Samsung AR-CH01U Manual

Air conditioner
Wireless Remote Control
• Thank you for purchasing this Samsung Product.
• Before operating this unit, please read this manual
carefully and retain it for future reference.
DB68-13019A-00
EN
Detailed User Manual
STEP 1 Check the model name.
STEP 2 Go to the Samsung website
(https://www.samsunghvac.com/Downloads/
Control) or scan the QR code on the previous page.
STEP 3 Search and check User manual.
Safety Information
This content is intended to protect the user's safety and prevent
property damage. Please read it carefully for correct use of the
product.
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
Failure to follow the instructions may result in electric shock,
injury, fire, breakdown or explosion.
Model:
AR-CH01U
Website for manual :
https://www.samsunghvac.com/Downloads/Control or
FOR INSTALLATION
WARNING
The installation of this product must be performed by a qualified
technician.
Do not install this product near a heater, or inflammable material.
Do not install this product in a humid, oily or dusty location, in a
location exposed to direct sunlight and water (rain drops).
Do not install this product in a location where gas may leak.
CAUTION
Install the product on a hard and level place that can support
its weight.
• If the place cannot support its weight, the product may fall
down and it may cause product damage.
FOR OPERATION
WARNING
If the product generates a strange noise, a burning smell or smoke,
unplug the product immediately and contact your nearest service centre.
Do not attempt to repair, disassemble, or modify the product
yourself.
CAUTION
Do not allow water to enter the product.
Do not operate the product with wet hands.
Do not spray volatile material such as insecticide onto the
surface of the product.
Do not give a strong impact to the product and do not
disassemble the product.
Do not use this product for other purposes.
• This product is designed to be used only for a system air
conditioner.
Do not press the buttons with any sharp objects.
Do not clean the product by spraying water directly onto it. Do not
use benzene, thinner, alcohol or acetone to clean the product.
EN
California Proposition 65 Warning (US)
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
ES
Advertencia de la propuesta 65 del Estado de California (EE. UU.)
ADVERTENCIA:
Cáncer y Daño Reproductivo - www.P65Warnings.ca.gov.
FR
Avertissement Proposition 65 de Californie (É.-U.)
AVERTISSEMENT:
Cancer et Troubles de l'appareil reproducteur - www.P65Warnings.ca.gov.
Using the remote control
Initial Settings
Before using the product, make sure to specify the air conditioner model
(using the Selecting Model menu) and the temperature unit (using the
Temp Unit menu).
Select
▶ ▶
Initial Settings.
Select
▶ ▶
Model Selection.
▶ ▶
▶ ▶
▶ ▶
Select
▶ ▶
℃ / ℉.
• Model Selection
– If the indoor unit is a 1-Way, 2-Way, 4-Way cassette type,
Duct type, Ceiling type or a Floor Standing type, select
Standard.
– If it is a round 360 cassette type indoor unit, select 360.
• Temp. Unit
– To use Celsius as the temperature unit, select '℃' . To use
Fahrenheit, select '℉' .
NOTE
• If the remote control battery discharges, this function is
canceled. in this case, run this function again.
Select
Standard / 360.
Select
Temp. Unit.
