SEGUE VK-2319 Setup Instructions

10' x 20' sunrise inline

Advertisement

Quick Links

© 2024
VK-2319 - 10' x 20' Sunrise Inline
10'
Plan View
20'
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the VK-2319 and is the answer not in the manual?

Questions and answers

Summary of Contents for SEGUE VK-2319

  • Page 1 © 2024 VK-2319 - 10’ x 20’ Sunrise Inline 10’ Plan View 20’ SETUP INSTRUCTIONS If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com...
  • Page 2: Plan View

    © 2024 Plan View = 1 sq foot...
  • Page 3: General Setup Instructions

    © 2024 General Information General Setup Instructions WARNING - Read entire setup instruction manual prior to unpacking parts and pieces. - The setup instructions are created specifically for this configuration. - Setup instructions are laid out sequentially in steps, including exploded views with detailed explanation for assembly.
  • Page 4 © 2024 Tool-less Frame Assembly Slide connector across seam of extrusions. Disassembly Tighten all knobs. Straight Connection 1) Loosen all knobs. When assembling frame, first attach all straight Straight Connector 2) Slide connectors off of one extrusion. connectors, then attach corner connectors.
  • Page 5 © 2024 SEG Installation Graphic Removal Corner A Corner B Corner D Corner C Step 1 Step 2 Step 3 It is important to first insert To remove the graphic from Insert corner A. Turn edge of Repeat Step 1 for opposite Once all corners are inserted, graphic into each alternate the frame, locate the fabric...
  • Page 6 © 2024 Case Packing VK-2319 Backwall Top View of Each Level 3 3A 4 4A 2 2A 5 5A Lights Graphics Wings Setup Hardware Monitor Mount Level 1 Level 2 Level 3 Level 4 (Bottom level) Case 1 of 4...
  • Page 7 © 2024 Case Packing VK-2319 Backwall Top View of Each Level 3 3A 4 4A 2 2A 5 5A Lights Graphics Wings Setup Hardware Monitor Mount Level 1 Level 2 Level 3 Level 4 (Bottom level) Case 2 of 4...
  • Page 8 © 2024 Case Packing LTK-1001 Counter Top View of Each Level Counter Top Front Panel Back Panel w/ Door (2) Side Panels Shelf Shelf Supports Standoffs Keys Hardware Floor Level 1 (Bottom Level) Level 2 Level 3 Level 4 Level 5 Case 3 of 4...
  • Page 9 © 2024 Case Packing LTK-1001 Counter Top View of Each Level Counter Top Front Panel Back Panel w/ Door (2) Side Panels Shelf Shelf Supports Standoffs Keys Hardware Floor Level 1 (Bottom Level) Level 2 Level 3 Level 4 Level 5 Case 4 of 4...
  • Page 10 © 2024 Backwall Assembly Item Qty. Description Steps: 1,1A 45” TSP46 Vertical Extrusion w/ Clamps Refer to the Tool-less Frame Assembly general information page. 2,2A 45” TSP46 Vertical Extrusion w/ Clamps 3,3A 45” TSP46 Horizontal Extrusion 1) Assemble vertical extrusions [1-1A], [2-2A], [5-5A] & horizontal 4,4A 45”...
  • Page 11 © 2024 Backwall Assembly (cont’d) Item Qty. Description Steps: 1,1A 45” TSP46 Vertical Extrusion w/ Clamps Refer to the Tool-less Frame Assembly general information page. 2,2A 45” TSP46 Vertical Extrusion w/ Clamps 3,3A 45” TSP46 Horizontal Extrusion 1) Assemble vertical extrusions [1-1A], [2-2A], [5-5A] & horizontal 4,4A 45”...
  • Page 12 © 2024 Backwall Attachments Steps: Refer to the SEG Installation general information page. Connect lights to horizontals [4/4A] 1) Apply SEG graphics to front of frame assemblies. where desired and 2) Attach wings to clamps, as shown. See A10 Clamp Attachment detail.
  • Page 13 © 2024 LTK-1001 Counter Assembly Setup Instructions: 1) Attach pins at bottom interior of side panels. Note: Pins are designed to be slightly angled. 2) Use screw caps to secure the side panels to front panel and back panels, making sure Velcro is facing inward. 3) Slide floor into the bottom of assembled pedestal base.
