ASSEMBLY INSTRUCTION FOR ACME FURNITURE
MODEL# DN01802 JASPER DINING TABLE
Thank you for purchasing the quality product. Be sure to check all packing material carefully for small parts which may
have come loose inside the carton during shipment. Separate, identify and count all parts and metal hardware. Compare
with all parts list to be sure all parts are present. If any part(s) are missing or damaged, please contact your local furniture
dealer. For efficient and speedy service, please indicate the model number and code letter of part(s) needed.
DESCRIPTION
HAREWARES REQUIRED
H1
H2
H3
H4
H5
H6
Attention:
*** Some number parts listed on the instruction sheet may not be in parts bag as they may already be assembled.
Carefully check parts and packing materials prior to ordering replacements.
***Do not fully tighten screws until fully assembled***
P1
TABLE TOP
P2
PEDESTAL LEG
P3
MOUNTING PANEL
JCBC SCREW M6 x 35MM - 8 PCS
SPRING WASHER - 8 PCS
FLAT WASHER - 4 PCS
LEG ADJUSTABLE GLIDE
WOOD DOWEL M8X30MM
ALLEN KEY
COMPONENT PARTS
PART NAME
-
- 1 PC
Q'TY (PCS)
1
1
1
- 4 PCS
4 PCS
PAGE 1/2
