AIR CLEANER CARBURETOR MUFFLER 1P75F...
Page 10  If the oil level is near or below the lower limit mark on the dipstick, fill with the recommended oil to the upper limit mark. Do not overfill.  Reinstall the oil filler cap/dipstick. OIL FILLER CAP/DIPSTICK UPPER LOWER 1P61FA、1P65FA、1P68FA、1P70F、1P70FA、1P75F...
Page 11 OIL FILLER CAP/DIPSTICK UPPER LOWER 1P61FE 1P65FE Engine oil capacities: : 0.55L (0.146 US Gal, 0.119 Imp Gal) 1P61FA、1P65FA 1P61FE、1P65FE 、1P75F: 0.5L (0.133 US Gal, 0.108 Imp Gal) 0.60L (0.16 US Gal, 0.13 Imp Gal) 1P68FA、1P70F、1P70FA : CAUTION Do not overfill. Overfilling with oil may cause: Smoking, Hard starting, Spark plug fouling, or Oil saturation of air filter.
Page 12 CONTROLS 3.3 STARTING ENGINE STOP IDLE FAST CHOKE 3.3.1 Control Lever  FOR STARTING A COLD ENGINE: Move the Control Lever to the choke position.  FOR RESTARTING A WARM ENGINE: Do not use the choke when the engine is warm. Move the control Level slightly past the idle position.
Page 13 MAINTENANCE 4. MAINTENANCE THE IMPORTANCE OF MAINTENANCE Good maintenance is essential for safe, economical, and trouble-free operation. It will also help reduce air pollution. WARNING Improperly maintaining this engine, or failure to correct a problem before operation, can cause a malfunction in which you can be seriously hurt or killed. Always follow the inspection and maintenance recommendations and schedules in this owner’s manual.
Page 14 MAINTENANCE MAINTENANCE SCHEDULE REGULAR SERVICE PERIOD Performed at every indicated First Every 3 Every 6 Every Before month or operating hour interval, month or months months year or Each use whichever comes first. 5 Hrs. or 25 Hrs. or 50 Hrs. 100 Hrs.
Page 15 CAP/DIPSTICK OIL FILLER CAP/DIPSTICK SEALING WASHER DRAIN BOLT 1P61FA、1P65FA、1P68FA、1P70F、1P70FA、1P75F 1P61FE、1P65FE REFUELING With the engine stopped, remove the fuel tank cap and check the fuel level. Refill the tank if the fuel level is low. Refuel in a well-ventilated area before starting the engine. If the engine has been running, allow it to cool.
Page 16 MAINTENANCE AIR CLEANER BODY AIR CLEANER FILTER FILTER, OUTER LATCH TABS COVER INSPECTION 1. Press the latch tabs on the air cleaner cover or remove the cap nuts, and remove the cover .check the filter to be sure it is clean and in good condition. 2.
Page 17 MAINTENANCE 5. Measure the spark plug electrode gap with a suitable gauge. The gap should be 0.028 - 0.031 in (0.70 - 0.80 mm). Correct the gap, if necessary, by carefully bending the side electrode. 6. Install the spark plug carefully, by hand, to avoid cross-threading. 7.
Page 18 STORAGE/ TRANSPORTING 5. STORAGE/ TRANSPORTING STORING YOUR ENGINE Storage Preparation Proper storage preparation is essential for keeping your engine trouble free and looking good. The following steps will help to keep rust and corrosion from impairing your engine’s function and appearance, and will make the engine easier to start after storage.
Page 19 STORAGE/ TRANSPORTING DRAINING THE FUEL TANK AND CARBURETOR 1. Place approved gasoline container below the carburetor, and use a funnel to avoid spilling CARBURETOR fuel. FLOAT BOWL 2. Remove the carburetor drain bolt SEALING WASHER and sealing washer, and then move the fuel valve lever to the ON position.
Page 20 STORAGE/ TRANSPORTING is partially or completely filled. The air in a partially filled fuel tank promotes fuel deterioration. Very warm storage temperatures accelerate fuel deterioration. Gasoline will oxidize and deteriorate in storage. Deteriorated gasoline will cause hard starting, and it leaves gum deposits that clog the fuel system.
Page 21 TROUBLESHOOTING 6. TROUBLESHOOTING ENGINE WILL NOT Possible Cause Correction START Move lever to CLOSE unless Choke OPEN. 1. Check control engine is warm. positions Engine switch OFF. Turn engine switch to ON. Out of fuel. Refuel fuel; engine stored 2. Check fuel. without treating or draining Drain fuel tank and carburetor.
Page 22 Quick Reference Information Type SAE 10W-30,API SE or SF, for general use Engine Oil 1P61FA、1P65FA : 0.55L (0.146 US Gal, 0.119 Imp Gal) Capacity 1P61FE 、1P65FE、1P75F : 0.5L (0.133 US Gal, 0.108 Imp Gal) 1P68FA、1P70F、1P70FA : 0.6L (0.16US Gal, 0.13mp Gal) Type F7RTC or other equivalents.
Page 23 SPECIFICATIONS 8. SPECIFICATIONS Model 1P61FA 1P65FA 1P61FE 1P65FE 1P70F 1P68FA 1P70FA 1P75F Type Single cylinder, 4-Stroke, Forced Air Cooling, OHV Rated. power(kW/3600rpm) Max. torque (N·m/rpm) 7/2500 8.3/2500 6.8/2500 7/2500 9/2500 9.5/2500 10.5/2500 14/2500 ≤395 Fuel consumption (g/kW·h) Idle speed 1800±150 rpm 75×50.8...
