Chamberlain 850CBMK Owner's Manual

NOTICE: To comply with FCC and or Industry Canada rules, adjustment or modifications of this
receiver and/or transmitter are prohibited, except for changing the code setting or replacing the
battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
The 80 Series remote control works only with door
openers and light controls having a green "SMART"
button and a green indicator light.
"SMART" GARAGE DOOR OPENERS
(With Green "SMART" Button
and Green Indicator Light)
PROGRAM THE OPENER TO ACCEPT THE REMOTE
CONTROL CODE
1. Press and hold the remote push button.
2. Then press and release the green "Smart" button on the
back panel of the opener in Figure 2. The opener light
will flash once.
Now the opener will operate when the remote control push
button is pressed.
If you release the remote control push button before
the opener light(s) flash(es), the opener has not
accepted the code.
To Erase All Remote Control Codes
• Press and hold the green "Smart" button on the opener
panel until the indicator light turns off (about 6 seconds).
All the codes the opener has learned will be erased.
• To reprogram, repeat Steps 1 and 2 for each remote
control in use.
FOR SERVICE DIAL OUR NUMBER:
OUTSIDE OF MEXICO CITY 01-800-500-9300
MEXICO CITY 5333-9900
U.S. 520-792-0511
Model 850CBMK remote case (circuit board not included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3V2032 Lithium battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10A20
114A2507
The Remote Control Battery
The lithium battery should produce
power for up to 5 years. To replace
battery, pry open case with visor
clip or screwdriver, as shown.
Insert battery positive side up.
Dispose of old battery properly.
Replacement Parts
© 2001, The Chamberlain Group, Inc.
All Rights Reserved
Single Function Remote Control
WARNING
Children operating or playing with a garage door opener
can injure themselves or others. The garage door could
CAUTION
close and cause serious injury or death. Do not allow
children to operate the wall push buttons or remote
controls.
A moving garage door could injure or kill someone under
it. Activate the opener only when you can see the door
clearly, it is free of obstructions, and is properly adjusted.
AVERTISSEMENT
Model 850CBMK
Remote Control
ATTENTION
Push button
Figure 1
WARNING
To prevent possible SERIOUS INJURY or DEATH:
• NEVER allow small children near batteries.
CAUTION
• If battery swallowed, immediately notify doctor.
AVERTISSEMENT
ATTENTION
Model 850CBMK
OWNER'S MANUAL
Garage Door Opener
(With Green "Smart" Button)
1 2 3
9 9
1 1
7 7
3 3
5 5
KG KG
Indicator
Green
Light
"Smart"
Button
Figure 2
.41A3984-14
Printed in Mexico
