Page 2
Single Earpiece Headset for VOX Function with In-line PTT ........40 Single Unit Rapid Charger ..................40 Carrying Case ......................40 REGULAR TEST OF THE RADIO ..............41 WARRANTY ....................41 Warranty Condition ....................41 Exclusions and Limitations ..................41 SPECIFICATIONS ................... 42 HT649 ........................42...
Page 3
The HT649 is a two-way VHF radiotelephone. The main features are as follows: In addition to channels 15, 16 and 17, the HT649 also operates on the following channels: 6, 8, 9, 10, 11, 12,13, 14, 67, 68, 69, 71, 72, 73, 74 and 77.
Page 4
CONTROLS AND INDICATORS HAND STRAP WEAK LINK BELT CLIP BATTERY PACK VOLUME CONTROL ACCESSORY CONNECTOR VOX BUTTON ANTENNA CONNECTOR * No Use LED INDICATOR SCAN LAMP/ UP/DOWN KEY LOCK POWER SWITCH...
Page 5
POWER SWITCH LED indicator Powers the transceiver on and off. RED Steady = Transmitting RED flashing slowly = Battery needs re-charging MON key GREEN Steady = Receiving Hold down to monitor when receiving GREEN flashing slowly = Invalid a weak signal. signal detecting signal detected SCAN key VOLUME CONTROL...
Page 6
LCD INDICATORS Keypad Lock The keypad is locked, with the exception of the [PTT] switch and [LAMP] and [POWER] keys. Battery State Monitor battery status. Channel Monitor Monitor displayed channel. Memorised Channel Currently scanned channel is stored in memory. VOX VOX Operation Voice operated mode enabled...
Page 7
PREPARATION PRIOR TO USE ATTACHING THE BELT CLIP Align the belt clip with the plastic slots on the battery pack. Slide the belt clip downwards onto the battery pack, pushing firmly until you hear a click. ATTACHING/DETACHING THE BATTERY To attach the battery, set the bottom part of the battery to the transceiver, press the To detach, battery against the transceiver then turn...
Page 8
Holding the transceiver approx. 1 inch from your mouth, speak slowly and clearly into the microphone. Release [PTT] switch for reception. REMARKS: The HT649 provides short range voice communications among crews, To prevent unnecessary battery drain, keep watch on channel 16 and reply when a call is received.
Page 9
VOX FUNCTION With connection of CHP1/750 Headset for VOX function, the HT649 becomes a "VHF radio communication set for rescue craft," complying with Chapter V of AMENDMENTS TO THE INTERNATIONAL LIFE-SAVING APPLIANCE (LSA) CODE. Res. MSC. 218 (82) Perform steps 1 and 2 of RECEPTION.
Page 10
PRIMARY BATTERY CLB750G STORAGE PLACE The emergency battery (primary battery, yellow) is normally set in the CSBHT3 3 Unit Charger. In an emergency, take out the yellow Storage place primary battery from the charger and carry it to the survival craft. EXPIRATION PERIOD The primary battery carries an expiration date.
Page 11
1. To reduce risk of injury, charge only the rechargeable Entel batteries. Other batteries may explode, causing personal injury and damage. 2. Use of accessories not recommended by Entel may result in risk of fire, electric shock, or injury. 3. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the charger.
Page 12
BATTERY SAFETY The battery pack contains lithium-Ion cells. This type of battery stores a charge powerful enough to be dangerous if misused or abused, especially when removed from the transceiver. Please observe the following precautions: DO NOT SHORTCIRCUIT THE BATTERY PACK TERMINALS Shorting the terminals of the transceiver can cause sparks, severe over heating, burns, and/or damage of battery cell.
Page 13
BATTERY PACK CHARGERS The battery should be charged with the following chargers. Type of chargers Type Charger Charging time 3 Unit Charger CSBHT3 (100–240VAC) Approx. 6 hours Single Unit Rapid Charger CSAHT (100–240VAC) Approx. 3 hours 3 Unit Charger Single Unit Rapid Charger Plug adaptor for European Outlet type...
Page 14
CHARGING THE BATTERY Connect the Charger to a mains supply (100 to 240 VAC). The green LED on CSBHT3 lights. The LED of CSAHT is not lit in this step. Turn the transceiver off. Place the battery pack into the charger with with with the transceiver attached.
Page 15
FIXING 3 UNIT CHARGER TO A TABLETOP Remove eight screws from both sides then remove the L-shape plate. Fix the bottom side of the L-shape plate with four screws. Fix the main unit to the L-shape plate with the eight screws removed at step 1.
Page 16
FIXING THE SINGLE UNIT RAPID CHARGER ON A BULKHEAD Using the supplied screws, fix the Single Unit Rapid Charger through the rear part as shown below. (mm) FIXING THE SINGLE UNIT RAPID CHARGER ON A TABLETOP Using the supplied screws, fix the Single Unit Rapid Charger through the bottom part as shown below.
Page 17
The clip may be rotated to one of 8 locking positions to aid attachment. This jack is for 3.5 mm earpiece jack socket for earpiece connector e.g. Entel earpiece. To use, unscrew the ear jack locking screw and insert the accessory.
Page 18
SINGLE EARPIECE HEADSET FOR VOX FUNCTION WITH IN-LINE PTT TYPE No: CHP1/750 Hands-free headset for rescue boat SINGLE UNIT RAPID CHARGER TYPE No: CSAHT CARRYING CASE TYPE No: CLC753...
Page 19
If a defect arises and a valid claim is received by Entel within the Warranty Period, at its option, Entel will (1) repair the product at no charge, using new or refurbished replacement parts, (2) exchange the product with a product that is...
Page 20
SPECIFICATIONS The HT649 VHF two-way radiotelephone apparatus complies with the requirements of IMO/SOLAS/GMDSS regulations. HT649 1. GENERAL (1) Type Approval ......EC Type-examination, Certificate No. 07212001/AA/00, Telefication B.V., Netherlands (2) Conforming Standards ...EN 300 225 V1.4.1 (2004-12), IEC60945 Ed.4 (2002-8) (3) Class of Emission ....G3E (4) Number of Channels .....3 channels...
Page 21
2. TRANSMITTER (1) RF Output Power ....0.8 W ±20% (2) Type of Oscillation ....Frequency synthesis (3) Frequency Error ......Within 10 ppm (4) Type of Modulation ....Phase modulation (5) AF Modulation Response ..Within ±3 dB at 6 dB / oct pre-emphasis for modulation 300 –...
