T-SB-0112-22
2023 Prius Pre-Delivery Service (PDS)
Service
Category
General
Section
Pre-Delivery Service
Applicability
YEAR(S)
2023
Introduction
Pre-Delivery Service (PDS) is a critical step in satisfying our new car customers. Customer
feedback indicates the following areas deserve special attention when performing PDS:
Careful inspection for paint chips/scratches and body dents/dings.
Proper operation of electrical accessories (including interior light, clock, and radio reset).
Interior cleanliness.
Proper function of mechanical systems.
Customer retention and proper maintenance of vehicles are and have always been a major focus
for Toyota. To help remind customers that regular service is essential to the proper maintenance
of the vehicle, dealers are required to install a service reminder sticker before delivery. By doing
this, customers will be reminded to return to your dealership for service. Your current service
reminder sticker may be used. (See PDS Check Sheet item 8 of "Final Inspection and Cleaning.")
This bulletin contains the PDS procedures that apply specifically to 2023 model year Prius
vehicles. A universal PDS
Toyota vehicles has been developed. To properly perform a complete PDS, you must complete
all procedures contained in this TSB as well as the universal PDS
In addition, if the vehicle is stored for over 30 days, be sure to follow
Storage
December 19, 2022
MODEL(S)
Prius
Check Sheet
Guidelines.
Market
ADDITIONAL INFORMATION
that contains PDS steps that apply to all 2023 model year
© 2022 Toyota Motor Sales, USA
USA
Check
Sheet.
Long-Term Vehicle
Page 1 of 12

Advertisement

loading
Need help?

Need help?

Do you have a question about the Prius 2023 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota Prius 2023

  • Page 1 Customer retention and proper maintenance of vehicles are and have always been a major focus for Toyota. To help remind customers that regular service is essential to the proper maintenance of the vehicle, dealers are required to install a service reminder sticker before delivery. By doing this, customers will be reminded to return to your dealership for service.
  • Page 2  Only ONE of the Techstream units listed above is required.  Software version 17.20.013 or later is required.  Additional Techstream units may be ordered by calling Approved Dealer Equipment (ADE) at 1-800-368-6787. © 2022 Toyota Motor Sales, USA...
  • Page 3 Installation of Rubber Body Plugs ..................11  Tire Pressure Warning System (TPWS) Initialization ............. 12  Set Hybrid Radio Feature to OFF ..................12  Navigation — Set Date & Time by GPS ................. 12 *If applicable. © 2022 Toyota Motor Sales, USA...
  • Page 4 With the D/C cut fuse (30A) removed, if ANY DTCs are detected when the ignition is turned on during transportation, use Global Techstream Software (GTS) to clear ALL DTCs AFTER ensuring that there are no malfunctions. © 2022 Toyota Motor Sales, USA...
  • Page 5 2023 Prius Pre-Delivery Service (PDS) Head Unit System Reset Before selling a Toyota vehicle, confirm that the welcome screen with language options appears on the head unit display when the ignition is switched to the ON position. There may be instances where the welcome screen with language options may not properly appear on the head unit display.
  • Page 6 NOTE If it is difficult to loosen the emergency towing eyelets, use a steel bar. Front Emergency Towing Eyelets Rear Emergency Towing Eyelet © 2022 Toyota Motor Sales, USA...
  • Page 7 2. Place one of the removed emergency towing eyelets into the luggage tray in the luggage compartment. NOTE Dispose of the other removed emergency towing eyelets. Figure 3. Type A Type C Type B Emergency Towing Eyelet © 2022 Toyota Motor Sales, USA...
  • Page 8 Arrow-shaped Part Eyelet Hole Front Emergency Towing Eyelet Hole Cover Rear No. 1 Emergency Towing Eyelet Hole Cover Rear No. 2 Emergency Towing Eyelet Hole Cover © 2022 Toyota Motor Sales, USA...
  • Page 9  Holes “A” are used for installation of the mounting bracket to the radiator lower grille.  Holes “B” are used for the installation of the front license plate to the mounting bracket. Mounting Bracket Dimples © 2022 Toyota Motor Sales, USA...
  • Page 10 Figure 7. 3. Install the front license plate to the mounting bracket at holes “B” using two noncorroding bolts with the following dimensions: Length: 15.0 mm (0.59 in.) Diameter: 6.0 mm (0.24 in.) Length Diameter © 2022 Toyota Motor Sales, USA...
  • Page 11  The installation of these plugs is required to prevent rust.  These plugs are stored in the glove box.  The number of plugs may vary according to production locations in the same vehicle model. © 2022 Toyota Motor Sales, USA...
  • Page 12 The Enable Hybrid Radio feature is factory preset to the ON position. Navigation — Set Date & Time by GPS Before selling a Toyota vehicle, it is necessary to turn the Set Date & Time by GPS setting to the ON position.
