Entel HT649 Quick Start Manual

PREPARING YOUR RADIO FOR USE

SWITCHING ON, RECEPTION
AND SWITCHING OFF

Attaching / removing the antenna

1. To switch on, press and hold the on/off control
(1) on the front of the radio.
2. When the radio has passed its diagnostic tests,
A
it will emit a fanfare tone.
3. The radio will enter standby mode. This is
indicated by the LED Amber flashing once
every 5 seconds, signalling that the radio is
B
ready for use.
4. Adjust the volume control to select the desired
volume level.
5. Using the channel buttons, ensure you have
the correct channel selected.
6. When receiving a valid signal, the LED will
illuminate steady green and audio will be
emitted from the radio's speaker or audio
accessory (if attached)
1. To attach, carefully align the antenna with the
7. When finished using the radio, switch off
socket. Screw in the antenna and clockwise
by pressing and holding the on/off button
(taking care not to cross the thread) until it
(1) until the radio beeps and the LED/LCD is
is seated firmly with the accessory cover's
extinguished.
rubber ring between the antenna and the top
of the radio. (A)
2. To remove, unscrew the antenna

TRANSMITTING

anti-clockwise. (B)
1. Perform steps 1 through to 5 of Switching On,

Attaching / removing the battery pack

Reception and Switching Off.
2. Before transmitting, monitor the channel and
C
make sure it is clear.
3. When receiving a signal, wait until the signal
stops before transmitting. The radio cannot
transmit and receive simultaneously.
4. Press the PTT (Push To Talk) button (4) to begin
your transmission. To confirm transmission the
LED illuminates red.
D
5. For best transmitted speech quality you must
talk directly into the radio's microphone (10) at
around 4cm between your mouth and the radio.
1. To attach, locate the pegs on the bottom of the
6. Please note: if you talk into the top of the
battery into the slots on the radio and press
radio or with your mouth further away, you will
the top of the battery against the radio. Secure
transmit poor quality speech
battery by tightening the screw clockwise
7. When the transmission is finished release the
by hand. (Do not use any implement or
PTT button.
overtighten). (C)
2. To remove, unscrew the locking screw anti-
clockwise and pull the battery away from the
top of the radio. (D)
www.entel.co.uk

EU DECLARATION OF CONFORMITY

We Entel UK Limited of:
320 Centennial Ave, Centennial Park,
Elstree. WD6 3TJ United Kingdom
Tel +44 208 236 0032
info@entel.co.uk
Declare under our sole responsibility that the
product ranges specified below conform to
the following standards or other nominative
documents.
HT649
EN 300 225: December, 2015 v1.5.1
EN 301 843-2: June, 2004 v1.2.1
EN 60945: October, 2002, Edition 4
IEC 60945/Corrigendum 1: April, 2008, Edition 4
IMO Resolution A.694 (17): 1991
IMO Resolution A.809 (19): 1995
ITU-R M.489-2: October, 1995
MSC Resolution 147 (77): June, 2003
For Assessment see:
EC Type-examination (Module B) certification
No. 13212002/AA/06 of 21 March 2017
Product quality assessment system (Module D)
Certificate No. P133(issue 7) of 06 June 2017
Product Category: A.1/5.17
Issued by Telefications B.V
Edisonstraat 12A, 6902 PK Zevenaar, The
Netherlands.
This declaration is issued according to the
provisions of European Council Directive 96/98/
EC on marine equipment amended by the
Commission Directive 2010/68/EU
Name: Mike Jamieson
Position: Quality Manager
Date: 8th June 2017
Signed:
HT649
Quick Start User Guide
Designed in the United Kingdom
