- Page 1 Illuminator System ™ Series E & IE 1.5 kW – 16.7 kW Installation Guide 44 South Commerce Way, Bethlehem, PA 18017 1-800-526-5088 • (610) 868-3500 • Fax: (610) 868-8686 Service: (610) 868-5400 www.myerseps.com...
-
Page 2: Important Safeguards
This unit contains LETHAL VOLTAGES. All repairs and service should be performed by AUTHORIZED SERVICE PERSONNEL ONLY! There are NO USER SERVICEABLE PARTS inside this unit. IMPORTANT SAFEGUARDS When using electrical equipment, you should always follow basic safety precautions, including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS. - Page 3 C A U T I O N READ ENTIRE MANUAL AND REVIEW ALL DOCUMENTATION BEFORE ATTEMPTING SYSTEM INSTALLATION! FOR SERVICE OR INSTALLATION INFORMATION: TELEPHONE: (610) 868-5400 (24 HR. HOTLINE) FAX: (610) 954-8227 FOR YOUR PROTECTION..PLEASE COMPLETE AND RETURN WARRANTY REGISTRATION CARD IMMEDIATELY. 114061H System Installation Manual...
- Page 4 C H A P T E R 1 AFETY ARNINGS Read the following precautions before you install the system. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. This manual contains important instructions that you should follow during installation and maintenance of the system and batteries. Please read all instructions before operating the equipment and save this manual for future reference.
- Page 5 C H A P T E R 2 NTRODUCTION Please read this manual thoroughly before operating your safety system. Keep this manual and the system User’s Guide in the folder mounted inside the unit’s door. WARNING Only qualified service personnel (such as a licensed electrician) should perform the system and battery installation and initial startup.
-
Page 6: Before Installing The Unit
C H A P T E R 3 EFORE NSTALLING THE Installation Dimensions and Clearances Figure 3.1 System Dimensions Table 3.1 Dimensions Unit Unit #1 47” 30” 25” 22 1/8” 8” 11 ½” 7” 11 ½” 4 3/8” 3 3/8” 9 ¼”... -
Page 7: Location Guidelines
Location Guidelines Keep the following guidelines in mind when choosing the location for your system and batteries: • Verify that the environment meets the requirements in “Storage and Operating Environment” on page 7. The environment can affect the reliability and performance of both the unit and the batteries. -
Page 8: Storage And Operating Environment
Storage and Operating Environment Make sure you store and install the system in a clean, cool, dry place with normal ventilation and level floors. Storage Temperature Store the batteries (in the system) at -18 to 40°C (0 to 104°F). Batteries have a longer shelf life if they are stored below 25°C (77°F). -
Page 9: Installation Overview
C H A P T E R 4 NSTALLATION VERVIEW Figure 4.1 shows typical installations of system. Standard 1.5 kW, 2.25 kW, 3.0 kW, 3.75 kW, 5.0 kW, 6.0 kW, 8.0 kW, 10.0 kW, 12.5 kW, and 16.7 kW models do not have external battery cabinets. Building Service Supported... - Page 10 C H A P T E R 5 AC I & AC O NPUT UTPUT NSTALLATION WARNING Only qualified service personnel (such as a licensed electrician) should perform the AC installation. There is a risk of electrical shock. Read the following cautions before you continue. CAUTION Unit contains hazardous AC and DC voltages.
- Page 11 4. Now, use the information you wrote down in Step 2 to find the correct circuit breaker for the service panel that is for your system. Table 5.1 Recommended Circuit Breaker for Maximum Input Current System Input Voltage (Vac) Max. Current Recommended Circuit Breaker 1.5 kW...
- Page 12 5. Write down the circuit breaker value that applies to your system from Table 5.1: __________ 6. Now, look at Table 5.2 below, and use the notes below to find the proper gauge wire for the recommended circuit breaker recorded in step 5. Table 5.2 Recommended Minimum Wire Sizes Read These Important Notes! For this Input...
- Page 13 The next step explains where to make the AC connections to the system. INSTALLING AC INPUT WIRES: 11. Connect AC utility from the service panel to the system’s terminal block labeled “INPUT”. For 2-wire input: connect hot wire to the input block marked “Line”, connect the common wire to the input block marked “Neutral”...
- Page 14 Figure 5.1 AC Connections for 1.5 k W– 5.0 kW systems Figure 5.2 AC Connections for 6 kW – 16.7 kW systems (5.0 kW system for 120 Minute run-time) 114061H System Installation Manual...
- Page 15 C H A P T E R 6 DC W NSTALLING ATTERIES AND IRING WARNING Only qualified service personnel (such as a licensed electrician) should perform the battery and DC wiring installation. There is a risk of electrical shock. This section explains how to install system batteries, fuses, and cables. For all models, you must install the batteries in the system cabinet.
- Page 16 A qualified electrician familiar with battery systems and required precautions must install and service the batteries. Any battery used with this unit shall comply with the applicable requirements for batteries in the standard for emergency lighting and power equipment, UL 924 (Canada’s National Building Code). Cabinets are designed to be used with, and batteries must be replaced with, manufacturer battery number BAT- CG12105 or a manufacturer approved equivalent (see the battery wiring diagram that came with the battery cables).
-
Page 17: Installing And Connecting The Batteries
Before Installing the Batteries Tools CAUTION Always use insulated tools when you work with batteries. Always torque connections to the manufacturer’s recommendations. When you work with system batteries, you need the following tools. The tools must be insulated so they do not short battery terminals to the cabinet. Wear the safety equipment required by local code whenever the doors are open and whenever you are working on batteries. - Page 18 Location The system batteries belong inside the unit. Before you start installing the batteries, you must install the system in its permanent location. If you have not already done this, see “Location Guidelines” on page 6 to choose a location. CAUTION To prevent damage to your equipment, do not move the system after the batteries are installed.
- Page 19 Table 6.1 Battery Torque Battery Type Torque BAT-CG12105 or SL-12105 Torque to 120 in lbs. (13.6 Nm) BAT-CG12105A or SL-12105M Torque to 120 in lbs. (13.6 Nm) BAT-CG12105B Torque to 55 in lbs. (6.5 Nm) BAT-CG12105E or 12AVR100-3ET Torque to 100 in lbs. (11.3 Nm) BAT-CG12105G Torque to 100 in lbs.
-
Page 20: Replacing The Batteries
6. Install only the battery fuses (10.0KW – 16.7KW). Next, use the voltmeter to check the DC voltage between the positive (+) position on the battery block inside the electronics cabinet and the unconnected battery negative terminal. This voltage should be approximately the battery voltage record on the unit ID label. - Page 21 CAUTION Do not dispose of batteries in a fire because the batteries could explode. Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes. It may be toxic. Dispose of Batteries Properly CAUTION Batteries contain lead. Many state and local governments have regulations about used battery disposal.
-
Page 22: Starting The Unit
CHAPTER 7 URNING ON THE YSTEM AND ETTING ARAMETERS Several parameters in the system software determine when and how your system conducts the automatic monthly and annual tests. Refer to “User Setup” in the “Front Panel Display” chapter of the system user’s Guide for a description of each test. Starting the Unit Before you can set the parameters, you must start the system. - Page 23 Figure 7.2 Battery Fuse, DC Pre-charge Switch & Installation Switch (6 kW – 8 kW) (5 kW System for 120 Minute run-time) Figure 7.3 Battery Fuse, DC Pre-charge Switch & Installation Switch (10 kW – 16.7 kW) (8 kW System for 120 Minute run-time) 114061H System Installation Manual...
-
Page 24: Front Panel Display
RONT ANEL ISPLAY The Front Panel Display assembly consists of a 4 x 20 vacuum fluorescent display and a 4-button keypad. The 4 buttons can navigate through all the menus by using the left and right arrow keys, the ENTER and the ESCAPE. The default menu will scroll between the status screen and the Identification/Date- Time screen. -
Page 25: Meter Functions
Meter Functions To get to the meter functions from the default screen, press the ENTER key, scroll to the METER menu using the left or the right arrow key, then press the ENTER key again. Use left or the right arrow key to view the meter function desired. Table 7.2 Meter Functions Function Description... -
Page 26: Alarm Log
Alarm Log To get the Alarm log menu from the default screen, press the ENTER key, scroll to the alarm log menu using the left or right arrow key, then press the ENTER key again. Use the left or right arrow key to view the alarm desired, and then press the ENTER key for more information. -
Page 27: System Information
Use the left or right arrow key to turn on or off this alarm. When the alarm is turned on, a number will appear. To change the number, press the ENTER key and then use the left or right arrow key. Once the desired number is reached, press the ENTER key and this will return to the top-level menu. -
Page 28: Completing The Installation
Completing the Installation Close the doors and lock the cabinet. You have finished installing the system. Follow the steps in the Startup and Warranty Validation form to test the installation and startup the system for the first time. After you complete this form, return it to the manufacturer to validate the warranty.
