- Page 1 Air conditioner User manual Wireless Remote Control • Thank you for purchasing this Samsung Product. • Before operating this unit, please read this manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Variety Smart Features Purify function • Turbo function Safety Information Auto Clean function Motion Detection feature Preparation Quiet function • Long Wind function Read before use Controlling the air flow direction individually Controlling the indoor units individually Remote Control Overview Freeze Wash Function Beep sound function •... -
Page 3: Safety Information
Safety Information California Proposition 65 Warning (US) WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. This content is intended to protect the user’s safety and prevent property damage. Please read it carefully for correct use of the product. WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage. -
Page 4: Preparation
Preparation Preparation Read before use Checking the package contents Wireless remote control M4 x L16 mm screw Remote control holder Wall-mount pad for remote User manual control holder Charging the remote control • Fully charge the remote control before use. •... -
Page 5: Installing The Remote Control Holder
Installing the remote control holder 1 Choose a location on the wall where to install the remote control holder. 2 Mark the two spots for fastening the two M4 x 16 mm screws. Then drill the two holes. 3 Attach the remote control holder to the wall-mount pad by sliding it down from the top of the pad until a ‘click’... -
Page 6: Remote Control Overview
Preparation Remote Control Overview Some features may not work, depending on the indoor unit specifications. • Common features: Set temperature, fan speed, airflow direction, Auto/Cool/Dry/Fan, on/off timer • Features that differ by model: Heat, AI Comfort, WindFree, Purify, Turbo, Auto Clean, Motion Detection, Quiet, Long Wind, Blades selection, Zones selection, Freeze Wash, Beep, Lighting, Filter Reset, AI Diagnostics, Model Selection, Good Sleep, Temp. - Page 7 NOTE • For a model that does not support heating, Heat is displayed on the remote control and a beep sounds when the corresponding button is pressed, but heating does not work on the air conditioner. • If you turn off the remote control and then turn it on, the settings of Timed on/off and other options that you set previously are cancelled.
- Page 8 Preparation Optional features on the remote control • To use appropriate features available on the installed air conditioner, from the remote control, navigate to ‘Settings’ > 'Model Selection’ , and select either 'Standard’ or ‘360’ , depending on the air conditioner model.
- Page 9 • When ‘360’ is selected Functions available using the Options button Functions available using the Options button when the remote control is on when the remote control is off Step 1 Step 2 Step 1 Step 2 Back Back Auto Clean Auto Clean Timer/Good Sleep Timer/Good Sleep...
-
Page 10: Remote Control Operation
Remote Control Operation Remote Control Operation Air conditioner operation Initial Settings - Model Selection / Temp. Unit Before using the product, make sure to specify the air conditioner model (using the Model Selection menu) and the temperature unit (using the Temp. Unit menu). Select ▶... -
Page 11: Setting Heating Range
NOTE • Set Model Selection and Temp. Unit, using the provided instructions. • The remote control works properly when Model Selection and Temp. Unit are set correctly. • If the remote control battery discharges, this function is canceled. in this case, run this function again. •... -
Page 12: Operation Modes • Controlling Temperature
Remote Control Operation Operation modes You can change the current mode between Auto, Cool, Dry, Fan, and Heat by pressing the button. Controlling temperature To control the temperature in each mode, push the [Temp] button up or down: Mode Temperature control Auto/Cool/Dry Adjust by 0.5℃... -
Page 13: Controlling Air Flow Direction
Controlling air flow direction You can change the air flow direction by pressing the Temp and Fan buttons. Vertical • 'Standard’ was selected from Model Selection during initial settings ▶ Press button ▶ Select Vertical or Fix. operation Select Horizontal ▶... -
Page 14: Windfree Cooling Function
Remote Control Operation WindFree Cooling function Use the WindFree Cooling function to enjoy a mild breeze coming through fine holes in the WindFree panel instead of air coming directly through the airflow blades. Cool In Cool, Dry, or Fan mode ▶... - Page 15 Change of the air flow blade by temperature and humidity High Breeze is Breeze is Breeze comes Indoor blown via the blown via the from the air temperature micro holes micro holes flow blade and humidity on the air flow on the air flow depending on blades...
-
Page 16: Power Smart Features
Remote Control Operation Power smart features AI Comfort mode Use the AI Comfort mode to learn users’ air-conditioner use patterns, and automatically adjusts the temperature level and Comfort switches between Cool, Dry, Purify or WindFree modes. ▶ NOTE • AI Comfort mode is available only on indoor units that support this mode. -
Page 17: Auto Mode • Auto Mode Function
Auto mode Use the Auto mode when you want the air conditioner to automatically control the mode (Heat or Cool). The air conditioner will Auto provide the most comfortable atmosphere that it can. Select ▶ ▶ Auto. NOTE • You can not change the fan speed. •... -
Page 18: Cool Mode • Dry Mode
Remote Control Operation Cool mode Use the Cool mode to stay cool in hot weather. Select Cool ▶ ▶ Cool. NOTE • The proper set temperature range for the Cool mode is 24 to 26 ℃ (75 ℉ to 79 ℉). •... -
Page 19: Fan Mode • Heat Mode
Fan mode Use Fan mode to run the air conditioner like a floor fan, providing a breeze without heating or cooling. Select ▶ ▶ Fan. NOTE • If the air conditioner will not be used for an extended period of time, run it in Fan mode for 3 to 4 hours to dry the internal components. -
Page 20: Variety Smart Features
Remote Control Operation Variety Smart Features Purify function Use the Purify function to create a clean room climate by removing Cool harmful substances from the air. This function can be used together when the air conditioner is operating. Purify In operation ▶ NOTE •... -
Page 21: Auto Clean Function
Auto Clean function Use the Auto Clean function to remove moisture from the inside of the air conditioner for preventing propagation of fungi, bacteria, etc. Press and hold for 3 or more seconds. Select ▶ ▶ ▶ Auto Clean. NOTE •... -
Page 22: Motion Detection Feature
Remote Control Operation Motion Detection feature Use the Motion Detection feature to sense the presence of people using the Motion Detection sensor, and adjusts the airflow direction Motion depending on whether direct wind or indirect wind is selected. Energy Detection saving mode can be used if the room is unoccupied. -
Page 23: Quiet Function • Long Wind Function
Quiet function Use the Quiet function to reduce operating noise. You can select this function both in the Cool and Heat modes. In Cool or Select ▶ ▶ ▶ Heat mode Quiet. ▶ NOTE • This function can be turned on when 'Standard’ was selected from Model Selection during Initial Settings. -
Page 24: Controlling The Air Flow Direction Individually
Remote Control Operation Controlling the air flow direction individually Use the individual air flow direction control function to individually control the air flow directions of the air outlets. Blades For 4-Way cassette air conditioners, set the positions for individual blades to Vertical or All mode. For 360 cassette air conditioners, set the positions for individual blades to Spot, Mid, Wide or Swing. -
Page 25: Controlling The Indoor Units Individually
Controlling the indoor units individually Use the Zone function to assign numbers to multiple indoor units installed in the same space, and control individual indoor units. Zones ▶ ▶ Select Zones. ▶ Select the desired ▶ ▶ ▶ indoor unit. NOTE •... -
Page 26: Freeze Wash Function
Remote Control Operation Freeze Wash Function Use the Freeze Wash function to wash away microorganisms or dust on the surface of the indoor heat exchanger by freezing and thawing operation. In operation stop condition, ▶ ▶ Select Freeze Wash. ▶ English 26... - Page 27 NOTE • This function is available only on indoor units that support this mode. • This function does not work when multiple indoor units are operating simultaneously. – If an indoor unit is operating (in Cool, Dry, AI Comfort or Purify mode), performing Freeze Wash function on a different indoor unit does not work.
-
Page 28: Beep Sound Function
Remote Control Operation Beep sound function Use the Beep sound function to turn on or off the beep sound that plays when you press a button on the remote control. Select ▶ ▶ ▶ Settings. Select ▶ ▶ ▶ Beep. Display lighting function Use the Display lighting function to turn on or off the air purity lighting of the indoor unit display. -
Page 29: Ai Diagnostics Function
AI Diagnostics function Use the AI Diagnostics function to determine the state of the air conditioner. Diagnostics Select ▶ ▶ ▶ Settings. Select ▶ ▶ ▶ AI Diagnostics. NOTE • This function can be turned on when ‘Standard’ was selected from Model Selection during Initial Settings. -
Page 30: Timed On/Timed Off Function
Remote Control Operation Timed on/Timed off function Use the Timed on/off function to turn the air conditioner on or off after a duration. Scheduling durations before the air conditioner turns on or off helps use the air conditioner economically. Select To set a ▶... - Page 31 NOTE • You can set the duration to from 30 minutes to 24 hours. • After starting the Timed on function, you can change the mode and the set temperature. When you apply the Timed on/off function to the Fan mode, you cannot change the set temperature. •...
- Page 32 Remote Control Operation Timed on/ Timed off function If you set the Timed on function, you can change the mode or temperature while the remote control is off. Basic selection Turn On Cool 01:00 Additional selection Turn On 01:00 English 32...
-
Page 33: Good Sleep Function
Good Sleep function Use the Good Sleep function to save energy while you are sleeping. You can select this function in Cool mode. To set a In Cool mode ▶ ▶ ▶ timer Select Timer/Good ▶ ▶ ▶ Sleep. Select ▶... - Page 34 Remote Control Operation NOTE • Fan speed and air flow directions are automatically adjusted. • You can adjust the set temperature by 0.5 °C (1 ℉) between 18 °C (65 ℉) and 30 °C (86 ℉). • The recommended set temperature in Good Sleep function is 25 ℃ to 27 ℃...
- Page 35 Memo English 35...
