- Page 1 Models: AWI-21HW1B AWI-25HW1D AWI-27HW1B AWI-36HW1B AWI-42HW1B AWI-42HW1D (Refrigerant R410A)
- Page 2 1 INSTALLATION OF THE UNIT 1�1 Important Notices (1) The unit installation work must be done by qualified personnel according to the local rules and this manual. (2) Before installing, please contact with local authorized maintenance center, if unit is not installed by the authorized maintenance center, the malfunction may not be solved, due to discommodious contacts.
- Page 3 2 INSTALLATION DIMENSION DIAGRAM Space to the ceiling 15cm Above Space to the wall 15cm Above Above 15cm Space to the wall 300cm Above Above Air outlet side Space to the floor The dimensions of the space necessary for correct installation of the appliance including the minimum permissible distances to adjacent structures.
- Page 4 3 INSTALL THE UNIT 3�1 Install the rear panel Wall (1) Always mount the rear panel horizontally. Wall Mark on the middle of it Gradienter Due to the water tray of indoor unit has been Space Space to the to the adopted the both-way drainage design, the outlet wall wall...
- Page 5 3�5 Install the connection pipe (1) Align the center of the piping flare with the relevant valve. Spring washer (2) Screw in the flare nut by hand and then tighten the nut Washer with spanner and torque wrench refer to the following: O-ring Hex nut diameter Tightening torque (N•m)
- Page 6 3.7.2 Test Operation (1) Before test operation 1) Do not switch on power before installation is finished completely. 2) Electric wiring must be connected correctly and securely. 3) All the impurities such as scraps and thrums must be cleared from the unit. (2) Test operation method 1) Switch on power, press "ON/OFF"...
