- Page 1 ITEM NO.90312 ASSEMBLY INSTRUCTIONS BOLT 1/4” x 1-1/8” BOLT 1/4” x 1/2” BOLT 1/4” x 1” FOOT CAP GLASS PAD 2PCS 34PCS 4PCS 16PCS 12PCS STRETCHER FOOT BOLT ALLEN WRENCH 2PCS 2PCS 2PCS...
- Page 2 ASSEMBLY INSTRUCTIONS ① ② ③ ④ TABLE LEG TABLE TOP FRAME TABLE BOTTOM FRAME GLASS TOP 4PCS ⑤ ⑥ ⑦ ⑧ GLASS SHELF MIRROR MIRROR STRETCHER CUSHION 2PCS ⑨ ⑩ ⑪ STOOL BOTTOM FRAME STOOL TOP FRAME STOOL LEG 4PCS...
- Page 3 STEP 1 Attach four stool legs (11) to stool bottom frame (9) and stool top frame (10) using bolts (A) as shown. Then, attach cushion (8) to the assembled metal base using bolt (C), and insert foot caps (D) into the bottom of the stool legs (11).
- Page 4 STEP 3 Attach table top frame (2) to table legs (1) using bolts (A) as shown. Then, insert foot caps (D) into the bottom of the table legs (1). STEP 4 Attach mirror stretchers (7) to the table frame using bolts (B) and bolts (A) as shown.
- Page 5 STEP 5 Attach glass pads (E) to the table frame, then carefully place the glass shelf (5) and glass top (4) to the table as shown.
