Acme Furniture DN02281-1 Assembly Instruction

ASSEMBLY INSTRUCTION FOR ACME FURNITURE
DESCRIPTION:PEDESTAL TABLE TOP/PEDESTAL TABLE BASE
Thank you for purchasing this quality product. Be sure to check all
packing materials carefully for small parts, which may have come
loose inside the carton during shipment. Identify and count all parts
and compare with the parts list below.
** Do not fully tighten screws until fully assembled **
PARTS LIST:
TABLE TOP : 1PC
PEDESTAL : 4PCS
STEP 1
F
D
6
Clean the surface of the Pedestal Table Top/Pedestal Table Base with furniture polish and a
soft cloth.
Attention
*** Some number parts listed on the instruction sheet may not be in parts bag as they may be
assembled. Carefully check parts and packing materials prior to ordering replacements.***
Page 1/2
Model #DN02281-1/DN02281-2
LEAF:1PC
B
C
CLEANING INSTRUCTION
Drawing
NO.
A
B
C
D
E
F
G
BASE : 1PC
STEP 2
D
E
1
G
HARDWARE LIST
Description
Bolt (Φ5/16"x2")
Bolt (Φ5/16"x1-1/2")
Flat washer (Ø5/16"x23mm)
Spring washer (Ø5/16")
Hex Nut (Ø5/16")
Allen wrench (108x31xØ5mm)
Ø5/16" Wrench(12mm)
MOUNTING PLATE A : 2PCS MOUNTING PLATE B : 2PCS
5
C
Made in Vietnam
Q'ty
8pcs
8pcs
44pcs
44pcs
28pcs
1pc
1pc
2
