SEGUE VK-1861 Setup Instructions

© 2024
Order #XXXXX
SEG Graphic Installation
Insert narrow side of
STEP 1: Attach Corners
silicone welt into the
1 3 channel at corner 1, with
fabric to the outside.
Repeat for opposite
corner 2, then corner 3,
Always insert graphic
then corner 4.
into each alternate corner,
then into the sides of
the frame. Otherwise
the graphic will not fit
into the frame correctly.
4 2
STEP 2: Attach Middle
1
Once corners are
attached, press the
middle of edge 1 into
the channel. Then press
middle of edge 2 into
4
3
the channel on opposite
side.
Repeat with edge 3 & 4.
2
Once the middle of sides
are attached, fully press
STEP 3: Attach Sides
the silicone welt into the
1 2
channel, between center
and corner at location 1.
5 7
Repeat the process
between center and
corner at location 2.
6 8
3 4
PRESS
in.
DON'T slide or push
along edge
Do the same for welt
To remove the graphic
from the frame, locate on opposite side, at
the fabric pull tab.
locations 3 & 4. Then
Gently pull on the tab
repeat for locations 5 & 6
to remove the graphic.
and 7 & 8.
VK-1861 Sunrise Banner Stand
Item Qty. Description
1 1 48"h TSP46 Vertical Extrusion
2 1 48"h TSP46 Vertical Extrusion
3 1 48"h TSP46 Vertical Extrusion
4 1 48"h TSP46 Vertical Extrusion
5 1 36"w TSP46 Horizontal Extrusion
6 1 36"w TSP46 Horizontal Extrusion
-- 2 SF-14 Boomerang Leg
*
Boomerang Foot Attachment
Hook keyhole to bolt
Tighten knob
to secure
*
Tool-less Straight Connector
1. Place extrusions end-to-end.
2. Slide tool-less connectors
across seam of extrusions.
3. Tighten all knobs to secure connection.
*
Tool-less Corner Connector
2. Tighten all knobs to
1. Slide extrusion onto
secure connection.
Corner Connector.
Keep corner connectors attached to horizontal extrusions.
Steps:
1) Assemble verticals [1-2], [3-4] together using
2) Connect vertical assemblies [1/2], [3/4] between horizontals [5,6]
using corner connectors.
3) Attach Boomerang feet to sides of frame assembly.
4) Apply SEG graphic to front of assembles frame.
6
*
2
*
1
*
boomerang
*
foot
5
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com
straight connectors.
*
4
When assembled
*
Assemble frame flat on ground.
3
*
boomerang
*
foot
