Yealink T46 User Manual

SequreVOICE UC Yealink T46 User Guide
PHONE INTERFACE
Number Item
1 LCD Screen
2 Power Indicator LED
3 Line keys
4 HEADSET key
MUTE key
5 MESSAGE key
HOLD key
REDIAL key
TRANSFER Key
6 Speakerphone key
VOLUME key
7
Keypad
8
9. Navigation keys
OK
X key
10 Soft keys
11 Speaker
12 Hookswitch Tab
13 Hookswitch
Shows information about calls, messages, soft keys, time date, and other relevant data.
Indicates call, message, and phone system statuses.
Use these keys to activate up accounts and assign various features.
Toggles and indicates the headset mode.
Toggles and indicates the mute feature.
Accesses voice messages
Places a call on hold or resumes a held call.
Redials a previously dialed number.
Transfer a call.
Toggles and indicates the hands-free speakerphone mode. The key LED illuminates solid
green when hands-free speakerphone mode is activated.
Adjusts the volume of the handset, headset, speaker, ringer or media.
Provides the digits, letters and special characters in context-sensitive applications.
Scroll through the displayed information.
Confirms actions or answers incoming calls.
Cancels actions or rejects incoming calls.
Label automatically to identify their context-sensitive features.
Provides hands-free speakerphone audio output.
Secures the handset in the handset cradle when the IP phone is mounted vertically.
Picking up the handset from the handset cradle, the phone connects to the line. Laying the
handset down on the handset cradle, the phone disconnects from the line.
Action
