Toyota PRIUS 2017 Manual

Toyota PRIUS 2017 Manual

Hide thumbs Also See for PRIUS 2017:

Quick reference manual (57 pages)

Table Of Contents

Table of Contents

Advertisement

Quick Links

Download this manual

Pictorial index

For safety

1

and security

Instrument

2

cluster

Operation of

3

each component

Driving

4

Audio system

5

Interior features

6

Maintenance

7

and care

When trouble

8

arises

Vehicle

9

specifications

For owners

10

Index

PRIUS v_OM_OM47B23U_(U)

Search by illustration

Make sure to read through them

How to read the gauges and meters, the variety of

warning lights and indicators, etc.

Opening and closing the doors and windows,

adjustment before driving, etc.

Operations and advice which are necessary for

driving

Operating the audio system

Usage of the interior features, etc.

Caring for your vehicle and maintenance

procedures

What to do in case of malfunction or emergency

Vehicle specifications, customizable features, etc.

Reporting safety defects for U.S. owners, and seat

belt and SRS airbag instructions for Canadian

owners

Search by symptom

Search alphabetically

Table of Contents

Advertisement

Table of Contents

Troubleshooting

Need help?

Need help?

Do you have a question about the PRIUS 2017 and is the answer not in the manual?

Questions and answers

jesse ford

March 4, 2025

Need manual for 2017 Prius Eco Two

0

1 comments:

Mr. Anderson

March 4, 2025

The Owner’s Manual for the 2017 Toyota Prius can be found in the vehicle’s glove box.

This answer is automatically generated

0

Garnet

May 29, 2025

how do I keep my trip ododer from clearing each time I turn off car? d

0

Summary of Contents for Toyota PRIUS 2017

Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Instrument cluster Reading this manual ....14 How to search......15 Pictorial index ......16 Instrument cluster Warning lights and For safety and security indicators ......86 Gauges and meters .....91 Multi-information display..100 1-1.
Page 3 3-4. Adjusting the steering 4-3. Operating the lights wheel and mirrors and wipers Steering wheel ....147 Headlight switch ....191 Inside rear view mirror..149 Automatic High Beam..196 Outside rear view Fog light switch....202 mirrors......151 Windshield wipers and washer......204 3-5.
Page 4 TABLE OF CONTENTS 5-4. Using the radio Audio system Radio operation....291 5-5. Playing an audio CD and MP3/WMA/AAC discs 5-1. Basic Operations CD player operation ..293 Audio system types ..272 5-6. Using an external device Audio system ....273 Listening to an iPod ..
Page 5 ® 5-9. Bluetooth phone Interior features ® Using a Bluetooth Phone ......323 Making a call..... 326 6-1. Using the air conditioning Receiving a call ....329 system and defogger Speaking on the phone..330 Automatic air conditioning ® system ......366 Bluetooth phone message function ...
Page 6 TABLE OF CONTENTS 6-4. Using the other interior Maintenance and care features Other interior features ..387 • Sun visors ..... 387 7-1. Maintenance and care • Vanity mirrors....387 Cleaning and protecting the vehicle exterior ..408 • Clock ......388 Cleaning and protecting •...
Page 7 When trouble arises Vehicle specifications 8-1. Essential information 9-1. Specifications Emergency flashers ..484 Maintenance data (fuel, oil level, etc.) ..554 If your vehicle has to be stopped in an Fuel information....563 emergency ...... 485 Tire information....566 8-2. Steps to take in an 9-2.
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. High voltage parts and cables on the hybrid vehicles emit approximately the...
Page 10 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 11 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 12 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 13 PRIUS v_OM_OM47B23U_(U)
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. 1 2 3 Indicates operating or working procedures.
Page 15: How To Search
How to search Searching by name ■ • Alphabetical index ..P. 606 Searching installation ■ position • Pictorial index....P. 16 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 602 Searching by title ■ • Table of contents .....P. 2 PRIUS v_OM_OM47B23U_(U)
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior The shape of the headlights may differ depending on the grade, etc. (P. 469) Side doors ........P. 120 Locking/unlocking .
Page 17 Pictorial index Windshield wipers ....... . . P. 204 Precautions against winter season ..... P. 265 Fuel filler door .
Page 18 Pictorial index ■ Instrument panel Power switch ........P. 174 Starting the hybrid system/changing the modes .
Page 19 Pictorial index Multi-information display ......P. 100 Display ......... . . P. 100 Energy monitor .
Page 20 Pictorial index ■ Switches Outside rear view mirror switches ....P. 151 Window lock switch....... . P. 153 Door lock switch .
Page 21 Pictorial index Clock adjustment buttons......P. 388 Tire pressure warning reset switch ....P. 448 : If equipped PRIUS v_OM_OM47B23U_(U)
Page 22 Pictorial index Audio remote control switches ..... P. 276 Meter control switches ......P. 100 Climate remote control switches .
Page 23 Pictorial index Seat heater switches ......P. 374 EV drive mode switch ......P. 181 Driving mode select switches .
Page 24 Pictorial index ■ Interior SRS airbags ........P. 41 Floor mats.
Page 25 Pictorial index Inside rear view mirror ......P. 149 Sun visors ........P. 387 Vanity mirrors.
Page 26 Pictorial index PRIUS v_OM_OM47B23U_(U)
Page 27: For Safety And Security
For safety and security 1-1. For safe use Before driving...... 28 For safety drive ....30 Seat belts ......32 SRS airbags......41 Front passenger occupant classification system ..53 Safety information for children ......58 Child restraint systems..59 Installing child restraints..
Page 28: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 29 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 30: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 31 1-1. For safe use WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. ●...
Page 32: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 33 1-1. For safe use Fastening the seat belt (rear center seat) Press the plate to release, and pull out the seat belt. Connect by inserting plate B Plate B into buckle B until a click sound is heard. Buckle B Secure the belt by inserting plate A into buckle A until a Plate A...
Page 34 1-1. For safe use Releasing the seat belt (rear center seat) Press the release button on Plate A buckle A with a hand on the Release button plate A and release the belt. Buckle A Use plate A etc. to push the button on buckle B, and uncou- Plate B ple plate B.
Page 35 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder Release button anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 36 1-1. For safe use Seat belt pretensioners (front seats) The pretensioners help the seat belts to quickly restrain the occu- pants by retracting the seat belts when the vehicle is subjected to certain types of severe frontal or side collision. The pretensioners do not activate in the event of a minor frontal impact, a minor side impact, a rear...
Page 37 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 38 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 39 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there’s no obvious damage.
Page 40 1-1. For safe use WARNING ■ Using a seat belt extender ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
Page 41: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 42 1-1. For safe use ◆ SRS side and curtain shield airbags SRS side airbags Can help protect the torso of the front seat occupants SRS curtain shield airbags ● Can help protect primarily the head of occupants in the outer seats ●...
Page 43 1-1. For safe use SRS airbag system components Front impact sensors Side impact sensors (rear) Front passenger’s seat belt Side impact sensors (front door) buckle switch Front passenger airbag Driver’s seat belt buckle switch “AIR BAG ON” and “AIR BAG OFF”...
Page 44 1-1. For safe use WARNING ■ SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
Page 45 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 46 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 47 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Page 48 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 49 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases. ● A loud noise and white powder will be emitted. ●...
Page 50 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 51 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 52 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 53: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. Seat belt reminder light SRS warning light “AIR BAG OFF”...
Page 54 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Side airbag on the front passenger seat Devices...
Page 55 1-1. For safe use Unoccupied ■ “AIR BAG ON” and “AIR BAG OFF” Not illuminated indicator lights Indicator/ warning light SRS warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Devices Curtain shield airbag in the front passenger side Activated Front passenger’s seat belt pretensioner...
Page 56 1-1. For safe use : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may recognize him/her as a child depending on his/her physique and posture. : In the event the front passenger is wearing a seat belt.
Page 57 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 58: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 59: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 60 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing  Infant seat/con- Forward facing  Convertible   vertible seat seat Booster seat ...
Page 61 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 62 1-1. For safe use WARNING ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 63: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 64 1-1. For safe use Installation with LATCH system Adjusting the angle of the seat- back. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place. Raise the head restraint. If the child restraint system is installed, it may interfere with the head restraint.
Page 65 1-1. For safe use Type A  Latch the hooks of the lower straps onto LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
Page 66 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear facing Infant seat/convertible seat ■ Adjusting the angle of the seatback. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place.
Page 67 1-1. For safe use While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 68 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 69 1-1. For safe use Booster seat ■ Adjusting the angle of the seatback. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place. Place the child restraint sys- tem on the seat facing the front of the vehicle.
Page 70 1-1. For safe use Removing a child restraint installed with a seat belt Press the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Secure the child restraint sys- tem using the seat belt or the LATCH anchors, and raise the head restraint.
Page 71 1-1. For safe use ■ Laws and regulations pertaining to anchors The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to the SAE J1819. WARNING ■...
Page 72 1-1. For safe use WARNING ■ When installing a child restraint system ● When installing a child restraint system in the rear center seat, adjust both seat cushions to the same position and align both seatbacks at the same angle. The seatbacks must be adjusted to the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sudden braking, sudden swerving or an accident.
Page 73: Exhaust Gas Precautions
Keep the back door closed. ● If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 74: 1-2. Hybrid System
1-2. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and operate it with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving condi- tions, improving fuel efficiency and reducing exhaust emis- sions.
Page 75 1-2. Hybrid system ◆ When stopped/during start off The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.
Page 76 30 minutes or 10 miles (16 km). If the hybrid battery (traction battery) becomes fully discharged and you are unable to start the hybrid system, contact your Toyota dealer. ■ Charging the 12-volt battery P.
Page 77 ■ Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. PRIUS v_OM_OM47B23U_(U)
Page 78: Hybrid System Precautions
1-2. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it is a high volt- age system (about 650V at maximum) as well as contains parts that become extremely hot when the hybrid system is operating. Obey the warning labels attached to the vehicle.
Page 79 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Hybrid warning message (vehicles with multi-information dis-...
Page 80 If a warning light comes on, a warning message is displayed, or the 12- volt battery is disconnected The hybrid system may not start. In this case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ Running out of fuel...
Page 81 1-2. Hybrid system WARNING ■ Road accident cautions Observe the following precautions to reduce the risk of death or serious injury: ● Pull your vehicle off the road, apply the parking brake, shift the shift posi- tion to P, and turn the hybrid system off. ●...
Page 82 Toyota dealer or a qualified service shop. If the hybrid battery is not dis- posed of properly, it may cause electric shock that can result in death or serious injury.
Page 83: Theft Deterrent System
1-3. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 84 1-3. Theft deterrent system ■ Certification for the immobilizer system For vehicles sold in the U.S.A., Hawaii, Guam, Saipan and Puerto Rico  For vehicles sold in Canada  NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
Page 85: Instrument Cluster Warning Lights And
Instrument cluster Instrument cluster Warning lights and indicators ......86 Gauges and meters .... 91 Multi-information display ... 100 Energy monitor/ consumption screen..108 PRIUS v_OM_OM47B23U_(U)
Page 86: Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 87 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in any of the vehicle’s systems. Brake system warning ABS warning light light (P. 492) (P. 493) (U.S.A.) (U.S.A.) Brake system warning ABS warning light light (P. 492) (P.
Page 88 There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate a malfunction.
Page 89 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Cruise control indicator (P. 189) (P. 212, 216) (Green) Headlight indicator Radar cruise control (P. 191) indicator (P. 216) (U.S.A.) (If equipped) Tail light indicator...
Page 90 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 91: Gauges And Meters
2. Instrument cluster Gauges and meters Vehicles without multi-information display  Vehicles with multi-information display  The units used on the meters may differ depending on the target region. PRIUS v_OM_OM47B23U_(U)
Page 92 2. Instrument cluster Hybrid System Indicator Displays hybrid system output or regeneration level Speedometer Displays the vehicle speed Shift position indicators Displays the selected shift position. (P. 183) Fuel gauge Displays the quantity of fuel remaining in the tank Hybrid battery (traction battery) status The amount of charge remaining in the hybrid battery (traction battery) is shown by 8 bars.
Page 93 2. Instrument cluster Changing the display Switches between odometer and trip meter displays. When the trip meter is displayed, pressing and holding the TRIP button will reset the trip meter. • While the odometer is being dis- played, or when the odometer/trip meter are not being displayed, the average fuel consumption from the last reset will be dis-...
Page 94 2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted by turn- ing the dial. Brighter Darker When the headlight switch is turned to ON, the brightness will be reduced slightly unless the control dial is turned fully up.
Page 95 2. Instrument cluster Current fuel consumption ■ Displays the instant fuel consumption. Average fuel consumption ■ The average fuel consumption is displayed on both the odometer and the trip meter. The function can be reset by pressing the DISP button for longer than 1 second when the average fuel consumption is displayed on the odometer.
Page 96 2. Instrument cluster Hybrid System Indicator Hybrid System Indicator displays the hybrid system power output and regenerative charging and provides Eco-friendly driving assistance in accordance with the driving conditions and the acceleration. Names and meaning of each icons ■ Eco Driving Indicator Light (vehicles without multi-infor- mation display) Turns on when the vehicle is...
Page 97 2. Instrument cluster Changing Hybrid System Indicator settings (vehicles without multi-information display) The items displayed on Hybrid System Indicator can be changed by operating the DISP button. Fully stop the vehicle and set the parking brake, and then press the P position switch. After pressing the DISP button to display the “SET”...
Page 98 2. Instrument cluster ■ The meters and display illuminate when The power switch is in ON mode. ■ Hybrid System Indicator Charge area Shows that energy is being recovered via the regenerative brake. Eco area Shows that the vehicle is being driven in an Eco-friendly manner.
Page 99 2. Instrument cluster ■ Remaining hybrid battery (traction battery) charge display The charge amount of the hybrid battery (traction battery) is automatically controlled by the hybrid system. For this reason, even if electricity is recov- ered via the regenerative braking, or electricity is generated via the gasoline engine, the displayed hybrid battery (traction battery) charge amount may not reach the highest level (level 8).
Page 100: Multi-Information Display
2. Instrument cluster  Multi-information display Display contents The multi-information display presents the driver with a variety of vehi- cle data. Multi-information display Meter control switches Select an item/change pages Enter/Set Return to the previous screen ● Menu icons Displays the following information when an icon is selected. Some of the information may be displayed automatically depending on the situation.
Page 101 2. Instrument cluster Clock Show the current time on the display. Cruise control/Dynamic radar cruise control (if equipped) Select to display the cruise control/dynamic radar cruise control infor- mation, when the system is used. (P. 212, 216) The displayed icon changes depending on the system used. Warning message display Select to display warning messages and measures to be taken if a malfunction is detected.
Page 102 2. Instrument cluster Drive information Items displayed can be switched by pressing of the meter control switches to select and pressing Energy monitor ■ The current vehicle hybrid system condition is displayed. (P. 103) Hybrid System Indicator ■ The hybrid system power output and regenerative charging condi- tions are displayed.
Page 103 2. Instrument cluster How to read the energy monitor Energy monitor When the vehicle is powered by electric motor (traction motor) When the vehicle is powered by both the gasoline engine and electric motor (traction motor) When the vehicle is powered by the gasoline engine PRIUS v_OM_OM47B23U_(U)
Page 104 2. Instrument cluster Energy monitor When the vehicle is charging the hybrid battery (traction bat- tery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions. PRIUS v_OM_OM47B23U_(U)
Page 105 2. Instrument cluster How to read the Eco score Displays the eco-driving total count to help improve the customer’s eco-driving techniques and the vehicle’s fuel economy. Score Totals the counts of Eco-Start, Eco- Cruise and Eco-Stop and displays the result. Eco-Start Eco-Cruise Eco-Stop...
Page 106 2. Instrument cluster How to read the distance to empty/Average vehicle speed after hybrid system started/Average fuel consumption after hybrid system started Distance to empty • Since it is calculated based on the average fuel consumption in the past, it may not be the actual distance that can be driven to be displayed.
Page 107 2. Instrument cluster ■ System check display After turning the power switch to ON mode, opening image is displayed while system operation is checked. When the system check is complete, the nor- mal screen will return. ■ Pop-up display When a system that supports pop-up displays, such as the air conditioning system, is operated, a pop-up display will be temporarily displayed.
Page 108: Energy Monitor/Consumption Screen
2. Instrument cluster Energy monitor/consumption screen You can view the status of your hybrid system on the audio sys- tem screen. Audio system Energy monitor Audio system with “CAR” button  Press the “CAR”. If the “Trip Information” or “Past Record”...
Page 109 2. Instrument cluster Audio system with “APPS” button  Press the “APPS”. Select “Eco” on the “APPS” screen. If the “Trip Information” or “Past Record” screen is displayed, select “Energy”. PRIUS v_OM_OM47B23U_(U)
Page 110 2. Instrument cluster Audio system screen When the vehicle is powered by electric motor (traction motor) When the vehicle is powered by both the gasoline engine and electric motor (traction motor) When the vehicle is powered by the gasoline engine PRIUS v_OM_OM47B23U_(U)
Page 111 2. Instrument cluster Audio system screen When the vehicle is charging the hybrid battery (traction bat- tery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions.
Page 112 2. Instrument cluster Trip information Audio system with “CAR” button  Press the “CAR” button. (P. 108) Audio system with “APPS” button  Press the “APPS” button. (P. 109) Select “ECO” on the “APPS” screen If “Energy Monitor” screen is displayed, select “Trip Information”. If “Past Record”...
Page 113 2. Instrument cluster Past record Audio system with “CAR” button  Press the “CAR” button. (P. 108) Audio system with “APPS” button  Press the “APPS” button. (P. 109) Select “ECO” on the “APPS” screen. If “Energy Monitor” screen is displayed, select “Past Record”. If “Trip Information”...
Page 114 2. Instrument cluster PRIUS v_OM_OM47B23U_(U)
Page 115: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........116 3-2. Opening, closing and locking the doors Side doors......120 Back door......125 Smart key system ..... 130 3-3. Adjusting the seats Front seats ......138 Rear seats......142 Head restraints....145 3-4.
Page 116: Keys
3-1. Key information Keys The keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key system (P. 130) • Operating the wireless remote control function Mechanical keys Key number plate Wireless remote control Locks all the doors (P. 120) Unlocks all the doors (P.
Page 117 ■ If you lose your mechanical keys New genuine mechanical keys can be made by your Toyota dealer using another mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 118 P. 464 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer. ■ If a wrong key is used The key cylinder rotates freely to isolate inside mechanism.
Page 119 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle. PRIUS v_OM_OM47B23U_(U)
Page 120: Side Doors
3-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry func- tion, wireless remote control or door lock switch. Unlocking and locking the doors from the outside ◆ Smart key system Carry the electronic key to enable this function.
Page 121 3-2. Opening, closing and locking the doors ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Security feature If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.
Page 122 3-2. Opening, closing and locking the doors Locking and unlocking the doors from the inside ◆ Door lock switch Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 123 3-2. Opening, closing and locking the doors Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 124 3-2. Opening, closing and locking the doors ■ Switching the door unlock function It is possible to set which doors the entry function unlocks. Turn the power switch off. When the indicator on the key surface is turned off, push and hold for approximately 5 seconds while pushing the button on the key.
Page 125: Back Door
3-2. Opening, closing and locking the doors Back door The back door can be unlocked/locked and opened by the fol- lowing procedures. ◆ Smart key system (if equipped) Carry the electronic key to enable this function. Locks all the doors Check that the door is securely locked.
Page 126 3-2. Opening, closing and locking the doors When closing the back door Lower the back door using the back door handle, and make sure to push the back door down from the outside to close it. Be careful not to pull the back door sideways when closing the back door with the handle.
Page 127 3-2. Opening, closing and locking the doors WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Before driving ● Make sure that the back door is fully closed. If the back door is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the luggage compartment may be thrown out, causing an acci- dent.
Page 128 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut closed again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an acces- sory part to the back door, using a genuine Toyota part is recommended. PRIUS v_OM_OM47B23U_(U)
Page 129 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back Damper stays door. ● Do not place your hand on the damper stay or apply lateral forces to it.
Page 130: Smart Key System
3-2. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ● Unlocks and locks the doors (P. 120) ●...
Page 131 3-2. Opening, closing and locking the doors ■ Alarms and warning messages Vehicles without multi-information display  The warning buzzer sounds and the warning light illuminates to protect against unexpected accidents resulting from erroneous operation or theft of the vehicle. When the warning light illuminates, take appropriate measures based on the situation.
Page 132 3-2. Opening, closing and locking the doors Alarm Situation Correction procedure The power switch was turned to ACCESSORY mode while the driver’s door Turn the power switch was open (The driver’s door close was opened when the driver’s door. power switch was in Interior alarm ACCESSORY mode).
Page 133 3-2. Opening, closing and locking the doors ■ Electronic Key Battery-Saving Function When battery-saving mode is set, battery depletion is minimized by stopping the electronic key from receiving radio waves. Press twice while pressing and holding . Confirm that the electronic key indicator flashes 4 times.
Page 134 3-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 135 3-2. Opening, closing and locking the doors ● A sudden approach to the effective range or door handle may prevent the doors from being unlocked. In this case, return the door handle to the origi- nal position and check that the doors unlock before pulling the door handle again.
Page 136 3-2. Opening, closing and locking the doors ■ Certification for the smart key system For vehicles sold in the U.S.A., Hawaii, Guam, Saipan and Puerto Rico  For vehicles sold in Canada  PRIUS v_OM_OM47B23U_(U)
Page 137 (P. 130) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 138: 3-3. Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Manual seat  Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (for driver’s side) Lumbar support adjustment switch (if equipped for driver’s side) Power seat (if equipped for driver’s side) ...
Page 139 3-3. Adjusting the seats Flattening the seatbacks Before flattening the seatbacks ■ Stop the vehicle in a safe place. Apply the parking brake firmly and shift the shift position to P. (P. 184) Slide the rear seats as far back as possible. (P. 142) Flattening the seatbacks ■...
Page 140 3-3. Adjusting the seats WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
Page 141 3-3. Adjusting the seats NOTICE ■ Flattening the seats ● Manual seats: When returning the seatback, adjust the reclining setting while holding the seatback. ● Do not move around on top of the flattened seats. Also, when climbing over a seat, move carefully and step on the center of the seat. PRIUS v_OM_OM47B23U_(U)
Page 142: Rear Seats
3-3. Adjusting the seats Rear seats Adjustment procedure Seatback angle adjustment lever Seat position adjustment lever Before folding down the seatbacks Park the vehicle in a safe place. Apply the parking brake firmly and shift the shift position to P. (P. 184) Adjust the position of the front seat and the angle of the seatback.
Page 143 3-3. Adjusting the seats Folding down the seatbacks Pull the seatback angle adjust- ment lever. To return the rear seatbacks to their original positions, lift them up until they lock. ■ Adjusting the position of the driver’s side seat back and forward The driver’s side seat can be slid forward further than the front passenger’s side seat, thus easing the loading and unload-...
Page 144 3-3. Adjusting the seats WARNING ■ When folding the seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, apply the parking brake firmly and shift the shift position to P.
Page 145: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button ■ Removing the head restraints Pull the head restraint up while pressing the lock release button.
Page 146 3-3. Adjusting the seats ■ Adjusting the height of the head restraints (front seats) Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. ■ Adjusting the center rear seat head restraint Always raise the head restraint one level from the stowed position when using.
Page 147: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 148 3-4. Adjusting the steering wheel and mirrors WARNING ■ While driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ■...
Page 149: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror (vehicles with manual anti-glare inside rear view mirror) The height of the rear view mirror can be adjusted to suit your driving posture.
Page 150 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror  Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 151: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 152 3-4. Adjusting the steering wheel and mirrors ■ Mirror angle can be adjusted when The power switch is in ACCESSORY or ON mode. ■ When the mirrors are fogged up The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the rear window defogger to turn on the outside rear view mirror defog- gers.
Page 153: Opening And Closing The Windows
3-5. Opening and closing the windows Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 154 1 second or more. If you release the switch while the window is moving, start again from the beginning. If the window reverses and cannot be closed or completely open, have the vehicle inspected by your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 155 3-5. Opening and closing the windows WARNING Observe the following precautions. Failing to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers. In order to prevent accidental operation, especially by a child, do not let a child operate the power windows.
Page 156 3-5. Opening and closing the windows PRIUS v_OM_OM47B23U_(U)
Page 157: Driving
Driving 4-1. Before driving 4-3. Operating the lights and wipers Driving the vehicle..... 158 Headlight switch....191 Cargo and luggage ... 167 Automatic High Beam ..196 Vehicle load limits ..... 171 Fog light switch ....202 Trailer towing..... 172 Windshield wipers and Dinghy towing ....
Page 158: Driving The Vehicle
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the hybrid system P. 174 Driving With the brake pedal depressed, shift the shift position to D. (P. 183) Check that the shift position indicator shows D. Release the parking brake.
Page 159 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 160 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the “READY” indicator is illuminated. This prevents the vehicle from creeping. ■...
Page 161 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● During normal driving, do not turn off the hybrid system. Turning the hybrid system off while driving will not cause loss of steering or braking control, however, power assist to the steering will be lost.
Page 162 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 163 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is stopped ● Do not depress the accelerator pedal unnecessarily. If the shift position is in any position other than P or N, the vehicle may accelerate suddenly and unexpectedly, causing an accident.
Page 164 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the hybrid system off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to hybrid system overheating.
Page 165 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 166 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 167: Cargo And Luggage
Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (P. 171) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. PRIUS v_OM_OM47B23U_(U)
Page 168 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 554) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 169 4-1. Before driving WARNING ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 170 4-1. Before driving NOTICE ■ If luggage is loaded on the roof (vehicles with panoramic roof) Observe the following precautions. Failure to observe them could lead to the roof rack being damaged or deformed, or the roof rack falling off. ●...
Page 171: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 172: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 173: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground. PRIUS v_OM_OM47B23U_(U)
Page 174: 4-2. Driving Procedures
4-2. Driving procedures Power (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the hybrid system or changes power switch modes. Starting the hybrid system Check that the parking brake is set. Firmly depress the brake pedal. Vehicles without multi-information display ...
Page 175 4-2. Driving procedures Press the power switch shortly and firmly. When operating the power switch, one short, firm press is enough. It is not necessary to press and hold the switch. If the “READY” indicator turns on, the hybrid system will operate nor- mally.
Page 176 4-2. Driving procedures Stopping the hybrid system Stop the vehicle completely. Set the parking brake. (P. 190) Shift the shift position to P. (P. 184) Check that the shift position indica- tor shows P. (P. 183) Press the power switch. The hybrid system will stop, and the meter display will be extinguished.
Page 177 4-2. Driving procedures Changing power switch modes Modes can be changed by pressing the power switch with the brake pedal released. (The mode changes each time the switch is pressed.) Vehicles without multi-information display  The emergency flashers can be used.
Page 178 ■ If the “READY” indicator does not come on In the event that the “READY” indicator does not come on even after perform- ing the proper procedures for starting the vehicle, contact your Toyota dealer immediately. ■ If the hybrid system is malfunctioning P.
Page 179 When the shift control system malfunctions The power switch will not be able to be turned off. In such a case, the switch can be turned off after applying the parking brake. Have the vehicle inspected by your Toyota dealer immediately. ■ Meter display When the power switch is turned off, each display will turn off as follows.
Page 180 ■ When starting the hybrid system If the hybrid system becomes difficult to start, have your vehicle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the power switch If the power switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 181: Ev Drive Mode
4-2. Driving procedures EV drive mode In EV drive mode, electric power is supplied by the hybrid bat- tery (traction battery), and only the electric motor (traction motor) is used to drive the vehicle. This mode allows you to drive in residential areas late at night, or in indoor parking lots etc.
Page 182 4-2. Driving procedures ■ Switching to EV drive mode when the gasoline engine is cold If the hybrid system is started while the gasoline engine is cold, the gasoline engine will start automatically after a short period of time in order to warm up. In this case, you will become unable to switch to EV drive mode.
Page 183: Hybrid Transmission
4-2. Driving procedures Hybrid transmission Shifting the shift lever Shift lever Operate the shift lever gently and ensure correct shifting operation. Release the shift lever after each shifting operation to allow it to return to position. When shifting to the D or R, move the shift lever along the shift gate.
Page 184 4-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the hybrid system Reversing Neutral (Condition in which the power is not transmitted) Normal driving Applying engine braking or strong braking when the accelerator pedal has been released on steep down- ward slopes etc.
Page 185 4-2. Driving procedures ■ For the shift positions ● When the power switch is off, the shift position cannot be changed. ● When the power switch is in ON mode (the hybrid system is not operating), the shift position can only be changed to N. The shift position will be changed to N even if the shift lever is shifted to D or R and held in that posi- tion.
Page 186 4-2. Driving procedures ■ About engine braking When shift position B is selected, releasing the accelerator pedal will apply engine braking. • When the vehicle is driven at high speeds, compared to ordinary gasoline- fueled vehicles, the engine braking deceleration is felt less than that of other vehicles.
Page 187 ■ For the shift lever Do not remove the shift lever knob or use anything but a genuine Toyota shift lever knob. Also, do not hang anything on the shift lever. Doing so could prevent the shift lever from returning to position, causing unexpected accidents to occur when the vehicle is in motion.
Page 188 If any of the following situations occurs, shift control system malfunctions are possible. Immediately stop the vehicle in a safe place on level ground, apply the park- ing brake, and then contact your Toyota dealer. ● Vehicles without multi-information display: When the “P LOCK MALFUNCTION WHEN PARKING, PARK IN FLAT...
Page 189: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions Right turn Lane change to the right (move the lever partway and release The right hand signals will flash until you release the lever. Lane change to the left (move the lever partway and release The left hand signals will flash until you release the lever.
Page 190: Parking Brake
4-2. Driving procedures Parking brake Operating instructions To set the parking brake, fully depress the parking brake pedal with your left foot while depress- (U.S.A.) ing the brake pedal with your right foot. (Depressing pedal again (Canada) releases the parking brake.) ■...
Page 191: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: U.S.A. (type A)  daytime running lights turn off. daytime running lights turn on.
Page 192 4-3. Operating the lights and wipers U.S.A. (type B)  The daytime running lights turn off. The headlights, parking (if equipped) lights, daytime running lights (P. 194) and so on turn on and off auto- matically (when power switch is in ON mode).
Page 193 4-3. Operating the lights and wipers Canada  The daytime running lights turn on. (P. 194) The side marker, park- ing, tail, license plate, daytime running lights (P. 194) and instru- ment panel lights turn The headlights and all the lights listed above (except daytime run- ning lights) turn on.
Page 194 4-3. Operating the lights and wipers ■ Daytime running light system ● To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically whenever the hybrid system is started and the parking brake is released with the headlight switch or in the position (Illuminate dimmer than the headlights).
Page 195 4-3. Operating the lights and wipers ■ Customization Settings (e.g. light sensor sensitivity) can be changed. (Customizable features: P. 577) NOTICE ■ To prevent 12-volt battery discharge Do not leave the lights on longer than necessary when the hybrid system is off.
Page 196: Automatic High Beam
4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns high beam on or off as necessary. Activating the Automatic High Beam system Push the lever away from you with the headlight switch in...
Page 197 4-3. Operating the lights and wipers High beam automatic turning on or off conditions When all of the following conditions are fulfilled, high beam will be automatically turned on (after approximately 1 second): ● Vehicle speed is above approximately 21 mph (34 km/h). ●...
Page 198 4-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam ■ Pull the lever to original posi- tion. The Automatic High Beam indi- cator will turn off. Push the lever away from you to activate the Automatic High Beam system again.
Page 199 4-3. Operating the lights and wipers ■ The Automatic High Beam can be operated when The power switch is in ON mode. ■ Camera sensor detection information ● High beam may not be automatically turned off in the following situations: •...
Page 200 4-3. Operating the lights and wipers ● In the situations below, the system may not be able to correctly detect the surrounding brightness levels, and may flash or expose nearby pedestrians to the high beam. Therefore, you should consider turning the high beams on or off manually rather than relying on the Automatic High Beam system.
Page 201 ● Do not overload the vehicle. ● Do not modify the vehicle. ● Do not replace windshield with non-genuine windshield. Contact your Toyota dealer. ● Do not replace headlights with non-genuine headlights. Contact your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 202: Fog Light Switch
4-3. Operating the lights and wipers  Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Operating instructions Type A  Turns the fog lights off Turns the fog lights on ...
Page 203 4-3. Operating the lights and wipers Type B  Turns the fog lights off Turns the fog lights on ■ Fog lights can be used when The headlights are on in low beam. NOTICE ■ To prevent 12-volt battery discharge Do not leave the lights on longer than necessary when the hybrid system is off.
Page 204: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows. Type A  Intermittent operation Low speed operation High speed operation Temporary operation Wiper intervals can be adjusted when intermittent operation is selected.
Page 205 4-3. Operating the lights and wipers Washer/wiper dual operation The wipers will automatically oper- ate a couple of times after the washer squirts. Type B  Intermittent operation Low speed operation High speed operation Temporary operation Wiper intervals can be adjusted when intermittent operation is selected.
Page 206 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. ■ To prevent 12-volt battery discharge Do not leave the wipers on longer than necessary when the hybrid system is off.
Page 207: Rear Window Wiper And Washer
4-3. Operating the lights and wipers Rear window wiper and washer Operating the wiper lever Turning the end of the lever turns on the rear window wiper and washer. Type A  Intermittent operation Normal operation Washer/wiper dual opera- tion Washer/wiper dual opera- tion PRIUS v_OM_OM47B23U_(U)
Page 208 4-3. Operating the lights and wipers Type B  Intermittent operation Normal operation Washer/wiper dual opera- tion Washer/wiper dual opera- tion ■ The rear window wiper and washer can be operated when The power switch is in ON mode. ■ If no washer fluid sprays Check that the washer nozzles are not blocked if there is washer fluid in the washer fluid tank.
Page 209: Refueling
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. Before refueling the vehicle ● Close all the doors and windows, and turn the power switch off. ● Confirm the type of fuel. ■...
Page 210 4-4. Refueling WARNING ■ When refueling Observe the following precautions to prevent fuel overflowing from the fuel tank: ● Securely insert the fuel nozzle into the fuel filler neck. ● Stop filling the tank after the fuel nozzle automatically clicks off. ●...
Page 211 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 212: Using The Driving Support
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
Page 213 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 214 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. ■ If the warning message for the cruise control is shown (vehicles with multi-information display) Press the “ON-OFF”...
Page 215 4-5. Using the driving support systems WARNING ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 216: Dynamic Radar Cruise Control
4-5. Using the driving support systems  Dynamic radar cruise control Summary of functions Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-vehicle distance control. In vehicle-to-vehicle dis- tance control mode, the vehicle automatically accelerates or deceler- ates in order to maintain a set following distance from vehicles ahead. Vehicle-to-vehicle distance button Indicators...
Page 217 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on. Press the button again to deacti- vate the cruise control. Accelerate or decelerate the vehicle to the desired speed, and push the lever down to set...
Page 218 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 219 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance Pressing the button changes the vehicle-to-vehicle distance as fol- lows: Long Preceding vehicle mark Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the power switch is turned to ON mode.
Page 220 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the cruise control. The speed setting is also canceled when the brakes are applied. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 221 4-5. Using the driving support systems Example of constant speed cruising When there are no vehicles ahead The vehicle travels at the speed set by the driver. The desired vehicle-to- vehicle distance can also be set by operating the vehicle-to-vehicle dis- tance control.
Page 222 4-5. Using the driving support systems Selecting conventional constant speed control mode Constant speed control mode differs from vehicle-to-vehicle distance control mode. When constant speed control mode is selected, your vehicle will maintain a set speed regardless of whether or not there are other vehicles in the lane ahead.
Page 223 The windshield wipers are operating at high speed. (when the wiper switch is set to the high speed wiper operation position). If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. ■...
Page 224 4-5. Using the driving support systems ■ Warning lights, warning messages and buzzers for dynamic radar cruise control Warning lights, warning messages and buzzers are used to indicate a system malfunction or to inform the driver of the need for caution while driving. (P.
Page 225 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes etc.
Page 226 4-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 227 4-5. Using the driving support systems WARNING ● When your vehicle is pointing upwards (caused by a heavy load in the luggage compartment, etc.) ■ Conditions under which the vehicle-to-vehicle distance control may not function correctly Apply the brakes (or accelerator pedal) as necessary in the following condi- tions as the radar sensor may not be able to correctly detect vehicles ahead, and a fatal or serious accident may result: ●...
Page 228 Do not subject the sensor or surrounding area to a strong impact. If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by a Toyota dealer. ●...
Page 229: Lda (Lane Departure Alert)
4-5. Using the driving support systems  LDA (Lane Departure Alert) Summary of function While driving on a road that has lane markers, this system recognizes the lane markers using a camera as a sensor to alert the driver when the vehicle deviated from its lane.
Page 230 4-5. Using the driving support systems Lane departure alert function Alert buzzer When the system judges that the vehicle is deviating from the current traffic lane, an alert buzzer sounds and it prompts cautions from the display screen of the multi-information display. When the alert buzzer sounds, please check the surrounding road situa- tion and return near the center of the white (yellow) lane markers by safely operating the steering wheel.
Page 231 4-5. Using the driving support systems Operating conditions for the function When the following conditions are satisfied, the function operates. When the lane departure alert function operates, lane lines is dis- played on the multi-information display. (P. 232) ● When the LDA is on. (P. 230) ●...
Page 232 4-5. Using the driving support systems Indication on the multi-information display When the inside of both lane lines turn white: Indicates that both right and left lane markers are recognized. If the vehicle deviates from the traf- fic lane, the lane display on the side the vehicle has deviated from will flash in amber.
Page 233 4-5. Using the driving support systems ■ LDA indicator Even if the LDA switch is pressed, when the LDA indicator does not come on the system may have a malfunction. Have the vehicle inspected by your Toy- ota dealer immediately. ■...
Page 234 4-5. Using the driving support systems ● When driving on rough or unpaved roads ● When driving on a sharp curve ● When lane markers are extremely narrow or extremely wide ● When the vehicle leans to one side an unusual amount due to a heavy load or improper tire inflation pressure ●...
Page 235 4-5. Using the driving support systems WARNING ■ Before using the LDA Do not over rely on the LDA. The LDA does not drive the vehicle automati- cally, nor does it reduce the amount of care you need to take. As such, the driver must always assume full responsibility for understanding his/her sur- roundings, for operating the steering wheel to correct the driving line, and for driving safely.
Page 236 Do not install or place anything on the hood or the grille. Also, do not install a grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer. ■ Camera sensor Observe the following to ensure that the LDA system functions correctly ●...
Page 237: Rear View Monitor System
4-5. Using the driving support systems Rear view monitor system The rear view monitor system assists the driver by displaying an image of the view behind the vehicle with fixed guide lines on the screen while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 238 4-5. Using the driving support systems Using the rear view monitor system Screen description ■ The rear view monitor system screen will be displayed if the shift lever is shifted to R while the power switch is in ON mode. Vehicle width extension guide line Displays a guide path when the vehicle is being backed straight up.
Page 239 4-5. Using the driving support systems Rear view monitor system precautions Area displayed on screen ■ The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. The image adjustment proce- dure for the rear view monitor system screen is the same as the procedure for adjusting the...
Page 240 4-5. Using the driving support systems Rear view monitor system camera ■ The camera for the rear view monitor system is located as shown in the illustration. ● Using the camera If dirt or foreign matter (such as water droplets, snow, mud etc.) is adhering to the camera, it cannot transmit a clear image.
Page 241 4-5. Using the driving support systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be far- ther away than they actually are.
Page 242 4-5. Using the driving support systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the fixed guide lines on the screen and the actual dis- A margin of error...
Page 243 4-5. Using the driving support systems ● Distance guide lines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 244 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 245 4-5. Using the driving support systems WARNING ■ When using the rear view monitor system The rear view monitor system is a supplemental device intended to assist the driver when backing up. When backing up, be sure to visually check all around the vehicle both directly and using the mirrors before proceeding.
Page 246 Doing so may result in the camera malfunc- tioning. ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. PRIUS v_OM_OM47B23U_(U)
Page 247: Driving Mode Select Switch
4-5. Using the driving support systems Driving mode select switch The driving modes can be selected to suit driving conditions. Eco drive mode Suitable for improving the fuel economy, because the torque cor- responding accelerator pedal depression amount can be generated more smoothly than it is in normal conditions and the oper- ation of the air conditioning system...
Page 248: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 249 4-5. Using the driving support systems ◆ Hill-start assist control Helps to prevent the vehicle from rolling backward when starting on an incline or slippery slope ◆ PCS (Pre-Collision System) (if equipped) P. 255 When the VSC/TRAC/ABS systems are operating The slip indicator light will flash while the VSC/TRAC/ABS sys- tems are operating.
Page 250 4-5. Using the driving support systems Disabling the TRAC system If the vehicle gets stuck in mud, dirt or snow, the TRAC system may reduce power from the hybrid system to the wheels. Pressing turn the system off may make it easier for you to rock the vehicle in order to free it.
Page 251 When the “TRAC OFF” indicator comes on/message is displayed on the multi-information display showing that TRAC has been disabled even if the VSC OFF switch has not been pressed TRAC cannot be operated. Contact your Toyota dealer. ■ Sounds and vibrations caused by the ABS, brake assist, VSC, TRAC and...
Page 252 4-5. Using the driving support systems ■ Reduced effectiveness of the EPS system The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the hybrid system off.
Page 253 4-5. Using the driving support systems WARNING ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick road. ■...
Page 254 The ABS, VSC and TRAC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 255: Pcs (Pre-Collision System)
4-5. Using the driving support systems  PCS (Pre-Collision System) When the radar sensor detects possibility of a frontal collision, brakes are automatically engaged to lessen impact as well as vehicle damage. The alert timing for the pre-collision system can be changed or turned ON/OFF, as necessary, by operating the switch.
Page 256 4-5. Using the driving support systems Changing the pre-collision system Changing the alert timing of the pre-collision system ■ Each time the PCS switch is pressed, the response to the distance changes as follows. Middle Near : Default setting Turning off the pre-collision system ■...
Page 257 4-5. Using the driving support systems Radar sensor The radar sensor detects vehi- cles or other obstacles on or near the road ahead and determines whether a collision is imminent based on the position, speed, and heading of the obstacles. ■...
Page 258 4-5. Using the driving support systems ■ Conditions that may trigger the system even if there is no possibility of a collision In any of the following situations where the frontal area of the radar sensor is interrupted, the radar sensor may detect possibility of a frontal collision and the system may be activated.
Page 259 4-5. Using the driving support systems ■ Situations in which the pre-collision system does not function properly The system may not function effectively in situations such as the following: ● On roads with sharp bends or uneven surfaces ● If a vehicle suddenly moves in front of your vehicle, such as at an intersec- tion ●...
Page 260 Do not attach accessories or stickers to the sensor, grille cover or sur- rounding area. ● Do not modify or paint the sensor and grille cover. ● If the sensor needs to be replaced, contact your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 261 4-5. Using the driving support systems WARNING ■ Cautions regarding the assist contents of the system By means of alarms and brake control, the pre-collision system is intended to assist the driver in avoiding collisions through the process of LOOK- JUDGE-ACT.
Page 262: 4-6. Driving Tips
4-6. Driving tips Hybrid vehicle driving tips For economical and ecological driving, pay attention to the fol- lowing points: ◆ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accel- erator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 263 4-6. Driving tips ◆ When braking Make sure to operate the brakes gently and in a timely manner. A greater amount of electrical energy can be regenerated when slow- ing down. ◆ Delays Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel economy.
Page 264 4-6. Driving tips ◆ Luggage Carrying heavy luggage will lead to poor fuel economy. Avoid carry- ing unnecessary luggage. Installing a large roof rack will also cause poor fuel economy. ◆ Warming up before driving Since the gasoline engine starts up and cuts out automatically when cold, warming up the engine is unnecessary.
Page 265: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 266 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road con- ditions. When parking the vehicle Park the vehicle and shift the shift position to P and block the wheel under the vehicle without setting the parking brake.
Page 267 4-6. Driving tips ■ Tire chain installation Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 268 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 269 4-6. Driving tips PRIUS v_OM_OM47B23U_(U)
Page 270: Audio System
Audio system 5-1. Basic Operations Audio system types ..272 Audio system ....273 Using the steering wheel audio switches....276 AUX Port/USB Port ..277 Basic audio operations ..278 5-2. Setup Setup menu ...... 280 General settings ....281 Audio settings ....
Page 271 Audio system ® 5-5. Playing an audio CD and 5-8. Bluetooth Audio ® MP3/WMA/AAC discs Listening to Bluetooth CD player operation..293 Audio ......321 ® 5-6. Using an external device 5-9. Bluetooth phone ® Listening to an iPod ..299 Using a Bluetooth Phone ......
Page 272: 5-1. Basic Operations
5-1. Basic Operations Audio system types Entune Audio  P. 273 Entune Premium Audio with Navigation  Owners of models equipped with a navigation system should refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating.
Page 273: Audio System
5-1. Basic Operations  Audio system Operations such as listening to audio, using the hands-free phone, confirming vehicle information and changing audio sys- tem settings are started by using the following buttons. Audio system operation buttons “AUDIO” button Display the “Select Audio Source” screen or audio top screen. (P.
Page 274 5-1. Basic Operations Operating the touch screen By touching the screen with your finger, you can control the audio sys- tem, etc. ■ Touch Quickly touch and release once. ● Changing and selecting various settings Drag ■ Touch the screen with your finger, and move the screen to the desired position.
Page 275 5-1. Basic Operations ■ When using the touch screen ● If the screen is cold, the display may be dark, or the system may seem to be operating slightly slower than normal. ● The screen may seem dark and hard to see when viewed through sun- glasses.
Page 276: Using The Steering Wheel Audio Switches
5-1. Basic Operations Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
Page 277: Aux Port/Usb Port
5-1. Basic Operations AUX Port/USB Port Connect an iPod, USB memory device or portable audio player to the AUX port/USB port as indicated below. Select “iPod”, “USB” or “AUX” on the audio source selection screen and the device can be operated via audio system. Connecting the AUX port/USB port iPod ■...
Page 278: Basic Audio Operations
5-1. Basic Operations Basic audio operations Basic audio operations and functions common to each mode are explained in this section. Operating the audio system Press this knob to turn the audio system on and off, and turn it to adjust the volume. Insert a disc into the disc slot.
Page 279 5-1. Basic Operations Random playback Select to change on/off. Repeat play Select to change on/off. ■ Certification CAUTION: THIS PRODUCT IS A CLASS  LASER PRODUCT. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIA- TION EXPOSURE.
Page 280: 5-2. Setup
5-2. Setup Setup menu You can adjust the audio system to your desired settings. Display “Setup” screen Press the “SETUP” button to display the “Setup” screen. Select to adjust the settings for operation sounds, screen ani- mation, etc. (P. 281) Select to set the voice settings.
Page 281: General Settings
The animation effect for the screen can be set to on/off. Select to delete personal data. (P. 282) Select to update program versions. For details, contact your Toyota dealer. Select to display the software information. Notices related to third party software used in this product are enlisted. (This includes instructions for obtaining such software, where applicable.)
Page 282 5-2. Setup Delete personal data Select “Delete Personal Data” on the “General Settings” screen. Select “Delete”. Check carefully beforehand, as data cannot be retrieved once deleted. A confirmation screen will be displayed. Select “Yes”. The following personal data will be deleted or changed to its default settings.
Page 283: Audio Settings
5-2. Setup Audio settings Settings are available for adjusting the radio operation, cover art, etc. Screen for audio settings Press the “SETUP” button. Select “Audio” on the “Setup” screen. Number of Radio Presets Select the number of radio preset stations. Display Cover Art on/off.
Page 284: Display Settings
5-2. Setup Display settings Settings are available for adjusting the contrast and brightness of the screen. Screen for display settings Press the “SETUP” button. Select “Display” on the “Setup” screen. Adjust screen contrast/bright- ness. Adjust screen contrast/bright- ness of the rear view monitor camera.
Page 285 5-2. Setup Adjusting the screen contrast/brightness Select “General” or “Camera” on the “Display Settings” screen. Adjust the display as desired by selecting “+” or “-”. Day mode When the headlights are turned on, the screen dims. However, the screen can be switched to day mode by selecting “Day Mode”.
Page 286: Voice Settings
5-2. Setup Voice settings This screen is used for guidance for voice command systems setting. Adjust the voice guidance vol- ume setting. voice recognition prompts “High”, “Low” or “Off”. Set the train voice recognition. The user will be asked to say 10 sample phrases.
Page 287: 5-3. Using The Multimedia System
5-3. Using the Multimedia system Selecting the audio source Switching between audio sources such as radio and CD are explained in this section. Changing audio source Press the “AUDIO” button to display the audio source selection screen. If the audio source selection screen is not displayed, press the “AUDIO” button again.
Page 288: List Screen Operation
5-3. Using the Multimedia system List screen operation When a list screen is displayed, use the appropriate buttons to scroll through the list. How to scroll : Select to scroll to the next or previous page. : If appears to the right of titles, the complete titles are too long for the display.
Page 289 5-3. Using the Multimedia system Selecting, fast-forwarding and reversing tracks/files/songs Selecting a track/file/song ■ Press the “” or “” button on “SEEK/TRACK” or turn the “TUNE SCROLL” knob to select the desired track/file/song number. To fast-forward or reverse, press and hold the “” or “” button on “SEEK/TRACK”.
Page 290: Optimal Use Of The Audio System
5-3. Using the Multimedia system Optimal use of the audio system On the “Sound Settings” screen, sound quality (Treble/Mid/ Bass), volume balance can be adjusted. How to adjust the sound settings and sound quality Select “-” or “+” to adjust 1 2 3 the treble, mid or bass to a level between -5 and 5.
Page 291: Using The Radio
5-4. Using the radio Radio operation Select “AM” or “FM” on the audio source selection screen to begin listening to the radio. Audio control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source. Audio source selection screen appears Preset stations...
Page 292 5-4. Using the radio Setting station presets Search for desired stations by turning the “TUNE SCROLL” knob or pressing the “” or “” button on “SEEK/TRACK”. Select “(add new)”. To change the preset station to a different one, select and hold the preset station.
Page 293: Cd Player Operation
5-5. Playing an audio CD and MP3/WMA/AAC discs CD player operation Insert disc or select “CD” on the audio source selection screen with a disc inserted to begin listening to a CD. Audio control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source.
Page 294 ■ Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause Correction procedures • The disc is dirty or •...
Page 295 5-5. Playing an audio CD and MP3/WMA/AAC discs ■ MP3, WMA and AAC files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 for- mat.
Page 296 5-5. Playing an audio CD and MP3/WMA/AAC discs ● AAC file compatibility • Compatible standards MPEG4/AAC-LC • Compatible sampling frequencies 11.025/12/16/22.05/24/32/44.1/48 (kHz) • Compatible bit rates 16-320 (kbps) Compatible channel modes: 1ch and 2ch ● Compatible media Media that can be used for MP3, WMA and AAC playback are CD-Rs and CD-RWs.
Page 297 5-5. Playing an audio CD and MP3/WMA/AAC discs ● ID3, WMA and AAC tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
Page 298 5-5. Playing an audio CD and MP3/WMA/AAC discs NOTICE ■ Discs and adapters that cannot be used Do not use the following types of CDs. Also, do not use 3 in. (8 cm) CD adapters, DualDiscs or printable discs. Doing so may damage the CD player and/or the CD insert/eject function. ●...
Page 299: Using An External Device
5-6. Using an external device iPod player operation Connecting an iPod enables you to enjoy music from the vehicle speakers. Select “iPod” on the audio source selection screen. When the iPod connected to the system includes iPod video, the system can only output the sound by selecting the browse screen.
Page 300 5-6. Using an external device Selecting a play mode Select “Browse” on the screen. Select the desired play mode. Then select a song to begin using the selected play mode. Shuffle play Select to change on/off. Repeat play Select to change on/off. PRIUS v_OM_OM47B23U_(U)
Page 301 5-6. Using an external device ■ About iPod ● “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone, respectively, and has been certified by the developer to meet Apple performance stan- dards.
Page 302 Owner’s Manual. ■ Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures “Connection error. Please consult your Owner’s...
Page 303 5-6. Using an external device ■ Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. ● Made for • iPod touch (5th generation) •...
Page 304: Memory Device
5-6. Using an external device USB memory device player operation Connecting a USB memory device enables you to enjoy music from the vehicle speakers. Touch “USB” on the audio source selection screen. Connecting a USB memory device P. 277 Audio control screen Pressing the “AUDIO”...
Page 305 Error messages for USB memory If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures “Connection error. Please...
Page 306 5-6. Using an external device ● MP3, WMA and AAC files MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 307 5-6. Using an external device ● ID3, WMA and AAC tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3 tags.
Page 308 5-6. Using an external device NOTICE ■ To prevent damage to the USB memory device or its terminals ● Do not leave the USB memory device in the vehicle. The temperature inside the vehicle may become high. ● Do not push down on or apply unnecessary pressure to the USB memory device while it is connected.
Page 309: Using The Aux
5-6. Using an external device Using the AUX To use the AUX port, connect a portable player, press the “AUDIO” button, then select “AUX” to display the audio control screen. Connecting a portable audio player P. 277 ■ Operating portable audio players connected to the audio system The volume can be adjusted using the vehicle’s audio controls.
Page 310 ® 5-7. Connecting Bluetooth Preparations to use wireless communication ® The following can be performed using Bluetooth wireless com- munication: A portable audio player can be operated and listened to via ■ audio system Hands-free phone calls can be made via a cellular phone ■...
Page 311: Connecting Bluetooth
® 5-7. Connecting Bluetooth Device registration/connection flow ® 1. Register the Bluetooth device to be used with audio sys- tem (P. 313, 314, 315) ® 2. Connect the Bluetooth device to be used (P. 317) To be used for audio To be used for hands-free phone ®...
Page 312 ® 5-7. Connecting Bluetooth Registering and connecting from the “Bluetooth* Setup” screen To display the screen shown below, press the “SETUP” button and select “Bluetooth ” on the “Setup” screen. Select to connect the device to be used with audio system. (P.
Page 313: Registering A Bluetooth ® Audio Player For The First Time
® 5-7. Connecting Bluetooth ® Registering a Bluetooth audio player for the first time ® To use the Bluetooth Audio, it is necessary to register an audio player with the system. Once the player has been registered, it is possible to use the ®...
Page 314: Registering A Bluetooth ® Phone For The First Time
® 5-7. Connecting Bluetooth ® Registering a Bluetooth phone for the first time To use the hands-free system, it is necessary to register a ® Bluetooth phone with the system. Once the phone has been registered, it is possible to use the hands-free system.
Page 315: Registering A Bluetooth ® Device
® 5-7. Connecting Bluetooth ® Registering a Bluetooth device ® Bluetooth compatible phones (HFP) and portable audio players (AVP) can be registered simultaneously. You can register up to 5 ® Bluetooth devices. ® How to register a Bluetooth device Display the “Bluetooth Setup”...
Page 316 ® 5-7. Connecting Bluetooth Check that this screen is dis- played when registration is complete. Select “OK” when connection status changes from “Connecting...” to “Connected”. If an error message is displayed, follow the guidance on the screen to try again. Registration can be performed from screens other than the “Bluetooth* Setup”...
Page 317: Connecting A Bluetooth ® Device
® 5-7. Connecting Bluetooth ® Connecting a Bluetooth device ® Up to 5 Bluetooth devices (Phones [HFP] and audio players [AVP]) can be registered. ® If more than 1 Bluetooth device has been registered, select which device to connect to. Press the “SETUP”...
Page 318 ® 5-7. Connecting Bluetooth Manual connection When auto connection has failed or “Bluetooth Power” is turned off, ® you must connect the Bluetooth device manually. ® Follow the steps in “Connecting a Bluetooth device” from (P. 317) : Bluetooth is a registered trademark of Bluetooth SIG, Inc. ®...
Page 319: Displaying A Bluetooth ® Device Details
® 5-7. Connecting Bluetooth ® Displaying a Bluetooth device details You can confirm and change the registered device details. ® Bluetooth device registration status Display the “Bluetooth Setup” screen. (P. 312) Select the device. Select “Device Info”. Following screen is displayed: Change device Name Change connection method (P.
Page 320: Detailed Bluetooth ® System Settings
® 5-7. Connecting Bluetooth ® Detailed Bluetooth settings ® You can confirm and change the detailed Bluetooth settings. ® How to check and change detailed Bluetooth settings Display the “Bluetooth Setup” screen. (P. 312) Select “System Settings”. The following screen is displayed: ®...
Page 321: Bluetooth ® Audio
® 5-8. Bluetooth Audio ® Listening to Bluetooth Audio ® The Bluetooth audio system enables the user to enjoy music played on a portable player from the vehicle speakers via wire- less communication. ® When a Bluetooth device cannot be connected, check the connec- tion status on the “Bluetooth Audio”...
Page 322 ® 5-8. Bluetooth Audio ® Playing Bluetooth audio Select to Play/Pause. For details on “Bluetooth Audio” screen operation methods, refer to Basic Audio Operations. (P. 278) For details on how to select a track or album, refer to selecting, fast- forwarding and reversing tracks/files/songs.
Page 323: Bluetooth ® Phone
® 5-9. Bluetooth phone ® Using a Bluetooth Phone The hands-free system is a function that allows you to use your cellular phone without touching it. ® ® This system supports Bluetooth . Bluetooth is a wireless data system that allows the cellular phone to wirelessly connect to the hands-free system and make/receive calls.
Page 324 ® 5-9. Bluetooth phone Telephone switch ■ P. 337 Microphone ■ The vehicle’s built in microphone is used when talking on the phone. The person you are speaking to can be heard from the front speak- ers. ® To use the hands-free system, you must register your Bluetooth phone in the system.
Page 325 ® 5-9. Bluetooth phone Status display You can check indicators such as signal strength and battery charge on the phone screen. Connection status Signal strength “Rm” is displayed when receiving in a roaming area. While roaming, display “Rm” top-left on the icon. Battery charge Indicators Conditions...
Page 326: Making A Call
® 5-9. Bluetooth phone Making a call ® Once a Bluetooth phone is registered, you can make a call using the following procedure: Dialing Display the phone screen. (P. 323) Select the “Dial Pad” tab and enter a phone number. To delete the input phone number, select For the first digit, you can enter “+”...
Page 327 ® 5-9. Bluetooth phone ® For PBAP compatible Bluetooth phones ■ When “Automatic Transfer” is set to off  Select the desired item. Select to transfer new con- tacts from a cellular phone, select “Always” and then enable “Automatic Trans- fer”.
Page 328 ® 5-9. Bluetooth phone Calling using favorites list You can make a call using numbers registered in the contact. Display the phone screen. (P. 323) Select “Favorites” tab. Select the desired number to make a call. Dialing from call history You can make a call using the call history, which has the 3 functions below.
Page 329: Receiving A Call
® 5-9. Bluetooth phone Receiving a call When a call is received, the following screen is displayed together with a sound. To answer the phone Press the switch on the steer- ing wheel or select To refuse a call Press the switch on the steering wheel or select To adjust the incoming call volume Turn the “PWR VOL”...
Page 330: Speaking On The Phone
® 5-9. Bluetooth phone Speaking on the phone The following screen is displayed when speaking on the phone. To adjust the call volume Select “-” or “+”. You can also adjust the volume using the steering switches or the volume knob. To prevent the other party from hearing your voice Select “Mute”.
Page 331 ® 5-9. Bluetooth phone ■ Release Tones ● A continuous tone signal is a character string that consists of numbers and the characters p or w. (e.g.056133w0123p#1) ● When the “p” pause tone is used, the tone data up until the next pause tone will be automatically sent after 2 seconds have elapsed.
Page 332 ® 5-9. Bluetooth phone To transfer a call Select “Handset Mode” to on from a hands-free call to a cellular phone call. Select “Handset Mode” to off from a cellular phone call to a hands-free call. Transmit volume setting Select “Transmit Volume”. Select the desired level for the transmit volume.
Page 333: Bluetooth ® Phone Message Function
® 5-9. Bluetooth phone ® Bluetooth phone message function Received messages can be forwarded from the connected ® Bluetooth phone, enabling checking and replying using the audio system. ® Depending on the type of Bluetooth phone connected, received messages may not be transferred to the message inbox. If the phone does not support the message function, this func- tion cannot be used.
Page 334 ® 5-9. Bluetooth phone ■ Receiving a message ● Depending on the cellular phone used for receiving messages, or its regis- tration status with the audio system, some information may not be dis- played. ● The pop up screen is separately available for incoming e-mail and SMS/ MMS messages under the following conditions: E-mail: •...
Page 335 ® 5-9. Bluetooth phone Checking the messages Display the message inbox screen. (P. 333) Select the desired message from the list. Check that the message is displayed. E-mails: Select “Mark Unread” or “Mark Read” to mark mail unread or read on the message inbox screen.
Page 336 ® 5-9. Bluetooth phone Replying to a message Display the message inbox screen. (P. 333) Select the desired message from the list. Select “Quick Message”. Select the desired message. Select “Send”. If an error message is displayed, follow the guidance on the screen to try again.
Page 337: Using The Steering Wheel Switches
® 5-9. Bluetooth phone Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone. Operating a telephone using the steering wheel switches Volume switch • Increase/Decrease the vol- • Press and hold: Continuously increase/ decrease the volume...
Page 338: Bluetooth ® Phone Settings
® 5-9. Bluetooth phone ® Bluetooth phone settings You can adjust the hands-free system to your desired settings. “Phone/Message Settings” screen To display the screen shown below, press the “SETUP” button, and select “Phone” on the “Setup” screen. Set the phone connection (P.
Page 339: Contact/Call History Settings
® 5-9. Bluetooth phone Contact/Call History Settings ® The contact can be transferred from a Bluetooth phone to the system. The contact also can be added, edited and deleted. The call history can be deleted and contact and favorites can be changed.
Page 340 ® 5-9. Bluetooth phone Update contacts from phone Operation methods differ between PBAP compatible and PBAP ® incompatible but OPP compatible Bluetooth phones. If your cellular phone is neither PBAP nor OPP compatible, the con- tacts cannot be transferred. ® ■...
Page 341 ® 5-9. Bluetooth phone Updating the contacts in a different way (From the “Call ■ History” screen) ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Transfer” is set to off. (P. 339) Display the phone screen. (P. 323) Select the “Call History”...
Page 342 ® 5-9. Bluetooth phone Editing the contact data ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Transfer” is set to off. (P. 339) Select “Edit Contacts”. Select the desired contact. Select corresponding to the desired name or number. For editing the name ...
Page 343 ® 5-9. Bluetooth phone Deleting the contact data ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Transfer” is set to off. (P. 339) Select “Delete Contacts”. Select the desired contact and select “Delete”. Select “Yes” when the confirmation screen appears. Deleting the contact in a different way (From the “Contact ■...
Page 344 ® 5-9. Bluetooth phone When 15 contacts have already been registered to the favorites  list When 15 contacts have already been registered to the favorites list, a registered contact needs to be replaced. Select “Yes” when the confirmation screen appears to replace a contact.
Page 345 ® 5-9. Bluetooth phone Deleting the contacts in the favorites list ■ Select “Remove Favorite”. Select the desired contacts and select “Remove”. Select “Yes” when the confirmation screen appears. Check that a confirmation screen is displayed when the opera- tion is complete. Deleting contacts in the favorites list in a different way (from the ...
Page 346 ® 5-9. Bluetooth phone Message Settings Display the “Phone/Message Settings” screen. (P. 338) Select “Messaging Settings”. Select the desired item to be set. automatic message transfer on/off. automatic message readout on/off. Set the SMS/MMS notifica- tion popup on/off. Set the e-mail notification popup on/off.
Page 347 ® 5-9. Bluetooth phone Displaying the “Messaging Settings” screen in a different way ■ Display the phone screen. (P. 323) Select Select “Settings”. Select “Messaging Settings”. Phone Display Settings Display the “Phone/Message Settings” screen. (P. 338) Select “Phone Display Settings”. Select the desired item to be set.
Page 348: What To Do If
 For a list of specific devices which operation has been confirmed on this system, check with your Toyota dealer or the following web- site: http://www.toyota.com/entune/ The Bluetooth version of the connected cellular phone may be older than the specified version.
Page 349 ® 5-9. Bluetooth phone When registering/connecting a cellular phone  A cellular phone cannot be registered. An incorrect passcode was entered on the cellular phone.  Enter the correct passcode on the cellular phone. The registration operation has not been completed on the cellular phone side.
Page 350  For a list of specific devices which operation has been confirmed on this system, check with your Toyota dealer or the following web- site: http://www.toyota.com/entune/ Automatic phonebook transfer function on this system is set to off.
Page 351 ® 5-9. Bluetooth phone In other situations  ® The Bluetooth connection status is displayed at the top of the screen each time the power switch is turned to the ACCESSORY or ON mode. Connection confirmation display on this system is set to on. ...
Page 352: Bluetooth
® 5-10. Bluetooth ® Bluetooth ® ■ When using the Bluetooth audio system ● In the following conditions, the system may not function. • If the portable audio player is turned off • If the portable audio player is not connected •...
Page 353 ® 5-10. Bluetooth ® ■ Bluetooth antenna The antenna is built into the display. ® If the Bluetooth device is behind the seat or in the glove box or console box, or is touching or covered by metal objects, the connection status may deterio- rate.
Page 354 ® 5-10. Bluetooth ■ Compatible models ® The Bluetooth audio system supports portable audio players with the follow- ing specifications. ® ● Bluetooth specifications: Ver. 2.0, or higher (Recommended: Ver. 3.0+EDR or higher) ● Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (Recommended: Ver.
Page 355 ® 5-10. Bluetooth  ■ Certifications for the Bluetooth For vehicles sold in the U.S.A.  PRIUS v_OM_OM47B23U_(U)
Page 356 ® 5-10. Bluetooth For vehicles sold in Canada  PRIUS v_OM_OM47B23U_(U)
Page 357 ® 5-10. Bluetooth ■ Reconnecting the portable audio player If the portable audio player is disconnected due to poor reception, the system automatically reconnects the portable audio player. If you have switched off the portable audio player yourself, follow the instruc- tions below to reconnect: ●...
Page 358: Using The Voice Command System Voice Command System
5-11. Using the voice command system Voice command system The voice command system enables the hands-free system to be operated using voice commands. Using the voice command system Press the talk switch. To cancel the voice command sys- tem, press and hold the talk switch. Select to train voice recogni- tion.
Page 359 5-11. Using the voice command system ■ Microphone P. 324 ■ When using the microphone ● It is unnecessary to speak directly into the microphone when giving a com- mand. ● When “Voice Prompt Interrupt” set to on, it is not necessary to wait for the confirmation beep before speaking a command.
Page 360 5-11. Using the voice command system Casual speech recognization Due to natural language speech recognition technology, this system enables recognition of a command when spoken naturally. However, the system cannot recognize every variation of each command. In some situations, it is possible to omit the command for the proce- dure and directly state the desired operation.
Page 361 5-11. Using the voice command system Command list Some recognizable voice commands and their actions are shown below as examples. Basic  Command Action Prompts voice guidance to offer examples of com- “Help” mands or operation methods “Go Back” Returns to the previous screen Phone ...
Page 362 5-11. Using the voice command system Mobile Assistant ® The Mobile Assistant feature will activate Apple’s Siri Eyes Free mode via the steering wheel switches. To operate the Mobile Assis- tant, a compatible cellular phone must be registered and connected to ®...
Page 363 5-11. Using the voice command system ■ Notes about Mobile Assistant ● The available features and functions may vary based on the iOS version installed on the connected device. ® ● Some Siri features are limited in Eyes Free mode. If you attempt to use an ®...
Page 364 5-11. Using the voice command system PRIUS v_OM_OM47B23U_(U)
Page 365: Interior Features
Interior features 6-1. Using the air conditioning 6-4. Using the other interior system and defogger features Automatic air conditioning Other interior features ..387 system......366 • Sun visors ..... 387 Using the steering wheel • Vanity mirrors....387 climate remote control •...
Page 366: Automatic Air Conditioning
6-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Control panel Switching functions and changing settings ■ Move left and right to select the function. The function currently being set up will be surrounded by a frame.
Page 367 6-1. Using the air conditioning system and defogger Changing the airflow mode ■ Air flows to the upper body. Air flows to the upper body and feet. Air flows to the feet. Air flows to the feet and the windshield defogger oper- ates.
Page 368 6-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■ Press The mode switches between recirculated air mode and outside air mode each time the button is pressed. The indicator on turns on when the recirculated air mode is selected.
Page 369 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected air flow mode. Adjusting the position of and opening and closing the air out- ■ lets Center Side ...
Page 370 6-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 371 6-1. Using the air conditioning system and defogger ■ Outside temperature display In the following situations, the correct out- side temperature may not be displayed, or the display may take longer than normal to change. ● When stopped, or driving at low speeds (less than 16 mph [25 km/h]) ●...
Page 372 6-1. Using the air conditioning system and defogger WARNING ■ To prevent the windshield from fogging up ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, block- ing your vision.
Page 373: Using The Steering Wheel Climate Remote Control Switches
6-1. Using the air conditioning system and defogger Using the steering wheel climate remote  control switches Some air conditioning features can be controlled using the switches on the steering wheel. Temperature control Outside air or recirculated air mode Adjusting the temperature setting Press “”...
Page 374: Seat Heaters
6-1. Using the air conditioning system and defogger  Seat heaters Heats the left front seat Heats the right front seat The indicator light comes on when the seat heater is operating. ● The seat heaters can be used when the power switch is in ON mode. ●...
Page 375: Using The Interior Lights
6-2. Using the interior lights Interior lights list Rear interior light (P. 377) Front personal/interior lights (P. 376) Shift lever lighting Footwell lights (if equipped) Front door courtesy lights PRIUS v_OM_OM47B23U_(U)
Page 376: Front Interior Light
6-2. Using the interior lights Front interior light Vehicles without panoramic roof Vehicles with panoramic roof   Turns the lights off Turns the lights off Turns the door position on Turns the door position on Turns the lights on Turns the lights on Front personal lights Vehicles without panoramic roof...
Page 377: Rear Interior Light
6-2. Using the interior lights Rear interior light Turns the door position on When the front interior light main switch is in the off position, the rear interior light will not turn on even if the door is opened with the rear interior light switch in door position.
Page 378: 6-3. Using The Storage Features
6-3. Using the storage features List of storage features Card holder (P. 382) Glove boxes (P. 379) Auxiliary boxes (P. 382) Bottle holders/door pockets (P. 380) Cup holders (P. 380) Console box (P. 379) WARNING ● Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: •...
Page 379: Glove Boxes
6-3. Using the storage features Glove boxes Upper glove box Lower glove box   Pull up the lever. Pull up the lever. ● If the lower glove box is opened when the parking lights are illuminated, the light illuminates. Console box Push the button to open the lid.
Page 380: Cup Holders/Bottle Holders/Door Pockets
6-3. Using the storage features Cup holders/bottle holders/door pockets Cup holders ■ Front passenger’s side Center console (front)   Push the lid. Type A Type B Pull out the lid. Center console (rear)  Open the lid and adjust the holder. When closing, stow the holder before closing the lid.
Page 381 6-3. Using the storage features Bottle holders/door pockets ■ Front doors Rear doors   ● The type B cup holder on the center con- sole (front side): The cup holder can be used store small objects if the inner tray is removed.
Page 382: Auxiliary Boxes
6-3. Using the storage features Auxiliary boxes Type A (if equipped) Type B   Press in the lid. The overhead console is useful for temporarily storing small items. WARNING Do not store items heavier than 0.44 lb. (200 g). Doing so may cause the auxiliary box to open and the items inside may fall out, resulting in an accident.
Page 383: Luggage Compartment Features
6-3. Using the storage features Luggage compartment features Cargo hooks Raise the hook to use. The cargo hooks are provided for securing loose items. PRIUS v_OM_OM47B23U_(U)
Page 384 6-3. Using the storage features Auxiliary boxes Center Side   Pull the lever upward to lift the Lift the center deck board and deck board. then lift the side deck boards. When using the auxiliary box on Lift the side deck board from the the front of the vehicle, fold and front side of the vehicle to prevent pick up the deck board and move it...
Page 385 6-3. Using the storage features Luggage cover Installing the luggage cover ■ Set the holder of one side into the installation position, then install both holders from below with the cover in its contracted state. Using the luggage cover ■ Pull out the luggage cover and secure it to the hook brackets.
Page 386 6-3. Using the storage features Stowing the luggage cover ■ Lift the center deck board and remove the side deck boards. Fold inwards together with the head restraint installation hooks and secure. Then, stow in the auxiliary boxes. WARNING ● To avoid injury, always return the cargo hooks to their stowed positions when not in use.
Page 387: Using The Other Interior Features
6-4. Using the other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. Vanity mirrors Slide the cover to open.
Page 388: Clock
6-4. Using the other interior features Clock The clock can be adjusted by pressing the buttons. Adjusts the hours Adjusts the minutes Rounds to the nearest hour : e.g. 1:00 to 1:291:00 1:30 to 1:592:00 ● The clock is displayed when the power switch is in ACCESSORY or ON mode.
Page 389: Armrest
6-4. Using the other interior features NOTICE ● To avoid damaging the power outlet, close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short circuit.
Page 390: Assist Grips
6-4. Using the other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. WARNING Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 391: Panoramic Roof Shades
10 seconds or more (until the panoramic roof shades have closed completely). If the panoramic roof shades continue to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 392 6-4. Using the other interior features ■ Customization The door lock linked automatic close function can be disabled. (Customizable features: P. 577) WARNING Observe the following precautions. Failing to do so may result in death or serious injury. ■ When closing the panoramic roof shades ●...
Page 393: Garage Door Opener
6-4. Using the other interior features  Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manu- ®...
Page 394 6-4. Using the other interior features ® Programming HomeLink ■ Point remote control transmitter for the device 1 to 3 in. (25 to 75 mm) from the ® HomeLink buttons. ® Keep the HomeLink indicator light in view while programming. Press and hold one of the ®...
Page 395 6-4. Using the other interior features ® Test the HomeLink opera- tion by pressing the newly programmed button. ® If a HomeLink button has been programmed for a garage door, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the rolling code type.
Page 396 6-4. Using the other interior features Programming a rolling code system (for U.S.A. owners) ■ If your device is rolling code equipped, follow the steps under the ® heading “Programming HomeLink ” before proceeding with the steps listed below. Locate the training button on the ceiling mounted garage door opener motor.
Page 397 HomeLink buttons. Programming other devices ■ To program other devices such as home security systems, home door locks and lighting, contact your Toyota dealer for assistance. Reprogramming a button ■ ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 398 6-4. Using the other interior features ® Operating HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator light should come on. ® The HomeLink compatible transceiver in your vehicle continues to send a signal for up to 20 seconds as long as the button is pressed. ®...
Page 399 6-4. Using the other interior features ■ Certification for the garage door opener For vehicles sold in the U.S.A., Hawaii, Guam, Saipan and Puerto Rico  For vehicles sold in Canada  ■ When support is necessary Visit on the web at www.homelink.com or call 1-800-355-3515. WARNING ■...
Page 400: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Connect service is subject to such then-applicable Terms and Conditions.
Page 401 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-25-TOYOTA (1-800-255-3987) or push the “SOS” button in your vehicle for further subscription details. PRIUS v_OM_OM47B23U_(U)
Page 402 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection availabil- ity, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 403 After filing a police report, call the Safety Connect response center at 1-800-25-TOYOTA (1-800-255-3987) and follow the prompts for Safety Connect to initiate this service. In addition to assisting law enforcement with recovery of a stolen...
Page 404 Enhanced Roadside Assistance ■ Enhanced Roadside Assistance adds GPS data to the already included warranty-based Toyota roadside service. Subscribers can press the “SOS” button to reach a Safety Connect response-center agent, who can help with a wide range of needs, such as: towing, flat tire, fuel delivery, etc.
Page 405 6-4. Using the other interior features ■ Certification for the Safety Connect FCC ID: O6Y-CDMRF101 FCC ID: XOECDMRF101B FCC ID: N7NGTM2 FCC WARNING: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
Page 406 6-4. Using the other interior features PRIUS v_OM_OM47B23U_(U)
Page 407: Maintenance And Care
Maintenance and care 7-1. Maintenance and care Cleaning and protecting the vehicle exterior..408 Cleaning and protecting the vehicle interior... 412 7-2. Maintenance Maintenance requirements ....415 General maintenance..418 Emission inspection and maintenance (I/M) programs......421 7-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 408: Maintenance And Care Cleaning And Protecting
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 409 7-1. Maintenance and care ■ Aluminum wheels ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical clean- ers. Use the same mild detergent and wax as used on the paint. ●...
Page 410 7-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 411 7-1. Maintenance and care NOTICE ■ To prevent damage to the panoramic roof (if equipped) Observe the following precautions. Otherwise, the surface of the panoramic roof may be damaged, or the deterioration of the coating may be acceler- ated. ● Before washing the vehicle, remove any dust, sand or other foreign matter using water.
Page 412: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 413 ● Wring out any excess water from the cloth and thoroughly wipe off remaining traces of detergent and water. ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available.
Page 414 7-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 415: Maintenance Maintenance Requirements
Toyota recommends the following main- tenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 416 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 417 7-2. Maintenance WARNING ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. ■ Handling of the 12-volt battery ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 418: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 419 7-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Hybrid transmission • When parked on a slope and the shift position “Park” mechanism is in P, is the vehicle securely stopped? •...
Page 420 7-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? • Does the engine hood lock system work prop- Engine hood erly? • There should not be any signs of fluid leakage Fluid leaks after the vehicle has been parked. •...
Page 421: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 422: Do-It-Yourself Maintenance Do-It-Yourself Service
• Rag or paper towel (P. 437) • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- life hybrid organic acid technology Engine/power For the U.S.A.:...
Page 423 7-3. Do-it-yourself maintenance Items Parts and tools • Water or washer fluid containing antifreeze (for win- Washer fluid ter use) (P. 440) • Funnel (used only for adding water or washer fluid) WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized.
Page 424: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
Page 425 7-3. Do-it-yourself maintenance WARNING ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 426: Positioning A Floor Jack
7-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 427 7-3. Do-it-yourself maintenance WARNING When raising the vehicle, do not set the Rear suspension floor jack under the rear suspension. Front PRIUS v_OM_OM47B23U_(U)
Page 428: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir Brake fluid reservoir (P. 434) (P. 437) Engine oil level dipstick Fuse box (P. 466) (P. 430) Radiator (P. 436) Engine oil filler cap (P. 432) Condenser (P. 436) Power control unit coolant Electric cooling fans reservoir (P.
Page 429 7-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover ■ Installing the clips ■ Push up center portion Insert Press NOTICE ■ After installing an engine compartment cover Make sure that the cover is securely installed in its original position. PRIUS v_OM_OM47B23U_(U)
Page 430 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 431 7-3. Do-it-yourself maintenance Holding a rag under the end, pull the dipstick out and check the oil level. Normal Excessive Flat dipstick Non-flat dipstick   Measuring side The shape of the dipstick may differ depending on the type of vehicle or engine.
Page 432 7-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 433 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 434 7-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the full (“FULL” or “F”) and low (“LOW” or “L”) lines on the reservoir when the hybrid system is cold. Engine coolant reservoir ■ Reservoir cap “FULL” line “LOW”...
Page 435 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine/power control unit coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. WARNING ■...
Page 436 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 437 7-3. Do-it-yourself maintenance Brake fluid Checking fluid level ■ The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Adding fluid ■ Slide and lift up the rubber strip to partly remove it as shown. Disconnect the claws and remove the service cover.
Page 438 7-3. Do-it-yourself maintenance Remove the reservoir cap. Add brake fluid slowly while checking the fluid level. Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel ■...
Page 439 7-3. Do-it-yourself maintenance WARNING ■ When filling the reservoir Take care as brake fluid can harm your hands and eyes and damage painted surfaces. If fluid gets on your hands or in your eyes, flush the affected area with clean water immediately.
Page 440 7-3. Do-it-yourself maintenance Washer fluid Open the lid. Check the washer fluid level on the level gauge. “NORMAL” “LOW” If the washer fluid level is at “LOW”, add washer fluid. PRIUS v_OM_OM47B23U_(U)
Page 441 7-3. Do-it-yourself maintenance WARNING ■ When adding washer fluid Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■ Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid.
Page 442: 12-Volt Battery
7-3. Do-it-yourself maintenance 12-volt battery Location The 12-volt battery is located in the right-hand side of luggage compartment. Removing the 12-volt battery maintenance cover Open the center and right side deck boards. (P. 384) Remove the center auxiliary box. (P. 527) Remove the right side auxiliary box.
Page 443 Restart the hybrid system, depress the brake pedal, and confirm that it is possible to shift into each shift position. If the system will not start even after multiple attempts at all methods above, contact your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 444 When replacing the 12-volt battery Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explosion. For replacement of the 12-volt battery, contact your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 445 7-3. Do-it-yourself maintenance WARNING ■ When disconnecting the 12-volt battery Do not disconnect the negative (-) termi- nal on the body side as shown. The dis- connected negative (-) terminal may touch the positive (+) terminal, which may cause a short and result in death or serious injury.
Page 446: Tires
Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the same interval as tire inspection. Front Do not fail to initialize the tire pressure warning system after tire rotation.
Page 447 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 448) ◆ Initializing the tire pressure warning system The tire pressure warning system must be initialized in the fol- ■...
Page 448 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 449 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage. If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not regis- tered, the tire pressure warning system will not work properly.
Page 450 7-3. Do-it-yourself maintenance ■ Tire types ● Summer tires Summer tires are high-speed performance tires best suited to highway driv- ing under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 451 In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • When a replacement tire is used, the system may not operate correctly due to the structure of the replacement tire.
Page 452 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the tire pressure warning reset switch, the tire pressure warning light does not blink 3 times.
Page 453 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 454 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 455: Tire Inflation Pressure
7-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (P. 561) PRIUS v_OM_OM47B23U_(U)
Page 456 Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 457 7-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 458: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 459 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 460: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the power switch off. Open the lower glove box and remove the filter exchange cover. Remove the filter cover. Slide and pull out the filter.
Page 461 7-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide”...
Page 462: Wiper Rubber Replacement
7-3. Do-it-yourself maintenance Wiper rubber replacement Replacing procedure Front ■ Remove the stopper, lift the wiper arm slightly upward, and then slide the wiper blade to remove it. Slowly lower the wiper arm until it contacts the windshield. Slide off the wiper rubber. Install the 2 metal plates from the removed wiper rubber to the replacement wiper rub-...
Page 463 7-3. Do-it-yourself maintenance When installing, insert the wiper rubber in the direction opposite that used during the removal procedure until the wiper rubber becomes locked and stops moving. Check the direction the wiper rubber is facing before installing. After installing the wiper rubber, install the wiper blade to the wiper arm and secure the stopper.
Page 464: Electronic Key Battery
7-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Lithium battery CR2032 Replacing the battery Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a rag.
Page 465 7-3. Do-it-yourself maintenance ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer. ●...
Page 466: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the power switch off. Open the fuse box cover. Engine compartment Left side instrument panel ...
Page 467 7-3. Do-it-yourself maintenance Check if the fuse is blown. Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type A Type B ...
Page 468 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 469) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 469: Light Bulbs
Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (P. 562) Removing the engine compartment cover P.
Page 470 7-3. Do-it-yourself maintenance Bulb locations Front ■ Vehicles with halogen Vehicles with LED headlights   headlights Front turn signal light Fog light Fog light Front turn signal light Headlight high beam/daytime running lights Headlight low beam Front side marker light Parking light Rear ■...
Page 471 7-3. Do-it-yourself maintenance Replacing light bulbs Headlight low beams (halogen headlights) ■ Unplug the bulb base coun- terclockwise. Unplug the connector while pressing the lock release. Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert.
Page 472 7-3. Do-it-yourself maintenance Headlight high beams/daytime running lights (halogen head- ■ lights) Turn the cover counterclock- wise and remove it. Turn the bulb base counter- clockwise. Unplug the connector while pulling the lock release. Confirm whether the O-ring of the cover has not come off.
Page 473 7-3. Do-it-yourself maintenance Replace the light bulb, and set the connector. Install the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn the bulb base clockwise to set. Shake the bulb base gently to check that it is not loose, turn the headlight high beams on once and visually confirm that...
Page 474 7-3. Do-it-yourself maintenance Parking lights (halogen headlights) ■ Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. PRIUS v_OM_OM47B23U_(U)
Page 475 7-3. Do-it-yourself maintenance Front side marker lights (halogen headlights) ■ Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. PRIUS v_OM_OM47B23U_(U)
Page 476 7-3. Do-it-yourself maintenance Halogen fog light (if equipped) ■ Remove the fender liner bolts and pull down the fender liner. Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. PRIUS v_OM_OM47B23U_(U)
Page 477 7-3. Do-it-yourself maintenance Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set. Set the connector. After installing connector, shake the bulb base gently to check that it is not loose, turn the fog lights on once and visually con- firm that no light is leaking through the mounting.
Page 478 7-3. Do-it-yourself maintenance Front turn signal lights ■ Turn the bulb base counterclockwise. Vehicles with halogen head- Vehicles with LED headlights   lights Remove the light bulb. When installing, reverse the steps listed. PRIUS v_OM_OM47B23U_(U)
Page 479 7-3. Do-it-yourself maintenance Rear turn signal lights and back-up lights ■ Open the back door and remove the cover. To prevent damage, cover the tip of the screwdriver with a rag. Turn the bulb base counter- clockwise. Rear turn signal light Back-up light Remove the light bulb.
Page 480 7-3. Do-it-yourself maintenance License plate lights ■ Open the back door and remove the cover. To prevent damage, cover the tip of the screwdriver with a rag. Turn the bulb base counter- clockwise. Remove the light bulb. ITO43P150 When installing, reverse the steps listed. PRIUS v_OM_OM47B23U_(U)
Page 481 ■ Condensation build-up on the inside of the lens Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Contact your Toyota dealer for more information in the following situations: ● Large drops of water have built up on the inside of the lens.
Page 482 7-3. Do-it-yourself maintenance WARNING ■ Replacing light bulbs ● Be sure to stop the hybrid system and turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ●...
Page 483: When Trouble Arises
When trouble arises 8-1. Essential information Emergency flashers ..484 If your vehicle has to be stopped in an emergency ...... 485 8-2. Steps to take in an emergency If your vehicle needs to be towed ......486 If you think something is wrong ......
Page 484: Emergency Flashers
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 485: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 486: 8-2. Steps To Take In An Emergency
In the following situations, it is not possible to be towed by another vehicle using cables or chains, as the front wheels may be locked due to the parking lock. Contact your Toyota dealer or commercial towing service. ● There is a malfunction in the shift control system. (P. 494, 508) ●...
Page 487 8-2. Steps to take in an emergency Towing with a wheel-lift type truck From the front From the rear   Release the parking brake. Use a towing dolly under the front wheels. Using a flat bed truck If your vehicle is transported by a flat bed truck, it should be tied down at the locations shown in the illustration.
Page 488 8-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing eyelets. This should only be attempted on hard surfaced roads for short distances at under 18 mph (30 km/h).
Page 489 8-2. Steps to take in an emergency Securely attach cables or chains to the towing eyelet. Take care not to damage the vehicle body. Enter the vehicle being towed and start the hybrid system. If the hybrid system does not start, turn the power switch to ON mode. Shift the shift position to N and release the parking brake.
Page 490 8-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle when towing using a wheel-lift type truck When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed.
Page 491: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 492: If A Warning Light Turns On Or A Warning Buzzer Sounds
• The brake system is malfunctioning  Immediately stop the vehicle in a safe place and con- (U.S.A.) tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. (Canada) This light also comes on when the parking brake is not released.
Page 493 Indicates a malfunction in: • The hybrid system; (U.S.A.) • The electronic engine control system; or • The electronic throttle control system  Have the vehicle inspected by your Toyota dealer (Canada) immediately. SRS warning light Indicates a malfunction in: •...
Page 494 Indicates a malfunction in: • The VSC system; • The TRAC system; or • The hill-start assist control system  Have the vehicle inspected by your Toyota dealer immediately. The light will flash when the above systems and/or ABS are operating.
Page 495  Stop and check. (P. 546) Cruise control indicator (yellow indicator) Indicates a malfunction in the cruise control  Have the vehicle inspected by your Toyota dealer (If equipped) immediately. Low hybrid battery (traction battery) warning light...
Page 496 8-2. Steps to take in an emergency Warning light Warning light/Details/Actions Low fuel level warning light Indicates that remaining fuel is approximately 1.6 gal. (6.0 L, 1.3 Imp.gal.) or less  Refuel the vehicle. Seat belt reminder light (warning buzzer) Warns the driver and/or front passenger to fasten their seat belts ...
Page 497 When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system (P. 499)  Have the system checked by your Toyota dealer. : Brake system warning buzzer: When there is a possible problem that could affect braking performance, the warning light will come on and a warning buzzer will sound.
Page 498 If it is, tighten it securely. The malfunction indicator lamp will go off after several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. PRIUS v_OM_OM47B23U_(U)
Page 499 1 minute If the tire pressure warning light frequently comes on after blinking for 1 minute when the power switch is turned to ON mode, have it checked by your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard due to being in a noisy location or audio sound.
Page 500 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 501 8-2. Steps to take in an emergency WARNING ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 502 The filter may be clogged, the air intake vent may be blocked or there may be a gap in the duct. (if equipped)  Have maintenance performed on the hybrid battery (traction battery) cooling component at your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 503 8-2. Steps to take in an emergency Follow the correction procedures. (vehicles without multi-infor- mation display) After taking the specified steps to correct the suspected problem, check that the smart key system warning light or the smart key system indicator light turn off. Interior Exterior Warning...
Page 504 8-2. Steps to take in an emergency Interior Exterior Warning Correction Warning light/Details buzzer buzzer light procedure Smart system warning light Indicates that a door other than the driver’s door has been opened Confirm the loca- Once 3 times and closed with the tion of the elec- power switch in any tronic key.
Page 505 15 low. seconds) Smart system Have the vehicle warning light inspected by your  Once Indicates a malfunc- Toyota dealer (Flashes in tion in the smart key yellow for 15 immediately. system. seconds) Smart system warning light • When the doors were...
Page 506: If A Warning Message Is Displayed
Multi-information display If any of the warning lights come on again after the following actions have been performed, contact your Toyota dealer.  : If equipped PRIUS v_OM_OM47B23U_(U)
Page 507 8-2. Steps to take in an emergency Warning message and warning buzzer list Warning message Details/Actions Indicates that: • There is a high possibility of a frontal collision; • The pre-collision braking function is operating A buzzer also sounds.  Slow the vehicle by applying the brakes. (If equipped) Indicates that your vehicle is nearing the vehicle ahead (in vehicle-to-vehicle distance control...
Page 508 If this happens, applying the parking brake will enable the switch to be turned off. A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer. Indicates a malfunction in the hybrid system A buzzer also sounds.
Page 509 Press the “ON-OFF” button once to deactivate the system, and then press the button again to reactivate the system. A buzzer also sounds.  Have the vehicle inspected by your Toyota (If equipped) dealer. Indicates that the LDA malfunction A buzzer also sounds.
Page 510  Stop and check. (P. 546) Indicates a malfunction in the Automatic High Beam A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer. (If equipped) Indicates that all maintenance according to the driven distance on the maintenance schedule should be performed soon.
Page 511 (If equipped) Hybrid battery (traction battery) inspection or replacement time.  Have the hybrid battery (traction battery) inspected by your Toyota dealer immedi- ately. Hybrid system restarting will soon be disabled.  If you continue to use the vehicle in this state, you will soon become unable to restart the hybrid system.
Page 512 12-volt battery may be deteriorating. The 12-volt battery may be discharged if this continues. Have the 12-volt battery inspected at your Toyota dealer. The shift lever and P position switch were repeat- edly operated in quick succession. A buzzer also sounds.
Page 513 8-2. Steps to take in an emergency Warning message Details/Actions An attempt was made to change the shift position from P with the brake pedal released. A buzzer also sounds.  When changing the shift position from P, depress the brake pedal. (Flashes) An attempt was made to change the shift position to B when the shift position was R.
Page 514 Toyota dealer. Shift control system malfunction A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer. • The hybrid system may not be able to start. • The parking lock mechanism may not func- tion.
Page 515 Warning message Details/Actions Shift control system communication malfunction A buzzer also sounds.  Have the vehicle inspected by your Toyota dealer. • The hybrid system may not be able to start. • May not be switched to the P position.
Page 516  Have maintenance performed on the hybrid battery (traction battery) cooling compo- nent at your Toyota dealer. Indicates that the EV drive mode is not available The reason the EV drive mode is not available (the vehicle is idling, battery charge is low,...
Page 517 8-2. Steps to take in an emergency Displayed message Details/Actions Indicates that the EV drive mode has been auto- matically canceled The reason the EV drive mode is not available (the battery charge is low, speed is higher than the EV drive mode operating speed range, accelerator pedal is depressed too much) may be displayed.
Page 518 8-2. Steps to take in an emergency ■ Warning messages The warning message illustrations used are intended as examples, and may differ from the image that is actually displayed on the multi-information dis- play. ■ Warning message in radar cruise mode (if equipped) In the following situations, the warning message may not be displayed even if vehicle-to-vehicle distance decreases: ●...
Page 519 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer Power was turned off due to the automatic power off function.  Next time when starting the hybrid system, oper-   ate the hybrid system for approximately 5 minutes to recharge the 12-volt bat- tery.
Page 520 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer The electronic key was carried outside the vehicle and a door other than the driver’s door was opened and closed while the power switch was in a mode other than off.
Page 521 8-2. Steps to take in an emergency Interior Exterior Warning message Details/Actions buzzer buzzer • An attempt was made to lock the doors using the smart key system while the electronic key was still inside the vehi- cle. • An attempt was made to lock Sounds either front door by opening a once for...
Page 522 (Flashes) The electronic key has a low battery.  Once  Replace the electronic key battery. (P. 464) Indicates a malfunction in the smart key system  Once  Have the vehicle inspected by your Toyota dealer. (Flashes) PRIUS v_OM_OM47B23U_(U)
Page 523 8-2. Steps to take in an emergency ■ Warning messages P. 518 ■ Warning buzzer P. 499 PRIUS v_OM_OM47B23U_(U)
Page 524: If You Have A Flat Tire
8-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 446 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 525 8-2. Steps to take in an emergency Location of the spare tire, jack and tools Jack handle Spare tire Towing eyelet Jack Wheel nut wrench PRIUS v_OM_OM47B23U_(U)
Page 526 8-2. Steps to take in an emergency WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 527 8-2. Steps to take in an emergency Taking out the jack Open the deck board and move it toward the front of the vehicle. Remove the left side deck board and then remove the center auxiliary boxes. Take out the jack. PRIUS v_OM_OM47B23U_(U)
Page 528 8-2. Steps to take in an emergency Taking out the spare tire Remove the deck boards and center auxiliary boxes. (P. 527) Unload the tool holder from the vehicle and loosen the center fastener that secures the spare tire. WARNING ■...
Page 529 8-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 530 8-2. Steps to take in an emergency Turn the tire jack portion hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel. They indicate the jack point positions. Raise the vehicle until the tire is slightly raised off the ground.
Page 531 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install the wheel nuts with the tapered ends facing inward.
Page 532 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 533 8-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) vehicles with inch wheels, reinstall wheel ornament.
Page 534 8-2. Steps to take in an emergency ■ The compact spare tire ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ●...
Page 535 8-2. Steps to take in an emergency WARNING ■ When using the compact spare tire ● Remember that the spare tire provided is specifically designed for use with your vehicle. Do not use your spare tire on another vehicle. ● Do not use more than one compact spare tire simultaneously.
Page 536 8-2. Steps to take in an emergency NOTICE ■ Be careful when driving over bumps with the compact spare tire installed on the vehicle. The vehicle becomes lower when driving with the compact spare tire compared to when driving with standard tires. Be careful when driving over uneven road surfaces.
Page 537: If The Hybrid System Will Not Start
8-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate procedure: The hybrid system will not start even though the correct starting procedure is being followed.
Page 538 ● The 12-volt battery may be discharged. (P. 541) ● One or both of the 12-volt battery terminals may be disconnected. (P. 442) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 539: If The Electronic Key Does Not Operate Properly
3 seconds unlocks the other doors. Starting the hybrid system Ensure that the shift position is in P and depress the brake pedal. Touch the Toyota emblem side of the electronic key to the power switch. When...
Page 540 8-2. Steps to take in an emergency Press the power switch. In the event that the hybrid system still cannot be operated, contact your Toyota dealer. ■ Stopping the hybrid system Set the parking brake, shift the shift position to P and press the power switch as you normally do when stopping the hybrid system.
Page 541: If The 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid sys- tem if the vehicle’s 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 542 8-2. Steps to take in an emergency Connect the jumper cables according to the following procedure: Connect a positive jumper cable clamp to the exclusive jump starting terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
Page 543 8-2. Steps to take in an emergency Make sure the “READY” indicator comes on. If the indicator light does not come on, contact your Toyota dealer. Once the hybrid system has started, remove the jumper cables in the exact reverse order from which they were connected.
Page 544 Do not allow children near the 12-volt battery. ■ After recharging the 12-volt battery Have the 12-volt battery inspected at your Toyota dealer as soon as possi- ble. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
Page 545 8-2. Steps to take in an emergency NOTICE ■ When handling jumper cables When connecting the jumper cables, ensure that they do not become entan- gled in the cooling fans, etc. ■ To prevent damaging the vehicle The exclusive jump starting terminal is to be used when charging the 12-volt battery from another vehicle in an emergency.
Page 546: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the hybrid system has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. PRIUS v_OM_OM47B23U_(U)
Page 547 (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the hybrid system immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 548 “F” line “L” line Add coolant if necessary. Water can be used in an emer- gency if coolant is unavailable. If water was added in an emer- gency, have vehicle inspected at your Toyota dealer as soon as possible. PRIUS v_OM_OM47B23U_(U)
Page 549 If the hybrid system overheat warning light does not turn off or the message does not disappear: Stop the hybrid system and contact your Toyota dealer. If the hybrid system overheat warning light does not come on or the message is not displayed: The hybrid system temperature has dropped and the vehicle may be driven normally.
Page 550 8-2. Steps to take in an emergency NOTICE ■ When adding engine/power control unit coolant Add coolant slowly after the hybrid system has cooled down sufficiently. Adding cool coolant to a hot hybrid system too quickly can cause damage to the hybrid system.
Page 551: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Set the parking brake and shift the shift position to P. Stop the hybrid system.
Page 552 8-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 553: Vehicle Specifications
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.) ..554 Fuel information ....563 Tire information ....566 9-2. Customization Customizable features ..577 9-3. Initialization Items to initialize ....585 PRIUS v_OM_OM47B23U_(U)
Page 554: Specifications Maintenance Data
9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight 182.9 in. (4645 mm) Overall length 182.3 in. (4630 mm) Overall width 69.9 in. (1775 mm) 62.0 in. (1575 mm) Overall height 63.0 in. (1600 mm) Wheelbase 109.4 in. (2780 mm) 60.6 in.
Page 555 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 556 9-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. Engine Model 1.8 L 4-cylinder (2ZR-FXE) Type 4-cylinder in line, 4-cycle, gasoline 3.17  3.48 in. (80.5  88.3 mm) Bore and stroke Displacement 109.7 cu.in.
Page 557 9-1. Specifications Hybrid battery (traction battery) Type Nickel-Metal hydride battery Voltage 7.2 V/module Capacity 6.5 Ah (3HR) Quantity 28 modules Overall voltage 201.6 V Lubrication system Oil capacity (Drain and refill — reference With filter 4.4 qt. (4.2 L, 3.7 Imp.qt.) Without filter 4.1 qt.
Page 558 9-1. Specifications Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil Recommended viscosity: SAE 0W-20...
Page 559 Capacity Power 2.9 qt. (2.7 L, 2.4 Imp.qt.) control unit Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol- Coolant type based non-silicate, non-amine, non- nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 560 : The fluid capacity is the quantity of reference. If replacement is necessary, contact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may ulti- mately damage the transmission of your vehicle. Brakes Pedal clearance 2.95 in. (75 mm) Min.
Page 561 9-1. Specifications Tires and wheels Type A  Tire size P205/60R16 91V Front tire  Tire inflation pressure 35 psi (240 kPa, 2.4 kgf/cm or bar) (Recommended cold tire Rear tire  inflation pressure) 33 psi (230 kPa, 2.3 kgf/cm or bar) 16 ...
Page 562 9-1. Specifications Light bulbs Light bulbs Bulb No. Type Halogen headlights Low beam High beam Fog lights Front turn signal lights Halogen headlights 7444NA LED headlights WY21W Exterior Front side marker lights (vehi- cles with halogen headlights) Parking lights (vehicles with halogen headlights) Rear turn signal lights WY21W...
Page 563: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 564 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcyclopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 565 9-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used, the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 566: Tire Information
9-1. Specifications Tire information Typical tire symbols Full-size tire  Compact spare tire  PRIUS v_OM_OM47B23U_(U)
Page 567 9-1. Specifications Tire size (P. 568) DOT and Tire Identification Number (TIN) (P. 568) Location of treadwear indicators (P. 446) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Summer tires or all season tires (P.
Page 568 9-1. Specifications Typical DOT and Tire Identification Number (TIN) Type A Type B   DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identification mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year Manufacturer’s code : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 569 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 570 9-1. Specifications Treadwear ■ The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 571 9-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been parked Cold tire inflation pres- for three hours or more, or has not been driven sure more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which a Maximum inflation pres- tire may be inflated, shown on the sidewall of the...
Page 572 9-1. Specifications Tire related term Meaning The combined weight of installed regular produc- tion options weighing over 5 lb. (2.3 kg) in excess of the standard items which they replace, Production options not previously considered in curb weight or weight accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty 12-volt bat- tery, and special trim...
Page 573 9-1. Specifications Tire related term Meaning A breakdown of the bond between components Bead separation in the bead A pneumatic tire in which the ply cords that extend to the beads are laid at alternate angles Bias ply tire substantially less than 90 degrees to the center- line of the tread The tire structure, except tread and sidewall rub- Carcass...
Page 574 9-1. Specifications Tire related term Meaning (a) The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on the other Intended outboard side- sidewall of the tire, or wall (b) The outward facing sidewall of an asymmetri- cal tire that has a particular side that must...
Page 575 9-1. Specifications Tire related term Meaning A mechanical device made of rubber, chemicals, fabric and steel or other materials, that, when Pneumatic tire mounted on an automotive wheel, provides the traction and contains the gas or fluid that sus- tains the load A pneumatic tire in which the ply cords that Radial ply tire extend to the beads are laid at substantially 90...
Page 576 9-1. Specifications Tire related term Meaning Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the (TWI) degrees of wear of the tread The fixture used to hold the wheel and tire Wheel-holding fixture assembly securely during testing...
Page 577: Customization
Entune Audio or Entune Premium Audio with Navigation, or at your Toyota dealer. Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Customizing vehicle features When customizing vehicle features, ensure that the vehicle is parked in a safe place with the parking brake set and the shift position in P.
Page 578 Vehicles with Entune Audio or Entune Premium Audio with Naviga- tion: Settings that can be changed using the Entune Audio or Entune Premium Audio with Navigation Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, – =Not available Door lock (P. 120, 539) ■...
Page 579 9-2. Customization Smart key system and wireless remote control (P. 130, 116) ■ Default Customized Function setting setting Operation signal – (buzzer) 1 to 7 Operation signal (emer- – gency flashers) Open door reminder buzzer (when locking the – – vehicle) Time elapsed before the automatic...
Page 580 9-2. Customization Wireless remote control (P. 116) ■ Default Customized Function setting setting Wireless remote control – – Driver’s door unlocked in first doors Unlocking operation step, all doors unlocked in first – unlocked in sec- step ond step Panic function –...
Page 581 9-2. Customization Illumination (P. 375) ■ Default Customized Function setting setting Time elapsed before the 15 seconds 7.5 seconds – interior lights turn off 30 seconds Operation after power switch is turned – – Operation when doors are unlocked with the smart key system or –...
Page 582 9-2. Customization Instrument cluster (P. 91) ■ Default Customized Function setting setting Sensor sensitivity darkening bright- ness of the instrument Standard -2 to 2 – – cluster depending on the outside brightness Sensor sensitivity returning the brightness of the instrument cluster Standard -2 to 2 –...
Page 583 9-2. Customization Automatic air conditioning system (P. 366) ■ Default Customized Function setting setting A/C auto switching oper- – ation Heating/cooling opera- tion minimized in Eco – – drive mode Switching between out- side air and recirculated – – air mode linked to A/C auto switch operation Panoramic roof shades (P.
Page 584 9-2. Customization ■ Vehicle customization ● When the Speed linked door locking function and the Shift position linked door locking function are both on, the door lock operates as follows. • When shifting the shift position to any position other than P, all the doors will be locked.
Page 585: Initialization
9-3. Initialization Items to initialize The following items must be initialized for normal system opera- tion after such cases as the 12-volt battery being reconnected, or maintenance being performed on the vehicle. Item When to initialize Reference • Maintenance required reminder light (if equipped) •...
Page 586 9-3. Initialization PRIUS v_OM_OM47B23U_(U)
Page 587: For Owners
For owners Reporting safety defects for U.S. owners......588 Seat belt instructions for Canadian owners (in French) ....... 589 SRS airbag instructions for Canadian owners (in French) ....... 591 PRIUS v_OM_OM47B23U_(U)
Page 588: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 589: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation adéquate des ceintures de sécurité...
Page 590 Faites glisser la ceinture au- delà de la fente du guide. L’élastique doit être placé derrière la ceinture de sécurité. Bouclez la ceinture de sécurité et placez-la afin de ne pas res- sentir d’inconfort. Entretien et nettoyage Ceintures de sécurité ■...
Page 591: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian own- ers (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. ◆...
Page 592 ◆ Coussins gonflables SRS latéraux et en rideau Coussins gonflables SRS latéraux Peuvent aider à protéger le torse des occupants des sièges avant Coussins gonflables SRS en rideau Peuvent aider à protéger principalement la tête des occupants des sièges latéraux PRIUS v_OM_OM47B23U_(U)
Page 593 Composants du système de coussins gonflables SRS Capteurs d’impact avant Contacteur de boucle de cein- ture de sécurité du passager Capteurs d’impact latéral (por- avant tière avant) Contacteur de boucle de cein- Coussin gonflable du passager ture de sécurité du conducteur avant Capteur de position du siège Voyants “AIR BAG ON”...
Page 594 Votre véhicule est doté de COUSSINS GONFLABLES ÉVOLUÉS dont la conception s’appuie sur les normes de sécurité des véhicules à moteur américains (FMVSS208). Le module de capteur de coussin gonflable (ECU) contrôle le déploiement des coussins gonflables en fonction des informations obtenues des capteurs et d’autres éléments affichés dans le diagramme des composants du système ci-dessus.
Page 595 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS Observez les précautions suivantes en ce qui concerne les coussins gonfla- bles SRS. Les négliger pourrait occasionner des blessures graves, voire mortelles. ● Le conducteur et tous les passagers du véhicule doivent porter leur cein- ture de sécurité...
Page 596 Un bébé ou un enfant trop petit pour utiliser une ceinture de sécurité doit être correctement retenu à l’aide d’un dispositif de retenue pour enfants. Toyota recommande vivement de placer et d’attacher correcte- ment tous les bébés et tous les enfants sur les sièges arrière du véhicule à...
Page 597 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS ● Ne vous asseyez pas sur le bord du siège et ne vous appuyez pas sur la planche de bord. ● Ne laissez pas un enfant se tenir face au coussin gonflable SRS du passager avant ni s’asseoir sur les genoux d’un passager avant.
Page 598 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS ● Ne fixez et n’appuyez rien sur des zones telles que la planche de bord, le tampon de volant ou encore la partie inférieure du tableau de bord. Ces objets peuvent se transformer en projectiles lorsque les coussins gonfla- bles SRS du conducteur, du passager avant et de protection des genoux se...
Page 599 SRS Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifica- tions suivantes sans d’abord consulter votre concessionnaire Toyota. Les coussins gonflables SRS pourraient fonctionner de manière incorrecte ou se déployer (gonfler) accidentellement, ce qui serait susceptible d’occasion- ner des blessures graves, voire mortelles.
Page 600 PRIUS v_OM_OM47B23U_(U)
Page 601: Index
Index What to do if... (Troubleshooting) ....602 Alphabetical index ..... 606 For vehicles with Entune Premium Audio with Navigation, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL” for information regarding the equipment listed below. • Navigation system • Audio/visual system PRIUS v_OM_OM47B23U_(U)
Page 602 Toyota dealer. (P. 117) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly. Contact your Toyota dealer immediately. (P. 119) The doors cannot be locked or unlocked ● Is the electronic key battery weak or depleted? (P. 464) ●...
Page 603 What to do if... (Troubleshooting) If you think something is wrong The hybrid system does not start ● Did you press the power switch while firmly depressing the brake pedal? (P. 174) ● Is the shift position in P? (P. 184) ●...
Page 604 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and the front passenger wearing the seat belts? (P. 496) ● The parking brake indicator is on Is the parking brake released? (P. 190) Depending on the situation, other types of warning buzzer may also sound.
Page 605 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (P. 524) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 606: Alphabetical Index
Alphabetical index Alphabetical index Airbags ........41 Airbag operating conditions ..49 A/C ..........366 Airbag precautions for Air conditioning filter ..... 460 your child......44 Automatic air conditioning Airbag warning light ....493 system ........ 366 Correct driving posture ... 30 Climate remote control Curtain shield airbag switches......
Page 607 Alphabetical index Antenna Automatic door locking Smart key system ....130 and unlocking systems ..123 Radio ........292 Automatic headlight Anti-lock brake system leveling system ..... 194 (ABS) ........248 Automatic High Beam ..... 196 Function ........ 248 Automatic light control Warning light......
Page 608 Alphabetical index ® Bluetooth audio ..... 321 CD player........293 ® Bluetooth phone....323 Chains ........266 Deleting the call history..343 Child restraint system....59 Making a call......326 Booster seats definition ..60 Managing the contacts..339 Booster seat installation ..69 Message function....
Page 609 Alphabetical index Child-protectors....... 123 Cleaning Daytime running light Aluminum wheels....409 system........194 Exterior ......... 408 Defogger Interior........412 Outside rear view mirrors ..368 Panoramic roof ..... 411 Rear window......368 Radar sensor ....228, 260 Windshield ......368 Seat belts......
Page 610 Alphabetical index Doors Automatic door locking ECB (Electronically and unlocking system..123 Controlled Brake System) ..248 Back door......125 Eco drive mode......247 Door glasses......153 EDR (Event data recorder)..11 Door lock....... 120 Electric motor Open door warning buzzer ... 495 Location ........
Page 611 Alphabetical index If you have a flat tire ..... 524 Engine coolant If you lose your keys ..... 119 Capacity........ 559 If you think something Checking....... 434 is wrong ......491 Preparing and checking If your vehicle becomes before winter ...... 265 stuck ........
Page 612 Alphabetical index Fuel Capacity........ 556 Flat tire........524 Fuel gauge......92 Floor mats ........28 Gas station information..624 Fluid Information......563 Brake ........560 Refueling ......209 Transmission ......560 Type........556 Washer ......... 440 Warning light......496 Fog lights Fuel filler door ......
Page 613 Alphabetical index High mounted stoplight Replacing......481 I/M test ........421 Hill-start assist control.... 249 Identification Hood ......... 424 Engine ........556 Hooks Vehicle........555 Cargo hooks ......383 Ignition switch Retaining hooks (floor mat)..28 (Power switch)....... 174 Horn .......... 147 Auto power off function..
Page 614 Alphabetical index Jack Language Positioning a floor jack..426 (multi-information display)... 577 Vehicle-equipped jack... 525 LATCH system......63 Jack handle ......525 LDA (Lane Departure Alert) ..229 Jam protection function Lever Panoramic roof shades..391 Auxiliary catch lever....424 Power windows.....
Page 615 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance... 422 Noise from under vehicle ... 8 General maintenance ... 418 Maintenance data ....554 Maintenance requirements ... 415 Odometer ........92 Malfunction indicator lamp..493 Meter Engine oil......557 Indicators ........ 86 Opener Instrument panel light Fuel filler door.......
Page 616 Alphabetical index Power switch ......174 Auto power off function..178 P position switch ..... 184 Changing the power Panic mode ......117 switch modes ..... 177 Parking brake If your vehicle has to be Operation ......190 stopped in an Parking brake engaged emergency ......
Page 617 Alphabetical index Rear turn signal lights Replacing light bulbs..... 479 Safety Connect ......400 Turn signal lever ....189 Seat belts ........32 Wattage ........ 562 Adjusting the seat belt .... 35 Rear view mirror Automatic Locking Inside rear view mirror ..149 Retractor ......
Page 618 Alphabetical index Seats Smart key system....130 Adjustment....138, 142 Antenna location....130 Adjustment precautions ..140 Entry functions...... 120 Child seats/child restraint Starting the hybrid system ..174 system installation ..59, 63 Warning message....519 Cleaning........ 412 Snow tires ........ 265 Front seats......
Page 619 Alphabetical index Stuck Panoramic roof shades..391 If the vehicle becomes PCS switch ......256 stuck ........551 Power door lock switch..122 Sun visors ........ 387 Power switch ......174 Sunshade Power window switch ... 153 Panoramic roof shades..391 Rear window wiper and Switch washer switch.....
Page 620 Alphabetical index Tires.......... 446 Chains ........266 Tail lights Checking....... 446 Light switch ......191 Glossary ....... 571 Replacing light bulbs..... 481 If you have a flat tire ..... 524 Talk switch ....... 337 Inflation pressure ....455 Telephone switch ....337 Replacing......
Page 621 Alphabetical index TRAC (Traction Control) Function ........ 248 Warning buzzers VSC OFF switch ....250 Approach warning....221 Trip information ......94 Brake system......492 Trip meters ......... 92 Downshifting ......185 Troubleshooting ...... 602 Driver’s seat belt reminder..496 Turn signal lights Front passenger’s seat Replacing light bulbs..
Page 622 Alphabetical index Open door......495 Parking lock system....494 PCS ........493 Seat belt reminder light..496 Slip indicator ......494 SRS ........493 Tire pressure......497 Warning messages....506 Washer Checking....... 440 Preparing and checking before winter....... 265 Switch ......204, 207 Washing and waxing ....
Page 623 Alphabetical index PRIUS v_OM_OM47B23U_(U)
Page 624 (Drain and refill — With filter 4.4 qt. (4.2 L, 3.7 Imp.qt.) reference) Without filter 4.1 qt. (3.9 L, 3.4 Imp.qt.) “Toyota Genuine Motor Oil” or equivalent Engine oil type Oil grade: ILSAC GF-5 multigrade engine oil P. 557 PRIUS v_OM_OM47B23U_(U)
