Page 1 Illuminator System ™ Series Hypernova 5 kVA/kW – 60 kVA/kW Installation Guide 44 South Commerce Way, Bethlehem, PA 18017 1-800-526-5088 • (610) 868-3500 • Fax: (610) 868-8686 Service: (610) 868-5400 www.myerseps.com 115893E - System Installation Manual...
Page 2 This unit contains LETHAL VOLTAGES. All repairs and service should be performed by AUTHORIZED SERVICE PERSONNEL ONLY! There is NO USER SERVICEABLE PARTS inside this unit. IMPORTANT SAFEGUARDS When using electrical equipment, you should always follow basic safety precautions, including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
Page 3 C A U T I O N READ ENTIRE MANUAL AND REVIEW ALL DOCUMENTATION BEFORE ATTEMPTING SYSTEM INSTALLATION! FOR SERVICE OR INSTALLATION INFORMATION: TELEPHONE: (610) 868-5400 (24 HR. HOTLINE) FAX: (610) 954-8227 FOR YOUR PROTECTION..PLEASE COMPLETE AND RETURN WARRANTY REGISTRATION CARD IMMEDIATELY. 115893E - System Installation Manual...
Page 4 Table of Contents PART 1 – INSTALLATION MANUAL…………………………………………….4 CHAPTER 1: SAFETY WARNINGS ......................4 CHAPTER 2: INTRODUCTION ........................5 CHAPTER 3: BEFORE INSTALLATION ....................6 CHAPTER 4: INSTALLATION OVERVIEW ................... 13 CHAPTER 5: AC INPUT & AC OUTPUT INSTALLATION ..............16 CHAPTER 6: INSTALLING BATTERIES AND DC WIRING ...............
Page 5 C H A P T E R 1 AFETY ARNINGS Read the following precautions before you install the Emergency Lighting Inverter. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. This manual contains important instructions that you should follow during installation and maintenance of the system and batteries. Please read all instructions before operating the equipment and save this manual for future reference.
Page 6 C H A P T E R 2 NTRODUCTION Please read this manual thoroughly before operating your safety system. Keep this manual and the system User’s Guide in the folder mounted inside the unit’s door. WARNING Only qualified service personnel (such as a licensed electrician) should perform the system and battery installation and initial startup.
Page 7 C H A P T E R 3 EFORE NSTALLING THE Installation Dimensions and Clearances Figure 3.1 Table 3.1 Dimensions: 5-10kW, 90m runtime (3.75-7.5kW, 120m runtime) Unit Height Width Depth Electronics 47” 24” 25” 22.5” 11.8” 10.5” 3.5” 2” Cabinet (119.4 cm) (61.0 cm) (64.0 cm)
Page 8 Figure 3.2 Table 3.2 Dimensions: 12.5-16.7kW, 90m runtime (9.3-12.5kW, 120m runtime) Unit Height Width Depth Electronics 47” 30” 25” 21.5” 19” 8” 11.1” 7” Cabinet (119.4 cm) (76.2 cm) (64.0 cm) (54.6 cm) (48.3 cm) (20.3 cm) (28.2 cm) (17.8 cm) Table 3.2 Dimensions: 12.5-16.7kW, 90m runtime (9.3-12.5kW, 120m runtime) Unit Electronics...
Page 9 Figure 3.3 Table 3.3 Dimensions: 25-50kW, 90m runtime (16.7-50kW, 120m runtime) Unit Height Width Depth Electronics 72” 37.5” 25” 20.9” 17.4” 12.6” 6.8” 9.6” Cabinet (182.9 cm) (95.3 cm) (64.0 cm) (53.1 cm) (44.2 cm) (32.0 cm) (17.3 cm) (24.4 cm) Table 3.3 Dimensions: 25-50kW, 90m runtime (16.7-50kW, 120m runtime) Unit Electronics...
Page 10 Figure 3.4 Table 3.4 Dimensions: 60kW, 90m runtime Unit Height Width Depth Electronics 72” 44” 31” 27.75” 24.25” 19.5” 6.75” 9.5” Cabinet (182.9 cm) (112.0 cm) (79.0 cm) (70.5 cm) (62.6 cm) (49.5 cm) (17.2 cm) (24.1 cm) Table 3.4 Dimensions: 60kW, 90m runtime Unit Electronics 22.65”...
Page 11 Location Guidelines Keep the following guidelines in mind when choosing the location for your system and batteries: Verify that the environment meets the requirements in “Storage and Operating Environment” on • page 11. The environment can affect the reliability and performance of both the unit and the batteries.
Page 12 Table 3.8 System Weight [in lbs. (kg)] for 120-Minute System Models 120-Minute System Models 9.38kw 9.38kw 12.5kw 12.5kw 3.75kw 5.63kw 7.5kw 18.8kw 24.9kw 28.1kw 37.5kw 50kw 1150 1150 1360 1360 1360 Inverter (220) (220) (268) (290) (290) (290) (290) (522) (522) (617) (617)
Page 13 Make sure that heaters, sunlight, air conditioners, or outside air vents are not directed toward the batteries. These conditions can make the temperature within battery strings vary, which can cause differences in the batteries’ voltages. Eventually, these conditions affect battery performance. If the batteries are not in the system, remember that the batteries should be installed as close as possible to the unit to reduce DC wiring costs and improve battery performance.
Page 14 C H A P T E R 4 NSTALLATION VERVIEW Figure 4.1a through 4.1d shows typical installations of systems. Battery Cabinet 17.5” Wide Inverter Cabinet 24” Wide AC Input & AC Output Figure 4.1 Typical Hardwired Installation – 5.0KW to 10.0KW Standard Systems Battery Cabinet 22.75”...
Page 15 Battery Cabinet 28” Wide Inverter Cabinet 30” Wide AC Input & AC Output Figure 4.3 Typical Hardwired Installation – 12.5KW to 16.7KW Custom Systems Battery Cabinets Inverter Cabinet 2 Cabinets, Total Width 45.5” 37.5” Wide AC Input & AC Output Figure 4.4 Typical Hardwired Installation –...
Page 16 Inverter Cabinet Battery Cabinets 37.5” Wide 3 Cabinets, Total Width 68.25” AC Input & AC Output Figure 4.5 Typical Hardwired Installation – 37.5KW to 50.0KW Standard Systems Inverter Cabinet Battery Cabinets 44” Wide 4 Cabinets, Total Width 91” AC Input & AC Output Figure 4.6 Typical Hardwired Installation –...
Page 17 C H A P T E R 5 AC I & AC O NPUT UTPUT NSTALLATION WARNING Only qualified service personnel (such as a licensed electrician) should perform the AC installation. Risk of electrical shock exists. Read the following cautions before you continue. CAUTION •...
Page 18 Does the input voltage available for the system at the AC service panel match the input voltage shown on the unit’s ID label? Service Panel Voltage = _____________ Input Voltage ___Yes /___No • Does the output voltage on the ID label match the voltage your loads (protected equipment) need? Load Voltage = ______________ Output Voltage ___Yes/___No If you answered NO to either of the preceding questions, call SERVICE.
Page 19 Table 5.2 Recommended Minimum Wire Sizes Read These Important Notes! For this Input Use this Size 90°C Circuit Breaker Copper Wire Size... This table lists the AWG and mm2 wire size for each circuit breaker size. The minimum recommended circuit breaker sizes for each model and 10, 15, 20 3.31 voltage application are listed in Table 5.1.
Page 20 Phasing must be clockwise Rotation – i.e. Phase B lags Phase A. Connect each Line (hot) wire to each of the input block positions marked “Line”, connect the Neutral (common) wire to the input block marked “Neutral” and the ground wire to the compression lug next to the input terminal block.
Page 21 Figure 5.2 AC Input and Output Locations 12.5.KW to 16.7KW Inverter Cabinet Figure 5.3 AC Input and Output Locations 25.0KW to 50KW Inverter Cabinet 115893E - System Installation Manual...
Page 22 Figure 5.4 AC Input and Output Locations 60KW Inverter Cabinet 115893E - System Installation Manual...
Page 23 C H A P T E R 6 DC W NSTALLING ATTERIES AND IRING WARNING Only qualified service personnel (such as a licensed electrician) should perform the battery and DC wiring installation. Risk of electrical shock exists. This section explains how to install system batteries, fuses, and cables. An electrician who is familiar with battery installations and applicable building and electrical codes should install the batteries.
Page 24 A qualified electrician familiar with battery systems and required precautions must install and service the batteries. Any battery used with this unit shall comply with the applicable requirements for batteries in the standard for emergency lighting and power equipment, UL 924. Cabinets are design to be used with, and batteries must be replaced with, manufacturer battery number BAT-CG12105X, BAT-CG12150X OR BAT-CG12180X,or a manufacturer approved equivalent.
Page 25 Before Installing the Batteries Tools CAUTION Always use insulated tools when you work with batteries. Always torque connections to the manufacturer’s recommendations. When you work with system batteries, you need the following tools. The tools must be insulated so they do not short battery terminals to the cabinet. Wear the safety equipment required by local code whenever the doors are open and whenever you are working on batteries.
Page 26 Location Before you start installing the batteries, you must install the system and battery cabinets in their permanent location. If you have not already done this, see “Location Guidelines” on page 10 to choose a location. CAUTION To prevent damage to your equipment, do not move the system or separate battery cabinets after the batteries are installed.
Page 27 Making the Equipment Ground Connection Each battery cabinet ground (or earth) must be connected to the system’s chassis ground. You can make this connection at the ground terminals inside the system and the battery cabinet as follows. CAUTION All grounding conductors should be insulated. If you are using non-insulated grounding conductors, take special care to make sure that the grounding conductors cannot accidentally contact live wires or the batteries.
Page 28 3. Repeat step 1 and 2 for each additional battery string (See battery layout drawing for quantity of battery strings). Fuse All systems come with a fuse for each battery string to protect the system. The battery-wiring diagram shows the fuse location; a label inside the battery cabinet shows the fuse size.
Page 29 Now, follow these steps to connect the cables: 1. Using the battery-wiring diagram, determine which batteries belong to each battery string. 2. Clean the cable connectors with the wire brush before you make the battery connections. Torque all battery terminal connections to the value shown for your battery in Table 6.1.
Page 30 Review all the safety instructions at the beginning of this chapter before you replace any batteries. Use the Same Quantity and Type of Battery CAUTION You must use the same quantity and type of battery. Substituting batteries not supplied by manufacturer voids the UL listing and may cause equipment damage. To ensure continued superior performance of your system and to maintain proper charger operation, you must replace the batteries in the system or battery cabinets with the same number of batteries.
Page 31 CHAPTER 7 URNING ON THE YSTEM AND ETTING ARAMETERS Several parameters in the system software determine when and how your system conducts the automatic monthly and annual tests. Refer to “Program Functions” in the “Front Panel Display” chapter of the system user’s Guide for a description of each test. Starting the Unit Before you can set the parameters, you must start the system.
Page 32 Figure 7.1 Battery Fuse, DCPre-charge Switch & Installation Switch (5KW – 10KW) Figure 7.2 Battery Fuse, DC Pre-charge Switch & Installation Switch (12.5KW – 16.7KW) 115893E - System Installation Manual...
Page 33 Figure 7.3 Battery Fuse, DC Pre-charge Switch & Installation Switch (25KW - 50KW) 115893E - System Installation Manual...
Page 34 Figure 7.4 Battery Fuse, DC Pre-charge Switch & Installation Switch (60KW) 115893E - System Installation Manual...
Page 35 RONT ANEL ISPLAY The Front Panel Display assembly consists of an OLED display and a 4-button keypad. The 4 buttons can navigate through all the menus by using the left and right arrow keys, the ENTER and the ESCAPE. The default menu will scroll between the Identification/Date-Time screen, the Status Screen, and the Meter screens.
Page 36 LED Function The inverter Front Panel Display (FPD) features three LEDs: A green LED (on the left), an amber LED (in the middle), and a red LED (on the right). One LED (and only one LED) will always be on. The following table describes the meaning behind each of the LEDs: Table 7.1 Keypad Functions LED Color...
Page 37 Indicates the Status of the machine – AC Present, Battery Charging, System Ready, On Battery Power, and any Alarms/Faults present. System Setup To get to System Setup from the default screen, press the ENTER key, scroll to the SYSTEM SETUP menu using the left or the right arrow key, then press the ENTER key again.
Page 38 Max Current – This will automatically generate an alarm when the system output current is higher than the setpoint number, set in Amps AC. Depending on the duration and severity of the overcurrent event, the inverter may shut down to protect the electronics. Log View To get to the Log menu from the default screen, press the ENTER key, scroll to the LOG VIEW menu using the left or right arrow key, then press the ENTER key again.
Page 39 Monthly Test The parameters are Day, and Time in Hour and Minute. The 24-hour standard is used so 2:00 PM would be 14 hours. To change any of the auto monthly test parameters, use the left or right arrow key depending on if you want to increase or decrease.
Page 40 When in Setup Mode, navigate as follows: Use the LEFT (<) and RIGHT (>) keys to toggle the currently selected setting. • Use the ENTER (») and ESCAPE (x) keys to navigate back and forth between setting. • Completing the Installation Close the doors and lock the cabinet(s).
Page 41 PART II – OPTIONS MANUALS 115893E - System Installation Manual...
Page 42 PTION ANUAL HREE HASE MERGENCY IGHTING ENTRAL NVERTER Myers Emergency Power Systems 44 South Commerce Way, Bethlehem, PA 18017 1-800-526-5088 • (610) 868-3500 • Fax: (610) 868-8686 Service: (610) 868-5400 www.myerseps.com 115893E - System Installation Manual BACNET COMMUNICATION OPTION SECTION...
Page 43 Table of Contents PART 1 – INSTALLATION MANUAL…………………………………………….4 ......3 PART 2 – OPTIONS MANUALS…………………………………………………33 ......3 PART 3 – DRAWINGS…………………………………………………………..126 ......3 ..................................13 ........................ Error! Bookmark not defined. Figure 7.5 Front Panel Display ............... Error! Bookmark not defined. SECTION 1 ..............................46 BACnet Communication Option Board ..................46 SECTION 2 ..............................46 Description of Operation .........................46...
Page 44 Gateway vs Router ...........................62 Configuring BB2-7030 As A Router .....................65 On Network Numbers ........................66 On Hop Counts ..........................66 Parsing File Records (Alarm, Event and Test Logs) ..............66 Alarm Logs ............................67 Event Logs ............................67 Test Logs ............................68 SECTION 1 ..............................71 MODBUS Serial Comm Option Board - Introduction..............71 Meter Panel / MODBUS Selector Switch ..................71 SECTION 2 ..............................72 Description of Operation .........................72...
Page 45 Meter Functions ..........................103 Get Alarm Status .......................103 Get Indicator Status ......................104 Get Input Voltage ......................104 Get Output Voltage ......................105 Get Output Current ......................105 Get Battery Voltage ......................105 Get Battery Current ......................105 Get Ambient Temperature ....................105 Get Battery Output Power ....................105 5.10 Get Output VA ........................106 5.11...
Page 46 Temperature Sensor PCB Connections: ...................128 System Schematic: .........................129 SECTION 2 ..............................129 Description of Operation .......................129 LED Definitions ..........................130 SECTION 3 ..............................131 System Installation .........................131 115893E - System Installation Manual BACNET COMMUNICATION OPTION SECTION...
Page 47 SECTION 1 BACnet Communication Option Board The BACnet Communication Option Board for the three phase Series C Emergency Lighting Central Inverter has two internal connections, the RS232 communication bus and the input power. There are two external connections, a RS485 output connector and a USB connection that is the computer interface. For detailed operation on the protocol and commands for the computer interface see Section RS-232 Communications.
Page 48 File objects include a writable Archive property. Files are used to access one of three dynamic logs of Alarms, Tests and Events. SECTION 3 Settings There are two objects, AV1 and AV2 that will allow the software to change the Baudrate and MAC address respectively.
Page 49 BI67.Object_Name Output Contact Status 8 115893E - System Installation Manual BACNET COMMUNICATION OPTION SECTION...
Page 50 SECTION 4 Object Summary objectID object name notes INPUT VOLTAGE PHASE A INPUT VOLTAGE PHASE B INPUT VOLTAGE PHASE C OUTPUT VOLTAGE PHASE A OUTPUT VOLTAGE PHASE B OUTPUT VOLTAGE PHASE C OUTPUT CURRENT PHASE A A AC OUTPUT CURRENT PHASE B A AC OUTPUT CURRENT PHASE C A AC...
Page 51 SECTION 5 Protocol Implementation Myers Power Products, Inc. Vendor Name: Product Name: Product Model Number: PCB404303P00 v2.00 Applications Software Version: Firmware Revision: v1.05 BACnet Protocol Revision: BACnet Standardized Device Profile (Annex L) EBI is capable of supporting the B-ASC profile and lower.
Page 52 ANUAL HREE HASE MERGENCY IGHTING ENTRAL NVERTER Myers Emergency Power Systems 44 South Commerce Way, Bethlehem, PA 18017 1-800-526-5088 • (610) 868-3500 • Fax: (610) 868-8686 Service: (610) 868-5400 www.myerseps.com 115893E – System Installation Manual, BACNET IP & SNMP SECTION...
Page 53 Table of Contents SECTION 1 BACNET MS/TP Communication Board ....... 42 SECTION 2 Description of Operation ............55 SECTION 3 Default Settings ................ 55 SECTION 4 Object Summary ..............56 SECTION 5 Connecting to the BBS-7030 Web Server the First Time ..
Page 54 BACNET MS/TP Communication Board BACnet IP and SNMP communication from the three-phase Illuminator Hypernova Emergency Lighting Central Inverter is achieved via a standard Myers EPS BACnet MS/TP communication board – which converts the RS-232 communication with the inverter controller into the BACnet MS/TP protocol – and a Babel Buster BB2-7030 BACnet MS/TP to BACnet IP Gateway and Router, made by Control Solutions Inc.
Page 55 BACnet IP and/or SNMP. The BB2-7030 is preprogrammed to: • Provide BACnet IP proxy objects to read the values of the BACnet objects presented by the Myers inverter (see Section 4). The proxy objects are updated every 5 seconds • Provide SNMP OIDs to access all BACnet objects, and act as an SNMP...
Page 56 Meter Panel / BACnet Selector Switch Important Note: The Meter Panel/BACnet selector switch on the front of the cabinet door must be set to ‘BACnet’ and left there for the BACnet integration to work. When the switch is in the ‘BACnet’ position, the nearby ‘BACnet ENABLED’...
Page 57 Default SNMP Settings • SNMP Version Support: v1, v2c (v3 is not supported) • Community: public Traps: Disabled • SECTION 4 Object Summary Analog Inputs (analog sensors or counters read from the inverter) Object Name Units SNMP OID Object Input Voltage Phase A Volts AC AI 1 1.3.6.1.4.1.3815.1.3.1.1.1.1.2.1...
Page 58 Binary Inputs (cont’d) Object Name SNMP OID Object Battery Charger Alarm BI 43 1.3.6.1.4.1.3815.1.3.1.1.1.1.2.31 Inverter Failure BI 44 1.3.6.1.4.1.3815.1.3.1.1.1.1.2.32 Near Low Battery BI 45 1.3.6.1.4.1.3815.1.3.1.1.1.1.2.33 Load Reduction Alarm BI 46 1.3.6.1.4.1.3815.1.3.1.1.1.1.2.34 File Inputs File Input objects can only be accessed when the BB2-7030 is in Router Mode (see Section 6 below).
Page 59 SECTION 5 Connecting to the BB2-7030 Web Server the First Time To be able to do things like change the IP address, set a different BACnet ‘Device Instance’ number, change the SNMP ‘community’ code, or set up SNMP traps, you will first need to connect to the BB2-7030’s web server. Start by directly connecting an Ethernet cable between your PC and the BB2-7030.
Page 60 Setting up IP Address and LAN Settings Click on the “System Setup” tab. You will be presented with a ‘Sign in’ popup prompt. Type “root” for Username, and “buster” for Password. Now navigate to “System Setup” >> “Setup” >> “Local Host”. The page should look like this: Enter the IP Address that you desire your BB2-7030 to have, and the Subnet Mask and Gateway address for the LAN that the BB2-7030 will be on.
Page 61 By default, the BB2-7030 acts as a BACnet MS/TP to BACnet IP gateway (proxy) for one device (the single Myers EPS inverter system). In the unlikely case that you wish to configure it to be a BACnet router, see the section below on Gateway vs Router.
Page 62 4. Set the value. For analog objects, use any value. For binary objects, use “0” to trap on a logic 0, or “1” to trap on a logic 1. 5. For analog values, consider setting a hysteresis. For example, if you are programming a trap for when ambient temperature is greater than 30°C, you might want to put in a hysteresis of 2°C so that if the temperature is right on the 30°C mark and oscillating with small variations over and...
Page 63 Finally, refer to the “Saving and Activating Your Changes” subsection below to make your programming changes permanent (otherwise, they may be lost if the inverter loses power for long enough for the entire battery to deplete, or if maintenance is performed on the inverter). Saving and Activating Your Changes Any changes you make on the BB2-7030 web pages - other than changing IP address - are temporary.
Page 64 RS-485 wiring (RS-485 is the physical layer of BACnet MS/TP), and/or systems with 3 party (non-Myers) BACnet MS/TP devices, but where BACnet IP integration is also required. This system topology is illustrated in Figure 4: 115893E –...
Page 65 (it has 3 screw terminals ; see Figure 2 in Section 1) while keeping the wires that connect to the BB2-7030 also connected. 2. Myers Emergency Power Systems cannot take responsibility for or assist in the behavior / programming / operation of 3 party (non-Myers) BACnet devices sharing the network.
Page 66 (marked Inverter ‘N’ in Figure 4 above) will be preconfigured to act as a BACnet Gateway, it will have an (inactive) XML file already loaded into it (from Myers EPS manufacturing) that reconfigures the device to be a BACnet Router instead, along with some manual steps on the ‘BACnet IP Port’...
Page 67 • Enter the allocated network numbers for the BACnet IP Network (on the Ethernet side of this BB2-7030), and for the MS/TP Network (on the MS/TP RS-485 side of this BB2-7030). See the section below marked “On Network Numbers” for more detailed information. •...
Page 68 Alarm Logs This is an example of an Alarm Log file: 19/08/21 09:31 INVERTER FAULT 19/08/25 22:14 LOW VAC • Each line in the file begins with a timestamp in the format “YY/MM/DD HH:MM”. Note that the time is in 24-hour format. Note also that the time must be set up correctly in the inverter control board, or the timestamps will be wrong.
Page 69 • The final three fields provide the recorded output currents (in Amps) of each of the three phases (phase A first, then phase B, then phase C) • Each line ends with a DOS style line ending (“\r\n”) Please contact Myers EPS Service at if you have questions or (610) 868-5400 concerns.
Page 70 HREE HASE ILLUMINATOR HYPERNOVA MERGENCY IGHTING ENTRAL NVERTER Myers Emergency Power Systems 44 South Commerce Way, Bethlehem, PA 18017 1-800-526-5088 • (610) 868-3500 • Fax: (610) 868-8686 Service: (610) 868-5400 www.myerseps.com 115893E – System Installation Manual, BATTERY THERMAL RUNAWAY MODBUS SERIAL COMMUNICATION SECTION...
Page 71 ABLE OF ONTENTS SECTION 1 MODBUS Serial Comm Option Board - Introduction ..711 SECTION 2 Description of Operation ............62 SECTION 3 Settings ..................62 SECTION 4 Object Summary (Registers and Coils) ........76 SECTION 5 Biasing, Link Load and Link Termination ......
Page 72 SECTION 1 MODBUS Serial Comm Option Board - Introduction The MODBUS Communication Option Board for the three phase Series C Emergency Lighting Central Inverter has two internal connections; the RS232 communication bus to the inverter controller, and the input power that powers the board.
Page 73 SECTION 2 Description of Operation The MODBUS Communication Option Board acts as a MODBUS slave. It supports both the RTU (binary) and ASCII modes of MODBUS Over Serial Line. For both modes, it supports either Even Parity or No Parity, and four baud rates: 9600bps, 19,200bps, 38,400bps and 115,200bps.
Page 74 MODBUS Slave Address Settings MODBUS Slave Address is set on SW1, an 8-position DIP switch. The tables below describe the possible address settings: ON ON OFF OFF OFF ON OFF ON 58 (0x3A) MODBUS Slave Addresses 1 – 63 ON ON OFF OFF OFF ON OFF OFF 59 (0x3B) ON ON OFF OFF OFF OFF ON ON 60 (0x3C) ON ON OFF OFF OFF OFF ON OFF 61 (0x3D)
Page 75 ON OFF OFF OFF ON ON OFF ON 114 (0x72) OFF ON OFF OFF ON OFF ON OFF 181 (0xB5) ON OFF OFF OFF ON ON OFF OFF 115 (0x73) OFF ON OFF OFF ON OFF OFF ON 182 (0xB6) ON OFF OFF OFF ON OFF ON ON 116 (0x74) OFF ON OFF OFF ON OFF OFF OFF 183 (0xB7) ON OFF OFF OFF ON OFF ON OFF 117 (0x75)
Page 76 OFF OFF OFF OFF ON OFF ON ON 244 (0xF4) OFF OFF OFF OFF OFF OFF ON ON 3 (0x03) OFF OFF OFF OFF ON OFF ON OFF 245 (0xF5) OFF OFF OFF OFF OFF OFF ON OFF 2 (0x02) OFF OFF OFF OFF ON OFF OFF ON 246 (0xF6) OFF OFF OFF OFF OFF OFF OFF ON 1 (0x01)
Page 77 SECTION 4 Object Summary (Registers and Coils) The sixteen-bit registers can be accessed via either MODBUS Function Code 3 (0x03 Read Holding Registers) or Function Code 4 (0x04 Read Input Registers). Results will be identical. The flag objects can be accessed via either MODBUS Function Code 1 (0x01 Read Coils) or Function Code 2 (0x02 Read Discrete Inputs).
Page 78 Inverter Failure 1 = alarm, 0 = normal (0x002B) Near Low Battery 1 = alarm, 0 = normal (0x002C) Load Reduction 1 = alarm, 0 = normal (0x002D) SECTION 5 Biasing, Link Load and Link Termination The MODBUS Communication Option Board includes weak (10kΩ) pull-up and pull-down resistors on the MODBUS RS-485 link for the purpose of link biasing.
Page 79 SECTION 6 Device Identification To enable identification and differentiation of MODBUS Communication Option Boards on the same MODBUS link, the board: • Allows you to set a custom User ID string (up to 31 bytes of printable ASCII characters, i.e. ASCII characters 0x20 through 0x7E) •...
Page 80 • Step 3: The entire MODBUS PDU (Protocol Data Unit) would therefore 15 47 06 00 04 00 00 00 20 00 32 00 6e 00 64 00 20 00 46 00 6c 00 6f 00 6f 00 72 00 20 00 57 00 65 00 73 00 74 00 20 00 45 00 6d 00 65 00 72 00 67 00 65 00 6e 00 63 00 79 00 20 00 4c 00 69 00 67 00 68 00 74 00 73 00 00 Where:...
Page 81 SECTION 7 Retrieving File Records (Alarm, Event, and Test Logs) The MODBUS Communication Option Board allows you to retrieve: • Alarm Logs: Time stamped data on alarm conditions that have occurred (if any). • Event Logs: Time stamped data that the inverter keeps on events (such as power ups) •...
Page 82 03 00 70 00 01 …and receive the following PDU in response from the MODBUS Communication Option Board: 03 02 00 37 The response says that the Alarm Log file is currently 0x37 (55) bytes long. • Step 2: Now we have to use function code 0x14 (Read File Record) to retrieve the Alarm Log file.
Page 83 14 07 06 00 01 00 20 00 17 Where: o 0x14 (20) is the Read File Record function code o 0x07 is the remaining length of the PDU in bytes o 0x06 is the Reference Type (fixed) o 0x0001 is the File Number (for the Alarm Log File) o 0x0020 (32) is the Record Number (we’re starting to read the file from byte 32, where we left off) o 0x0017 (23) is the Record Length.
Page 84 115893E – System Installation Manual, SERIAL MODBUS COMMUNICATION SECTION...
Page 85 Parsing File Records (Alarm, Event and Test Logs) This section will describe the information contained in Alarm, Event and Test log files, and how to parse them. Alarm Logs This is an example of an Alarm Log file: 19/08/21 09:31 INVERTER FAULT 19/08/25 22:14...
Page 86 Test Logs This is an example of a Test Log file: 19/08/15 02:45 ALARMS 28.0 277.9 277.0 278.3 10.8 10.5 19/08/30 23:00 NO ALARMS 27.6 276.1 277.1 276.9 10.6 10.5 • Each line in the file begins with a timestamp in the format “YY/MM/DD HH:MM”.
Page 87 HASE ILLUMINATOR HYPERNOVA MERGENCY IGHTING ENTRAL NVERTER Myers Emergency Power Systems 44 South Commerce Way, Bethlehem, PA 18017 1-800-526-5088 • (610) 868-3500 • Fax: (610) 868-8686 Service: (610) 868-5400 www.myerseps.com 115893E – System Installation Manual, MODBUS TCP & SNMP COMMUNICATIONS OPTIONS SECTION...
Page 88 Table of Contents SECTION 1 ..............................88 MODBUS Serial Communication Board ....................88 Babel Buster BB2-6010..........................89 Meter Panel / MODBUS Selector Switch ....................90 SECTION 2 ..............................90 Description of Operation ........................90 SECTION 3 ..............................90 Default Ethernet Settings ........................90 Default MODBUS TCP Settings ......................90 Default SNMP Settings ..........................90 SECTION 4...
Page 89 MODBUS Serial Communication Board MODBUS TCP and SNMP communication from the three-phase Illuminator Hypernova Emergency Lighting Central Inverter is achieved via a standard Myers EPS MODBUS serial communication option board – which converts the RS-232 communication with the inverter controller into the MODBUS RTU protocol – and a Babel Buster BB2-6010 MODBUS RTU to MODBUS TCP Gateway, made by Control Solutions Inc.
Page 90 Babel Buster BB2-6010 The Babel Buster BB2-6010 is a DIN-rail mounted protocol bridge that is pre-programmed to convert between MODBUS RTU and MODBUS TCP and/or SNMP. It features two external connectors; one for MODBUS RTU RS485 and power in (24 Volts AC or DC), and the other for Ethernet (LAN connection) out. Figure 2 is a diagram of the BB2-6010.
Page 91 Meter Panel / MODBUS Selector Switch Important Note: The Meter Panel/MODBUS selector switch on the front of the cabinet door must be set to ‘MODBUS’ and left there for the MODBUS integration to work. When the switch is in the ‘MODBUS’ position, the nearby ‘MODBUS ENABLED’...
Page 92 SECTION 4 Object Summary All registers below are accessible via either MODBUS Function Code 3 (0x03 Read Holding Registers) using the specified register address, or SNMP ‘Get’ / ‘Get Next’ using the specified SNMP OID. Register / Object Name Units SNMP OID Analog Values (analog sensors or counters read from the inverter) Input Voltage Phase A...
Page 93 1.3.6.1.4.1.3815.1.2.2.1.1.1.1.1.2.104 Register / Object Name Units SNMP OID Unit Is 3-Phase Status 0 (false) or 1 (true) (0x0068) 1.3.6.1.4.1.3815.1.2.2.1.1.1.1.1.2.105 Input not Present 0 (false) or 1 (true) (0x007B) 1.3.6.1.4.1.3815.1.2.2.1.1.1.1.1.2.124 Battery Low 0 (false) or 1 (true) (0x007D) 1.3.6.1.4.1.3815.1.2.2.1.1.1.1.1.2.126 High Ambient 0 (false) or 1 (true) (0x0017F) Temperature...
Page 94 SECTION 5 Connecting to the BB2-6010 Web Server the First Time To be able to do things like change the IP address, change the SNMP ‘community’ code, or set up SNMP traps, you will first need to connect to the BB2-6010’s web server.
Page 95 Setting Up IP Address and LAN Settings Click on the “System” tab. You will be presented with a ‘Sign in’ popup prompt. Type “root” for Username, and “buster” for Password. Now navigate to “System Setup” >> “Setup” >> “Network”. The page should look like this: Enter the IP Address that you desire your BB2-6010 to have, and the Subnet Mask and Gateway address for the LAN that the BB2-6010 will be on.
Page 96 When done, click the “Change IP” button to save your changes. Wait at least 15 seconds until the settings are changed and the webpage reloads. Now cycle power to your BB2-6010 by pulling out and then re-inserting the “MODBUS RTU and Power In” connector. At this point, if you wish you may disconnect the direct ethernet connection between your PC and the BB2-6010 and put it on the LAN and connect to it through the LAN via its new IP address setting.
Page 97 The first step in programming a trap is to program a ‘Threshold’ rule (a rule that when true, will send a trap). To program a ‘Threshold’ rule, first navigate to the following web page: “System” >> “Action Rules” >> “Thresholds” . Initially, there is just one threshold rule, and it is blank.
Page 98 Once you have programmed all your desired rules, the next step is to make them generate traps. The BB2-6010 lets you send traps to up to three different groups of “Trap Receivers” (in case you want some traps to go to one destination, and other traps to go to another).
Page 99 To download and save the xml file, press Ctrl-S (⌘-s on an Apple) or right click on white space on the page and click “Save As”. Please contact Myers EPS Service at (610) 868-5400 if you have questions or concerns.
Page 100 RS-232 Communications Illuminator Hypernova Users Manual Myers Emergency Power Systems 44 South Commerce Way, Bethlehem, PA 18017 1-800-526-5088 • (610) 868-3500 • Fax: (610) 868-8686 Service: (610) 868-5400 www.myerseps.com 115893E – System Installation Manual, RS-232 COMMUNICATION OPTIONS SECTION...
Page 101 ABLE OF ONTENTS 1.0 - Introduction ..................91 2.0 - Connection .................... 91 3.0 - Terminal Settings .................. 91 4.0 - Protocol Overview ................92 5.0 - Commands .................... 93 Control Functions ..................97 Log Functions .................... 99 Self-Test Functions ..................
Page 102 1.0 - I NTRODUCTION This manual is intended to explain the RS-232 communication protocol for the Hypernova Emergency Lighting Central Inverter. Serial Communication can be established by means of a computer using terminal emulation software (such as Tera Term, PuTTy, xterm, etc.), or by any embedded device capable of RS-232 communication.
Page 103 *0DA0 *0da09/16/19X *0TM0 *0tm12:59X If this is the case, look for the setting in your terminal emulator software that automatically appends line feeds after (outgoing or incoming) carriage returns. Finally, the inverter will not echo back characters you type. If it looks like nothing is happening when you type, until you press enter, then turn on the ‘local echo’...
Page 104 5.0 - C OMMANDS Meter Functions Get Alarm Status *0AS0<CR> Command: *0as[dddd]0<CR> Response: dddd represents a 16-bit field in HEX format. Please refer to the table below for bit definitions. Alarm Name Alarm Description Overload Alarm Too much load connected to inverter output Overload Shutdown Alarm Inverter has shutdown due to too much load High AC Voltage Alarm...
Page 105 are asserted: Overload, Overload Shutdown, Low AC Voltage, Near Low Battery, Utility Power Down. Get Indicator Status *0IS0<CR> Command: *0is[dddd]0<CR> Response: dddd represents a 16-bit field in HEX format. Please refer to the table below for bit definitions. Status Flag Name Status Flag Description System Ready 0 while rebooting, on battery or charging.
Page 106 *0vi277.9V òBX<CR> (it responds) *0VI2<CR> (you send) *0vi277.6V òCX<CR> (it responds) Get Output Voltage *0VO[φ]<CR> Command: Where φ represents the phase. Use ‘0’ for phase A, ‘1’ for phase B or ‘2’ for phase C. For a single-phase inverter, always use ‘0’) *0vo[ddd.d]VX<CR>...
Page 107 *0WA0<CR> Command: *0wa[dddd]X<CR> Response: Where dddd represents the output power from the batteries, in Watts (for example, 27, 8045, 19822, or 44781). Note that there is no decimal point; the output is a whole number in Watts. When on utility power, this value will be very low. 5.10 Get Output VA *0VA[φ]<CR>...
Page 108 Control Functions 5.13 Set Date *0DA[MM][DD][YY]0<CR> Command: Where MM is month (01=January...12=December), DD is day (01..31) and YY is year (19 = 2019). Do not forget the final 0 in the command, or it won’t work. None! Use the Get Date command to confirm it worked. Response: 5.14 Get Date...
Page 109 5.20 Get Output Current Load Reduction Fault *0F[φ]0<CR> Command: φ is the phase (A for phase A or if single-phase, B for phase B, or C for phase C). *0lf[ddd.d]AX<CR> Response: dddd is the ‘nominal output current’ (in Amps). If this value is set, and if the current value of output current dips below 90% of this value, the Load Reduction Fault alarm will trigger.
Page 110 5.26 Get High AC Voltage Alarm *0HV0<CR> Command: *0hv[ddd.d]VX<CR> Response: Where ddd.d is the voltage (in Volts) that is currently set as the ‘high AC input voltage’ threshold that triggers the ‘High AC Voltage’ alarm. 5.27 Set Ambient Temperature Alarm *0AT[DD]0<CR>...
Page 111 Field Field name Response Syntax Description *0lt[mm]/[dd]/[yy]X<CR> Date is month (01..12), is day (01..31), is year *0lt[hh]:[mm]X<CR> Time is hour (00..23, 24-hour format) and is minute (00..59) *0lt[dd]MinX<CR> Duration is the test duration, in minutes (for example, , etc) *0lt[ddd.d]V òAX<CR>...
Page 112 *0lt24.6ßCX<CR> (it responds) *0LT0310<CR> (you send) *0ltAlarms: NoX<CR> (it responds) *0LT0311<CR> (you send) *0ltMonthlyX<CR> (it responds) 5.31 Dump Test Log *0DT0<CR> Command: This command dumps all Test Log entries to the RS-232 port. It is essentially a script which reads out all log entries (where for each log entry, it reads out all fields). Each field gets its own line.
Page 113 *0leE[dd]/[ee]X<CR> Response: Where dd is the last log entry that was fetched (ignore this value), and ee is the current ‘total number of Event Log entries’ (max possible value is 75). 5.33 Get Event Log Entry Field Each time a user manually invokes an inverter self-test (AKA ‘event’), the inverter logs the results in the Event Log as multiple fields.
Page 114 *0AL9100<CR> Command: If there are no alarms logged in the Alarm Log yet: *0alNo Alarms X<CR> Response: If there is at least one alarm log entry, or more: *0alA[dd]/[ee]X<CR> Response: Where dd is the last log entry that was fetched (ignore this value), and ee is the current ‘total number of Alarm Log entries’...
Page 115 This command dumps all Alarm Log entries to the RS-232 port. It is essentially a script which reads out all log entries (where for each log entry, it reads out all fields). Each field gets its own line. Log entries are separated by two blank lines. Here is a sample of the response syntax (showing the first two log entries, and the last log entry): (you send) *0DF0...
Page 116 *0TT0<CR> Command: *0tt[hh][mm]X<CR> Response: Where hh is the hour in 24-hour format (00..23), and mm is the minute (00..59) at which the monthly self-test will be run when the programmed ‘day of the month’ is reached. 5.43 Set Yearly Self-Test Month and Day *0YD[MM][DD]0<CR>...
Page 117 6.0 - L RS-232 P OCATING THE LOCATION OF THE RS-232 PORT For Illuminator Hypernova 5.0 –16.7KVA LOCATION OF THE RS-232 PORT For Illuminator Hypernova 25.0 –50.0KVA 115893E – System Installation Manual, RS-232 COMMUNICATION OPTIONS SECTION...
Page 118 7.0 - T ZOOM M ODEM OPTIONAL Configuring the Zoom Modem Connect the 9VDC Power Adapter Connect the PC serial port to the modem’s serial port (if your PC doesn’t have a serial port, you can use an off-the-shelf ‘USB to RS-232’ adapter. On the PC, bring up a terminal emulator program such as PuTTy, Tera Term or xterm.
Page 119 Type ATO0 <enter> to enter online mode again DETAILED WIRING DIAGRAM ZOOM MODEM BACK VIEW OF PC PHONE LINE STANDARD CABLE COM PORT (NOT PROVIDED) ZOOM MODEM GENDER CHANGER (PROVIDED) NULL MODEM CABLE (PROVIDED) RS232 REF DWG. 113838 115893E – System Installation Manual, RS-232 COMMUNICATION OPTIONS SECTION...
Page 120 115893E – System Installation Manual, RS-232 COMMUNICATION OPTIONS SECTION...
Page 121 Serial to Ethernet Adapter Illuminator Hypernova Quick Start Manual Myers Emergency Power Systems 44 South Commerce Way, Bethlehem, PA 18017 1-800-526-5088 • (610) 868-3500 • Fax: (610) 868-8686 Service: (610) 868-5400 www.myerseps.com 115893E – System Installation Manual, SERIAL TO ETHERNET ADAPTER SECTION...
Page 122 Serial to Ethernet Communication Interface – QuickStart Guide The Serial to Ethernet Communication Interface primarily allows you to monitor and control your Myers EPS Emergency Lighting Central Inverter over an SSH connection (on port 2222) using the Myers EPS RS-232 Communication Protocol. The SSH port number can be configured, or if you choose, Telnet may be selected instead of SSH.
Page 123 Your Serial to Ethernet Communication Interface is now ready for SSH communication with your Myers EPS Emergency Lighting Central Inverter, using the IP address you set in Section 1 above, and SSH on port 2222. If you would like to change 115893E –...
Page 124 Use “myerseps” as the username, and “inverter” as the password. You should now be connected to your Myers EPS Emergency Lighting Central Inverter, and ready to communicate with it using the Myers EPS RS-232 Communication Protocol, as described in the RS-232 Protocol Manual Section.
Page 125 8. Click the “Reboot IOLAN” button that just appeared in the bottom right. After the IOLAN SDG1 reboots (give is 60 seconds), it will accept SSH connections on the new port number you specified. 4 - Changing the Protocol from SSH to Telnet Depending on your organization’s IT policies or available client software on your PCs, you may desire to use Telnet protocol instead of SSH.
Page 126 UNAWAY ILLUMINATOR HYPERNOVA MERGENCY IGHTING ENTRAL NVERTER Myers Emergency Power Systems 44 South Commerce Way, Bethlehem, PA 18017 1-800-526-5088 • (610) 868-3500 • Fax: (610) 868-8686 Service: (610) 868-5400 www.myerseps.com 115893E – System Installation Manual, SYSTEM OPTIONS BATTERY THERMAL RUNAWAY SECTION...
Page 127 Table of Contents SECTION 1 System Description ......................127 SECTION 2 Description of Operation .................... 12919 SECTION 3 System Installation ....................... 12131 115893E – System Installation Manual, SYSTEM OPTIONS BATTERY THERMAL RUNAWAY SECTION...
Page 128 SECTION 1 System Description The Thermal Runaway Detection Option consists of two components. The first PCB component is the Power Supply Relay PCB that performs a summary dry contact closure on an alarm from any of the temperature sensor boards. This PCB is shown in Picture 1.
Page 129 -40°C to 125°C**. The wire length of the temperature probes can be cut to any length without adversely affecting the temperature accuracy. **Note – Only use Myers Emergency Power Systems supplied temperature probes (Part# RE-THER2100I). Picture 2 – Temperature Sensor PCB 115893E –...
Page 130 System Schematic: Figure 1 shows a schematic of the power supply and temperature sensor PCB and the connections. The schematic shows a two temperature sensor board system with four temperature probes connected to each monitoring board but there are many other different possible configurations. Dry contacts are setup for normally open configuration.
Page 131 If a battery is in a thermal runaway condition there are four indications that will result. The four conditions will remain in a latched state until the reset button is depressed for a few seconds and then released. 1) The summary alarm contact will be activated. 2) The audible summary alarm will be activated on the temperature sensor pcb with the battery that is in a thermal runaway condition.
Page 132 SECTION 3 System Installation 1) Power Supply/Summary Relay – The PCB’s will be installed in the Emergency Lighting Inverter Electronics Cabinet. Dependant on the number of batteries there may be more than one power supply presenting the electronics module please refer to Battery Thermal Runaway drawing specific to the Emergency Lighting Inverter System Installed.
Page 133 Picture 3 Brown Black Picture 4 2) Temperature Sensor PCB – The PCB’s will be mounted in the battery cabinets of the Emergency Lighting Inverter. If the batteries are in the same cabinet as the electronics then it will be mounted in the electronics/battery cabinet.
Page 134 PCB via the wire supplied in the kit. This will follow the instruction in item a until the last temperature sensor pcb has been wired. c. The temperature probes are installed following the instruction below: i. Make sure that the stripped wire is removed and ends of the temperature probe are full insulated and separated by at least 1 inch.
Page 135 Use supplied Velcro in kit and attach it to the plastic box. See diagram for location placement. Figure 2 – Stripped Probe leads insert into connectors 115893E - System Installation Manual, SYSTEM OPTIONS BATTERY THERMAL RUNAWAY SECTION...
Page 136 NOTES: 115893E - System Installation Manual, SYSTEM OPTIONS BATTERY THERMAL RUNAWAY SECTION...
Page 137 PART III RAWINGS (Drawings section continues on next page) 115893E – System Installation Manual PART III - DRAWINGS...
Page 138 115893E – System Installation Manual PART III - DRAWINGS...
Page 139 115893E – System Installation Manual PART III - DRAWINGS...
Page 140 115893E – System Installation Manual PART III - DRAWINGS...
Page 141 115893E – System Installation Manual PART III - DRAWINGS...
Page 142 115893E – System Installation Manual PART III - DRAWINGS...
Page 143 115893E – System Installation Manual PART III - DRAWINGS...
Page 144 115893E – System Installation Manual PART III - DRAWINGS...
Page 145 115893E – System Installation Manual PART III - DRAWINGS...
Page 146 115893E – System Installation Manual PART III - DRAWINGS...
Page 147 115893E – System Installation Manual PART III - DRAWINGS...
Page 148 115893E – System Installation Manual PART III - DRAWINGS...
Page 149 115893E – System Installation Manual PART III - DRAWINGS...
Page 150 115893E – System Installation Manual PART III - DRAWINGS...
Page 151 115893E – System Installation Manual PART III - DRAWINGS...
Page 152 115893E – System Installation Manual PART III - DRAWINGS...
Page 153 115893E – System Installation Manual PART III - DRAWINGS...
Page 154 115893E – System Installation Manual PART III - DRAWINGS...
Page 155 115893E – System Installation Manual PART III - DRAWINGS...
Page 156 115893E – System Installation Manual PART III - DRAWINGS...
Page 157 115893E – System Installation Manual PART III - DRAWINGS...
Page 158 This page is intentionally left blank. 115893E – System Installation Manual PART III - DRAWINGS...
